- Page 1 USE AND MAINTENANCE MANUAL SLASHER WITH HORIZONTAL AXLE TYPE FLIPPER FLIPPER-EN-R2024.01 – USE AND MAINTENANCE MANUAL...
-
Page 3: Table Of Contents
SAFETY RESTRICTIONS ............................10 SAFETY LABELS ON THE IMPLEMENT ..................11 BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME ............12 SHIFTING HITCH ASSEMBLY ..........................12 FLIPPER 106-186 ...........................12 FLIPPER 214 ............................14 a) SCREW SHIFTING .........................15 b) HYDRAULIC SHIFTING ......................17 QUICK HITCH KIT ASSEMBLY FOR FIXED HITCH (IF REQUIRED) ................19 QUICK HITCH KIT ASSEMBLY FOR SHIFTING HITCH (IF REQUIRED) ..............21... -
Page 4: Preface
Caroni di Sotto, 19 - I-52033 Caprese Michelangelo AR Italy Phone: +39-575-791059 - Fax: +39-575-791210 Website: http://www.delmorino.it – e-mail: export@delmorino.it All rights reserved Printed in Italy DEL MORINO thanks you for choosing us and for your confidence in the quality of our implements. - Page 5 PREFACE This manual is an integral part of the implement It must always come with the implement and be at user’s disposal. All attachments are integral part of the manual. The purpose of this manual This manual provides information for the correct and safe use of the implement. The owner must read this manual carefully before working with the implement.
-
Page 6: Description
DESCRIPTION DESCRIPTION FIELD OF USE The implement according to the different flails can makes different functions like cut grass, cut up poles exc. The use of a technical constructive concept trended to the search of high performances, reduction of trebles and durability, improves the power/consumption ratio of the tractor thanks to the elasticity of the implement frame, to the flails shape, to the perfect rotor balancing and to many original technical solutions. -
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS... -
Page 8: Specifications Per Model
TECHNICAL FEATURES SPECIFICATIONS PER MODEL Roto Tip Speed Dimensions Versio Working Flails Model Power* Weight width A x B x H n° n° 29-4 38x32x2 22-32 94x60x60 2410 29-4 120x60x6 48x32x2 22-32 2410 29-4 133x60x6 58x32x2 22-32 2410 FLIPPE 29-4 133x60x6 68x32x2 22-32... - Page 9 TECHNICAL SPECIFICATIONS 3C = 3 blade flails (Y blade flails + I short blade flail) M = Hammer flail S= Scarifying flail (Y blade flails + I long blade flail)
-
Page 10: Safety Information
SAFETY INFORMATIONS SAFETY INFORMATION GENERAL REQUIREMENTS CAUTION: to prevent injury due to objects or parts of the flails thrown by the implement, be sure that no persons or animals are within a radius of 50 meters (164 ft) of the implement before starting to work. -
Page 11: Safety Labels On The Implement
SAFETY LABELS ON THE IMPLEMENT SAFETY LABELS ON THE IMPLEMENT In this section, the safety labels of the implement are reproduced and explained. Fig. 1 Legend 1. Read the manual. 2. Remove the key from the ignition of the tractor before performing maintenance or repairs. 3. -
Page 12: Before Operating The Implement For The First Time
IMPORTANT: In order to avoid any damage to the third-point of the hydraulic side shifting, before to operate the hydraulic translator, it is MANDATORY to lift the machine from the ground. FLIPPER 106-186 The following instructions are valid for the assembly of both the hydraulic shifting kit and the screw shifting kit. - Page 13 BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME Hydraulic shifting kit Screw shifting kit 4. Assemble the kit “K” using the four bolts “B3” to fix the kit on top of the gearbox and the four bolts “B4” to fix the kit to the frame of the implement. All the mentioned bolts are provided with the kit. NOTE: for 132, 158, 186 models be careful to put the spacer “S”...
