Summary of Contents for DynAmp LKP-100
- Page 1 MODEL LKP-100 DIRECT CURRENT METERING SYSTEMS Installation, Operation and Service Manual Manual Item No. 041738 Rev. I DynAmp, LLC 3735 Gantz Road Phone +1 614.871.6900 www.dynamp.com Grove City, Ohio 43123 USA Fax +1 614.871.6910 help@dynamp.com...
- Page 2 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page ii 041738 I...
- Page 3 Items and components not manufactured and resold by Seller are warranted by their manufacturer. Warranty repair shall be, at DynAmp’s option, in the form of repair or replacement of the defective items or components. Concerning warranty repairs, DynAmp will be responsible for DynAmp provided time, material and transportation costs (shipping or travel).
- Page 4 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page iv 041738 I...
- Page 5 According to EN 50082, the manufacturer must state the degradation of performance level acceptable during immunity tests. Unless other wise noted in the manual or data sheet, DynAmp limits degradation during immunity tests for this equipment to < 0.5% FS for A-criterion tests.
- Page 6 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page vi 041738 I...
- Page 7 Disconnect power to the system before servicing or replacing fuses. GENERAL DynAmp does not assume liability for the customer’s failure to comply with the rules and requirements provided in this manual. Use of the equipment in a manner not specified by the manufacturer can impair the protection provided within.
- Page 8 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page viii 041738 I...
- Page 9 Installation, Operation and Service Manual LKP Series DynAmp, LLC Customer Support For further assistance, contact DynAmp Customer Support at: Americas: Telephone: +1 614.871.6900 Fax: +1 614.871.6910 8:00 AM to 5:00 PM USA Eastern Time From first Sunday in November to second Sunday in March – 13:00 GMT to 22:00 GMT From second Sunday in March to first Sunday in November –...
- Page 10 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page x 041738 I...
- Page 11 Updated Accuracy Diagnostics & Spare Parts section 04/02 iii, 7 Rev D Updated Warranty and Installation paragraph 10/03 Rev E Updated to DynAmp, LLC 12/04 vii, 1, 32, Rev F Update fuse precautions per ECR 1304 07/06 ECO 3166 update accuracy diagnostics drawings/list 09/08 PAR 10245 –...
- Page 12 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page xii 041738 I...
-
Page 13: Table Of Contents
6.11 OUTPUT CIRCUIT ......................26 6.12 ACCURACY DIAGNOSTICS (OPTIONAL) ................ 27 7. MAINTENANCE & SPARE PARTS ______________________________________________29 PERIODIC MAINTENANCE ....................29 ANNUAL MAINTENANCE....................29 CALIBRATION INTERVALS ....................30 SPARE PARTS ORDERS - ROUTINE OR EMERGENCY........... 31 © 2016 DynAmp, LLC Page xiii 041738 I... - Page 14 Table 5.1. Measuring Head Resistance Chart ............... 17 Table 5.2 Form for Recording Channel Voltage Measurements ..........21 Table 7.1 Spare Parts List * ....................31 Table 8.1 Technical Bulletins List ..................33 Table 9.1 Drawing List ......................35 © 2016 DynAmp, LLC Page xiv 041738 I...
-
Page 15: Safety
Use a wire and breaker or fuse (time-delay) sized adequately for the maximum burden of 20 VA/kA of measured current. The wire should have an insulation rating of 600Vac and 80°C minimum temperature rating. © 2016 DynAmp, LLC Page 1 041738 I... - Page 16 Use of the equipment in a manner not specified by the manufacturer can impair the protection provided within. DynAmp does not assume liability for the customer’s failure to comply with the rules and requirements provided in this manual. © 2016 DynAmp, LLC...
-
Page 17: Handling And Storage
-40 to 70°C -40 to 158°F Storage Humidity: 85%, non-condensing DynAmp, LLC does not assume liability for the customer’s failure to comply with handling and storage requirements. For further assistance, contact DynAmp customer support. © 2016 DynAmp, LLC Page 3... - Page 18 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page 4 041738 I...
-
Page 19: Description
LKP Series 3. DESCRIPTION OVERVIEW The DynAmp, LLC LKP-100 is a 10 channel metering system for accurately measuring direct current in a bus up to 100 kA. The system consists of a Measuring Head, a Metering Unit, and two multi-conductor cables. - Page 20 5.) A normally closed relay contact for accuracy diagnostics output. This feature is only available when the accuracy diagnostics option is ordered. 6.) Optional isolated shunt output. Scaling is per customer order: 0-10V, 4-20mA available. © 2016 DynAmp, LLC Page 6 041738 I...
