HSM2HOST 2-Way Wireless Transceiver
V1.0 Installation Manual
WARNING: This manual contains information on limitations regarding product use and func-
tion and information on the limitations as to liability of the manufacturer. The entire manual
should be carefully read.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSM2HOST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC HSM2HOST

Summary of Contents for DSC HSM2HOST

  • Page 1 HSM2HOST 2-Way Wireless Transceiver V1.0 Installation Manual WARNING: This manual contains information on limitations regarding product use and func- tion and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.

  • Page 2: Specifications And Features

    ** Available in North America, South America and New Zealand only. *** For Residential Fire installations, two PG9920 must be used. Note: This manual covers models HSM2HOST9 (UL/ULC listed), HSM2HOST4 and HSM2HOST8. The reference to HSM2HOST in this manual covers all three variants unless stated differently.

  • Page 3: Safety Instructions

    Safety Instructions • This equipment must be installed by Service Persons only (service person is defined as a person having the appropriate technical training and experience necessary to be aware of hazards to which that person may be exposed in performing a task and of measures to minimize the risks to that person or other persons).

  • Page 4: Installation Process Overview

    On steady when location is bad. Off when location is good. Tamper The HSM2HOST has separate built-in wall and case tampers. The tampers are disabled by default on the NA version (enabled on EU version). Section [804][510] option 3 enables or disables the tampers.

  • Page 5: Setup & Wiring

    HSM2HOST. To enroll the HSM2HOST: Once the HSM2HOST is wired to the alarm panel and power has been applied, power up a wireless keypad. Press any button on the keypad to enroll it on the HSM2HOST. The HSM2HOST is...
  • Page 6 The HSM2HOST performs best in locations where RF interference is minimal. To find a suitable mounting location: • With the alarm panel powered up and the HSM2HOST enrolled, observe the status of the green LED. If the LED is on, interference levels are high and a new mounting location should be found.

  • Page 7: Other Options

    Press [#] to label another module or [#][#] to exit. 2.4.4 [804] Enroll Wireless Devices Once the HSM2HOST is installed and enrolled on the alarm panel, wireless devices can be enrolled using one of the following methods: Auto enroll (use to enroll devices during installation): Enter the following Installer Programming section: [804] (Wireless Programming) >...
  • Page 8 The alarm panel determines the type of device being enrolled and presents the appro- priate programming options. Table 2-2 Wireless Device Options Device Type Programming Options Zone (01) Zone type (02) Partition assignment (03) Zone label Wireless key (01) User label Siren (01) Partition assignment (02) Siren label...
  • Page 9 Press [*] to delete or [#] to exit. 2.5 Wireless Device Programming The following wireless device programming options are available through section [804]. 2.5.1 [201]-[204] Modify Wireless Device Setup Options To modify wireless device setup options: Enter Installer Programming section [804] (Wireless Programming) then navigate to one of the following sub-sections using the scroll keys or by entering a hotkey: Table 2-4 Modify Wireless Device Sub-Sections Sub-Section...
  • Page 10 2.5.3 [401]-[410] Wireless Device Defaults Wireless device default parameters used during enrollment can be changed at any time. Once default values are changed, any new devices enrolled inherit the modified default values. The defaults of devices already enrolled are not changed. To modify wireless device defaults: Enter [*]>[8]>[804](Wireless Programming) then navigate to one of the following sub-sections using the scroll keys or by entering a hotkey:...
  • Page 11 NOTE: For EN installations, 1 hour or 2 hours must be selected. To program the Wireless Supervisory Window: Enter Installer Programming section [804] (Wireless Programming)>[502] (Wireless Supervisory Window). Select one of the following options by scrolling or entering the hotkey: Table 2-7 Wireless Supervisory Window Options Enabled/Disabled After 1 Hour...
  • Page 12 Test wireless keys Test individual wireless keys. Once in this section, press a button on the wireless key to begin the test. Test sirens Test each enrolled wireless siren. Test repeaters Test each enrolled wireless repeater. Two test results are provided: •...

  • Page 13: 999] Reset To Factory Defaults

    2.5.10 [997] View Module Information This section is used to display the model, hardware revision and software version of the HSM2HOST. 2.5.11 [999] Reset to Factory Defaults Selecting this option resets all module programming to factory settings. Panel and other...

