RADIO SETING AND OPERATION
Because the mAT-40 tuner is fully compatible with the original brand tuners. After matching
the corresponding interface cable, it can be used as the original tuner, and the setting and operation
of the radio station are the same.
Different brands and models of radio, its function menu settings are different, please refer to
their manual for necessary settings.
For ICOM brand radio, you can refer to AT-120, AT-130, AH-4 tuner settings and use
methods, most of the ICOM brand radio does not need any settings, connect the data cable and
radio frequency cable can be used.
For YAESU brand radio, you need to set up the tuner related options in the function menu.
Please read the radio manual for specific settings. Refer to FC-30, FC-40, FC-50 and other
original tuner settings.
For KENWOOD brand radio, please refer to their manual, AT-250, AT-300 and other original
tuner settings and use methods.
In particular, for some radios with built-in tuners and multiple antenna sockets, their built-in
tuners are fixed to a particular antenna pedestal, which can no longer be connected to an external
tuner. For example, KENWOOD's TS-480SAT, TS-2000 and TS-590S/G models, because their
built-in tunes are fixed to ANT2, can only be used when using external tunes, otherwise the tuner
will not work.

RE-TUNING

If you are using ICOM or KENWOOD transmitter, when tuning for the first time after
changing the transmitter's frequency, the tuner automatically transfers data from memory and
configures tuner. The tuner will start a complete tuning cycle when tuning second times.
If you use the YAESU transmitter, when you change the transmitter's frequency, the tuner
automatically follows the transmitter's frequency to query data from memory and configure the
LC network. After you press the tuning button of the transmitter, the tuner will start a full tuning
cycle and re-tune.

TECHNICAL SUPPORT

Visit the Support Center at: http://www.mat-tuner.com. The website provides links to product
manuals, just in case you lose this one! When you are thinking about the purchase of other
products our website also has complete product specifications and photographs
you can use to help make your purchase decision. Don't forget the links to all of the quality
Dealers also ready to help you make that purchase decision.

PRODUCT FEEDBACK

We encourage product feedback! Tell us what you really think of your
In an email tell us how you used the product and how well it worked in your application. We like
to share your comments with our staff, our dealers, and even other customers at the MAT-TUNER
website.