-
Page 21: Specifications
Installation Category Pollution Degree Contingent upon DynAmp, LLC computer analysis of bus system. The LKP systems are factory-set for the correct voltage and frequency (50 or 60 Hz) per customer order. To operate an LKP system at a different line frequency than was ordered, move jumper JP1 (located on the control board inside each module) to the desired frequency. -
Page 22: Table 4.2 Typical Error At Zero Bus Current
PHYSICAL Overall Dimensions, in. (mm): LKP 100 Metering Unit (all) 66 (1676)H x 48 (1220)W x 16 (406)D LKP-100 Measuring Head 44.6 (1134)H x 51.2 (1300)W x 11.8 (300)D Aperture Dimensions in. (mm): LKP-100 Measuring Head 30.5 (775) H x 46.1 (1170)W... -
Page 23: Installation
Visible damage must be reported to the carrier immediately. Concealed damage (not evident until the system is operated) must be reported to DynAmp, LLC immediately. For all handling of the Measuring Head, use a lifting strap capable of withstanding 1000lbs (454kg) Figure 5.1 Typical Measuring Head Sectional Layout... - Page 24 I.) CAUTION: The part-line insulation pieces (located on the mating surfaces of the head) are brittle and contain sensitive electronic devices that can be easily damaged if one is not careful during installation. © 2016 DynAmp, LLC Page 10 041738 I...
-
Page 25: Installation Precautions (Live Bus)
Warning : Keep all exposed head cable leads from touching the bus, ground, or any support structures. Consult with DynAmp about using a shorting plug at each connector. INSTALLATION PRECAUTIONS (LIVE BUS) If the unit is to be installed on a live bus, the following precautionary measures must be taken before installing the Measuring Head: A.) Make sure that the cables are disconnected from the head during installation. -
Page 26: Magnetic Considerations: Measuring Head
The general guidelines below should be applied only when a detailed analysis of your bus system is not available. DynAmp, LLC will perform one detailed computer analysis of the proposed location of the Measuring Heads within your bus system at no charge. -
Page 27: Head Installation
(the head sections do not have to be put together at this point), and performing the head resistance check as described late in this section. The © 2016 DynAmp, LLC Page 13 041738 I... - Page 28 Measuring Head rest upon the window insulation as it can be easily damaged. Also, the interconnecting cable is of top quality, but it is not armored - protect it from abrasion and sharp edges. © 2016 DynAmp, LLC Page 14 041738 I...
-
Page 29: Completing The Head Installation
Measurements are made between cable leads listed, at Metering Unit end of cable. The resistance values shown in the table are for readings obtained with cable disconnected from the Metering Unit. Split channels 1 and 6 will read half the © 2016 DynAmp, LLC Page 15 041738 I... -
Page 30: Metering Unit Installation
(Some installations have been made much closer to high current buses without difficulty, but the distance given is on the safe side.) Anchor the cabinet in the desired location after ensuring adequate cable reach. © 2016 DynAmp, LLC Page 16 041738 I... -
Page 31: Table 5.1. Measuring Head Resistance Chart
Hall Signal - Channel #8 63 & 64 240-550 Hall Signal - Channel #9 65 & 66 240-550 Hall Signal - Channel #10 71 & 75 600-800 Hall Current - Channels # 6-10 © 2016 DynAmp, LLC Page 17 041738 I... -
Page 32: Metering Unit Wiring
(to verify no condition exists that may cause damage to the LKP Metering Unit), and the second set after a 24-hour period of time (to thermally stabilize the head). Proceed as follows: © 2016 DynAmp, LLC Page 18 041738 I... -
Page 33: Magnetic Centering
B.) The necessity of moving the head because of voltage readings that are too high or too low for certain channels. C.) The desirability of moving the head to obtain a better balance of channel voltages. © 2016 DynAmp, LLC Page 19 041738 I... - Page 34 24 hours to thermally stabilize the head. Then make any necessary adjustments and record the final position values on one of the book copies of table 5.2 and label accordingly. This data will be valuable for future troubleshooting or maintenance. © 2016 DynAmp, LLC Page 20 041738 I...
- Page 35 [ ] LOOP BURDEN (TS2 - 5 & 6): [ ] LINE VOLTAGE (TS 3-2 & -3): [ ] BUS CURRENT (kA): Serial Number: ________________________ * Read notes in “Magnetic Centering” section of the manual carefully. © 2016 DynAmp, LLC Page 21 041738 I...
