Page 1 Series M22/M23/M24 Instruction Manual Table of Contents VorTek Series M22, M23 and M24 Pro-V™ Vortex Volumetric and Mass Flow Meters Instruction Manual Document Number M-000-00010 Rev 8/2018 8475 W I-25 Frontage Rd Suite 300 Longmont, CO 80504 (303) 682-9999 (888) 386-7835 Fax (303) 682-4368 http://www.vortekinst.com...
Page 2 Some models can only be properly cleaned during the manufacturing process. VorTek Instruments, LLC., is not liable for any damage or personal injury, whatsoever, resulting from the use of VorTek Instru- ments standard mass flow meters for oxygen gas.
Page 3 VorTek Instruments. The information contained in this manual is subject to change without notice. TRADEMARKS Pro-V™ is a trademark of VorTek Instruments, LLC. Other product and company names listed in this manual are trademarks or trade names of their respective manufacturers. M-000-00010...
Page 4: Table Of Contents
Table of Contents Series M22/M23/M24 Instruction Manual Table of Contents Chapter 1 Introduction Pro-V™ Vortex Mass Flow Meters ............. 1-1 Using this Manual ................. 1-1 Note and Safety Information ............1-2 Receipt of System Components ............ 1-2 Technical Assistance ..............1-2 How the Pro-V Vortex Meter Operates ..........
Page 5 Series M22/M23/M24 Instruction Manual Table of Contents 4-20 mA Output Connections ............. 2-29 Frequency Output Connections ........... 2-30 Pulse Output Connections ............2-31 Alarm Output Connections ............2-33 Remote Electronics Wiring ............2-34 Optional Input Electronics Wiring ..........2-35 Optional Energy EMS RTD Input Wiring ........2-35 Optional External 4-20 mA Input Wiring ........
Page 6 Table of Contents Series M22/M23/M24 Instruction Manual Level Two Hidden Diagnostics Values ......... 5-4 Analog Output Calibration ..............5-7 Display Contrast Adjustment .............. 5-7 Troubleshooting the Flow Meter ............5-8 First Check Items ................. 5-8 Record Values ..................5-8 Determine the Fault ................5-9 Symptom: Output at no Flow ............
Page 7 Series M22/M23/M24 Instruction Manual Table of Contents 2-19. Isolated Frequency Output Using External Power Supply ... 2-23 2-20. Non-Isolated Freq. Out. Using External Power Supply ..2-23 2-21. Backlight Using External Power Supply ......2-23 2-22. Loop Power Volumetric Flowmeter Junction Box ....2-24 2-23.
Page 8 Caution! Calibration must be performed by qualified personnel. VorTek Instruments, Inc., strongly recommends that you return your flow meter to the factory for calibration. In order to achieve accurate and repeatable performance, the flow meter must be in- stalled with the specified minimum length of straight pipe upstream and downstream of the flow meter’s sensor head.
Page 9 Series M22/M23/M24 Instruction Manual Table of Contents Revision History Rev. 2/2018 to 8/2018 Page Change Description Changed Model M22 Pro-V Multivariable Mass Vortex Flowmeters to Pro-V Multivariable Mass Vortex Flowmeters 2-37 Added Figure 2-47 External 4-20 mA Input and RTD Wiring – Loop Power 2-38 Added Figure 2-48 External 4-20 mA Input and RTD Wiring –...
Page 10: M-000-00010
Table of Contents Series M22/M23/M24 Instruction Manual 0-10 M-000-00010...
Page 11: Chapter 1 Introduction
MODBUS, HART, or BACnet communications are also available. Pro-V digital electronics allows for easy reconfiguration for most gases, liquids and steam. The VorTek Series M22, M23, and M24 Pro-V Meters’ simple installation combines with an easy-to-use interface that provides quick set up, long term reliability and accurate mass flow measurement over a wide range of flows, pressures and temperatures.
Page 12: Note And Safety Information
Receipt of System Components When receiving a VorTek mass flow meter, carefully check the outside packing carton for damage incurred in shipment. If the carton is dam- aged, notify the local carrier and submit a report to the factory or distrib- utor.
Page 13: Velocity Measurement
How the Pro-V Vortex Mass Flow Meter Operates Figure 1-1. In-Line Vortex Multi-Parameter Mass Flow Meter VorTek Series M22, M23, and M24 Pro-V™ Multi-Parameter Vortex Mass Flow Meters use a unique sensor head to monitor mass flow rate by directly measuring three variables–fluid velocity, temperature and pres- sure.
Page 14: Vortex Shedding Frequency
Chapter 1 Introduction Series M22/M23 Instruction Manual Vortex Shedding Frequency Von Karman vortices form downstream of a shedder bar into two distinct wakes. The vortices of one wake rotate clockwise while those of the oth- er wake rotate counterclockwise. Vortices generate one at a time, alter- nating from the left side to the right side of the shedder bar.
Page 15: Flow Velocity Range
Series M22/M23/M24 Instruction Manual Chapter 1 Introduction Flow Velocity Range To ensure trouble-free operation, vortex flow meters must be correctly sized so that the flow velocity range through the meter lies within the measurable velocity range (with acceptable pressure drop) and the linear range.
Page 16: Pressure Drop
Chapter 1 Introduction Series M22/M23 Instruction Manual The Strouhal number is the other dimensionless number that quantifies the vortex phenomenon. The Strouhal number is defined as: St = f d Where St = Strouhal Number frequency of vortex shedding shedder bar width fluid velocity As shown in Figure 1-3, Pro-V™...
Page 17: Temperature Measurement
Series M22/M23/M24 Instruction Manual Chapter 1 Introduction its vapor phase. The resulting two-phase flow degrades the liquid calibra- tion accuracy. For some applications, a valve downstream of the flow me- ter may be required to increase the pressure in the meter, thereby avoiding cavitation.
Page 18: Flow Meter Configurations
Chapter 1 Introduction Series M22/M23 Instruction Manual Flow Meter Configurations Pro-V™ Vortex Mass Flow Meters are available in two model configurations: • Series M22/M24 in-line flow meter (replaces a section of the pipeline) • Series M23 insertion flow meter (requires a “cold” tap or a “hot” tap into an existing pipeline) Both the in-line and insertion configurations are similar in that they both use identical electronics and have similar sensor heads.
Page 19: Line Size / Process Conditions / Materials
Series M22/M23/M24 Instruction Manual Chapter 1 Introduction Line Size / Process Connections / Materials The M22/M24 In-line model is built for line sizes ½ through 4 inch wa- fer or ½ through 12 inch flanged design using ANSI 150, 300, 600, PN16, 40, or 64 class flanges.
