Legacy Compatibility Reference - Simplex TrueAlert 4906-9228 Instructions

TrueAlert Strobe LEGACY Compatibility Reference
Compatible Controller
4100ES or 4100U with TrueAlert Power Supply
4009 TPS, Remote TrueAlert Power Supply
TrueAlert Addressable Controller (4009T)
Electrical Ratings Difference for Retrofit Applications
17 VRMS Current Ratings, use when connected
to TrueAlert Addressable SLCs per above
TYCO, SIMPLEX, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. NFPA 72 and National Fire Alarm and
Signaling Code are registered trademarks of the National Fire Protection Association (NFPA).
© 2013 Tyco Fire Protection Products. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
Data Sheet
Reference
S4100-0031
S4100-0037
S4009-0003
Voltage Range 17 VRMS to 31 VRMS, Special Application
Candela Setting
Horn Output Selection
High
82 mA
Tyco Fire Protection Products • Westminster, MA • 01441-0001 • USA
www.simplexgrinnell.com
Controller Output
TrueAlert
Addressable SLC
15 cd 30 cd
Low High Low
77 mA 135 A 130 mA
Available Strobe Appliance Voltage
Intensity Minimum
15, 30, 75, and
17 VRMS
110 cd
75 cd 110 cd
High Low High
249 mA 244 mA 335 mA
S4906-0005-3 5/2013
Low
330 mA
