  • Page 1 v1.1 User manual R599900...
  • Page 2 Changes Cineversum provides this manual ‘as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied warranties or merchantability and fitness for a particular purpose. Cineversum may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1.0  SAFETY INSTRUCTIONS ....................Important Information ........................5 Regional Specific Information......................5 Important Safeguards ........................5 Image projector classification ......................7 2.0  INSTALLATION GUIDELINES ..................Introduction ............................7 THX 4K Display Certification (Blackwing Elite model only) .............8 Environment of Use........................8 Air-Flow and Space Requirements ....................8 Installing the projection screen.......................9 When to use the High Altitude mode .....................9 Ceiling Mounting the Unit ......................9...
  • Page 4 11.1 General Information about 3D playback ..................27 11.2 3D Settings ...........................27 11.3 Operating the 3D Glasses ......................28 12.0  INSTALLATION ........................12.1 Installation Modes ........................29 12.2 Lens Control ..........................29 12.3 Pixel Adjust ..........................29 12.4 Mask .............................30 12.5 Anamorphic ..........................30 12.6 Screen Adjust and Screen No.

  • Page 5: Safety Instructions

    FCC Information (USA only) Changes or modification not approved by Cineversum could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules.
  • Page 6 SAFETY INSTRUCTIONS Please read these Important Safeguards carefully before use. • All the safety and operating instructions should be read before the product is operated. • All warnings on the product and in the operating instructions should be adhered to. •...

  • Page 7: Image Projector Classification

    INSTALLATION GUIDELINES Do not look into the inside of this unit through vents (ventilation holes). Do not stare into the beam. The light is so powerful that your eyesight can be impaired. RG2 from the IEC 62471-5:2015 classification. • Do not drop, hit or damage the light-source lamp (lamp unit) in any way. It may cause the light source lamp to break and lead to injuries.

  • Page 8: Thx 4K Display Certification (Blackwing Elite Model Only)

    INSTALLATION GUIDELINES 2.2  THX 4K Display Certification (Blackwing Elite model only) The THX 4K Display certification proves that the Blackwing Elite has undergone over 400 individual tests to ensure color, tone and images reproduce the director’s intentions accurately in 4k: Amongst the important points, the THX labs have verified upscaling, motion processing, correct gamma and color accuracy, overscan and scaling.

  • Page 9: Installing The Projection Screen

    INSTALLATION GUIDELINES 2.5  Installing the projection screen Install the projection screen and this unit such that they are perpendicular to each other as showed in the picture below. Place this unit perpendicular to the screen. Use the electronic shift and zoom to correct the picture size and position as needed. You can also use the feet to adjust the projected picture level.

  • Page 10: Projection Distance

    • Regardless whether the unit is still under guarantee, Cineversum is not liable for any product damage caused by mounting the unit with third party ceiling mount or when the environment is not suitable for ceiling-mount.
  • Page 11 INSTALLATION GUIDELINES position. Adjust the picture to your screen. • The Vertical Shift level is between -80% and 80% of the Screen Height (0.80 x H). • The Horizontal Shift level is between -34% and 34% of the Screen Base (0.34 x B). •...

  • Page 12: Remote Control Unit (Rcu)

    REMOTE CONTROL UNIT (RCU) 3.0  REMOTE CONTROL UNIT (RCU) Stand by Power [On] Display the Installation Mode menu Switch [INPUT] [LENS CONTROL] Focus, Zoom, Shift [Hide] the current picture Standby/ON LED will flash Displays [Info] menu green when picture is hidden Directional keys Confirm button Display the main [MENU] [BACK] to previous menu...

  • Page 13: Getting Started

    GETTING STARTED 4.0  GETTING STARTED 4.1  General View Front side Operating LEDs Optical Lens (/!\) Front IR receiver Air outlet Air outlets (/!\)Optical Lens: This unit comes with a lens plastic cover that is used to protect the lens during transport. Please remove the lens before first operation.