Page 20 Chapter 1 Introduction Series M22/M23/M24 Instruction Manual 1-10 M-000-00010...
Page 21: Chapter 2 Installation
Chapter 2 Installation Chapter 2 Installation Installation Overview VorTek’s Pro-V Vortex Flow Meter installations are simple and straight- forward. Both the Series M22/M24 In-Line and Series M23 Insertion type flow meter installations are covered in this chapter. After reviewing the installation requirements given below, see page 2-3 for Series M22/M24 installation instructions.
Page 22: Unobstructed Flow Requirements
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Unobstructed Flow Requirements Select an installation site that will minimize possible distortion in the flow profile. Valves, elbows, control valves and other piping components may cause flow disturbances. Check your specific piping condition against the examples shown below.
Page 23: Recommended Meter Locations
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Recommended Meter Locations Liquid Horizontal Liquid Vertical Gas or Steam Horizontal Gas or Steam Vertical M-000-00010...
Page 24: Series M22 And M24 In-Line Flow Meter Installation
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Series M22/M24 In-Line Flow Meter Installation Install the Series M22/M24 In-Line Flow Meter between two convention- al pipe flanges as shown in Figures 2-3 and 2-4. The meter inside diameter is equal to the same size nominal pipe ID in schedule 80.
Page 25: Wafer-Style Flow Meter Installation
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Wafer-Style Flow Meter Installation Install the wafer-style meter between two conventional pipe flanges of the same nominal size as the flow meter. If the process fluid is a liquid, make sure the meter is located where the pipe is always full. This may require locating the meter at a low point in the piping system.
Page 26: Flange-Style Flow Meter Installation
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Place the remaining studs between the pipe flanges. Tighten the nuts in the sequence shown in Figure 2-2. Check for leaks after tightening the flange bolts Flange-Style Flow Meter Installation Install the flange-style meter between two conventional pipe flanges of the same nominal size as the flow meter.
Page 27: Series M23 Insertion Flow Meter Installation
Series M22/M23/M24 Instruction Manual Chapter 2 Installation 2. Seat the meter level and square on the mating connections with the flange stamped with a flow arrow on the upstream side, with the arrow head pointing in the direction of flow. Position a gasket in place for each side. Make sure both gaskets are smooth and even with no gasket material ex- tending into the flow profile.
Page 28: Cold Tap Guidelines
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Cold Tap Guidelines Refer to a standard code for all pipe tapping operations. The following tapping instructions are general in nature and intended for guideline pur- poses only. 1. Turn off the flow of process gas, liquid or steam. Verify that the line is not pressurized.
Page 29: Hot Tap Guidelines
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Hot Tap Guidelines Refer to a standard code for all pipe tapping operations. The following tapping instructions are general in nature and intended for guideline pur- poses only. Warning! Hot tapping must be 1.
Page 30: Hot Tap Sequence
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Connect isolation valve and test for leaks xxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx Purge pipe xxxxxxxxxxxxxxxxxxxx xxxxxxxxxxxxxxxxxxxx Figure 2-5. Hot Tap Sequence M-000-00010...
Page 31: Flow Meter Insertion
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Flow Meter Insertion The sensor head must be properly positioned in the pipe. For this reason, it is important that insertion length calculations are carefully followed. A sensor probe inserted at the wrong depth in the pipe will result in inaccu- rate readings.
Page 32: Installing Meters With A Compression Connection
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Installing Flow Meters with a Compression Connection* Use the following formula to determine insertion length for flow meters (NPT and flanged) with a compression process connection. The installa- tion procedure is given on the next page. Insertion Length Formula I = S –...
Page 33: Flow Meter With Compression Type Fitting
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Insertion Procedure for Meters with a Compression Connection Figure 2-7. Flow Meter with Compression Type Fitting 1. Calculate the required sensor probe insertion length. Caution! 2. Fully retract the stem until the sensor head is touching the bottom of The sensor alignment the stem housing.
Page 34: Installing Meters With A Packing Gland Connection
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Installing Flow Meters with a Packing Gland Connection* Use the formula below to determine the insertion depth for flow meters (NPT and flanged) equipped with an insertion tool. To install, see the next page for instructions for meters with a permanent insertion tool.
Page 35: Flow Meter With Permanent Insertion Tool
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Insertion Procedure for Flow Meters with Permanent Insertion Tool Figure 2-9. Flow Meter with Permanent Insertion Tool 1. Calculate the required sensor probe insertion length (see previous page). Measure from the depth marker arrow down the stanchion and scribe a mark at the calculated insertion depth.
Page 36 Chapter 2 Installation Series M22/M23/M24 Instruction Manual Insertion Procedure for Flow Meters with Removable Insertion Tool Figure 2-10. Flow Meter with Removable Insertion Tool 1. Calculate the required sensor probe insertion length. Measure from the depth marker arrow down the stanchion and scribe a mark at the calculated insertion depth.
Page 37: Insertion Calculation (Meters Without Insertion Tool)
Series M22/M23/M24 Instruction Manual Chapter 2 Installation 7. Tighten the packing gland nuts to stop leakage around the stem. Do not torque over 20 ft-lbs. 8. Slide the stem clamp back into position. Torque stem clamp bolts to 15 ft-lbs. Replace the stem clamp nuts and torque to 10-15 ft-lbs. 9.
Page 38 Chapter 2 Installation Series M22/M23/M24 Instruction Manual Insertion Procedure for Flow Meters with No Insertion Tool (Packing Gland Connection) 1. Calculate the required sensor probe insertion length. Warning! 2. Fully retract the stem until the sensor head is touching the bottom of the The line pressure stem housing.
