MikroTik RouterBOARD QRTG-2SHPnD Quick Setup Manual And Warranty Information

RouterBOARD QRTG-­‐2SHPnD
Quick Setup Guide and Warranty Information
The RouterBOARD QRT comes as a c omplete kit. It i ncludes a b uilt
in 8 02.11b/g/n dual chain wireless device, and a d ual polarization
17dBi antenna. It h as one Gigabit Ethernet c onnector which
supports MDI-­‐X a uto detection.

First use

1. Connect an E thernet cable to t he port behind
the small plastic door
2. The QRT accepts 24V Passive P oE f rom a P oE i njector
3. The default IP a ddress from LAN is 192.168.88.1 f or
configuration from a web browser
4. Username is admin and there i s no password

Powering

The device accepts powering from the Ethernet p ort ( Passive PoE) 8-­‐30V DC. Package contains a 2 4V
adapter. Maximum power consumption of the device is 21W @ 2 4V. s
Booting p rocess
Initial connection has to be done via t he Ethernet c able. Open 192.168.88.1 i n y our w eb b rowser.
Username is admin and there is no password. In case IP connection is not a vailable, Winbox can be used
to connect t o the MAC address of the device. More information here:
http://wiki.mikrotik.com/wiki/First_time_startup
In case you wish to boot t he device from network, for example to use MikroTik Netinstall, hold the
RESET button of the device when starting it u ntil
the LED light t urns off, and Metal will start t o look
for Netinstall servers.

Mounting

The QRT box contains several parts that n eed to be
assembled. Please follow this process:
Start by attaching the t wo pole b rackets (A) to the
swivel adjuster (B), by using the f our provided screws
(use a PH1 screwdriver).
See w ww.routerboard.com for m ore information. Contact s upport@mikrotik.com for s upport q uestions.
B
A
21/08/13