  • Page 14: Operating And Navigation Buttons

    CONNECTIONS 4.3  Operating and Navigation Buttons Back Rear IR receptor Directional keys and input select INPUT MENU BACK Power button Menu OK button Button Description Back To return to previous menu or cancel action. Directional keys Use the Navigation Keys to navigate into the On Screen Display (OSD) Menu. and input select Up and Down keys may be used to switch Inputs between HDMI1 and HDMI2 when no OSD menu is shown.

  • Page 15: Connecting A Video Source To The Projector

    CONNECTIONS 5.2  Connecting a Video Source to the Projector HDMI 1 HDMI 2 RF Dongle 3D syncro Emitter Audio/Video Connection Device to connect HDMI 1, HDMI 2 HDMI or DVI-D sources: Blu-ray Disc player, DVD-player equipped with an HDMI (DVI compatible) output, Game Console, Computer with DVI-D output.

  • Page 16: First Start Up

    FIRST START Up 6.0  FIRST START UP Always remove the lens cover or lens protection before powering up this unit. To power up this unit, make sure that the power cord is connected to the power input terminal. 6.1  Turn the power ON You can turn ON this unit with the remote control unit (RCU) or directly pressing the power button located on the back panel.

  • Page 17: Menu Structure

    MENU STRUCTURE 7.0  MENU STRUCTURE MAIN MENU SUBMENU AVAILABLE OPTIONS Picture Adjust Picture Modes (Video and drama programs) Natural (4+6 User) (Vivid colors suitable for all movies) Cinema (HDR10 movies, auto tone mapping) HDR10 (HDR movies using Hybrid Log) (Movie films N.A.
  • Page 18 MENU STRUCTURE Picture Adjust Advanced Gamma If Custom 1 or 2, Gamma Corr. Value 1.8 - 2.6 (within 0.1 steps) Cinema 1, Cinema 2 HDR (PQ), HDR (HLG) Import Auto Tone Mapping On, Off Mapping Level -7 +7 Color Selection White / Red / Green / Blue Picture Tone -16 +16...
  • Page 19 MENU STRUCTURE Installation Pixel Adjust Adjust (Pixel) Adjust (Fine) Reset Confirm Mask On, Off Top, Bottom, Left, Right 0 - 220 Anamorphic Off, A, B, C Screen Adjust Screen No. 000 - 255 (Color Profile must be On) On, Off Installation Style Front, Ceiling Mount, Rear, Ceiling Mount (Rear) Keystone (vertical)

  • Page 20: Picture Adjust

    pICTURE ADjUST 8.0  PICTURE ADJUST 8.1  Picture Modes and Color Profiles The preset Picture Modes are available and they can be applied to any input. A picture mode retains the picture adjustments. When adjusting the Picture Mode, you can also select pre-configured Color Profiles. Type of source Movie Dramas...

  • Page 21: Advanced Color Profile

    pICTURE ADjUST Picture Adjust User Name Edit >> Input cursor Select cursor Name User 1 Character list SPACE Clear All Clear Operate Exit MENU Select BACK a) Select the user name you want to edit from User 1 to User 5. Press [OK] to enter the edit mode. b) The input cursor displays the place where the new character will be insert.

  • Page 22: Advanced Color Temperature

    pICTURE ADjUST 8.5  Advanced Color Temperature When selecting a Color temperature, you can manually set the Gains and Offsets of each primary color: red, green and blue to finely adjust the color balance. 8.6  Gamma Gamma is the relationship between the color values of the data and the color values displayed. The Gamma coefficient makes it possible to adjust the brightness of the mid tones only without affecting the very bright and very dark areas.

  • Page 23: Multiple Pixel Control Level (Mpc Level)

    pICTURE ADjUST 8.8  Multiple Pixel Control Level (MPC Level) The MPC Level control gives control over the video processing parameters in order to fine tune the global picture sharpness and quality. 8K E-shift (N.A. with 3D) • On: sets this unit to upscale the content in 8K resolution. •...

