Thanks for purchasing the Diamond Fireburst! This newly revised
version offers a smaller footprint with top jacks to make it more
pedalboard friendly while retaining the same high gain tones and low
noise of the original.

We hope you have as much fun playing guitar through this pedal as we
did designing and testing it. Our goal is to provide a new twist on the
classic high gain guitar tone, and to make it just plain fun to play.
Remember to protect your hearing and wear appropriate hearing
protection when playing loud...
!

Design Features

• True bypass signal path
• MID toggle offers thick liquid tone or a focused, mid-boosted distortion
• Premium audio components, including film capacitors and 1% metal film
resistors
• All discrete-component distortion, no clipping diodes
• Active Baxandall bass/treble tone control system with audiophile grade op-
amp
• Battery or standard negative tip 9V DC adapter operation
!
Diamond

Fireburst
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fireburst and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Diamond Fireburst

  • Page 1 Diamond
 Fireburst Thanks for purchasing the Diamond Fireburst! This newly revised version offers a smaller footprint with top jacks to make it more pedalboard friendly while retaining the same high gain tones and low noise of the original.
 We hope you have as much fun playing guitar through this pedal as we did designing and testing it.
  • Page 2 Switches On/Off This switches the pedal between bypass and in-circuit operation. A yellow LED indicates that the pedal is on. When bypassed, the Fireburst is completely out of the signal path maintaining the sonic integrity of your signal. MID The ‘MID’ toggle switch provides two tonal variations to select from. One fat and thick, the other tight and mid focused.