  • Page 14: Programming Worksheets

    Zone Expander Labels (1 x 14 Characters) 001: 009: 002: 010: 003: 011: 004: 012: 005: 013: 006: 014: 007: 015: 008: 016: Output Expander Labels (1 x 14 Characters) HSM2HOST Label (1 x 14 Characters) HSM2955 Audio Verification Label (1 x 14 Characters)
  • Page 15 HSM2300 Power Supply Label (1 x 14 Characters) Siren Label (1 x 14 Characters) Repeater Label (1 x 14 Characters) [802] Audio Programming (See HSM2955 Installation Manual) [804] Wireless Programming Enroll Wireless Device 01 - Zone 02 - Wireless Key 03 - Siren 04 - Repeater Delete Devices...
  • Page 16  Image Bright -1  Image Bright 0  Image Bright +1  Image Bright +2  Image Bright +3 Image Contrast:  Image Contrast -3  Image Contrast -2  Image Contrast -1  Image Contrast 0  Image Contrast +1 ...
  • Page 17 Wireless Key Available programming options: 00- Disabled 20- Comm. Output 4 01- Stay Arm 27- Bypass Mode 02- Away Arm 28- Bypass Recall 03- [*][9] No Entry 29- Bypass Group Recall 04- Instant Stay Arm 30- Quick Bypass 05- Night Arm 32- Chime On/Off 07- Disarm 33- System Test...
  • Page 18  Microphone  AC Power Disarm Activity:  Not Active  Yes-No Delay  Yes-5 Second Delay  Yes-15 Second Delay  Yes-30 Second Delay  Yes-1 Minute Delay  Yes-10 Minute Delay  Yes-60 Minute Delay Image Brightness:  Image Bright -3 ...
  • Page 19   Cold  Very Cold  Freezing  Freezer Set Wireless Key Default (See section 521 for options) Set Siren Default Device Toggles  Auto Tmp Alarm  AC Power  Smash Alarm Strobe Alarm  Disabled  Timer Limited ...
  • Page 20  Always View Time Window  Alarm + 5 Minutes  Alarm + 15 Minutes  Alarm + 1 Hour View Other Alarm  Fire  Duress  Medical  Panic Module Information Model Name Software Version Hardware Version Default HSM2HOST...
  • Page 21 Keypad Programming Keypad Partition Mask  Global Keypad  Partition Function Key Programming: 01 - Null Key 16 - Local PGM Active 32 - Chime On/Off 02 - Stay Arm 17 - Command Output 1 33 - System Test 03 - No Entry Arm 18 - Command Output 2 34 - User Programming 04 - Instant Stay Arm...
  • Page 22 481 - Audio Verification 101 - 8-Zone Expander 491 - Alternate Comm. 201 - Output Expander 501 - Power Supply 461 - HSM2Host 521 - High-Current Output Installer Walktest Zone Soak Test 000 - Soak Test Duration (001-255 Days): 001/0128 - Zone 1-128 soak test...

  • Page 23: Appendix 1: Wireless Device

    Appendix 1: Wireless Device C o n f i g u r a t i o n O p t i o n s [*]>[8]>[804]Wireless Programming>[201]-[204] Device Toggles Sub- Section Option 1 Option 2 Device Type Section (201) (001) Contacts (01) Alarm LED Modify (Toggles)
  • Page 24 Sub- Section Option 1 Option 2 Device Type Section (009) (010) Flood (01) Alarm LED (011) Temperature (01) Alarm LED (02) Temperature °C (03) Very Hot (04) Hot (05) Cold (06) Very Cold (07) Freezing (08) Freezer (202) (001) Wireless Siren (01) Device Toggles (01) Auto Tmp Alarm Modify...
  • Page 25 Warning Please Read Carefully Note to Installers This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warning to the attention of the users of this system. System Failures This system has been carefully designed to be as effective as possible.
  • Page 26 EULA, even if this EULA is deemed to be a modification of any previous arrangement or contract. If You do not agree to the terms of this EULA, DSC is unwilling to license the SOFTWARE PRODUCT to You, and You have no right to use it.
  • Page 27 The Customer assumes all responsibility for the proper selection, installa- tion, operation and maintenance of any products purchased from DSC. Custom products are only warranted to the extent that they do not func- tion upon delivery.
  • Page 28 © 2012 Tyco International Ltd. e suas Respectivas Empresas. Todos os Direitos Reservados. © 2012 Tyco International Ltd. and its Respective Companies. All Rights Reserved. Toronto, Canada • www.dsc.com Tech. Support/Centre d’aide technique/Líneas Tech: 1-800-387-3630 (Canada, US), 905-760-3000 Printed in Canada / Imprimé au Canada / Impreso en Canadá / Impresso no Canadá...
