2.2.4

Layout contents

Slots/Sockets
1. CPU sockets
2. DDR4 sockets
3. PCI Express x16 / PCI Express x8
Onboard LEDs
1. Standby Power LED (SBPWR1)
2. CATT ERR LED (CATTERR1)
3. ME LED (MELED1)
4. BMC LED (BMCLED1)
5. Message LED (MLED1)
Jumpers
1. Clear RTC RAM (CLRTC1)
2. VGA controller setting (3-pin VGA_SW1)
3. LAN controller setting (3-pin LAN_SW1-4)
4. ME firmware force recovery setting (3-pin ME_RCVR1)
5. PCH_MFG1 setting (3-pin PCH_MFG1)
6. Smart Ride Through (SmaRT) setting (3-pin SMART_PSU1)
7. DMLAN setting (3-pin DM_IP_SEL1)
8. SATADOM power setting (3-pin DOM1_PWR1)
9. CPU PCIE configuration setting (3-pin U2_CFG5-6)
Rear panel connectors
1. RJ-45 port for iKVM
2. Q-Code LED
3. Power-on Button
4. Video Graphics Adapter port
5. RJ-45 ports for LAN 1-4
6. USB 3.1 Gen 2 ports 1 and 2
7. USB 3.1 Gen 1 ports 5 and 6
ASUS P11C-M/4L
Page
2-7
2-13
2-17
Page
2-19
2-19
2-20
2-20
2-21
Page
2-22
2-23
2-23
2-24
2-24
2-25
2-25
2-26
2-26
Page
2-27
2-27
2-27
2-27
2-27
2-27
2-27
2-5
