  • Page 1 OWNER’S MANUAL...
  • Page 2 CONTENTS...

  • Page 3: Main Features

    OVERVIEW Thank you for purchasing our dogtra e-Fence System. With dogtra e-Fence System your dog can freely play around within the boundaries you have selected. With the proper training you will enjoy seeing your dog in good demeanor. MAIN FEATURES •...
  • Page 4 SAFETY • Dogtra e-Fence collars use state-of-the-art microcomputer technology. The receiver has an automatic control which limits the stimulus to eight seconds. • Dogtra’s filtering system prevents reception from outside sources other than your transmitter. DOGTRA e-Fence System PACKAGE CONTENTS •...

  • Page 5: Description Of Transmitter Parts

    DESCRIPTION OF TRANSMITTER PARTS dogtra e-Fence Transmitter Wire Indicator Light ON/OFF Indicator Light Intensity Selection Dial ON/OFF & Function Selection Switch Field Width Adjustment Knob Wire Connectors Adaptor Jack Connector...
  • Page 6 ON/OFF & Function Selection Switch The On/Off Selection switch has three functions. When the toggle switch is up, the warning/vibration followed by stimulation will occur. When this switch is down, only stimulation occurs. When the switch is in the middle, the power is Off. Pager/Stimulation Stimulation...
  • Page 7 Field Width Adjustment Knob This knob controls the width of the signal field (the distance from the boundary wire to the location where the collar/receiver first activates). Turning the knob clockwise increases the field width, giving your dog wider buffer area before the activation. Turning it counterclockwise decreases the distance between the dog and fence before activation.
  • Page 8 ON/OFF Indicator Light When the On/Off & Function Selection switch is either in the up or down position, the LED light will be on, indicating that the power is on. When the switch is in the middle position, the light goes off, indicating that the power is off.
  • Page 9 Wire Indicator Light When the wires are connected properly, the wire indicator light will be on. In the event the e-Fence wire becomes damaged, the light will automatically turn off.

  • Page 10: Wire Connectors

    Black Connector (for the protective wires) Wire Connectors The easy-to-use push-release wire connectors let you instantly connect or disconnect the boundary wire leads. Wires should be stripped about a half inch before being inserted into the red connectors on the bottom of the wall mount transmitter. Dogra e-Fence comes with lightning/surge protective wires.
  • Page 11 Adaptor Jack Connector Adaptor Jack Connector Plug the 110-volt adaptor into a 110-volt wall outlet and insert the adaptor plug into the adaptor jack connector of the transmitter.
  • Page 12 Wall-Mount Transmitter Use the (2) included screws to mount the transmitter to a wall securely, near any standard 110-volt household outlet. The unit will withstand freezing temperatures, but it is not waterproof. Therefore, we recommend mounting the transmitter in a safe, dry indoor area. To power the wall transmitter, plug the AC adaptor into the standard 110-volt outlet and connect it to the adaptor jack connector of the transmitter.

  • Page 13: Description Of Collar Parts

    110-volt DESCRIPTION OF COLLAR PARTS dogtra e-Fence Receiver Collar strap Battery Charging Receptacle and Cover Contact Point ON/OFF Magnetic Switch Indicator Light...
  • Page 14 Accessory Magnetic Switch ON/OFF Magnetic Switch To activate the Dogtra e-Fence, place the accessory magnetic switch (located on the top of the wall mount transmitter) to the red dot on the collar/receiver. Hold them together for a moment until the LED indicator light starts flashing on the receiver. The indicator light will blink once every two seconds showing that the unit is charged and ready to use.
  • Page 15 Receiver Indicator Light (LED) Located on the front of the collar, the indicator light comes on and blinks once every two seconds after the collar is turned on. The blinking will change from a single flash to a double flash when the collar needs to be recharged. The indicator light will come on when the dog reaches the edge of the signal field in the yard.

