- Page 1 SMART PICKER SERIES acusto-optical modulators Manual...
-
Page 2: Introduction
Dissemination and copying of this manual are allowed on special request only. All rights reserved for the case of patent or registered-design application. More information is available at the manufacturer http://www.lacosys.com/ or at the responsible distributor. Manufacturers address: LaCoSys GmbH Hans-Knöll-Straße 6... - Page 3 Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017...
-
Page 4: Table Of Contents
Software description ......................13 Maintenance information ....................... 17 Warranty ..........................17 Maintenance .......................... 17 Service ........................... 17 Transport ..........................18 Disposal ..........................18 Technical Data ........................19 General data .......................... 19 Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017... -
Page 5: Safety Information
This symbol marks a danger for the device. ATTENTION Laser-radiation may be emitted! ATTENTION Electrostatic delicate components. ATTENTION Please use appropriate safety precautions against electrostatic discharge (safety pack, antistatic wristband etc.) Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017... -
Page 6: Electric Safety / Personnel Protection Insulation
Electrostatic charges on persons and objects may cause voltages up to 4000 V. They can discharge invisible. To prevent aging or damage it is important to use precautions against electrical charging. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017... -
Page 7: Laser Safety / Labeling
Please store the manual near to the device and accessible for all users. Furthermore, please take care that all necessary documents like laser safety regulations or country- specific safety regulations are present. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017... -
Page 8: Description Of The System
POWER LED PHOTODIODE MONITOR SMA(f) AOM-TTL OUT SMA(f) AOM-TTL MONITOR OUT SMA(f) GATE-TTL INPUT PHOTODIODE FC Fig. 3 Rear panel AOM INTERFACE – SUB-D15 (f) 4 On/Off Switch USB-Connection 24VDC Input Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017... -
Page 9: General
The AOM-output is optimized for an output impedance of 50 Ω. For other output impedance values the voltages are not correct. 3.3 AOM-MONITOR (OUTPUT) Output Connector: SMA(f) Voltage: (square wave) Current: ± 100 mA < 1.5 ns Rise Fall Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017... -
Page 10: Gate-Input
The counter will be set back and counts again following the next Trigger input pulses. 3.6 PHOTODIODE MONITOR OUTPUT Output Connector: SMA(f) Voltage: Pulses < 2Vpp Current: ± 100 mA < 1.5 ns Rise Fall Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -10-... -
Page 11: Mains
The AOM interface provide an easy connection for example RF-Driver from manufacturer AA http://www.aaoptoelectronic.com/Documents/MODAxx-MODAGxx-2014.pdf. Here we advise to use the TTL-Version. The AOM-Interface output is optimized for 24V-DC Drivers. Shortening the output may lead to irreparable device damage. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -11-... -
Page 12: Use Of The Device
A possible set-up of the SmartPicker AOM with a AOM-Driver and modulator is depicted in Fig. 4. Your set-up may differ from this. The oscilloscope can used on monitor ports for the visibility of the electrical pulses for modulator control. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -12-... -
Page 13: Installation Of Software Drivers
4.4 Installation of LabView SmartControl AOM The SmartPicker is controlled by SmartControl AOM Software. For installation please start the setup.exe on delivered USB-Stick and follow the instructions. 4.5 Software description Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -13-... - Page 14 Attention, Delay must be smaller than output period time ���������� ������������������ −1 ���������� < ( �������������� Attention, Pulse width must be smaller than output period time ���������� ������������������ −1 ���������� ��������ℎ < ( �������������� Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -14-...
- Page 15 In this section you can use the additional Level Check to ensure signal quality and power at optical input port. When activated the AOM Output and monitor Port is blocked in any case of limit error. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -15-...
- Page 16 LIMITS- ON /OFF ... turn on off the level check Photovoltage: This chart shows the actual peak value of the optical input. Info Section: Here you find information to Type, Serial an Product IDS CLOSE: Stop the Program. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -16-...
-
Page 17: Maintenance Information
The warranty expires in this case. LaCoSys declines any liability for damages which are due to disregard of the safety information. 5.2 Maintenance... -
Page 18: Transport
5.5 Disposal Defect devices must be disposed according the legal rules. Do not put it into the domestic waste. The device manufacturer is obligated by law to withdraw defect devices. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -18-... -
Page 19: Technical Data
99 % (non-condensing) Storage: Vertical height of use: Operation: 3000 m Storage: 12000 m Installation position Horizontal Please visit our website www.lacosys.com . You will find more information about further models. Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -19-... - Page 20 For your notices: Manual SmartPicker AOM Rev. A ENG LaCoSys Nov 2017 -20-...
