TTW Air Conditioner
Models
26TTW09AC115V1A 26TTW09HP115V1A
26TTW12AC115V1A 26TTW09AC230V1A
26TTW09HC230V1A 26TTW07HP230V1A
26TTW09HP230V1A 26TTW12AC230V1A
26TTW12HC230V1A 26TTW12HP230V1A
Thank you for choosing our product.
For proper operation, please read and keep this manual carefully.

Advertisement

Table of Contents
loading

Summary of Contents for Gree 26TTW09AC115V1A

  • Page 1 TTW Air Conditioner Models 26TTW09AC115V1A 26TTW09HP115V1A 26TTW12AC115V1A 26TTW09AC230V1A 26TTW09HC230V1A 26TTW07HP230V1A 26TTW09HP230V1A 26TTW12AC230V1A 26TTW12HC230V1A 26TTW12HP230V1A Thank you for choosing our product. For proper operation, please read and keep this manual carefully.
  • Page 2: Table Of Contents

    IMPORTANT NOTE TO THE HOMEOWNER This manual is to be used by qualified, professionally trained HVAC technicians only. Gree does not assume any responsibility for property damage or personal injury for improper service proce- dures or services performed by an unqualified person.
  • Page 3: Installation Instructions

    VOLTAGE MEASUREMENTS CHASSIS INSTALLATION Before connecting the unit, measure the supply voltage. Voltage 1. Remove front grille. See Figure A. must fall within the voltage utilization range given in the following table. Operating Voltage Voltage Utilization Range Unit Voltage Lift up on Filter Handle Rating Minimum...
  • Page 4 If outlet is on the left side of the unit, route power cord as shown in Figure D. Power Cord Clamp Figure 3 Figure D 3. Remove shipping pads inside air conditioner next to compressor. (See Figure B.) To replace front grille: Grille Remove shipping...
  • Page 5 To open or close the vent: 1. Remove the front grille. 2. Remove the vent card screw. 3. Remove the vent card, turn it over and replace it by locating rear hole in card over locating pin inside air discharge and reattaching screw at front.
  • Page 6: Wiring

    WIRING Before wiring the unit, please review the following warnings and cautions.
  • Page 7: Air Conditioner Features

    AIR CONDITIONER Before you begin, thoroughly familiarize yourself with the control panel and remote as FEATURES shown below and all its functions. Then follow the symbol for the functions you desire. The unit can be controlled by the touch pad alone or with the remote. LOWERS TEMPERATURE DISPLAYS...
  • Page 8 AIR CONDITIONER FEATURES Notice: • When power is connected (stand by condition), you can + / - button operate the air conditioner through the remote control. • Pressing “+” or “-” button once will increase or decrease • When unit is on, each time you press the button on the set temperature by 1°F(°C).
  • Page 9 Note: AUXILIARY CONTROLS-DIP SWITCHES • Range of time setting is: 0.5~24h. The auxiliary dip switch controls are lacated behind the room cabinet-as shown in the following figure. • The interval between two motions can’t exceed 5 sec- onds, otherwise the remote control will exit setting sta- The owner is responsible for checking switches and ensuring tus.
  • Page 10 AIR CONDITIONER FEATURES (continued) PRESS ON/OFF BUTTON RESET RESET FILTER FILTER TO CHANGE TEMPERATURE SETTING: PRESS TO RAISE PRESS TO LOWER RESET RESET FILTER FILTER Note: Tap or hold either up(^) or down(v) button until the desired temperature is seen on display. This temperature will be automatically maintained anywhere between 61F (16°...
  • Page 11 AIR CONDITIONER FEATURES (continued) TO OPERATURE ON FAN ONLY: PRESS MODE BUTTON RESET CHOOSE FILTER FAN ONLY Note: Use this function only when cooling is not desired, such as for room air circulation. You can choose any fan speed you prefer, EXCEPT AUTO FAN.During this function, the display will show the actual current temperature, not the set temperature as in the cooling mode TIMER-DELA START/ST...
  • Page 12 AIR CONDITIONER FEATURES (continued) PRESS MODE BUTTON RESET RESET FILTER FILTER SELECT HEAT Note: This feature can be used with any combination of FAN Speeds, Timer . When in the Heat Mode, the Note: This feature can be used with any combination of FAN speeds, Timer. When in the “Heat” Mode, the fan will run continuously fan will run continuously while heat is needed.
  • Page 13: Additional Information

    ADDITIONAL INFORMATION • The remote control will operate all the control panel features. Instructions will be the same. • The “COOL” circuit has an automatic 3 minute time de- layed start if the unit is turned off and on quickly. This prevents overheating of the compressor and possible cir- cuit breaker tripping.
  • Page 14: Product Warranty

    EXTENDED FOUR YEAR PARTS AND LABOR LIMITED WARRANTY ON SEALED REFRIGERATION SYSTEM ONLY – During the second through fifth years after date of original installation, GREE will at its sole discretion, through its authorized servicing dealers and service stations* and free of charge to the user or subsequent users, repair (i.e.
  • Page 15 GREE. Reimbursement for replacement parts or repair services which are not supplied or designated by GREE and which are specifically covered under this warranty. GREE products installed outside the continental U.S.A., and Canada Shipping damage or damage as a result of transporting the unit. This is the responsibility of the selling dealer or the authorized service station.
  • Page 16 Gree Electric Appliances, Inc .2015 All rights reserved. Cat No. 26-TTW-1OM Version 1.0 66129917060...