-
Page 14: Flipper 214
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME FLIPPER 214 1. Remove the four bolts “B1”, 2. Remove the locking plate “F”, 3. Remove the cotter pin “C” and the two spacer “S”, ONLY FOR SCREW SHIFTING → Remove the two bolts “B2”,... -
Page 15: A) Screw Shifting
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME a) SCREW SHIFTING 4a. Screw the bracket with threaded hole “M” on the screw “V” on the opposite side of the hole "H" about 4 inches apart. Screw one nut "D" onto the screw "V" about 4 inches from the side with the hole "H", lock it in position with another nut “D”... - Page 16 BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME 7a. Insert the crank into the screw in position “1” and rotate it to move the three-point hitch to the desired position. Tighten all the nuts. 8a. Remove the crank and secure it to the three-point hitch in position “2” by using the wingnut “DA” to prevent losing it during work.
-
Page 17: B) Hydraulic Shifting
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME b) HYDRAULIC SHIFTING 4b. Mount the bracket “SCP” and the mechanical stop “SC” onto the tube “T” using the two bolts “B3”, 5b. Mount the hydraulic piston “P” onto the bracket at the bottom end of the cylinder. Insert the end of the rod into the pin of the three-point hitch. - Page 18 BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME 6b. Lock the hydraulic piston in position using the two cotter pin “C”. Hydraulic Shifting Kit Assembled...
-
Page 19: Quick Hitch Kit Assembly For Fixed Hitch (If Required)
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME QUICK HITCH KIT ASSEMBLY FOR FIXED HITCH (IF REQUIRED) The implement is shipped with a standard Category I and II hitch suitable for tractors with a standard 3-point hitch. A Category I “Quick Hitch Kit” is supplied with the implement to make the hitch suitable for tractors equipped with a Category I Quick-Hitch. - Page 20 BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME 1. Insert the bushing "BI" onto the lower right pin "PI" and then lock it with the spring pin "SE". 2. Repeat step 1 with the left lower pin "PI". 3. Insert the bushing "BS" into the III-point hitch, then insert the bolt "BU" and tighten the nut. Quick Hitch Compatible for Fixed Attachment...
-
Page 21: Quick Hitch Kit Assembly For Shifting Hitch (If Required)
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME QUICK HITCH KIT ASSEMBLY FOR SHIFTING HITCH (IF REQUIRED) The implement is shipped with a standard Category I and II hitch suitable for tractors with a standard 3-point hitch. A Category I “Quick Hitch Kit” is supplied with the implement to make the hitch suitable for tractors equipped with a Category I Quick-Hitch. - Page 22 BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME 1. Fit the two lower pins "PBN, tighten the nuts securely. 2. Insert the bushing "BSN" in the iii-point hitch, insert the pin "PS" and lock it with the safety pin "SS". Quick Hitch Compatible for Shifting Attachment...
