Motherboard Features

CPU
•
Intel® Atom SoC C3858/C3850 FCBGA1310 Processor
Memory
•
Up to 64GB DDR4 ECC/Non-ECC Unbuffered SO-DIMM, two DPC (DIMM Per Channel) up to 2400MT/s
DIMM Size
•
Up to 16GB at 1.2V
Expansion Slots
•
One (1) PCI Express 3.0 x4
•
One (1) Mini PCI Express x1
•
One M.2 3.0 x4
Network
•
Intel i350-AM4 Base-T NIC
•
Intel X557-AT2 Base-T PHY
•
CS4227 SFP+ PHY
BaseBoard Management Controller (BMC)
•
ASpeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0
•
One (1) Dedicated IPMI LAN port located on the rear IO back panel
Graphics
•
Graphics controller via ASpeed 2400 BMC
I/O Devices
•
Serial (COM) Port
•
SATA 3.0 Ports
Peripheral Devices
•
Two (2) USB 3.0 ports on the rear I/O panel (USB0/1)
•
Two (2) internal USB 2.0 headers with two (2) USB connections each for front access (USB2/3, USB4/5)
BIOS
•
128 Mb SPI AMI BIOS
®
•
ACPI 4.0, USB keyboard, Plug-and-Play (PnP), SPI quad speed support, Riser card auto detection support, RTC (Real
Time Clock) wakeup, Dual Boot Block support, and SMBIOS 2.7
Note: The table above is continued on the next page.
Motherboard Features
•
One (1) serial header
•
Four (4) SATA 3.0 ports (I-SAT0 ~ I-SATA3) I-SATA0 is SuperDOM
SM Flash UEFI BIOS