  • Page 16: Contact Points

    Contact Points The collar should be fitted so that the stainless steel contact points press firmly against the dog’s skin. A loose fit can allow the collar to move around on the dog’s neck which may cause irritation to the skin. If the collar is too loose, electrical contact will be inconsistent and your corrections will be inconsistent as well.
  • Page 17 Collar/Receiver Battery Charging Receptacle On the inside of the collar/receiver, next to the collar strap, is the battery charging receptacle with a rubber cover plug.

  • Page 18: Battery Charger

    110 volt charger Battery Charger The battery charger is designed for a 110-volt wall outlet. (European 220-volt AC charger is also available.)

  • Page 19: Charging The Batteries

    110-volt CHARGING THE BATTERIES Dogtra uses Ni-MH (Nickel-Metal Hydride) batteries that do not have a memory. They can be charged on a regular basis without harm. There is no need to completely drain the batteries between charges. 1. Plug the 110-volt adaptor into a 110-volt wall outlet and insert the adaptor plug into the battery charging receptacle of the receiver.
  • Page 20 TESTING YOUR DOGTRA e-Fence System 1. Activate the Dogtra e-Fence, place the accessory magnetic switch (located on the top of the wall mount transmitter) to the red dot on the collar/receiver. Hold them together for a moment until the LED indicator light starts flashing on the receiver.

  • Page 21: Operating Instructions

    (Please refer to the diagrams at the end of this manual.) The DOGTRA e-Fence includes 500 feet of boundary wire and 50 training flags. If you need more wire, you can purchase it through Dogtra Company. The estimated length of...
  • Page 22 Tools To install your e-Fence, you will need a flat-blade shovel, standard screwdriver and wire cutter/stripper. If your layout calls for the wires to be connected across concrete, you will also need a caulking gun, exterior silicon caulk and a circular saw with a masonry blade for cutting the pavement.
  • Page 23 DO NOT run fence wire of one section within 10 feet of another section of fence wire or the signal may cancel. DO NOT run the fence within 10 feet of a neighboring e-fence system’s boundary wire. Driveways/Sidewalks When crossing an asphalt driveway, make a 1/2-inch deep cut across the driveway using a circular saw and masonry blade.
  • Page 24 The waterproof splices included in Dogtra’s e-Fence system are designed to provide a sealed connection between the wires. The insulation on the boundary wire should not be stripped before placing wire into the holes.
  • Page 25 E-fence Training Tips To get the most effective results with your Dogtra e-Fence, keep these tips in mind : The collar must be on relatively tight. The contact points should maintain contact with the dog’s skin without restricting breathing.
  • Page 26 Always praise your dog for desirable behavior. Getting Started With Your Dogtra E-fence Step 1 : Initial Experience With Stimulation On Leash Place the collar/receiver on your leashed dog in a safe area of the yard. Walk your dog into the flagged area where it will feel the vibration followed by stimulation.

  • Page 27: Troubleshooting And Maintenance

    Follow the procedures in step 2 except do not hold the end of the leash. Drop the leash on the ground and let it drag behind the dog. You can use the leash to retrieve your dog should he ignore the e-fence stimulation and get outside the boundary. If your dog runs through the fence, take the dog back in the safe area.

  • Page 28: General Maintenance Tips

    Recharge the battery in the collar receiver and repeat the test. GENERAL MAINTENANCE TIPS Your system requires very little maintenance. The collar receiver for Dogtra’s e-Fence is waterproof and activates even after being immersed in water. To remove dirt, simply rinse with soap and water.
  • Page 29 CAUTION Any changes or modifications of this device which are not specifically approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 30: Warranty And Repair Information

    Write a note briefly explaining the problem and include your name, address, city/state/zip code, daytime and evening phone numbers. Return shipping for warranty is the owner’s responsibility. Costs for shipping(via regular ground service) back to the customer is covered by Dogtra Co. within the continental...
  • Page 31 1250 E. 223 Street, Suite 119 Carson, Ca 90745 For any questions concerning your Dogtra products call us Toll Free at 1-888-811-9111. Out of Warranty Repair For repair work that is no longer covered by warranty, the cost of repair will include parts, labor and shipping.
