- Page 1 Del Morino srl , v.Caroni di Sotto 19, I-52033 Caprese Michelangelo AR Italy Ph: +39-575-791059 Fax: +39-575-791210 E.mail: export@del-morino.it http://www.del-morino.it USE AND MAINTENANCE MANUAL LIGHT SLASHER TYPE FUNNY Funny-e-18 Use and maintenance manual : Funny...
-
Page 2: Preface
PREFACE This manual is an integral part of the machine. It must always accompany the machine and be kept within reach of the operator. The enclosures mentioned are on integral part of this manual. The purpose of this manual. This manual gives information for the correct and safe use of the machine. The owner must read this manual carefully before work with the machine. -
Page 3: Description
DESCRIPTION UNCTION OF USE The machine according to the different tools can makes different functions like cut grass, cut up poles exc. The use of a technical constructive concept trended to the search of high performances, reduction of trebles and durability, improves the power/consumption ratio of the tractor thanks to the elasticity of the machine frame, to the tools shape, to the perfect rotor balancing and to many original technical solutions. -
Page 4: Technical Specifications
12-28 9-20 94x60x60 2410 12-28 9-20 94x60x60 2410 12-28 9-20 107x60x60 2410 12-28 9-20 107x60x60 2410 12-28 9-20 120x60x60 2410 FUNNY 12-28 9-20 120x60x60 2410 12-28 9-20 146x60x60 2410 12-28 9-20 146x60x60 2410 12-28 9-20 172x60x60 2410 12-28 9-20 172x60x60... -
Page 5: Safety Informations
SAFETY INFORMATIONS RESCRIZIONI GENERALI Only work in daylight. To prevent damage due to lunch of objects or parts of blades, before to start job be sure that any persons or animals should be in the radius of 50 meters from the machine. ... -
Page 6: Safety Signs On The Machine
SAFETY SIGNS ON THE MACHINE In this section, the safety signs on the machine are reproduced and explained. 1. Read the operator manual. 2. Disconnect the tractor key before maintenance and repair operations. 3. Stay at safety distance from blades when machine is moving. 1. -
Page 7: Instructions For Use
INSTRUCTIONS FOR USE EFORE BEGINNING WORK a) Hook the machine to the tractor, operate as follows : 1. Remove the safety pins from the two lower connection points of the machine. 2. Plug in the raising tractor beams into the lower connection points of the machine and lock with the safety pins. -
Page 8: Maintenance Instructions
MAINTENANCE INSTRUCTIONS On diagram "A" the maintenances are indicated with their terms to effect on the machine. Not follow the scheduled terms can compromise the functionality of the machine and in this case the warranty is not applicable. DIAGRAM “A” SCHEDULED MAINTENANCE FIRST AFTER EACH... -
Page 9: Greasing
1. G REASING At the scheduled time on diagram "A", grease points "B" “C”, “D”,”E”, “F”, “G”. Greasing point is equipped with greaser HYDRAULIC TYPE MODEL "A" UNI 7663. To greasing use only MULTIFUNCTIONAL GREASE LITHIUM BASED Type NLGI 2. IL CHECK - OIL REPLACEMENT IN GEAR BOX At the scheduled time on diagram "A", check or replace oil into gear box. -
Page 10: Tools Replacement
OOLS REPLACEMENT a) To change tools, operate as follow : 1. Unscrew the nut then take out the screw “B”. 2. Take out tools “A” with bushes. 3. Assemble the new tool. 4. Fit the screw “B” then screw the nut. 5. -
Page 11: Problems Solving
PROBLEMS SOLVING TROUBLES GROUNDS AND SOLUTIONS -Not balanced rotor – Enquire a dealer. Abnormal vibrations -Loss of one or more tools – Replace. -Damaged bearings – Replace. -Damaged tools – Replace. Uneven or unsatisfactory cut -Tools choice not good – Change with another type. -
Page 12: Transport
TRANSPORT Except when working, moving the machine takes place when the machine is standing still and the transmission is disconnected. <Important>: keep speed low avoiding holes and ground roughness. <Important>: Before begin the movements always make sure that the safety hooks be in position. <Note when on the road, obey existing traffic laws. -
Page 13: Work And Maintenance Sheet
WORK AND MAINTENANCE SHEET Every user should register on this sheet the facts about the life of the machine (both work and maintenance), so as to attest its conditions. DATE HOURS MAINTENANCE NOTE OPERATOR... - Page 14 SPARE PARTS & OPTIONS...
-
Page 15: Sheets
SHEETS... -
Page 16: Sheets T
SHEETS T... -
Page 17: Mechanisms
MECHANISMS... -
Page 18: Mechanisms T
MECHANISMS T... -
Page 19: Table Of Contents
INDEX PREFACE ................................2 DESCRIPTION ................................ 3 FUNCTION OF USE ............................3 PERFORMANCES ............................... 3 PERFORMANCES LIMIT ............................. 3 STANDARD EQUIPMENTS ..........................3 VARIANTS & OPTIONS ............................3 TECHNICAL SPECIFICATIONS ..........................4 SAFETY INFORMATIONS ............................5 PRESCRIZIONI GENERALI ..........................5 SAFETY RESTRICTIONS ........................... - Page 20 Custode del Fascicolo Tecnico : Dott. A. Del Morino, Via Caroni di Sotto 19, 52033 Caprese Michelangelo Arezzo Italy. Keeper of the technical folder : Dott. A. Del Morino, Via Caroni di Sotto 19, 52033 Caprese Michelangelo Arezzo Italy. Dépositaire du dossier technique: Dott. A. Del Morino, Via Caroni di Sotto 19, 52033 Caprese Michelangelo Arezzo Italy.
