Summary of Contents for Alcolock V3
- Page 1 SERIES B-2 12V & 24V ECU Installation Manual...
- Page 2 2. The devices must be installed in such a manner that all applicable technical rules, and also observing other technical directives and regulations, for the vehicles to be modified still apply. The ALCOLOCK V3 alcohol interlock can be installed in all 12V & 24V vehicles. NOTE: Open vehicles excluded.
- Page 3 • Round mouthpieces (bag of 25) (95-000250) Also: wire strippers, soldering iron, heat gun, multimeter, screwdriver. To order replacement parts, consult the preceding list. INSPECTION Before the ALCOLOCK V3 device is installed, an inspection of the vehicle’s electrical system is required. Check: • Battery voltage •...
- Page 4 Using the wire strippers, expose a 2 cm section of the wire. Twist the exposed end of the white wire in the wiring harness to the exposed section of the source wire. ALCOLOCK V3 SERIES B-2...
- Page 5 ACTIVATION All ALCOLOCK V3 devices are shipped in pre-delivery mode, which does not require a breath test in order to start the vehicle engine. Prior to testing, the ALCOLOCK V3 device must be activated. Enter the following code to activate: 2,1,3,2.
- Page 6 DISPOSAL AT END OF SERVICE LIFE To dispose of the ALCOLOCK V3 device (ECU, handset, or both) when it is deemed to be at the end of its service life: • Return the device to the dealer for disposal •...
- Page 7 INSTRUCTION MANUAL...
- Page 8 INM-ENG-60-000310-C © 2012-2013...