  • Page 24: Color

    4K INpUTS 8.12  Color The Color function is used to adjust the saturation levels. Adjust the Color value between -50 and 50. 8.13  Tint The hue function is used to adjust the color tint to obtain true color reproduction. Adjust the Tint value between -50 (more red) and 50 (more green).

  • Page 25: Contents And Their Color Profiles

    4K INpUTS to raise the global brightness or lower its value if the picture is too bright. Tone Mapping or manual HDR10 Gamma Adjustment Depending on the source or the content, this information may be wrong and manual setting is needed to obtain a perfect picture Tweaking for 1000 nits MaxCLL (UHD Bluray standards) •...

  • Page 26: Input Signal

    INpUT SIGNAL 10.0  INPUT SIGNAL 10.1  Input Level Sets the dynamic rang of the video input: • Auto: The input dynamic range is automatically detected and configured. • Standard: Force dynamic range to 16-235. • Enhance: Force dynamic range to 0-255. •...

  • Page 27: Content And 3D Projection

    3D CONTENT AND 3D pROjECTION 11.0  3D CONTENT AND 3D PROJECTION 11.1  General Information about 3D playback Comfort and Caution with 3D Content The closer one looks at stereoscopic images, the greater the binocular disparity, which means greater perception of outward projection. At the same time, the spectator must focus on these outward objects on the screen. The projecting image and the real focus distance cause a great contradiction, this strain contributes to fatigue and discomfort.

  • Page 28: Operating The 3D Glasses

    3D CONTENT AND 3D pROjECTION 3D video inputs limitations When a 3D Signal is input, the following settings are automatically disabled: • Menu => Picture Adjust => MPC e-shift => 8K e-shift interpolation is turn Off (Blackwing Elite only) • Menu =>...

  • Page 29: Installation

    INSTALLATION 12.0  INSTALLATION 12.1  Installation Modes An Installation Mode is a memory slot that collectively manages the setting values of “Lens Control”, “Pixel Adjust”, “Mask”, “Anamorphic”, “Screen Adjust”, “Installation Style”, “Keystone”, “Pincushion” and “Aspect” There are a total of 10 Installation Modes. Mode Select Selects a specific memory amongst the 10 available.

  • Page 30: Mask

    INSTALLATION horizontally and vertically by 1-pixel steps. • H settings: -2 +2 • V settings: -2 +2. Adjust (Fine) Use this function to move the selected color within smaller steps. • H settings: -31 +31 • V settings: -31 +31 Reset Reset all pixel adjustments to default factory settings.

  • Page 31: Screen Adjust And Screen No

    001 - 009: select a profile between 001 and 009 when watching 3D content with 3D shutter glasses. Profile 001 is recommended when using Cineversum’s active 3D glasses. b) 010 to 255: select the best compensation profile depending on your screen and environment.

  • Page 32: Display Setup

    DISpLAY SETUp 13.0  DISPLAY SETUP Back Color Configures the screen color displayed when there is no active input. Set to Blue or Black. Menu Position Upper left, Upper right, Center, Lower right, Lower left. Signal Display On: Display the source of the input signals after input selection. Off: Don’t display. Logo On: Display D-ILA logo during startup for 5 seconds.

  • Page 33: High Altitude Mode

    INFORMATION MENU simultaneously [MENU]+[BACK] buttons on the RCU. All the buttons on the RCU will blink. • Two blinks indicate that the RCU uses code B. • Three blinks indicate that the RCU uses code A. If the Remote Control Unit (RCU) code differs from the projector remote code setting, then the Standby / On LED indicator will blink green when receiving the remote control orders.

  • Page 34: Cinemascope Setups

    CINEMASCOpE SETUpS Calibrator Stores up to 18 ASCII characters set by the Calibrator. Shown only if set during ISF profile adjustment. 16.0  CINEMASCOPE SETUPS The Blackwing Series centralizes the controls and automation commands for a unique, versatile and unexpectedly simple to operate 2.35:1 theatre experience using Lens Zoom or the Static Cinemascope kit.

