- Page 1 Del Morino srl , v.Caroni di Sotto 19, I-52033 Caprese Michelangelo AR Italy Ph: +39-575-791059 Fax: +39-575-791210 E.mail: export@del-morino.it http://www.del-morino.it USE AND MAINTENANCE MANUAL TS52E SIDE SHIFT FLAIL MOWER (FUNNY TOP 132) FunnyT-EN-R2023.05 Use and maintenance manual: Funny Top...
-
Page 2: Preface
PREFACE This manual is an integral part of the machine. It must always accompany the machine and be kept within reach of the operator. The enclosures mentioned are on integral part of this manual. The purpose of this manual. This manual gives information for the correct and safe use of the machine. The owner must read this manual carefully before work with the machine. -
Page 3: Description
DESCRIPTION UNCTION OF USE The machine according to the different tools can makes different functions like cut grass, cut up poles exc. The use of a technical constructive concept trended to the search of high performances, reduction of trebles and durability, improves the power/consumption ratio of the tractor thanks to the elasticity of the machine frame, to the tools shape, to the perfect rotor balancing and to many original technical solutions. -
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS HARATTERISTICS PER MODEL Dimensions Working Tools Rotor Model Typo Version Power Weight width A x B x H Inch n° g/min 12-28 9-20 94x60x60 2410 12-28 9-20 94x60x60 2410 12-28 9-20 107x60x60 2410 12-28 9-20 107x60x60 2410 12-28 9-20 120x60x60 2410... -
Page 5: Safety Informations
SAFETY INFORMATIONS ENERAL PRESCRIPTIONS Only work in daylight. To prevent damage due to lunch of objects or parts of blades, before to start job be sure that any persons or animals should be in the radius of 50 meters from the machine. Wear long pants and heavy shoes. -
Page 6: Safety Signs On The Machine
SAFETY SIGNS ON THE MACHINE In this section, the safety signs on the machine are reproduced and explained. 1. Read the operator manual. 2. Disconnect the tractor key before maintenance and repair operations. 3. Stay at safety distance from blades when machine is moving. 1. -
Page 7: Cardan Shaft Length Checking
CARDAN SHAFT LENGTH CHECKING 1. After having linked up the machineto the third point, please check it is placed in a horizontal and central position in relation to the tractor using the adjustment devices. 2. Place the PTO shaft between the tractor' PTO and the machine's PTO. 3. - Page 8 HOW TO SHORTEN THE CARDAN SHAFT Figure 1 1. Move the machine as close as possible to the tractor, by using an hydraulic lift. 2. Once in this position, stop the hydraulic lift and switch the engine off. 3. Separate the two parts of the PTO shaft. 4.
-
Page 9: Instructions For Use
INSTRUCTIONS FOR USE EFORE BEGINNING WORK a) Hook the machine to the tractor, operate as follows: 1. Remove the safety pins from the two lower connection points of the machine. 2. Plug in the raising tractor beams into the lower connection points of the machine and lock with the safety pins. -
Page 10: Maintenance Instructions
MAINTENANCE INSTRUCTIONS On diagram "A" the maintenances are indicated with their terms to effect on the machine. Not follow the scheduled terms can compromise the functionality of the machine and in this case the warranty is not applicable. DIAGRAM “A” SCHEDULED MAINTENANCE FIRST AFTER EACH... -
Page 11: Greasing
1. G REASING At the scheduled time on diagram "A", grease points "B" “C”, “D”,”E”, “F”, “G”. Greasing point is equipped with greaser HYDRAULIC TYPE MODEL "A" UNI 7663. To greasing use only MULTIFUNCTIONAL GREASE LITHIUM BASED Type NLGI 2. IL CHECK - OIL REPLACEMENT IN ALUMINUM GEAR BOX At the scheduled time on diagram "A", check or replace oil into gear box. -
Page 12: Oil Check - Oil Replacement In Iron Casting Gear Box
IL CHECK - OIL REPLACEMENT IN IRON CASTING GEAR BOX At the scheduled time on diagram "A", check or replace oil into gear box. To fill oil use only OIL SAE 90. Gear box capacity: 0,8 L a) To check oil level into the gear box, operate as follow: 1. -
Page 13: Tools Replacement
OOLS REPLACEMENT a) To change tools, operate as follow : 1. Unscrew the nut then take out the screw “B”. 2. Take out tools “A” with bushes. 3. Assemble the new tool. 4. Fit the screw “B” then screw the nut. 5. -
Page 14: Quick Hitch Kit Assembly
UICK HITCH KIT ASSEMBLY The machine is shipped with the standard hitch suitable for tractors with category I 3-point hydraulic lift, a "quick hitch kit" is supplied with the machine to make the hitch suitable for tractors equipped with a "Quick Attaching Coupler". - Page 15 Insert the bushing "BI" onto the lower right pin "PI" and then lock it with the spring pin "SE". Repeat step 1 with the left lower pin "PI". Insert the bushing "BS" into the upper connection of the III° point, then insert the pin "PS" and lock it with the safety pin "SS".
-
Page 16: Rear Roller Extension Assembly
7. R EAR ROLLER EXTENSION ASSEMBLY To install the rear roller extension, proceed as follows: Unscrew the bolts "B1" and "B2" on both sides of the machine, then pull out the rear roller "RP". Fit the left extension "PS" and the right extension "PD" to the roller supports using the bolts "B3" supplied with the kit. -
Page 17: Problems Solving
PROBLEMS SOLVING TROUBLES GROUNDS AND SOLUTIONS -Not balanced rotor – Enquire a dealer. Abnormal vibrations -Loss of one or more tools – Replace. -Damaged bearings – Replace. -Damaged tools – Replace. Uneven or unsatisfactory cut -Tools choice not good – Change with another type. -
Page 18: Transport
TRANSPORT Except when working, moving the machine takes place when the machine is standing still and the transmission is disconnected. <Important>: keep speed low avoiding holes and ground roughness. <Important>: Before begin the movements always make sure that the safety hooks be in position. <Note when on the road, obey existing traffic laws. -
Page 19: Work And Maintenance Sheet
WORK AND MAINTENANCE SHEET Every user should register on this sheet the facts about the life of the machine (both work and maintenance), so as to attest its conditions. DATE HOURS MAINTENANCE NOTE OPERATOR... -
Page 20: Table Of Contents
INDEX PREFACE ................................2 DESCRIPTION ................................ 3 FUNCTION OF USE ............................. 3 PERFORMANCES ............................... 3 PERFORMANCES LIMIT ............................. 3 STANDARD EQUIPMENTS ..........................3 VARIANTS & OPTIONS ............................3 TECHNICAL SPECIFICATIONS ..........................4 SAFETY INFORMATIONS ............................5 GENERAL PRESCRIPTIONS ..........................5 SAFETY RESTRICTIONS............................