-
Page 36: Reversing Cable Exit Direction On Measuring Head
Reconnect the cables to the head and reapply ac power to the Metering Unit. WARNING: WITH THE SYSTEM ON A LIVE BUS, THE AC POWER IS OFF, AND THE CABLE DISCONNECTED FROM THE HEAD, A SHOCK HAZARD EXISTS ON THE MEASURING HEAD CONNECTOR TERMINALS. © 2016 DynAmp, LLC Page 22 041738 I... -
Page 37: Theory Of Operation
SYSTEM DESCRIPTIONS Effects of stray fields are nullified by joining a number of magnetic assemblies like the one just described in a closed path around the bus. Figure 6.2 shows four such assemblies © 2016 DynAmp, LLC Page 23 041738 I... -
Page 38: Circuit Functions
The Metering Unit also contains one main power transformer, circuit breaker, and the resistors or shunts to develop output voltages. A 4-channel system is used here as an illustration to simplify the explanation. © 2016 DynAmp, LLC Page 24 041738 I... -
Page 39: Metering Unit
COMPARATORS AND PULSE GENERATOR The comparators consist of U110 and U111. They compare the amplified and filtered output of the error amplifiers to the two ramps generated by PLL and ramp generators. © 2016 DynAmp, LLC Page 25 041738 I... -
Page 40: Pulse Transformer Drivers
The burden resistor should have a low temperature coefficient (25 ppm or better). The Metering Unit is supplied with a two-pole circuit breaker mounted inside the enclosure, on the main panel. © 2016 DynAmp, LLC Page 26 041738 I... -
Page 41: Accuracy Diagnostics (Optional)
FIRST- Lock out control actions that could drive the rectifier output higher and SECOND-alert the operator. Basically, each module inside the Metering Unit has four channel LEDs and 2 power supply monitoring LEDs. The following is a description of their functionality: © 2016 DynAmp, LLC Page 27 041738 I... - Page 42 Contact Terminals Condition TS2-17,18 TS2-18,19 Open Closed Fault condition, zero bus current*, or Metering Unit turned off Closed Open Normal operation * See notes above on zero bus current condition. © 2016 DynAmp, LLC Page 28 041738 I...
-
Page 43: Maintenance & Spare Parts
As is true with any electronic circuitry, proper maintenance will prolong the service life. DynAmp, LLC recommends the following program be performed at the recommended interval to prevent or detect damage to the LKP system and to ensure continuing high- accuracy performance. -
Page 44: Calibration Intervals
Laboratory Accreditation Bureau "Guidance for Documenting and Implementing ISO/IEC 17025:2005 and Laboratory Guidance." As a guideline, DynAmp recommends a 24-month interval of calibration for all permanently installed products and a 12-month interval of calibration for all products used in portable applications. -
Page 45: Spare Parts Orders - Routine Or Emergency
LKP Series SPARE PARTS ORDERS - ROUTINE OR EMERGENCY Requests for spare parts should be directed to "Service" at DynAmp, LLC during normal hours. When contacting us, please present as much information as possible, such as the related equipment Model and Serial Numbers (available on the equipment tag); the required part name;... -
Page 46: Customer Support
Installation, Operation and Service Manual LKP Series 6-7. CUSTOMER SUPPORT For further assistance, contact DynAmp Customer Support at: Americas: Telephone: +1 614.871.6900 Fax: +1 614.871.6910 8:00 AM to 5:00 PM USA Eastern Time From first Sunday in November to second Sunday in March – 13:00 GMT to 22:00 From second Sunday in March to first Sunday in November –... -
Page 47: Related Technical Bulletins
The following is a list of available technical bulletins that contain relevant information in regards to high current measurements and the use of LKB systems. The technical bulletins are available upon request from DynAmp, LLC. Always consult the factory for a list of the latest technical bulletins. - Page 48 Installation, Operation and Service Manual LKP Series This Page is Intentionally Blank © 2016 DynAmp, LLC Page 34 041738 I...
-
Page 49: Drawings
Totalizing Diagram: LKP Series Metering Units 02C108033 Assembly: Accuracy Diagnostics 07A109083 Schematic: LKP Accuracy Diagnostic Board 05B109034 Outline and Mounting: LKP-100 Measuring Head 02C108200 Outline and Mounting: LKP Series 10-16 Channel Metering Unit 02D107892 Assembly: Supply & SCR Drive PC Board 75B108106...
