Internal Storage
Internal MPEG
Recorder (Encoder)
Internal MPEG Player
(Decoder)
Page 32
• Original LABvault-SD: 120 GB internal hard drive
• Version 2 LABvault-SD: 250 GB internal hard drive provides 200 GB of digital
media storage
The LABvault-SD creates industry-standard, MPEG-2 video files. The maximum
recorded file length allowed by the LABvault-SD is 23 hours, 59 minutes, and 50
seconds.
Digital video recording results are based on a combination of the selected recording
quality default and the quality of the input source. Video being fed to the encoder
must have stable sync. Input signals with copy protection are not recordable.
The LABvault-SD encoder can capture video at one of the following recording
qualities:
• Good: VBR of 3.00-5.00 Mb/s, half video resolution (352x480), 192 kb/s audio
bit rate, 44.1 kHz audiosample rate
• Better: VBR of 4.00-7.00 Mb/s, full video resolution (720x480), 192 kb/s audio
bit rate, 44.1 kHz audiosample rate
• Best: VBR of 7.00-9.00 Mb/s, full video resolution (720x480), 224 kb/s audio bit
rate, 44.1 kHz audiosample rate
• Streaming: VBR of 1.50-2.50 Mb/s, half video resolution (352x480), 160 kb/s
audio bit rate, 44.1 kHz audio sample rate
NOTE: If you select "Internet VOD Streaming" as an automatic file
transfer destination, your files will be recorded at "Streaming"
quality for all enabled file transfer destinations.
• Full D1 MPEG-2 resolution
• 10Mb/s maximum video bit rate
LABvault-SD
Specifications