Page 39: Adjusting Meter Orientation
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Adjusting Meter Orientation Depending on installation requirements, you may need to adjust the meter orientation. There are two adjustments available. The first rotates the posi- tion of the LCD display/keypad and is available on both in-line and inser- tion meters.
Page 40: Enclosure Adjustment
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Enclosure Adjustment (Series M22/M24 Only) Figure 2-13. Enclosure Viewing Adjustment To avoid damage to the sensor wires, do not rotate the enclosure beyond 180-degrees from the original position. To adjust the enclosure: 1. Remove power to the flow meter. 2.
Page 41: Loop Power Flow Meter Wiring Connections
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Loop Power Flow Meter Wiring Connections The NEMA 4X enclosure contains an integral wiring compartment with one dual strip terminal block (located in the smaller end of the enclosure). Two 3/4-inch female NPT conduit entries are available for separate power Warning! and signal wiring.
Page 42: 4-20 Ma Output Connections
Chapter 2 Installation Series M22/M23/M24 Instruction Manual 4-20 mA Output Connections The Pro-V meter has a single 4-20 mA loop. The 4-20 mA loop current is controlled by the meter electronics. The electronics must be wired in se- ries with the sense resistor or current meter. The current control electron- ics require 12 volts at the input terminals to operate correctly.
Page 43: Pulse Output Connections
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Pulse Output Connections The pulse output is used for a remote counter. When the preset volume or mass (defined in the totalizer settings, see page 3-10) has passed the me- ter, the output provides a 50 millisecond square pulse. The pulse output requires a separate 5 to 36 VDC power supply.
Page 44: Frequency Output Connections
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Frequency Output Connections The frequency output is used for a remote counter. It can be scaled to out- put a 1 to 10 kHz signal proportional to mass or volume flow, tempera- ture, pressure or density. The frequency output requires a separate 5 to 36 VDC power supply.
Page 45: Remote Electronics Wiring
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Remote Electronics Wiring The remote electronics enclosure should be mounted in a convenient, easy to reach location. For hazardous location installations, make sure to ob- serve agency requirements for installation. Allow some slack in the inter- face cable between the junction box and the remote electronics enclosure.
Page 46 Chapter 2 Installation Series M22/M23/M24 Instruction Manual VORTEX BLK 1 RED 1 BLK 2 SENSOR V1 RED 2 SENSOR V2 SHLD 1&2 SHIELD Figure 2-23. Loop Power Volumetric Flowmeter Junction Box Sensor Con- nections Supplied Prior to Jan. 1, 2014 ( Wires enter the flow connector from the right side of the connector shown above.) TEMPERATURE...
Page 47: High Power Flow Meter Wiring Connections
Series M22/M23/M24 Instruction Manual Chapter 2 Installation High Power Meter Wiring Connections The NEMA 4X enclosure contains an integral wiring compartment with one dual strip terminal block (located in the smaller end of the enclosure). Two 3/4-inch female NPT conduit entries are available for separate power and signal wiring.
Page 48: Dc Power Connections
Chapter 2 Installation Series M22/M23/M24 Instruction Manual OPTION 1 OPTION 2 1 2 3 FREQ PULSE ALARM ALARM ALARM 4-20 4-20 4-20 mA 1 mA 2 mA 3 Figure 2-27. DC Wiring Terminals DC Power Wiring The DC power wire size must be 20 to 12 AWG with the wire stripped 1/4 inch (7 mm).
Page 49: 4-20 Ma Output Connections
Series M22/M23/M24 Instruction Manual Chapter 2 Installation 4-20 mA Output Connections The standard Pro-V Flow Meter has a single 4-20 mA loop. Two addi- tional loops are available on the optional communication board. The 4-20 mA loop current is controlled by the meter electronics. The electronics must be wired in series with the sense resistor or current meter.
Page 50: Frequency Output Connections
Chapter 2 Installation Series M22/M23/M24 Instruction Manual mA Meter For HART communications the signal loop must have a DC Power minimum of 250 ohms load DC Common resistance. > 250 Ohm DC powered meters only Figure 2-31. Non-Isolated 4–20 mA Output Using Meter Input Power Supply mA Meter For HART communications...
Page 51: Pulse Output Connections
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Freq. Out voltage = +V Freq. Out + Select resistor so that current Freq. Out - through Freq . Out <= 40 mA Figure 2-33. Isolated Frequency Output Using External Power Supply Freq. Out + Freq.
Page 52: Isolated Pulse Output Using External Power Supply
Chapter 2 Installation Series M22/M23/M24 Instruction Manual AC powered unit only. In any case, the voltage of the pulse output is the same as the voltage supplied to the circuit. Figure 2-36. Isolated Pulse Output Using External Power Supply DC Powered meters only Figure 2-37.
Page 53: Alarm Output Connections
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Alarm Output Connections One alarm output (Alarm 1) is included on the standard Pro-V™ Flow Meter. Two or more alarms (Alarm 2 and Alarm 3) are included on the optional communication board. The alarm output requires a separate 5 to 36 VDC power supply.
Page 54: Remote Electronics Wiring
Chapter 2 Installation Series M22/M23/M24 Instruction Manual + 24 VDC Out - 24 VDC Out AC units only Meter provided DC Power +24 VDC Figure 2-41. Isolated Alarm Output Using Meter Provided Power Supply Remote Electronics Wiring The remote electronics enclosure should be mounted in a convenient, easy to reach location.
Page 55: Optional Input Electronics Wiring
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Optional Input Electronics Wiring The meter has two optional input wiring terminals, maximum wire size is 16 AWG. These can be used to input a Remote or Second RTD input in the case of an Energy Monitoring meter, for the input of a Remote Pres- sure Transducer, to pass a Contact Closure or for a Remote Density meas- urement to name a few.
Page 56: Optional External 4-20 Ma Input Wiring
Chapter 2 Installation Series M22/M23/M24 Instruction Manual Optional External 4-20 mA Input Wiring The meter is set to have Option 1 used for the external input. Program- ming menus that pertain to the optional 4-20 mA input are located in the Hidden Diagnostics Menu in Chapter 5.
