Dogtra ELEMENT 3000M series Owner's Manual

Dogtra ELEMENT 3000M series Owner's Manual

Remote controlled dog training collars
Hide thumbs Also See for ELEMENT 3000M series:
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELEMENT 3000M series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dogtra ELEMENT 3000M series

Summary of Contents for Dogtra ELEMENT 3000M series

  • Page 2: Table Of Contents

    CONTENTS MAIN FEATURES PRODUCT SAFETY AND HEALTH STATEMENTS PACKAGE CONTENTS DESCRIPTION OF TRANSMITTER PARTS BUTTON FUNCTIONS DESCRIPTION OF RECEIVER / COLLAR PARTS BATTERY CHARGER TESTING YOUR COLLAR FITTING THE COLLAR ON THE DOG CHARGING THE BATTERIES RECEPTION ACCESSORIES BASIC MAINTENANCE TROUBLESHOOTING GUIDE WARRANTY AND REPAIR INFORMATION EC DECARATION OF CONFORMITY...

  • Page 3: Main Features

    MAIN FEATURES MAIN FEATURES Easy-to-use, ergonomic transmitter. Rheostat dial that allows for gradual increases in stimulation intensity with no jumps between levels. has a 1/2-mile range. Two-dog model allows the trainer to control two different dogs from one transmitter. Waterproof receiver/collar and handheld transmitter.

  • Page 4: Product Safety And Health Statements

    PRODUCT SAFETY AND HEALTH STATEMENTS PRODUCT SAFETY AND HEALTH STATEMENTS Proper e-collar use Dogtra e-collars are intended for the sole purpose of behavior modification of dogs. They are not intended for human use or use on other animals. Dogtra Company does not assume any liability for improper use of the dogtra e-collar.

  • Page 5: Package Contents

    PACKAGE CONTENTS PACKAGE CONTENTS Transmitter Receiver (two receiver/collars for dogtra two-dog models) Battery charger and splitter cable Owner’s manual...

  • Page 6: Description Of Transmitter Parts

    DESCRIPTION OF TRANSMITTER PARTS DESCRIPTION OF TRANSMITTER PARTS transmitter (2-dog unit) Antenna Nick/Constant Rheostat Toggle Switch Intensity Dial Indicator Light (LED Window) -dog -dog Nick &Constant Pager (Gray Button) (Gray Button) -dog -dog Pager Nick &Constant (Orange Button) (Orange Button) Battery Charging On/Off Magnetic Receptacle &...
  • Page 7 DESCRIPTION OF TRANSMITTER PARTS DESCRIPTION OF TRANSMITTER PARTS transmitter (1-dog unit) Antenna Rheostat Intensity Dial Indicator Light (LED Window) “Nick” Button Pager Button “Constant” Button Battery Charging On/Off Magnetic Receptacle & Red Dot Rubber Plug...
  • Page 8 DESCRIPTION OF TRANSMITTER PARTS Transmitter Antenna A short 2 antenna is supplied with the transmitter. The antenna must be fastened to the transmitter before using the unit.
  • Page 9 DESCRIPTION OF TRANSMITTER PARTS Rheostat Intensity Dial The Rheostat Intensity Dial is located on the top of the transmitter: (0) being the lowest level and (100) being the highest level. You will need to adjust the setting (upward or downward) depending on your dog’s temperament and threshold for stimulation.
  • Page 10 DESCRIPTION OF TRANSMITTER PARTS Transmitter Indicator Light (LED Window) The transmitter indicator light (LED) is located near the Rheostat Intensity Dial. The LED light will come on when a button is pressed. The color of the light indicates the status of battery life.
  • Page 11 DESCRIPTION OF TRANSMITTER PARTS Transmitter Battery Charging Receptacle & Rubber Plug Located on the backside of the transmitter, the charging receptacle is covered by a rubber plug. Insert one end of the battery charging cable into the receptacle to charge the battery (See Battery Charging Procedure on page 25).

  • Page 12: Button Functions

    BUTTON FUNCTIONS BUTTON FUNCTIONS (1-dog unit) Nick Button Pager Button Constant Button The transmitter for the single dog unit has three buttons (one on the face of the transmitter, two on the left side). “Nick” Button The “Nick” button is located on the top left. It is imprinted with the letter “N”...
  • Page 13 BUTTON FUNCTIONS “Constant” Button The “Constant” button is located on the bottom left. Pressing the “Constant” button gives continuous stimulation as long as the button is pushed, for up to 12 seconds. If the button is not released after 12 seconds, the stimulation will automatically turn off as a safety feature.
  • Page 14 BUTTON FUNCTIONS (2-dog unit) Nick/ Constant Toggle Switch -dog Nick & Constant -dog (Gray Button) Pager (Gray Button) -dog -dog Nick & Constant Pager (Orange Button) (Orange Button) two-dog unit has four buttons and a toggle switch on the transmitter (Two on the face of the transmitter, two on the left side).
  • Page 15 BUTTON FUNCTIONS When either the orange or gray stimulation button is pressed and the toggle is set on “Nick”, the receiver emits a single rapid pulse of electrical stimulation. When you press either the orange or gray stimulation button and the toggle is set on “Constant”, the receiver emits a continuous stimulation as long as the button is pushed, for up to 12 seconds to the corresponding collar.

