FIG. 3 - PLUS91SE DEVICE - G800A69
KEY
1 – Rotary bead depressing unit
2 – Control unit
3 – Pneumatic cylinder
4 – Pressing roll - bead lifting
5 – Entrainer G1000A98 (if required)
6 – Lifting device (G800A69 if required)
FIG. 4 - PLUS91SA DEVICE - G800A69
KEY
1 – Rotary bead depressing unit
2 – Control unit
3 – Pneumatic cylinder
4 – Pressing roll - bead lifting
5 – Entrainer G1000A98 (if required)
6 – Lifting device (G800A69 if required)
ASSEMBLING AND USE
INSTRUCTIONS
7700-M002-3
Page 4 of 22

PLUS91S - PLUS91N

PLUS91SE - PLUS91SA - G800A69
GB
