BellSouth GH9407 Manual

2.4 ghz filtered sound with 40 channel autoscan
Hide thumbs Also See for GH9407:
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Safety Instructions -------------------------------------------------------------------------------------------- 2
Getting Started ------------------------------------------------------------------------------------------------ 4
Desk Mounting ------------------------------------------------------------------------------------------------- 7
Wall Mounting ------------------------------------------------------------------------------------------------- 8
Basic Operation --------------------------------------------------------------------------------------------- 10
Receiving Calls ---------------------------------------------------------------------------------------------- 11
Placing Calls ------------------------------------------------------------------------------------------------- 12
Headset Feature --------------------------------------------------------------------------------------------- 12
Storing Numbers --------------------------------------------------------------------------------------------- 13
Recalling Stored Numbers ------------------------------------------------------------------------------- 14
Security System --------------------------------------------------------------------------------------------- 15
Recharging the Battery Pack ---------------------------------------------------------------------------- 16
Changing the Battery Pack ------------------------------------------------------------------------------ 17
Problem Solving -------------------------------------------------------------------------------------------- 18
Technical Information ------------------------------------------------------------------------------------- 19
FCC Requirements ------------------------------------------------------------------------------------------ 20
Warranty -------------------------------------------------------------------------------------------------------- 22
Wall Mounting Template --------------------------------------------------------------------------------- 26
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GH9407 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BellSouth GH9407

Summary of Contents for BellSouth GH9407

  • Page 1: Table Of Contents

    Contents Safety Instructions -------------------------------------------------------------------------------------------- 2 Getting Started ------------------------------------------------------------------------------------------------ 4 Desk Mounting ------------------------------------------------------------------------------------------------- 7 Wall Mounting ------------------------------------------------------------------------------------------------- 8 Basic Operation --------------------------------------------------------------------------------------------- 10 Receiving Calls ---------------------------------------------------------------------------------------------- 11 Placing Calls ------------------------------------------------------------------------------------------------- 12 Headset Feature --------------------------------------------------------------------------------------------- 12 Storing Numbers --------------------------------------------------------------------------------------------- 13 Recalling Stored Numbers ------------------------------------------------------------------------------- 14 Security System --------------------------------------------------------------------------------------------- 15 Recharging the Battery Pack ---------------------------------------------------------------------------- 16 Changing the Battery Pack ------------------------------------------------------------------------------ 17...

  • Page 2: Safety Instructions

    Safety Instructions IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electric shock and/or injury, always follow these basic safety precautions when using your cordless telephone equipment. 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the telephone. 3.
  • Page 3 Safety Instructions E. If the telephone has been dropped or the case has been damaged. F. If the telephone exhibits a distinct change in performance. 13. Do not use the telephone to report a gas leak in the vicinity of the leak. 14.

  • Page 4: Getting Started

    Getting Started Connecting Your Phone This section is a reference guide to the basic functions and operations of your cordless telephone. For more detailed descriptions of the operations and features of this telephone, refer to the Contents on page 1. 1.
  • Page 5 Getting Started BASE UNIT ANTENNA BASE UNIT TELEPHONE LINE CONNECTION JACK TONE/PULSE 9VDC 300mA SELECT SWITCH TELEPHONE JACK TONE PULSE TEL LINE USE ONLY WITH CLASS 2 POWER SOURCE 120V WALL OUTLET POWER-IN CONNECTION TELEPHONE JACK LINE CORD AC ADAPTER BATTERY PACK 7.
  • Page 6 BELT CLIP until the other HOOK locks into the slot on the side of the HANDSET. 11. Before initial use, charge the HANDSET for 12 hours. You are now ready to use your new BellSouth Cordless Telephone.

  • Page 7: Desk Mounting

    Desk Mounting Desk Mounting One of the special features of your telephone is the unique design of the MOUNTING BRACKET which can hold your phone at an angle of 30 when desk mounting. There are two positions to choose from: 1.