  • Page 35: Maintenance

    MAINTENANCE Anamo Kit installed Mode B 2.35 screen Mode A 16:9 format 16:9 on 2.35 screen 2.35:1 format 2.35 on 2.35 screen Mode A Mode B When the source switches format..press [Anamo] button to obtain the correct anamorphic mode. 17.0 ...

  • Page 36: Dirt On The Lens

    MAINTENANCE 17.2  Dirt on the Lens The lens shall be cleaned using commercial blowers or lens cleaning papers (for cleaning glasses and cameras). Do not use fluid-type cleaning agents. This may lead to peeling of the surface coating film. The lens surface is fragile.
  • Page 37 MAINTENANCE • Pull out the lamp unit using the handles. • Insert the new lamp unit until it is firmly in place. • Tighten the screws of the lamp unit. • Attach the lamp cover and fasten the lamp trap screw. Resetting Lamp Time • Resetting the Lamp Time during playback After installing a new lamp, reset the lamp time using the OSD menu...

  • Page 38: Blinking Leds And Troubleshooting

    MAINTENANCE 17.4  Blinking LEDs and Troubleshooting WARNING (orange/red LED) LIGHT (orange LED) STANDBY/ON (green/red LED) When the projector is running for more than 1 minute, the Standby/ON LED will automatically switch OFF. Operating LED Description WARNING LIGHT STANDBY/ON (orange/red) (orange) (green or red) Unit is in standby mode.

  • Page 39: Miscellaneous

    MISCELLANEOUS 18.0  MISCELLANEOUS 18.1  RS-232C protocol Serial communication specifications Control of this unit is possible using a computer or automation device connected with a RS-232 cross cable (female - female D-sub 9 pins cable) or LAN/ RJ-45 cable. Communication specifications for this unit are as follows: Baud Rate 19200 bps...
  • Page 40 MISCELLANEOUS Function Command Command Data Description Hide Display 52h 43h 37h 33h 31h 44h Toggle Hide On/Off 37h 33h 44h 30h Switch Hide to On 37h 33h 44h 31h Switch Hide to Off Picture Modes 52h 43h 37h 33h 36h 38h Cinema Mode 37h 33h 36h 39h Film Mode...

  • Page 41: Lan Protocol

    MISCELLANEOUS Examples You want to... Command to send Switch this unit On send: 21h 89h 01h 50h 57h 31h 0Ah receive: 06h 89h 01h 50h 57h 0Ah Switch this unit Off send: 21h 89h 01h 50h 57h 30h 0Ah receive: 06h 89h 01h 50h 57h 0Ah Change active Inpu PJACK t to send: 21h 89h 01h 52h 43h 37h 33h 37h 31h 0Ah HDMI2.

  • Page 42: Infra Red, Long Hex-Pronto Compatible Rcu

    MISCELLANEOUS Examples You want to... Command to send Switch this unit On 1. open TCP connection 2. receive PJ_OK: 50h 4Ah 5Fh 4Fh 4Bh 3. send PJREQ: 50h 4Ah 52h 45h 51h 4. receive PJACK: 50h 4Ah 41h 43h 4Bh 5.

  • Page 43: Specifications

    18.4  Specifications The Blackwing Series uses the latest 4K panels developed to provide the most exciting video-projection experience ever. Model Blackwing One and Blackwing Two Blackwing Elite Emission method LCoS (Reflective Active Matrix Principle) Display panel size 0.69” LCoS 4K panels Display Resolution 4096 x 2160 pixels (D-Cinema 4K format) 8192 x 4320 pixels Contrast ratio...

  • Page 44: Dimensions

    18.5  Dimensions 26 cm 10.1” 2 cm 0.79” 57 cm 54 cm 22.3” 21.3” 57 cm 22.3” 54 cm 21.3” Blackwing One & Blackwing Two Blackwing Elite...
