Manson Engineering Industrial USB-2928 Quick Start Manual

Quick
Start
Guide
USB-2928
8 Ports USB Power Station
1
Precaution
•
Use the USB power station indoor only
•
Do not cover USB power station during use
•
Do not use to charge damaged battery
•
Voltage and Current meters are for reference only.
3
Features
•
8 x USB port, each port may provide Max 2 Amp
•
Voltage and Current meter
•
mAh record
•
Intelligent sleep mode
•
Smart rolling display, automatic skip no load port.
•
Button to select port to display
•
mAh clear button
5
Display and Indications
2
4
1. Output Voltage
1 2
2. Output Current
V A
3. mAh Record
mAh
4. Port number
3 4
Introduction
Manson USB-2928 8-port USB power station is a
smart power source for USB powered device.
General application;
•
Charger for smart mobile device (iPad, iPhone,
Android device) with automatic optimization.
•
Power source for DIY project,
such as Raspberry Pi, Arduino, and etc.
•
Power source for mini-wifi station.
•
Voltage and Current measure for USB device.
Electrical Specification
Input
Input Frequency
Output Voltage for each port
Max. Output Current for each port
For more information,
please visit our website:
http://www.manson.com.hk
: 110/240Vac
: 50Hz/60Hz~
: 5V ±0.2V
: 2Amp