  • Page 8: Wall Mounting

    Wall Mounting Wall Mounting You may choose to put the BASE UNIT of your cordless telephone on a wall. 1. With the back of the BASE UNIT facing up, connect the SHORT TELEPHONE LINE CORD to the TELEPHONE LINE CONNECTION JACK. 2.
  • Page 9 Wall Mounting 5. This cordless telephone has a HANDSET RETAINER TAB located on the BASE UNIT and a RETAINER TAB NOTCH located on the back of the HANDSET to secure the HANDSET in the CHARGE CRADLE when wall mounting. 1. Pull out the HANDSET RETAINER TAB using a finger tip or a small flat tool. (See Figure 1) 2.

  • Page 10: Basic Operation

    Basic Operation Preparing for Use Before you can use your cordless telephone, you must charge the HANDSET for 12 hours. Failure to do so will require recharging of the BATTERY PACK more often. 1. Place the HANDSET on the BASE UNIT for 12 hours. 2.

  • Page 11: Receiving Calls

    Receiving Calls Receiving Calls with the HANDSET on the BASE UNIT 1. When the phone rings, lift the HANDSET. The IN USE LED indicator will light up. (NOTE: The HANDSET REDIAL FLASH RINGER Switch must be in the “ON” position for ringer TALK to operate.) PAUSE...

  • Page 12: Placing Calls

    Placing Calls Placing Calls 1. Press the button. The IN USE LED indicator TALK will light up. IN USE BATT LOW 2. Listen for a dial tone. 3. Dial the phone number. G H z 4. When you have finished with your call, press the button again.

  • Page 13: Storing Numbers

    Storing Number Storing Numbers 1. Be sure the BASE UNIT IN USE LED indicator is OFF and the HANDSET is in STANDBY mode. 2. Press the button. MEMO 3. Dial the number you want to store. 4. Press the button again. MEMO 5.

  • Page 14: Recalling Stored Numbers

    Recalling Stored Numbers Recalling Stored Numbers from Memory 1. Press the button. TALK IN USE 2. Press the button. MEMO BATT LOW 3. Press the TELEPHONE KEYPAD OPER G H z button for the number you have stored. The stored number will be dialed automatically.

  • Page 15: Security System

    Security System Security System Your cordless telephone uses a digital coding security system to prevent unauthorized use of your telephone line by another near by cordless telephone. The system has its own identifying signal created by microcomputers in both the BASE UNIT and HANDSET. Security Code This telephone has an internal security code with 65,536 possible combinations.

  • Page 16: Recharging The Battery Pack

    Recharging the Battery Pack Battery Type Use the following type and size of BATTERY PACK: Cordless Telephone BATTERY PACK 3.6V, 600mAh U.S. Electronics Inc. Ni-MH Battery Pack: model B655 This BATTERY PACK is available through: U.S. Electronics Service Center 105 Madison Avenue New York, NY 10016 1-800-825-5208 NOTE: During a power interruption, the BASE UNIT does not operate, and a phone...

  • Page 17: Changing The Battery Pack

    Changing the BATTERY PACK Changing the BATTERY PACK The BATTERY PACK provides power for the HANDSET of your cordless telephone. To Replace BATTERY PACK: 1. Remove the HANDSET BATTERY COMPARTMENT COVER by sliding it down. 2. Pull out the BATTERY PACK PLUG and remove the BATTERY PACK. 3.

  • Page 18: Problem Solving

    Problem Solving Problem Solving Section For your assistance, we have listed below a few common problems. Phone does not work, check the following: 1. BASE UNIT is plugged into power source. 2. HANDSET is charged. 3. TONE/PULSE SELECT switch is in the right position. 4.

  • Page 19: Technical Information

    Technical Information Technical Information This cordless telephone uses radio frequencies to allow mobility. There are certain difficulties in using radio frequencies with a cordless telephone. While these are normal, the following could affect the operation of your system. Noise Electrical pulse noise is present in most homes at one time or another. This noise is most intense during electrical storms.