  • Page 16: Description Of Receiver / Collar Parts

    DESCRIPTION OF RECEIVER / COLLAR PARTS DESCRIPTION OF RECEIVER / COLLAR PARTS Collar strap Contact Points On/Off Magnetic Switch (Red Dot) Battery Charging Receptacle and Cover Indicator Light (LED Window)
  • Page 17 DESCRIPTION OF RECEIVER / COLLAR PARTS Receiver On/Off Magnetic Switch (Red Dot) To activate the receiver/collar, place the red dot on the back of the transmitter to the red dot on the receiver/collar. Hold the two red dots together for a moment until the LED light on the receiver/collar comes on.
  • Page 18 DESCRIPTION OF RECEIVER / COLLAR PARTS Receiver Indicator Light (LED) Located on the front of the receiver/collar, the indicator light comes on and blinks once every 4 seconds after the collar has been turned on. The color of the LED indicates the battery life of the receiver. (Green = full charge, Amber = medium charge, Red = needs charge) When the “Constant”...
  • Page 19 (See Battery Charging Procedure on page 25). If the dog was in salt-water, be sure to rinse the receiver and charging port with clean water. Internal Antenna All Dogtra E-collars have non-exposed antennas that are located inside the receiver/collar.

  • Page 20: Battery Charger

    BATTERY CHARGER BATTERY CHARGER Charging Cable 120 volt Charger Wall Outlet Two-dog unit only The battery charger and charging cables allow you to charge both the transmitter and receiver at the same time. The battery charger is designed for a 120-volt wall outlet (European 230-volt AC chargers and 12-volt car chargers are also available.).

  • Page 21: Testing Your

    TESTING TESTING YOUR COLLARS 1. To activate your place the red dot on the back of the transmitter to the red dot on the receiver/collar. Hold the two red dots together for a moment until the green colored LED indicator light comes on. The indicator light will blink every two seconds showing the unit is charged and ready to use (If the indicator light emits a red color, the...
  • Page 22 TESTING 2. The indicator light(LED) on the receiver/collar will light briefly when the nick button is pressed. Pressing the Constant button will light the indicator for as long as you hold the button down, up to twelve seconds. 3. As a safety feature, the will automatically shut off stimulation if the Constant button is depressed for twelve seconds or longer.

  • Page 23: Fitting The Collar On The Dog

    FITTING THE COLLAR ON THE DOG FITTING THE COLLAR ON THE DOG PROPER FIT The collar should be fitted so that the surgical stainless steel contact points press firmly against the dog’s skin. You should be able to fit a finger in between the contact point and your dog’s skin.
  • Page 24 Dogtra uses surgical stainless steel contact points and Anti-microbial plastic to protect the dog’s skin. ATTENTION! Leaving the receiver/collar in the same location on the dog’s neck, for an extended period of time can...

  • Page 25: Charging The Batteries

    CHARGING THE BATTERIES CHARGING THE BATTERIES uses Ni-MH (Nickel- Metal-Hydride) batteries. 1. Charge the unit before using the unit for the first time. 2. Do not charge the batteries near any flammable substances. 3. Fully charge the batteries for 10 hours if the unit is to be stored without use for a period of 3 months or more.
  • Page 26 CHARGING THE BATTERIES The indicator light on the transmitter or receiver will not ACTIVATE. The transmitter or receiver does not stay on when one of the stimulation or pager buttons is pushed. Battery Charging Procedure 1. Attach the charging cables to both the transmitter and receiver(s), as shown on page 24.

  • Page 27: Reception

    RECEPTION RECEPTION collar has a range of 1/2-mile. Depending on the way you use your transmitter, the range may vary. Hold the transmitter away from your body and avoid touching the antenna, to get the greatest range. For maximum signal strength, keep your unit properly charged.

  • Page 28: Accessories

    ACCESSORIES ACCESSORIES The following items may be purchased separately by calling our customer service at 1-888-811-9111. You may also browse the selection at shop.dogtra.com. European Charger Designed for use with 230V AC electrical outlets in Europe. Field Auto Charger Designed for use with the 12-volt cigarette lighter in your car.

  • Page 29: Basic Maintenance

    Troubleshooting If you suspect your unit is malfunctioning please refer to the “Troubleshooting Guide” before you send your unit in for service. If you have any questions or concerns, you may direct your inquiries to info@dogtra.com or call 1-888-811-9111.

  • Page 30: Troubleshooting Guide

    TROUBLESHOOTING GUIDE TROUBLESHOOTING GUIDE 1. My dog is not reacting to the collar. - Make sure the receiver is turned on. Place the two red dots together to activate the receiver. - Be sure the collar strap is tight enough so both contact points are touching the dog’s skin.
  • Page 31 - If you have a full charge, and you have done all of the above, your unit may need to be serviced. Please contact Customer Service at info@dogtra.com or 1-888-811-9111. 3. The transmitter has no range, or stimulation is less when the dog is farther away.
  • Page 32 - For Dogtra units over two years old from the purchase date, the batteries may need to be replaced. You can replace them yourself by contacting Dogtra. Damages incurred to the unit due to improper battery installation are not covered under any warranty.

  • Page 33: Warranty And Repair Information

    If your product is not registered and a proof of purchase is not available at the time of service, Dogtra will estimate the age of the unit by the serial number. Serial number estimates can differ from the actual purchase date.
  • Page 34 If the products purchased from an authorized dealer are after 30 days from the date of purchase, please send the units to Dogtra for service and repair.27 Dogtra DOES NOT cover the cost of repairs and replacements due to misuse by the owner or dog, improper maintenance, and/or lost units.
  • Page 35 WARRANTY AND REPAIR INFORMATION time or inconvenience while the unit is in for repair work. Dogtra does not provide loaner units or any form of compensation during the repair period. A copy of the sales receipt showing the purchase date may be required before warranty work is initiated.

  • Page 36: Ec Decaration Of Conformity

    EC DECLARATION OF CONFORMITY Appendix : EC DECLARATION OF CONFORMITY We, Dogtra Company declare under our sole responsibility that the product Model Name : Element 300M to which this declaration relates is in conformity with R&TTE Directive 1999/5/EC By application of the following standards...
  • Page 37 MEMO...
