Summary of Contents for Happy Fabric HappyPress

  • Page 1 HappyPress BEDIENUNGSANLEITUNG OPERATING MANUAL www.happyfabric.de...
  • Page 2 BEDIENUNGSANLEITUNG D - DEUTSCH...
  • Page 3: Wichtige Sicherheitsvorschriften

    Inhaltsverzeichnis Wichtige Sicherheitsvorschriften Wenn du deine Presse benutzt, solltest du immer einige grundlegende Vorkehrun- gen befolgen, einschließlich der folgenden: Lies dir die komplette Bedienungsanleitung druch, bevor du deine Presse in Gebrauch nimmst. Verwende die Presse ausschließlich zum Bedrucken von Textilien oder anderen geeigneten Pro- dukten, die keine wärmeempfindlichen Bestandteile enthalten und nicht mit chemischen Zu- sätzen behandelt wurden.
  • Page 4: Table Of Contents

    Inhaltsverzeichnis Wichtige Sicherheitsvorschriften Detailabbildung Bedienfelderklärung Technische Daten Vorwort Bedienungsanleitung Anschliessen des Stromkabels Inbetriebnahme Temperatureinstellung Drucken / Pressen EG Konformitätserklärung Garantiebedingungen...
  • Page 5: Detailabbildung

    Detailabbildung LED Display Bedienfeld Anschluss Bedienfeld Bedienfeld Kabel Stromanschluss EIN/AUS Schalter www.happyfabric.de...
  • Page 6: Bedienfelderklärung

    Bedienfelderklärung Bedienfeld Digitales Display Temperatur- einstellung Mode-Anzeige Plus (+) Taste Mode Taste Minus (-) Taste Technische Daten Energie Leistung: 700 Watt/230 V Abmessung: Presse ca. 35 cm L x 36 cm B x 20 cm H (ungeöffnet); Bedienteil ca. 20 cm L x 15 cm B x 7 cm Gewicht: ca.
  • Page 7: Vorwort Bedienungsanleitung

    Vorwort Vorwort Bedienungsanleitung Diese Bedienungsanleitung wurde anwenderfreundlich gestaltet. Lies sie sorgfältig und folge der Schritt-für-Schritt Anleitung um die besten Druckergebnisse zu erzielen. Arbeite vorsichtig und vermeide den Kontakt mit der heißen Heizplatte. Diese könnte zu ernsthaften Verbrennungen führen. Halte deine Hände während des Schließvorgangs von der Heizplatte fern., um Quet- schungen und Verbrennungen zu vermeiden.
  • Page 8: Anschliessen Des Stromkabels

    Verwende kein Verlängerungskabel, da es sonst zu einer Überhitzung des Kabels (Brandgefahr) oder zu Spannungsverlusten kommen kann. Der Stecker des Verbindungskabels zwischen Bedienelement und HappyPress hat am äußeren Rand kleine Nasen. Drehe den Stecker so, dass sie über den Aussparungen im Anschluss liegen.
  • Page 9: Temperatureinstellung

    Bedienungsanleitung Temperatureinstellung Drücke den Mode-Knopf an deinem LED-Display. Die (SET)- und (TEMP)-Lämpchen direkt neben dem Display leuchten auf und zeigen dir an, dass du dich jetzt im Temperatureinstell- modus befindest. Mit der Minus-Taste “-” bzw. der Plus-Taste “+” regulierst du die Temperatur nach oben oder unten, bis die gewünschte Temperatur im Display angezeigt wird.
  • Page 10: Drucken / Pressen

    Bedienungsanleitung Drucken / Pressen Wenn deine Presse die eingestellte Temperatur erreicht hat: Platziere das Textil auf der Bodenplatte der Presse. Positioniere das Transfer. Schließ die Presse vollständig mit Hilfe beider Handgriffe. Öffne die Heizplatte nach der gewünschten Zeit. Warnung: Es ist unbedingt notwendig den Deckel der Presse mit Hilfe beider Handgriffe zu senken um ein Umkippen des Gerätes zu vermeiden.
  • Page 11: Eg Konformitätserklärung

    CE-Zertifizierung EG Konformitätserklärung: Im Sinne der EG-Maschinen-Richtlinie 98/37/EU, Anhang II A und der EG Niederspannungs- richtlinie 73/23 EWG, sowie der EG-EMV-Richtlinie 89/336. Wir als europäischer Importeur erklären, dass unser Produkt: Transferpresse zum Aufbügeln von Thermodrucken Fabrikat: Happy Press in der gelieferten Ausführung folgende einschlägigen Bestim- mungen –...
  • Page 12 Garantiebedingungen Kontaktdaten: Adresse: GSE TexPrint Solutions GmbH Telefon: +49 30 897 47 348 Kablower Weg 89 Fax: +49 30897 47 348 12526 Berlin, Germany Web: www.happyfabric.de eMail: kontakt@happyfabric.de Garantiebedingungen Für dieses Gerät leistet die Firma GSE TexPrint Solutions GmbH gegenüber dem Kunden zu den nachstehenden Bedingungen folgende Garantie: Garantiezeit Die Garantiezeit beträgt 2 Jahre und beginnt mit dem Zeitpunkt der Übergabe, der durch die...
  • Page 13: Garantiebedingungen

