Napoleon HDX52 Installation And Operating Instructions Manual

Napoleon HDX52 Installation And Operating Instructions Manual

Log burner assembly b52ntl natural gas b52ptl propane
Hide thumbs Also See for HDX52:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
CONFORMS TO AMERICAN NATIONAL STANDARDS: ANSI Z21.50, CERTIFIED TO CANADIAN CSA 2.22 FOR VENTED GAS FIREPLACES.
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
SAFETY INFORMATION
WARNING
!
If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call the
fi re department.
- Installation and service must be performed by a
qualifi ed installer, service agency or the supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certifi ed kit is used.
Decorative Product: Not for use as a heating appliance.
Phone (705)721-1212 • Fax (705)722-9081 • www.napoleonfi replaces.com • hearth@napoleonproducts.com
$10.00
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
B52NTL
NATURAL GAS
B52PTL
PROPANE
HDX52
LOG BURNER
ASSEMBLY
DANGER
!
HOT GLASS WILL CAUSE
DO NOT TOUCH GLASS UNTIL
NEVER ALLOW CHILDREN TO
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
BURNS.
COOLED.
TOUCH GLASS.
1.22D
W415-1632 / A / 05.02.16
EN
FR
PG
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDX52 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Napoleon HDX52

Summary of Contents for Napoleon HDX52

  • Page 1 Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone (705)721-1212 • Fax (705)722-9081 • www.napoleonfi replaces.com • hearth@napoleonproducts.com $10.00...

  • Page 2: Table Of Contents

    NOTE: Changes, other than editorial, are denoted by a line in the margin. 1.0 GENERAL INFORMATION This burner and log assembly are approved for use in the HDX52 gas fi replace only. They are not approved for use as a stand alone appliance or in conjunction with any other appliance.

  • Page 3: Bulkheads

    BULKHEADS NOTE: Bulkhead covers need to be removed. Connect the main burner gas fl ex line and the pilot line to the gas fi ttings on the bulkheads located under the valve access opening.Care must be taken to ensure the Main pilot line isn’t damaged and ensuring gas Burner Gas...

  • Page 4: Hearth Panel Installation

    HEARTH PANEL INSTALLATION NOTE: It is recommended to remove the grate assembly prior to panel installation. Hearth fl oor panels are shipped separate from unit and are included with the mandatory brick panel kits. Due to the brittle material of the panels, care must be taken not to bend or force them into place. When shipped, the hearth panels range in varying shades of Sandstone / New Port.

  • Page 5: Hearth Log & Log Placement

    HEARTH LOG & LOG PLACEMENT NOTE: All logs are stamped with a part number. Align the 2 holes in the bottom of the Align the 2 pins in the bottom of the top bottom rear log with the studs located rear log with the holes in the top of the on the rear log support.
  • Page 6 Align the 2 holes located in the bottom Align the 2 holes in the bottom of the right middle log with the 2 studs on the of the front left crossover log with the 2 studs on the left hand side of the right hand side of the burner.

  • Page 7: Charcoal Lumps

    CHARCOAL LUMPS WARNING CHARCOAL EMBERS, VERMICULITE AND CHARCOAL LUMPS ARE NOT TO BE PLACED ON THE BURNER. Place the lumps in front of the logs in a realistic manner taking care not to block any of the burner ports. 34.1 CHARCOAL EMBERS Randomly place the charcoal embers along the front and sides of the log support tray in a realistic manner.

  • Page 8: Vermiculite

    VERMICULITE Sprinkle vermiculite around the charcoal embers. NOTE: Vermiculite is not to be placed on the burner. 33.1 GLOWING EMBERS Tear the embers into pieces and place along the front row of ports covering all of the burner area. Care should be taken to shred the embers into thin, small irregular pieces as only the exposed edges of the fi...

  • Page 9: Replacements

    4.0 REPLACEMENTS Contact your dealer or the factory for questions concerning prices and WARNING policies on replacement parts. Normally all parts can be ordered through your Authorized dealer / distributor. FAILURE TO POSITION THE PARTS FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE IN ACCORDANCE WITH THIS ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM.

  • Page 10: Hdx52 Log Burner Assembly(Ng)

    W415-1632 / A / 05.02.16...

