TECHNICAL PARAMETERS
Key button
Shackle
Bypass switch
Sound module
Measured variable
Acceleration
internal
Acceleration
external
Acceleration
external 3D ICP®
Temperature
Relative Humidity
Analogue Input
Digital Input
3x green (power, active, memory)
1x "control" to display the operating state via LEDs
magnetic on/off-switch
toggle switch to bypass the safety bar (permanently switched on)
Device sensors
Measuring range
2, 5, 10, 20, 50,
100, 200 g, discrete
configurable
100, 200, 500,
1000, 2000 pC
50, 100, 250, 500,
1000 mV
-40...+120 °C
(depends on the
model)
0...100 %rh
0...2.5 V
4 channels with
respectively high/low
- 6 -
Only for EnDaL vi
Tolerance
±2 % of measuring
range
thereof 10 or 20 with
±5 % of measuring waveform (depending
value
±1 K
±2 %rh at
20...80 %rh
±0.1 %
Low: 0...0.8 V
High: 2.4...12 V
EnDaL curve/vi
Data storage
16384
on curve duration)
16384
4096