    Garantiebedingungen Solutions GmbH möglich. Bitte achte darauf, dass deine Transferpresse im Falle einer Rück- sendung im Originalkarton verpackt und mit deinem Absender versehen an uns zurück- geschickt wird. Leg bitte ebenfalls eine kurze Fehlerbeschreibung bei. Schreibe außerdem die Rücksendungsnummer gut sichtbar auf den Versandkarton, den du gegebenenfalls von unserem Servicepersonal gegen eine Gebühr erhälst (falls du den Originalkarton nicht mehr zur Verfügung haben).
  • Page 14 Steht die 232 im Display der HappyPress, möchte die HappyPress dir mitteilen, dass sie keine Temperatur fühlen kann. Das kann zwei Gründe haben: a) Das Kabel ist nicht richtig angeschlossen. Überprüfe den Sitz des Kabels an der HappyPress und stelle sicher, dass es festgedreht ist. Auch wenn der Anschluss auf den ersten Blick symmetrisch aussehen mag, gibt es doch am Außenring kleine Nasen, die in der richtigen...
  • Page 15 Die Stifte/Nasen helfen dabei, den Stecker richtig in die HappyPress einzustecken. The protrusions around the edge help you to plug in the cable correctly. Die Einkerbungen sind passend zu den Stiften am Stecker angeordnet. Somit kann der Stecker nur in einer Position eingesteckt werden.
  • Page 16 OPERATING MANUAL EN - ENGLISH...
  • Page 17: Important Safety Instructions

    Safety Important Safety Instructions Before you use your press, you should follow some basic precautions, including the following: Read the complete manual before you start to use your press. Use the press exclusively for prin- ting textiles, or other suitable products that do not contain heat sensitive components, and have not been treated with chemical additives.
  • Page 18 Contents Important Safety Instructions Detail Picture Panel Technical Specifications Preface to the Manual Connecting the Power Cord Commissioning Temperature Setting Printing/Pressing EC Declaration of Conformity Warranty Terms...
  • Page 19: Detail Picture

    Detail Picture LED Display Panel Control Panel Cable Connection Panel Power Connection On/Off Switch www.happyfabric.de...
  • Page 20: Panel

    Preface to the Manual Panel Digital Display Temperature Setting Mode Setting Plus (+) Button Mode Button Minus (–) Button Technical Specifications Power: 700 Watt/230 V Dimensions: Press ca 35 cm W x 36 cm D x 20 cm H (unopened); Panel ca 20 cm W x 15 cm D x 7 cm H Weight: ca.
  • Page 21: Preface To The Manual

    Preface to the Manual Preface to the Manual This manual has been designed to be user friendly. Read it carefully, and follow the step-by- step instructions, to get the best possible printing results. Work very carefully and avoid contact with the hot plate. This could lead to serious burns. Keep hands away during the closing operation of the heat plate.
  • Page 22: Connecting The Power Cord

    Do NOT use extension cords, as this can lead to overheating of the cable (fire hazard), or to a loss of voltage. The plug of the connecting cable between the control panel and the HappyPress has little nibs on the edge. Turn the plug so the nibs align with the indents in the receptacle. The plug should connect easily.
  • Page 23: Temperature Setting

    User Manual Setting the Temperature Press the mode button on your control panel. The (SET) and (TEMP) lights located next to the display will illuminate indicating you are in the Adjust Temperature Mode. Use the Minus (-) button or the Plus (+) button to lower or raise the temperature until the desi- red temperature appears in the display.
  • Page 24: Printing/Pressing

    User Manual Print/Pressing Once your press has reached the set temperature: Place your fabric on the bottom plate of the press. Position your transfer and close the press completely. Use both handles to push down. Open the machine by lifting the heat plate, after the time you require has passed. Warning: It is strictly necessary to close the press with both handles to avoid any tipping over while...
  • Page 25: Ec Declaration Of Conformity

    EC Declaration of Conformity In relation to the EC Machinery Directive 98/37/EC, Annexe II A and the EC Low Voltage Directive 73/23 EEC and the EC EMC Directive 89/336 We as the European Importer declare that our product: Transfer Press for ironing of thermal printing Make: Happy Press Is delivered matching the latest relevant provisions.
  • Page 26: Warranty Terms

    Warranty Terms Contact Data: Address: GSE TexPrint Solutions UK Ltd Anglia Way Braintree Essex CM7 3RG Web: www.happyfabric.co.uk Email: sales@happyfabric.co.uk Warranty Terms GSE TexPrint Solutions UK Ltd provides the following warranty subject to the following terms: Warranty Period The warranty period is two years and begins from the date of the sale, which will be evidenced by the invoice or similar documents.
  • Page 27 Error Code 232 If the display of your HappyPress is displaying the number 232, your HappyPress is infor- ming you that it can not feel any temperature. There can be two reasons for this error: a) The cable is not sufficiently connected. Make sure your the cable is plugged in securely and screwed tight.