Page 57: External 4-20 Ma Input Wiring - Ac Powered Meter
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Option 1 Option 2 AC units only. Meter provided DC power. + 24 VDC OUT - 24 VDC OUT Ext. 4-20 mA Input Device Figure 2-46. External 4-20 mA Input Wiring - AC Powered Meter Follow the above diagram to wire the external 4-20 mA input into the flow meter using power from the 24 VDC output of an AC powered me- ter.
Page 58 Chapter 2 Installation Series M22/M23/M24 Instruction Manual High Power Option 1 Option 2 Red Red Black Black R = 1000 ohm External Power Ext. 4-20 mA Input Device Figure 2-48. External 4-20 mA Input and RTD Wiring – High Power Optional Energy EMS External 4-20 mA Input and RTD Wiring Option 1 Option 2...
Page 59: Optional Contact Closure Input Wiring
Series M22/M23/M24 Instruction Manual Chapter 2 Installation Optional External Contact Closure Input Wiring Option 1 Option 2 Figure 2-50. Optional External Contact Closure Input Wiring Follow the above diagram to wire an external switch input into the flow meter. The meter is configured to have Option 1 used for the external in- put.
Page 60 Chapter 2 Installation Series M22/M23/M24 Instruction Manual M-000-00010...
Page 61: Chapter 3 Operating Instructions
2 x 16 characters for flow monitoring and pro- Pro-V gramming. The six push-buttons can be operated with the enclo- VorTek Instruments, sure cover removed. Or, the explosion-proof cover can remain in place and the keypad operated with a hand-held magnet posi- tioned at the side of the enclosure as shown in the illustration at the left.
Page 62: Start Up
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Display Contrast Adjustment The flow meter display contrast is set at the factory but if the dis- play characters appear too dark or too light proceed as follows: 1) Hold down the “Exit” button on the front panel for 5 to 10 sec- onds.
Page 63: Run Mode Screens
Series M22/M23/M24 Instruction Manual Chapter 3 Operation Run Mode Screens ENTER Mass Flow Password Rate ENTER Volume Flow Rate Press Exit to return Setup Menus to Run Mode Temperature Pressure Energy EMS Energy Meters Only Density Total keys to access each item Alarm 1 Status...
Page 64: Using The Setup Menus
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Using the Setup Menus M-000-00010...
Page 65: Programming The Flow Meter
Series M22/M23/M24 Instruction Manual Chapter 3 Operation Programming the Flow Meter 1. Enter the Setup Menu by pressing the ENTER key until prompted for a password. (All outputs are disabled while using the Setup Menus.) 2. Use the  keys to select the password characters (1234 is the factory-set password).
Page 66: Output Menu
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Output Menu ENTER Run Mode Password ENTER Output Menu keys to access menus < Measure > None Mass Volume 4-20 mA Output 1 < 4 mA = xxxx > < 20mA = xxxx > <...
Page 67 Series M22/M23/M24 Instruction Manual Chapter 3 Operation Example for Setting an Output The following shows how to set Output 1 to measure mass flow with 4 mA = 0 lb/hr and 20 mA = 100 lb/hr with a time constant of 5 seconds. (All outputs are disabled while using the Setup Menus.) First, set the desired units of measurement: Use ...
Page 68: Display Menu
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Display Menu ENTER Run Mode Password ENTER Display Menu keys to access menus Cycle Time (sec) If Cycle Time is set to zero, manual advance is required Number of Digits Used to set the number of digits displayed after the decimal point Display TC (sec) TC = Display Time constant, used to smooth display MF Vf Te Pr De T...
Page 69: Alarms Menu
Series M22/M23/M24 Instruction Manual Chapter 3 Operation Alarms Menu ENTER Run Mode Password ENTER Alarms * see below Menu keys to access menus <Measure> None Mass <Mode> Volume Relay Alarm 1 None <Measure> units ** Energy More > HIGH Alarm (>) xxxx Temp 1,2 LOW Alarm (<)
Page 70: Totalizer #1 Menu
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Totalizer #1 Menu ENTER Run Mode Password ENTER Totalizer Menu keys to access menus Totaling Example: Inactive Mass Volume Maximum flow rate = 600 gallons per minute Energy (600 gallons per minute = 10 gallons per second) (unit) / Pulse If unit per pulse is set to 600 gallons per pulse, xxxx...
Page 71: Totalizer #2 Menu
Series M22/M23/M24 Instruction Manual Chapter 3 Operation Totalizer #2 Menu ENTER Run Mode Password ENTER Totalizer Menu keys to access menus Totaling Inactive Mass Volume Energy Reset Total ? YES or NO Use the Totalizer #2 to Monitor Flow or Energy. The totalizer maximum count is 999,999,999 at which point it will roll over to 0.
Page 72: Energy Menu
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Energy Menu – For EMS Energy Meters Only ENTER Run Mode Password ENTER Energy Menu keys to access menus Loc in Sent Flow Yes or No Heating System Yes or No % Returned Configuration: There are several possibilities regarding the measurement of water or steam energy given the location of the meter and the use of a second RTD.
Page 73: Fluid Menu
Series M22/M23/M24 Instruction Manual Chapter 3 Operation Fluid Menu ENTER Run Mode Password keys to access menus ENTER < Liquid Water Fluid Ammonia Menu Chlorine < Density > < AL > < BL xxxx xxxx xxxx Flowing Fluid < Mole Weight > <...
Page 74: Units Menu
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Units Menu ENTER Run Mode Password ENTER Units Menu keys to access menus Mass Flow Unit Ston = Short Ton = 2000 lb lb, Ston, Lton, gram Lton = Long Ton = 2240 lb sec, min, hr, day Mton = Metric Ton = 1000 kg kg, Mton, scf, nm3...
Page 75: Time And Date Menu
Series M22/M23/M24 Instruction Manual Chapter 3 Operation Time & Date Menu ENTER Run Mode Password ENTER Time & Date Menu keys to access menus Set Time xx:xx:xx Set Date xx/xx/xx Use the Time and Date Menu to enter the correct time and date into the flow meter’s memory.
Page 76: Diagnostics Menu
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Diagnostics Menu ENTER Run Mode Password ENTER Diagnositcs Menu keys to access menus Simulate Vortex Sim Vor Freq Frequency (Hz) * The unit of measure of the displayed value is the * Simulate Temperature Sim Temp 1, 2 same as the unit configured for the flow meter.
Page 77: Calibration Menu