-
Page 23: Change The Cutting Height
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME CHANGE THE CUTTING HEIGHT Adjust the position of the Rear Roller Extension to achieve the desired cutting height as follows: CUTTING HEIGHT “H” * ASSEMBLY COMBINATION [mm] [in] * All heights are referenced to the implement in the horizontal position... -
Page 24: Check The Length Of The Pto Shaft
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME CHECK THE LENGTH OF THE PTO SHAFT Fig. 4 1. Connect the implement to the 3-point hitch and adjust it so that it is level and centered on the tractor. 2. Insert the PTO shaft between the PTO of the tractor and the implement. 3. -
Page 25: How To Shorten The Pto Shaft
BEFORE OPERATING THE IMPLEMENT FOR THE FIRST TIME HOW TO SHORTEN THE PTO SHAFT Fig. 5 1. Lift the implement to bring it as close as possible to the tractor. 2. In this position, block the lift arms and turn off the engine. 3. -
Page 26: Instructions For Use
INSTRUCTIONS FOR USE INSTRUCTIONS FOR USE BEFORE STARTING TO WORK a) Connect the implement to the tractor as follows: 1. Remove the safety pins from the two lower connection points of the implement. 2. Insert the lower connection points of the implement into the lower arms of the tractor hitch and lock with the safety pins. -
Page 27: Maintenance Instructions
MAINTENANCE INSTRUCTIONS MAINTENANCE INSTRUCTIONS Maintenance operations and their corresponding intervals are listed in sheet “A”. Not following the schedule maintenance intervals jeopardizes the proper functioning of the implement, thus voiding the guarantee. SHEET “A” - SCHEDULED MAINTENANCE BEGINNIN END OF THE END OF FIRST USE AFTER 10 H. -
Page 28: Greasing
MAINTENANCE INSTRUCTIONS 1. GREASING Grease the points "B", “C”, “D”,”E”, “F”, and “G” (refer to Fig.8). Greasing points are equipped with a HYDRAULIC GREASER MODEL “A” UNI 7663. Use only MULTIFUNCTIONAL LITHIUM-BASED OIL TYPE NLGI 2. Fig. 8 2. OIL LEVEL - OIL CHANGE At the times indicated in sheet “A”, check the level or and top up or replace the oil in the gearbox. -
Page 29: Flails Replacement
4. Fit the screw “B” then tighten the nut. 5. ATTENTION: all flails must be of the same type, size and weight. 6. ATTENTION: changing type of flail is possible using original Del Morino flails. If other flails are used the rotor may have to be balanced. -
Page 30: Adjustment And Replacement Of The Transmission Belts
MAINTENANCE INSTRUCTIONS 4. ADJUSTMENT AND REPLACEMENT OF THE TRANSMISSION BELTS a) To adjust the tension of the transmission belts (refer to Fig 12a and Fig 12b): 1. Remove belt cover “A” by unscrewing the eight screws “B”. 2. Loosen the lock nut “C” of the belt tensioner and screw/unscrew the nut “D” to increase or decrease the tension of the belts. -
Page 31: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING MALFUNCTION POSSIBLE CAUSE SOLUTION 1) Unbalanced rotor. 1) Contact the dealer. 2) Loss or breakage of one or more Abnormal vibrations 2) Replace missing flails. flails. 3) Replace worn out bearings. 3) Worn out bearings. 1) Worn out flails. 1) Replace worn out flails. -
Page 32: Various Information
VARIOUS INFORMATION VARIOUS INFORMATION TRANSPORT Outside its normal field of use, the PTO must be disengaged when transporting the implement. IMPORTANT: proceed at moderate speed avoiding holes and rough surfaces. NOTE: on public road, abide by the traffic laws. Attach warning labels to the rear and side of the implement indicating the contour of the implement. -
Page 33: Work And Maintenance Record
WORK AND MAINTENANCE SHEET WORK AND MAINTENANCE RECORD Every user should register the facts about the history of the implement (both operation and maintenance) on this sheet, to verify its condition. HOURS OF DATE MAINTENANCE NOTES OPERATOR OPERATION... -
Page 34: Notes
NOTES NOTES... - Page 35 Déclaration CE de conformité conforme à la Directive Machine 2006/42/CE Eg konformitätserklärung im Sinne der Eg Vorschrift Maschine 2006/42/CE Declaración CE de conformidad según la Directiva Máquinas 2006/42/CE DEL MORINO S.R.L. - Via Caroni di Sotto, 19 - - CAP 52033 - CAPRESE MICHELANGELO - AR, ITALY - Dichiara sotto la propria responsabilità...
- Page 36 NOTES Matr. n°: Caprese Michelangelo, __________________________ ___________________________ Custode del Fascicolo Tecnico-Keeper of the technical folder-Dépositaire du dossier technique-Verwalter der technischen Unterlagen–Responsable documentación técnica Dott. A. Del Morino, Via Caroni di Sotto, 19, Cap 52033 - Caprese Michelangelo - AR, Italy...
