ASSEMBLY INSTRUCTIONS CZ-730/Qi

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Qi CZ-730 and is the answer not in the manual?

Questions and answers

Related Manuals for Cozzia Qi CZ-730

Summary of Contents for Cozzia Qi CZ-730

  • Page 1 ASSEMBLY INSTRUCTIONS CZ-730/Qi...
  • Page 2 Massage chair arrives in three boxes. As pictured below. Base & Backrest CZ-730/Qi-B EVC 178.2 217.8 56.7"x34.4"x34.6" Espresso & Vintage Copper COLOR:Espresso & Vintage Copper Side Panels & Rear Cover Footrest & Head Unit CZ-730/Qi EVC CZ-730/Qi-S EVC CZ-730/Qi-F EVC CZ-730/Qi EVC 15.4 lbs 66.0 lbs...
  • Page 3 Open box 3 and remove the packing material on the top. Take out the footrest and the speaker unit. Move the footrest close to the chair. Zip the zipper to join the two fabrics together. As pictured below. Take off three cotter pins and three bolts, put them aside the chair. Then move footrest close to the chair. Engage the joint of the footrest actuator and footrest.
  • Page 4 Engage the joints of the footrest and the base. Lift footrest up to align the holes on the joints. Then insert the bolt Attach the speaker unit to the backrest. Make sure the metal plates engage to the bolts. Connect the wire connector and lock with the cotter pin.
  • Page 5 Open box 2 and take out the side board, decoration strips and rear cover. Attach decoration strips. Move the side board cover close to the side board and align the snap joints. Pinch the lower side board to clamp the Align the snap joints first.
  • Page 6 Attach the rear cover of the backrest. Use two cross recessed pan head screws to fasten it. As pictured below. 861 S. Oak Park Road, Covina, CA 91724 TEL: 1-877-977-0656 FAX: 1-800-521-4712 SERVICE@COZZIAUSA.COM WWW.COZZIAUSA.COM Remove the packing materials of the Ipad mini holder. Connect the chair to power supply. Unlock the main switch first, and then turn on the power switch.
