1 - After the wheel has been placed onto the lifting de-
vice (Fig. 18 pos. 1), lift the control unit lever (Fig.
18 pos. 2) and move the wheel upwards, until it can
be placed onto the mandrel (use a hand to follow its
movement) (see Fig. 19).
Fig. 18
Fig. 19
ASSEMBLING AND USE
INSTRUCTIONS
2 - Position the wheel on the chuck.
3 - Lower the control unit lever in order to lower the lift-
4 - Carry out all the tyre assembly and disassembly op-
5 - To raise the lifting device, lift the control unit lever
6 - Place the wheel onto the lifting device.
7 - Lower again the control unit lever (Fig. 20 pos. 1) in
ing device.
eration, loose the chuck wheel.
again.
order to let the lifting device move down (use a hand
to follow its descent) (see Fig. 20).
Fig. 20
KEEP A HAND ON THE WHEEL
DURING ALL LIFT RISING AND
DESCENT PHASES TO ENSURE
THAT THE WHEEL CANNOT
FALL FROM THE LIFTING DE-
VICE DUE TO IMBALANCES.
