2.4 GHz Cordless Telephone with Digital Answering
Machine & Caller ID on Call Waiting
40 CHANNEL AUTOSCAN WITH 4 SEPARATE MAILBOXES
Model GH9492
OWNER'S MANUAL
INSTALLATION AND
OPERATING
INSTRUCTIONS
PLEASE READ THIS
MANUAL CAREFULLY
BEFORE USE.
KEEP FOR YOUR
REFERENCE.
For installation information, please
see "Getting Started" instructions
on page 6 or your separate Quick
Start Guide.
Visit Us on the Web:
www.uselectronics.info
© 2004 Bellsouth Corporation
