2.4GHz CORDLESS TELEPHONE
ALL DIGITAL ANSWERING SYSTEM
WITH CALLER ID/CALL WAITING
40 CHANNEL AUTOSCAN WITH 4 SEPARATE MAILBOXES
Model GH9640
OWNER'S MANUAL
INSTALLATION AND
OPERATING
INSTRUCTIONS
PLEASE READ THIS
MANUAL CAREFULLY
BEFORE USE.
KEEP FOR YOUR
REFERENCE.
For installation information, please
see "Getting Started" instructions
or your separate Quick Start Guide.
Visit Us on the Web:
www.uselectronics.info
©2004 BellSouth Corporation
The system can be expanded to 9 handsets maximum.
Special Features
Congratulations on your selection of a quality BellSouth product. With proper care and
adherence to the set-up and user instructions in this Owner's Manual, this unit will provide
you with years of trouble-free service.
BellSouth is committed to providing quality products that fit your needs. We would like to have any
comments or suggests you might have on this product. You may mail your comments to:
U.S. Electronics
105 Madison Avenue
New York, NY 10016
When examining your new BellSouth cordless telephone, you will find an array of special features
including:
CORDLESS TELEPHONE FEATURES
Filtered Sound™ System – Gets considerably less noise than conventional cordless telephones
because of a special circuit which delivers the clearest possible reception.
40 Channel Auto Scan – Press the button
clearest channel for any call.
Desk or Wall Mount – Use this equipment as a desk phone or as a wall phone.
Tone or PULSE Dialing – Use this phone for either TONE or push-button PULSE (rotary) dialing.
Automated Functions – Redial the last number called and automatic STANDBY mode.
Security – Ensures greater privacy because a built-in security code with 65,536 combinations
prevents use of your telephone line by another nearby cordless phone.
Dependable Battery – Recharge your BATTERY PACK many times with the built-in charger. The
battery low warning tone tells you when the BATTERY PACK needs recharging.
flash
Special Services – Use the
button to access special services such as Call Waiting supplied
by your Telephone Company or company switchboard.
STANDBY Mode – When in STANDBY mode (ON-HOOK), the phone is capable of receiving a call.
When the HANDSET is on the BASE UNIT, it is automatically in the STANDBY mode (ON-HOOK).
When the HANDSET is taken off the BASE UNIT, it remains in the STANDBY mode until you
talk
activate the
button
Battery Power Saver – Once fully charged, in STANDBY mode, the HANDSET can receive/send
calls for a maximum of give days without the need for recharging. Length of charge depends on
frequency of use.
Luminous LCD Screen – The LCD Screen emits light for 5 seconds every time you press any of the
buttons on the HANDSET, or when call comes in.
HANDSET Ringer Level – Select the ringer volume level (HI, LOW, OFF).
HANDSET VOLUME CONTROL Switch – Select the receiver volume level (HI, MID, LOW).
HEADSET JACK – Your telephone can utilize a headset for hands-free communication.
BELT CLIP – Use the BELT CLIP to hang your HANDSET on your belt.
Scan
delete
on the HANDSET to find and lock on the