Series M22/M23/M24 Instruction Manual Chapter 3 Operation If the meter display indicates a temperature or pressure fault, a substitute value can be entered to allow flow calculations to continue at a fixed value until the source of the fault is identified and corrected.
Page 78: Password Menu
Chapter 3 Operation Series M22/M23/M24 Instruction Manual Password Menu ENTER Run Mode Password ENTER Password Menu keys to access menus Set Password 1234 Use the Password Menu to set or change the system password. The factory-set password is 1234. 3-18 M-000-00010...
Page 79: Chapter 4 Serial Communications
Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications Chapter 4 Serial Communications HART Communications The HART Communications Protocol (Highway Addressable Remote Trans- ducer Protocol) is a bidirectional digital serial communications protocol. The HART signal is based on the Bell 202 standard and is superimposed on 4-20 mA Output 1.
Page 80: Dc Powered Meter Wiring (Hart)
Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual DC Powered Meter Wiring Vortex Meter RS485 RS485 RS485 GND R load, Current Power 250 ohm Meter Supply minimum Field Connection Remote Connection for Communicator for Communicator Figure 4-2.DC Powered Meter Wiring (HART) AC Powered Meter Wiring Vortex Meter RS485...
Page 81: Hart Commands With The Dd Menu
Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications HART Commands with the DD Menu Online Menu 1 Process Variables 1 Mass Flo 2 Vol 3 Temp 4 Temp 2 5 Delta Temp. 6 Energy flo 7 Pres 8 Dens 9 Total Total 2 1 Enter Password To Enter Password Menu...
Page 82 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual HART Commands with the DD Menu Continued Analog Output Menu 1 Fix Analog Output 2 Trim Analog Output From Online Menu 1 PV is 3 Configure AO1 2 PV AO1 Out 4 PV is 3 PV 5 PV AO1 Out 4 PV % range...
Page 83 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications HART Commands with the DD Menu Continued Fluid Menu 1 Fluid Liquid Water From Online Menu 2 Fluid Type Other Liquid Ammonia Goyal-Dorais Chlorine API-2540 Nat Gas AGA8 Real Gas Other Liquid Density Other Gas Viscosity Coef AL Liquified Gas...
Page 84 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual HART Commands with the DD Menu Continued Diagnostics Menu 1 Vel 1 Vtx Freq From Online Menu 2 Pres 2 Sim Vtx Freq 3 Temp 3 Vtx AtoD 4 Temp 2 4 Filter Set 5 Internal Temp 5 Change Filter Set 6 Vortex Diag.
Page 85 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications HART Commands with the DD Menu Continued Sensor Cal Menu 1 K Factor 2 Base Reynolds * 1 Calibration Review From Online Menu 2 Ck Value 1 Vol unit 1 Vtx Freq 2 Vortex Sensor 3 Low flow cutoff 2 USL...
Page 86: Hart Commands With Generic Dd Menu
Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual HART Commands with Generic DD Menu Online Menu From Device setup / Review 1 Device setup 1 Process Variables 1 PV 1 Model 1 4 mA 2 PV 2 PV % Rnge 2 Distributor 2 20 mA 3 PV Loop current...
Page 87: Modbus Communications
Chapter 4 Serial Communications Modbus Communications Applicable Flow Meter Models Warning! VorTek Pro-V® Mass Flow Meters, Models M22, M23, and M24 with Modbus Place controls in manual communication protocol and firmware version 4.00.58 and above. mode when making configuration changes to the vortex meter.
Page 88: Menu Items
Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual Menu Items The following menu items are in the Output Menu and allow selection and control of the Modbus communication protocol. Address When the Modbus protocol is selected, the Modbus address is equal to the user programmable device address if it is in the range 1…247, in accordance with the Modbus specification.
Page 89 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications The following four selections are available in this menu; when selecting an item, the protocol is changed immediately without having to press the Enter key. 0-1:2-3 Most significant register first, most significant byte first (default) 2-3:0-1 Least significant register first, most significant byte first 1-0:3-2...
Page 90: Register Definitions
Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual Each range of register numbers maps to a unique range of addresses that are determined by the function code and the register number. The address is equal to the least significant four digits of the register number minus one, as shown in the following table.
Page 91 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications Registers Variable Data type Units Function Addresses code 65100-65101 Serial number unsigned long — 03, 04 30525-30526 Totalizer unsigned long display units* 03, 04 524-525 32037-32042 Totalizer units string — 03, 04 2036-2041 30009-30010 Mass flow...
Page 92 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual The floating point registers with values in display units are scaled to the same units as are displayed, but are instantaneous values that are not smoothed. If display smoothing is enabled (non-zero value entered in the Display TC item in the Display Menu), then the register values will not agree exactly with the displayed values.
Page 93 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications Control Register Definitions The only writeable registers in this implementation are the Reset Exception Status, Reset Meter and Reset Totalizer functions, which are implemented as ”coils” which may be written with the Write Single Coil command (function code 05) to address 7 through 9, respectively, (register #00008 through #00010).
Page 94 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual Exception Response Message Format Examples Read the exception status byte from the device with address 1: 01 07 41 E2 01 Device address 07 Function code, 07 = read exception status 41 E2 CRC A typical response from the device is as follows: 01 07 03 62 31 01 Device address...
Page 95 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications An attempt to read register(s) that don’t exist 01 04 00 00 00 50 F1 D2 01 Device address 04 Function code 4 = read input register 00 00 Starting address 00 50 Number of registers = 80 F0 36 CRC results in an error response as follows: 01 84 02 C2 C1...
Page 96 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual The unit responds with an identical message to that transmitted, and the totalizer is reset. If the “coil” is turned off as in the following message, the response is also identical to the transmitted message, but the totalizer is not affected. 01 05 00 09 00 00 1D C8 01 Device address 05 Function code 5 = write single coil...