  • Page 11: Hdx52 Log Burner Assembly(Lp)

    W415-1632 / A / 05.02.16...
  • Page 12 6.0 NOTES 44.1 W415-1632 / A / 05.02.16...
  • Page 13 6.0 NOTES 44.1 W415-1632 / A / 05.02.16...
  • Page 14 napoleonproducts.com...
  • Page 15 à risque. ÉCRAN DE PROTECTION Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Téléphone 705-721-1212 • Télécopieur 705-722-9081 • www.napoleonfoyers.com • hearth@napoleonproducts.com 1.22D 10,00 $ W415-1632 / A / 05.02.16...

  • Page 16: Information Générale

    NOTE : Les modifi cations, autres qu’éditoriales, sont indiquées par une ligne verticale dans la marge. 1.0 INFORMATION GÉNÉRALE Ce brûleur et cet assemblage de bûches sont approuvés pour utilisation dans l’appareil au gaz HDX52 seulement. Ils ne sont pas approuvés pour utilisation comme appareil autonome ou avec n’importe quel autre appareil.

  • Page 17: Raccords

    RACCORDS NOTE : Les couvercles des raccords doivent être retirés. Branchez les conduites de gaz fl exibles et la conduite de la veilleuse aux raccords de gaz situés en dessous de l’ouverture d’accès de la soupape. Usez de prudence pour vous assurer de ne pas endommager la conduite Raccords de la veilleuse et que les connexions de gaz...

  • Page 18: Installation Des Panneaux De Plancher

    INSTALLATION DES PANNEAUX DE PLANCHER NOTE: Nous vous suggérons de enlever l’ensemble de la grillage avant l’installation du panneau. Les panneaux de plancher sont expédiés séparément de l’unité et ils sont inclus avec l’assemblage du brûleur et les bûches. En raison de la fragilité des panneaux, prenez grand soin de ne pas courber ou forcer les panneaux pour les mettre en place.

  • Page 19: Disposition Des Bûches

    DISPOSITION DES BÛCHES NOTE: Tous les bûches sont estampillés avec un numéro de pièce Alignez les deux trous du dessous Alignez les deux tiges du dessous de la bûche inférieure arrière sur de la bûche supérieure arrière dans les goujons situés sur le support à les trous sur le dessus de la bûche bûches arrière.
  • Page 20 Alignez les deux trous du dessous Alignez les deux trous du dessous de la bûche transversale avant de la bûche centrale droite sur les gauche sur les deux goujons situés deux goujons situés à droite du à gauche du brûleur. brûleur.

  • Page 21: Morceaux De Charbon

    MORCEAUX DE CHARBON AVERTISSEMENT LES BRAISES DE CHARBON DE BOIS, LA VERMICULITE ET LES MORCEAUX DE CHARBON NE DOIVENT PAS ÊTRE PLACÉS SUR LE BRÛLEUR. Placez les morceaux de charbon devant les bûches de façon réaliste. Prenez garde de ne pas bloquer les orifi...

  • Page 22: Vermiculite

    VERMICULITE Éparpillez la vermiculite autour des braises de charbon de bois. NOTE : La vermiculite ne doit pas être placée sur le brûleur. 33.1 BRAISES INCANDESCENTES Défaites les braises en morceaux, puis placez-les le long de la rangée avant des orifi ces de façon à recouvrir la zone entière du brûleur.

  • Page 23: Rechanges

    MATÉRIELS OU DES BLESSURES CORPORELLES. 41.1 11 9 11 10 11 6 POUR REMPLACEMENT DES PIÈCES DE REFERENT: “BRÛLEUR DE BÛCHES DU HDX52” CES ARTICLES PEUT DIFFÉRER DE CELLE ILLUSTRÉ REF. NO. PART NUMBER DESCRIPTION BÛCHES DE BRÛLEUR , ASSEMBLAGE - GN W010-3821 W010-3858 BÛCHES DE BRÛLEUR , ASSEMBLAGE - PL...

  • Page 24: Brûleur De Bûches Du Hdx52 (Gn)

    W415-1632 / A / 05.02.16...
  • Page 25 W415-1632 / A / 05.02.16...
  • Page 26 5.0 NOTES 44.1 W415-1632 / A / 05.02.16...
  • Page 27 5.0 NOTES 44.1 W415-1632 / A / 05.02.16...
  • Page 28 napoleonproducts.com...
