Michell Instruments Easidew User Manual page 32

APPENDIX D
78 004E R/W
Register confi guration in 1 decimal place precision mode
Dec Hex Access
1 0001 R
2 0002 R
Register configuration in 4 decimal place precision mode
Dec Hex Access
1 0001 R
2 0002 R
7 0007 R
26
special Natural Gas Configuration &
Precision Select
Data Description
Type
int16 Humidity Parameter
int16 Ambient Temperature
Data Description
Type
special Humidity Parameter (Low
Word)
special Humidity Parameter (High
Word)
int16 Ambient Temperature
Easidew Transmitter User's Manual
Natural gas configuration
bit1, 0=IGT, 1=ISO
bit2, lb/MMscf
bit3, ppmV NG
bit4, mg/m
Precision Select
bit15, 0=1 Decimal Place,
1=4 Decimal Places
Default dew-point, selected
with register 4 (and 78 for
Natural gas)
10x multiplier, i.e. -811 = -81.1
10x multiplier, i.e. 214 = 21.4
Default dew-point, selected
with register 4 (and 78 for
Natural gas)
1000x multiplier,
i.e. 14321 = 1.4321
10x multiplier, i.e. 214 = 21.4
NG
3
Comment
Comment
97504
Issue 2, May 2018