  • Page 20: Fcc Requirements

    FCC Requirements Federal Communications Commission Requirements This equipment complies with Part 68 of the FCC rules. A label on the BASE UNIT of this equipment contains, among other information, the FCC Registration Number and the Ringer Equivalence Number (REN) for this equipment. You must, upon request, provide this information to your telephone company.
  • Page 21 FCC Requirements Federal Communications Commission Requirements (continued) NOTE: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 22: Warranty

    There are no other expressed or implied warranties from BellSouth Products. Warranty Service Provided If you purchased the telephone new from a retail vendor, BellSouth Products warrants the telephone against defects in material and workmanship for a period of one (1) year from the original date of purchase.
  • Page 23 7137 Southlake Parkway Morrow, GA 30260 NOTE: A telephone received which was not made for BellSouth Products or which is not defective as determined by our test procedures will not be repaired and will be returned to you C.O.D., freight collect.
  • Page 24 Notes...
  • Page 25 Notes...

  • Page 26: Wall Mounting Template

    Wall Mounting Template This page serves as a template for attachment of screws to the wall when mounting this telephone on the wall. 1. Cut out this page. 2. Use this template to determine the distance between screws when mounting this phone on the wall. The two cross hairs identify where to attach the screws.
  • Page 27 IMPORTANT In order to get maximum life from the HANDSET BATTERY PACK, be sure to charge the HANDSET for 12 hours before initial use. IMPORTANT Placing your BASE UNIT near appliances such as televisions, refrigerators, radios, or microwave ovens may cause interference. IMPORTANT When you hear interference, press the button to change the operating...
  • Page 28 OPERATING INSTRUCTIONS PLEASE READ THIS MANUAL CAREFULLY BEFORE USE. KEEP FOR YOUR REFERENCE. For installation information, please see “Getting Started“ instructions on page 4 or your separate Quick Start Guide. Visit Us on the Web www.uselectronics.info c 2002 BellSouth Corporation...
  • Page 29 STOP Make certain you receive the best performance from your telephone. Read this manual first. Visit Us on the Web www.uselectronics.info Made in China...
  • Page 30 HANDSET controls 1. HANDSET ANTENNA HANDSET ANTENNA 2. IN USE/BATT LOW INDICATOR Pg. 11, IN USE BATT LOW 12, 16 3. REDIAL BUTTON 8. FLASH BUTTON Pg. 12 4. TALK BUTTON Pg. 5, REDIAL FLASH 6, 11, 12, 14, 18 TALK 9.
  • Page 31 HANDSET controls 1. HANDSET ANTENNA 2. IN USE / BATT LOW LED Indicator: Lights up when the HANDSET is in TALK mode. Blinks when battery power is low. (See page 12 for detail.) 3. REDIAL Button: Press to redial the last number you dialed. REDIAL 4.
  • Page 32 BASE UNIT controls 1. TONE/PULSE SELECT SWITCH Pg. 5 2. POWER-IN CONNECTION JACK Pg. 4 3. TELEPHONE LINE CONNECTION JACK Pg. 4, 8, 18 4. BASE UNIT ANTENNA 5. HANDSET RETAINER TAB Pg. 9 6. CHARGE TERMINALS 7. PAGE BUTTON PAGE CHARGE IN USE...
  • Page 33 BASE UNIT controls 1. TONE/PULSE Select Switch 2. POWER-IN CONNECTION JACK 3. TELEPHONE LINE CONNECTION JACK 4. ANTENNA 5. HANDSET RETAINER TAB: Secures the HANDSET in the CHARGE CRADLE when wall mounting. 6. CHARGE TERMINALS: For charging the HANDSET BATTERY PACK. For best performance, clean the CHARGE TERMINALS periodically with a damp cloth.
  • Page 34 BellSouth is committed to providing quality products that fit your needs. We would like to have any comments or suggestions you might have on this product. You may mail your comments to: U.S.
