A2SDi-TP8F/LN4F User's Manual
Connector
JSD1
JSMB1
JTGLED1
JTGLED2
JTPM1
LAN1 ~ LAN8
SLOT7
SRW1, SRW3, SRW4
UID
USB0/1
USB2/3, USB4/5
VGA
Description
SATA DOM Power Connector
PCH SMBus Header
LAN5/LAN6 Acitivity LED Header
LAN7/LAN8 Acitivity LED Header
Trusted Platform Module/Port 80 Connector
LAN1 - LAN4: GbE LAN (RJ45) Ports
LAN5 - LAN6: 10GBaseT LAN (RJ45) Ports
LAN7 - LAN8: 10G LAN (SFP+) Ports
(LAN5 - LAN8 not available on A2SDi-LN4F)
CPU PCI-E 3.0 x4 Slot
M.2 Holding Screws
Unit ID Button
Back panel Universal Serial Bus (USB) 3.0 Ports
Front Accessible USB 2.0 Headers
VGA Port