Page 97: Bacnet Mstp Communications
Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications BACnet MS/TP Communications 1. BACnet MS/TP Description BACnet Master-Slave/Token-Passing (MSTP) driver implements a data link protocol that uses the services of the RS- 485 physical layer. The MS/TP bus is based on BACnet standard protocol SSPC-135, Clause 9.
Page 98: Supported Bacnet Objects
Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual 12. Change the required settings and press Exit & Enter buttons to save the configuration 13. Reboot the device by power off and on for the changes to take effect Note: a. IUT support 9600, 19200, 38400 baud rates b.
Page 99 3.1. Device Object: The Device object default property values are as follows – Property Name Default Values object-identifier object-name Device,1 object-type Device system-status operational vendor-name VorTek Instruments vendor-identifier model-name Multivariable Flowmete firmware-revision application-software- 1.07 version protocol-version protocol-revision protocol-services- {F,F,F,F,F,F,F,F,F,F,F,F,T,F,T,T,T,T,F,F,F,F,F,F,F,F,F,F,F,F,T,T,F,F,F,F,F} supported...
Page 100 3000 number-of-APDU-retries max-master max-info-frames device-address-binding database-revision Note - Device Communication Control: Password – “vortek” 3.2. Analog Input Object: Vortex Mass Flow Meters Analog Input type objects are described in the below Table – Object Instance Object Name Unit Description...
Page 101 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications tons-per-hour, grams-per-second , grams-per-minute Temperature 1 degrees-Celsius, This AI object measures degrees-Kelvin, Temperature in one of degrees-Fahrenheit the given Unit. Temperature 2 degrees-Celsius, This AI object measures degrees-Kelvin, Temperature in one of degrees-Fahrenheit the given Unit.
Page 102 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual liters-per-minute, liters-per-second, liters-per-hour, cubic-meters-per-second, cubic-meters-per-minute, cubic-meters-per-hour If Totalizer selection for Energy measure – Kilowatts, Horsepower, btus-per-hour,, kilo-btus-per-hour, megawatts StatusRegister NO UNITS Channel 1 milliamperes (4-20mA) Channel 2 milliamperes (4-20mA) Channel 3 milliamperes (4-20mA) Scaled Freq hertz...
Page 103 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications 3.3. Binary Input Object: Vortex Mass Flow Meters Binary Input type objects are described in the below Table. Object Object Description Instance Name Alarm1 The status of the three alarms may be monitored via the Modbus command.
Page 104: Annex - Bacnet Protocol Implementation Conformance Statement
Series M22/M23/M24 Instruction Manual 4. ANNEX - BACnet PROTOCOL IMPLEMENTATION CONFORMANCE STATEMENT Date: 19-April-2012 Vendor Name: VorTek Instruments Product Name: Pro-V M22/M23/M24 multivariable flow-meter Product Model Number: M22/M23/M24 VT/VTP Applications Software Version: 1.07 Firmware Revision: N/A BACnet Protocol Revision: 4...
Page 105 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications Services Supported Read Property Execute Write Property Execute Read Property Multiple Execute Write Property Multiple Execute Who-Is Execute I-Am Initiate Who-Has Execute I-Have Initiate Device Communication Control Execute Segmentation Capability:  Able to transmit segmented messages Window Size Able to receive segmented messages Window Size...
Page 106 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual Standard Object Types Supported: Standard Object Types Supported Additional Dynamically Dynamically Range Object Type Writable Creatable Delete-able Restrictions Properties Analog None None Input (AI) Binary Input None None (BV) Binary None None Value Device None...
Page 107 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications Object List: Properties of Analog Input/Value Objects Type Present Status Event Out of Name Units Value Flags State Service Volume Flow F,F,F,F Normal False Mass Flow F,F,F,F Normal False Temperature 1 F,F,F,F Normal False Temperature 2...
Page 108 Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual Properties of Analog Input/Value Objects Type Present Status Event Out of out-of-service Name Value Flags State Service Reset False F,F,F,F Normal False Data Link Layer Options: BACnet IP, (Annex J) BACnet IP, (Annex J), Foreign Device ISO 8802-3, Ethernet (Clause 7) ANSI/ATA 878.1, 2.5 Mb.
Page 109 Series M22/M23/M24 Instruction Manual Chapter 4 Serial Communications  Multiple Application-Specific Keys:  Supports encryption (NS-ED BVBB)  Key Server (NS-KS BVBB) Character Sets Supported: Indicating support for multiple character sets does not imply that they can all be supported simultaneously. ...
Page 110: Acronyms And Definitions
Chapter 4 Serial Communications Series M22/M23/M24 Instruction Manual 5. Acronyms and Definitions Item Description APDU Application Protocol Data Unit BACnet Building Automation and Control Network- Data communication protocol MS/TP Master-Slave Token passing(a twisted pair RS485 network created by BACnet) BIBB BACnet Interoperability Building Block (Specific individual function blocks for data exchange between interoperable devices).
Page 111: Chapter 5 Troubleshooting And Repair
Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair Chapter 5 Troubleshooting and Repair Warning! Hidden Diagnostics Menus Before attempting any flow meter repair, verify that the The menus shown on the following page can be accessed using the password line is not pressurized.
Page 112 Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual Hidden Diagnostics Menus { ------------ Level One Values ------------ } { ------------------------------ Level Two Values ------------------------------ } 4-20(1), Zero Alarm(1) Test Output Type xxxx None 4-20(1), Fscale Adj. Filter Alarm(2) Test Calibration Mode xx dB xxxx...
Page 113: Level One Hidden Diagnostics Values
Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair Level One Hidden Diagnostics Values • f = Vortex shedding frequency (Hz). • fi = Adaptive filter – should be approximately 25% higher than the vortex shedding frequency, this is a low-pass filter. If the meter is using the Filter Control (see below) in the manual mode, fi will be displayed as fm.
Page 114: Level Two Hidden Diagnostics Values
Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual this menu can be compared to the actual Ck setting in the calibration menu to help determine if the Ck setting is correct. • Lvl = Threshold level. If the Low Flow Cutoff in the calibration menu is set above this value, the meter will read zero flow.
Page 115 Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair • 4-20(3) Zero = Analog counts to calibrate zero on analog output 3. • 4-20(3) FScale = Analog counts to cal. full scale on analog output 3. • Ext. 4 mA Cal. = Enter 0 for auto calibration or enter factory supplied A/D counts.
Page 116 Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual before performing this process, it is required only in very rare cases. • Meter Type = Insertion (M23) or Inline (M22/M24) meter. • Config Code = Factory use only. • Test Pulse Out = Force totalizer pulse. Set to Yes and press enter to send one pulse.
Page 117: Analog Output Calibration
Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair Analog Output Calibration To check the 4–20 mA circuit, connect a DVM in series with the output loop. Select zero or full scale (from the second level of the hidden diagnostics) and then actuate the enter key twice. This action will cause the meter to output its 4 mA or 20 mA condition.
Page 118: Troubleshooting The Flow Meter
Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual Troubleshooting the Flow Meter Warning! Before attempting any flow meter repair, verify that the line is not pressurized. Always remove main power before disassembling any part of the mass flow meter. Use hazardous area precautions if applicable.
Page 119: Determine The Fault
Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair Record values - Hidden Diagnostics Menu continued: With No Flow With Flow (if possible) Ck = Lvl = Adj. Filter = Iso. Power Volts = Record the following values from the Calibration Menu. Meter Size / Pipe ID = Meter Factor = Vortex Coef Ck =...
Page 120: Electronics Stack Sensor Connections
Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual The displayed values can be smoothed using the time constant in the Display Menu. The analog outputs can be smoothed using the time constant in the Output Menu. A time constant of 1 will result in the change in value reaching 63% of its final value in one second.
Page 121: Symptom: No Output
Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair VORTEX PRESSURE TEMPERATURE Figure 5-2.Remote Feed Through Board Sensor Connections Symptom: No Output 1. For remote mounted electronics, carefully check all the wiring connections in the remote mount junction box. There are 18 connections that must be correct, verify each color (black and red), shield, and wire number.
Page 122: Symptom: Meter Displays Temperature Fault
Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual f. Hold a finger on the three exposed pins on the analog board. The meter should read electrical noise, 60 Hz for example. If all readings are correct, re-install vortex sensor wires. 4.
Page 123: Symptom: Meter Displays Pressure Fault
Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair Symptom: Meter Displays Pressure Fault 1. For remote mounted electronics, carefully check all the wiring connections in the remote mount junction box. There are 15 connections that must be correct, verify each color (black and red), shield, and wire number.
Page 124: Electronics Assembly Replacement
Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual Electronics Assembly Replacement (All Meters) The electronics boards are electrostatically sensitive. Wear a grounding wrist strap and make sure to observe proper handling precautions required for static-sensitive components. 1. Turn off power to the unit. 2.
Page 125: Pressure Sensor Replacement (Series M22 And M24 Only)
Series M22/M23/M24 Instruction Manual Chapter 5 Troubleshooting & Repair Pressure Sensor Replacement (Series M22/M24 Only) 1. For local mounted electronics, remove the electronics stack as previously described. For remote mount electronics, remove all wires and sensor connectors from the remote feed through board in the junction box at the meter.
Page 126 Chapter 5 Troubleshooting & Repair Series M22/M23/M24 Instruction Manual 5-16 M-000-00010...
Page 127: Appendix A Product Specifications
Series M22/M23/M24 Instruction Manual Appendix A Specifications Appendix A Product Specifications Accuracy Process M22/M24 Series In-Line Meters M23 Series Insertion Meters Variables Liquids Gas & Steam Liquids Gas & Steam Mass Flow ±1% of rate ±1.5% of rate ±1.5% of ±2% of rate Rate over a 30:1...
Page 128 Appendix A Specifications Series M22/M23/M24 Instruction Manual Typical Air Minimum and Maximum Flow Rates (SCFM) Air at 70 Nominal Pipe Size (in) Pressure 0.75 0 psig 1437 3258 5708 100 psig 1730 2890 6466 11254 25515 44698 1332 200 psig 1322 3248 5427...
Page 129 Series M22/M23/M24 Instruction Manual Appendix A Specifications Typical Saturated Steam Minimum and Maximum Flow Rates (lb/hr) Nominal Pipe Size (in) Pressure 0.75 1264 5 psig 1087 2431 4231 9594 16806 1652 2893 100 psig 1386 3405 5690 12729 22156 50233 87998 2229 3905...
Page 130 Appendix A Specifications Series M22/M23/M24 Instruction Manual M23 Pressure Ratings Probe Seal Process Material Rating Ordering Connection Code Compression Fitting 2-inch MNPT 316L SS ANSI 600 lb CNPT 2-inch 150 lb flange, 316L SS ANSI 150 C150, DN50 PN16 lb, PN16 2-inch 300 lb flange, 316L SS ANSI 300...
Page 131 Series M22/M23/M24 Instruction Manual Appendix A Specifications User is responsible for the provision of an external disconnect means, disconnect line 1 and line 2 when 220 / 240 VAC power is used, also provide over-current protection for the equipment (both AC and DC models).
Page 132 Appendix A Specifications Series M22/M23/M24 Instruction Manual Mounting Position Series M22/M24 In-Line Flow Meter: No effect. Series M23 Insertion Flow Meter: Meter must be perpendicular with- in ± 5° of the pipe centerline. Material Certificate – US Mill certs on all wetted parts Certifications Pressure Test Certificate Certificate of Conformance...
Page 133 Series M22/M23/M24 Instruction Manual Appendix A Specifications Model Number Information - Pro-V Model M22/M24 Inline Mass Vortex Flowmeter * See follow ing page. M22/M24 Parent Num ber Code M22/M24 In-line Multivariable Mass Vortex Flow Meter Feature 1 : Multivariable Options Volumetric Flow Meter for liquid, gas and steam Velocity and Temperature Sensors Velocity, Temperature and Pressure Sensors...
