Thank you for purchasing a LABvault-SD digital video player/recorder. With the LABvault-SD, anyone
can easily create and display industry standard MPEG-2 files with very little training. The LABvault-
SD includes a Web interface that can be used to operate the LABvault-SD's record, playback, and
transfer features from any location while also providing administrative options for setting up file
transfer destinations, changing recording quality presets, managing files on the LABvault's internal
hard drive, and accessing the system's log files.
One of the most powerful features of the LABvault-SD is its ability to be controlled by a wide variety
of external sources. The most popular control interfaces include Crestron
technology, giving users an intuitive and simple way to record a video source, display the resulting
digital file on a connected television monitor, and then transfer the file to one or more destinations.
The LABvault-SD accommodates a variety of playback and storage destinations. For instance, users
may send files to an archive server and then later download the files to view on a PC, burn to a DVD,
or drag into an editing system timeline. Further options include sending each digital file from the
LABvault-SD to a LEIGHTRONIX NEXUS series server/controller (UltraNEXUS-SDI, UltraNEXUS, or
NEXUS) for scheduled or immediate broadcasting. The LABvault-SD can also be integrated with a
LEIGHTRONIX streaming video-on-demand application like the PEG Central Web service, with the
option to host files on the PEG Central web servers or in-house on an LGX-SVOD server.
ABOUT THIS MANUAL
This manual describes how to install your LABvault-SD as well as use the included LABvault-SD
Web interface to set up and control the player/recorder. Instructions on using a touch screen or other
external control system with the LABvault-SD should be obtained from the third party provider. Refer
to the "CONTROL COMMANDS" on page 26 of this manual for a list of the commands needed to
program your external control system.
PACKING LIST
(1) LABvault-SD Digital Player/Recorder
(1) Product Resource Disc, Including LABvault-SD Manual
(1) Part #10-0311, AC Power Cord, 6 ft.
(1) Part #10-4856, CAT 5e Ethernet Cable, 7 ft.
Page 1
LABvault-SD
About This Manual
and AMX
touch screen
®
®
2018-06-08