Page 134 Appendix A Specifications Series M22/M23/M24 Instruction Manual Model Number Information - Pro-V Model M22/M24 Inline Mass Vortex Flowmeter * See previous page. M22/M24 Feature 8: Output Loop pow ered option - one analog output (4-20 mA), one alarm, one pulse, HART, DCL input pow er only * 1AHL One analog output (4-20 mA), one alarm, one pulse, HART Communication Protocol, DCH or AC option only * One analog output (4-20 mA), one alarm, one pulse, MODBUS Communication Protocol, DCH or AC option only *...
Page 135 Series M22/M23/M24 Instruction Manual Appendix A Specifications Model Number Information - Pro-V Model M23 Insertion Mass Vortex Flowmeter * See follow ing page. Parent Num ber Code Insertion Multivariable Mass Vortex Flow Meter Feature 1 : Multivariable Options Volumetric Flow Meter for liquid, gas and steam Velocity and Temperature Sensors Velocity, Temperature and Pressure Sensors VTEP...
Page 136 Appendix A Specifications Series M22/M23/M24 Instruction Manual Model Number Information - Pro-V Model M23 Insertion Mass Vortex Flowmeter * See previous page. Feature 8: Pressure Options No Pressure Sensor Maximum 30 psia (2 bara), Proof 60 psia (4 bara) Maximum 100 psia (7 bara), Proof 200 psia (14 bara) Maximum 300 psia (20 bara), Proof 600 psia (41 bara) Maximum 500 psia (34 bara), Proof 1000 psia (64 bara) Maximum 1500 psia (100 bara), Proof 2500 psia (175 bara)
Page 137: Appendix B Approvals
Series M22/M23/M24 Instruction Manual Appendix B Approvals Appendix B Approvals ATEX-IECEx Specifications / Approval EN 60079-0 (2012+A11:2013) IEC 60079-0 (2011) Electrical Apparatus for explosive gas atmospheres General Requirements EN IEC 60079-1 (2014) Electrical Apparatus for explosive gas atmospheres Flameproof enclosures “d” EN 60079-31 (2014) Explosive atmospheres.
Page 138: Longmont, Co
Appendix B Approvals Series M22/M23/M24 Instruction Manual Declaration of Conformity VorTek Instruments, LLC 8475 W I-25 Frontage Rd Longmont, CO 80504 Declares in sole responsibility that the product: Vortex Flow Meter Type M22 / M23 / M24 / Pro-T Conforms to the regulations of the European Directives:...
Page 139 Series M22/M23/M24 Instruction Manual Appendix B Approvals Registrant: VorTek Instruments, LLC (Azbil VorTek, LLC) Equipment Name: Vortex Flowmeter Registration No’s: MSIP-REM-A1V-A001 MSIP-REM-A1V-A002 MSIP-REM-A1V-A003 Date of Registration: 2014-02-14 Technical assistance may be obtained by contacting Customer Service at: (888) 386-7835 or (303) 682-9999 in the USA...
Page 140 Appendix B Approvals Series M22/M23/M24 Instruction Manual M-000-00010...
Page 141: Appendix C Flow Meter Calculations
Series M22/M23/M24 Instruction Manual Appendix C Flow Meter Calculations Appendix C Flow Meter Calculations In-Line Flow Meter Calculations Volume Flow Rate Flowing Velocity Mass Flow Rate  Where: A = Cross sectional area of the pipe (ft^2) f = Vortex shedding frequency (pulses / sec) K = Meter factor corrected for thermal expansion (pulses / ft^3) = Mass flow rate (lbm / sec) = Volume flow rate (ft^3 / sec)
Page 142 Appendix C Flow Meter Calculations Series M22/M23/M24 Instruction Manual Insertion Flow Meter Calculations Flowing Velocity Volume Flow Rate Mass Flow Rate  Where: A = Cross sectional area of the pipe (ft^2) f = Vortex shedding frequency (pulses / sec) = Meter factor corrected for Reynolds Number (pulses / ft) = Volume flow rate (ft^3 / sec) = Mass flow rate (lbm / sec)
Page 143 Series M22/M23/M24 Instruction Manual Appendix C Flow Meter Calculations Energy Flow Calculations Energy is calculated for a steam supply/condensate return or hot/chilled water system. For steam/water, the meter must be located in the supply line; otherwise, the meter may be located in either the supply line or in the return line. Steam supply, water return, meter steam supply Energy = mdot * (h0 - pctRet * h1) Where:...
Page 144 Appendix C Flow Meter Calculations Series M22/M23/M24 Instruction Manual Fluid Calculations Calculations for Steam T & P When “Steam T & P” is selected in the “Real Gas” selection of the Fluid Menu, the calculations are based on the equations below. Density The density of steam is calculated from the formula given by Keenan and Keys.
Page 145 Series M22/M23/M24 Instruction Manual Appendix C Flow Meter Calculations Calculations for Gas (“Real Gas” and “Other Gas”) Use this formula to determine the settings for “Real Gas; Gas” selections and “Other Gas” selections entered in the Fluid Menu. The calculations for gas were taken from Richard W.
Page 146 Appendix C Flow Meter Calculations Series M22/M23/M24 Instruction Manual Calculations for Liquid Use this formula to determine the settings for “Goyal-Dorais” selections and “Other Liquid” selections entered in the Fluid Menu. The liquid cal- culations were taken from Richard W. Miller, Flow Measurement Engi- neering Handbook (Third Edition, 1996).
Page 147: Appendix D Glossary
Series M22/M23/M24 Instruction Manual Appendix D Glossary Appendix D Glossary A B C D Cross sectional area. ACFM Actual Cubic Feet Per Minute (volumetric flow rate). ASME American Society of Mechanical Engineers. Bluff Body A non-streamlined body placed into a flow stream to create vortices.
Page 148 Appendix D Glossary Series M22/M23/M24 Instruction Manual I J K L In-Line Flow Meter A flow meter which includes a short section of piping which is put in-line with the user’s piping. Insertion Flow Meter A flow meter which is inserted into a hole in the us- er’s pipeline.
Page 149 Series M22/M23/M24 Instruction Manual Appendix D Glossary Liquid vapor pressure at flowing conditions (psia or bar absolute). Q R S T Flow rate, usually volumetric. Rangeability Highest measurable flow rate divided by the lowest measurable flow rate. Reynolds Number A dimensionless number equal to the density of a fluid or Re times the velocity of the fluid times the diameter of the fluid channel, divided by the fluid viscosity (i.e., Re =...
Page 150 Appendix D Glossary Series M22/M23/M24 Instruction Manual M-000-00010...

This manual is also suitable for:

Pro-v m23 Pro-v m24 Turbo-pro Pro-t

VorTek Pro-V M22 Instruction Manual

Chapter 1 Introduction

Chapter 2 Installation

Chapter 3 Operating Instructions

Chapter 4 Serial Communications

Chapter 5 Troubleshooting and Repair

Appendix A Product Specifications

Appendix B Approvals

Appendix C Flow Meter Calculations

Appendix D Glossary

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for VorTek Pro-V M22

Summary of Contents for VorTek Pro-V M22

This manual is also suitable for:

Table of Contents
