Installation Instructions Original Instructions High-bright Display Modules Catalog Number 2711P-RDT12H Topic Page Important User Information Summary of Changes About the Module Environment and Enclosure Outdoor Installation Hazardous Locations Environnements dangereux Wiring and Safety Guidelines About the Terminals Install the Terminal... -
Page 2: Important User Information
High-bright Display Modules Important User Information Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards. -
Page 3: Summary Of Changes
High-bright Display Modules Summary of Changes This document contains new and updated information as indicated in the following table. Topic Page Updated the Attention note in the section titled External Power Supply for Nonisolated DC Terminals. Removed outdated error messages from the Troubleshooting section and added references to appropriate user manuals. -
Page 4: Environment And Enclosure
Outdoor Installation When using the high-bright display module, catalog number 2711P-RDT12H, outdoors, considerations in maximizing the field life of the front bezel and display are the following: • Selecting the proper enclosure •... -
Page 5: Hazardous Locations
High-bright Display Modules The high-bright display module has a built-in temperature sensor that automatically reduces the backlight intensity if the temperature inside the cabinet exceeds 55 °C (131 °F). This reduces the risk of damage to the display. The paint color, size, and power dissipated by the internal components of an enclosure affect the temperature rise inside the cabinet. -
Page 6: Environnements Dangereux
High-bright Display Modules terminals in environments where atmospheric gases have ignition temperatures than 135 °C (275 °F). Environnements dangereux Cet équipement ne peut être utilisé que dans les environnements suivants : • Classe I, Division 2, Groupes A, B, C, D •... - Page 7 High-bright Display Modules PanelView Plus 700 to 1500 Terminals Control Drawing Associated Nonincendive Field Wiring Apparatus Nonincendive Field PanelView Plus 700 to 1500 Host Product Wiring Apparatus Nonincendive Field Wiring Peripheral Device USB Port Table 1 - PanelView Plus 700 to 1500 USB Port Circuit Parameters Groups A and B Groups C and D Groups A and B...
-
Page 8: Wiring And Safety Guidelines
High-bright Display Modules Symbol Definitions Open circuit voltage of the host USB port. Maximum output current of the host USB port. Maximum applied voltage rating of the USB peripheral device. shall be greater than or equal to V in Table 1 (V ≥... -
Page 9: About The Terminals
High-bright Display Modules About the Terminals High-bright display modules are available only as separate components. Logic modules and communication modules must be ordered separately. Power Input, DC Logic Module Display Module Ethernet Port Serial Port USB Ports Attach the logic module and communication module to the display module before panel installation. - Page 10 High-bright Display Modules Mounting Clearances Allow adequate clearance around the terminal, inside the enclosure, for adequate ventilation. Consider heat produced by other devices in the enclosure. The ambient temperature around the terminals must be between 0…55 °C (32…131 °F). These minimum clearances are required for ventilation: •...
- Page 11 High-bright Display Modules 2. Make sure the terminal sealing gasket is properly positioned on the terminal. This gasket forms a compression type seal. Do not use sealing compounds. Sealing Gasket 3. Place the terminal in the panel cutout. 4. Slide the ends of the mounting clips into the slots on the terminal. Mounting Clip Mounting Clip Slot 5.
- Page 12 High-bright Display Modules 6. Tighten the mounting clip screws to a torque of 0.90…1.1 N•m (8…10 lb•in) by using the specified torque sequence, making sure not to over-tighten. ATTENTION: Tighten the mounting clips to the specified torque to provide a proper seal and prevent damage to the product.
-
Page 13: Logic Module Compatibility
High-bright Display Modules Logic Module Compatibility The high-bright display module is only compatible with the following DC logic modules. PanelView Plus, PanelView Plus CE, and PanelView Plus 6 Logic Modules Cat. No. Description PanelView Plus 700 to 1500 Logic Modules 2711P-RP2 Logic module with 128 MB flash/128 MB RAM, DC input PanelView Plus CE 700 to 1500 Logic Modules... -
Page 14: External Power For Isolated Dc Terminals
High-bright Display Modules Multiple AC Power Supplies to Power Multiple DC Terminals AC/DC Power Supply AC/DC Power Supply (2711P-RSACDIN) (2711P-RSACDIN) Circuitry Circuitry PanelView Plus PanelView Plus External Power for Isolated DC Terminals Isolated DC logic modules are identified by catalog number 2711P-RPxDx. Use an SELV or PELV 24V DC power supply, such as catalog number 2711P-RSACDIN, to power the isolated DC PanelView Plus terminal. -
Page 15: Remove And Install The Power Terminal Block
High-bright Display Modules On most PanelView Plus devices, the earth/ground terminal is internally connected to the DC- terminal within the product. ATTENTION: Damage or malfunction can occur when a voltage potential exists between two separate ground points. Make sure the terminal does not serve as a conductive path between ground points at different potentials. -
Page 16: Dc Power Connections
High-bright Display Modules 2. Gently pull the terminal block away from the connector. Three-position Terminal Block Two-position Terminal Block (Series A to D logic modules) (Series E or later logic module) Follow these steps to install the terminal block. 1. Reattach the terminal block to the connector until seated. 2. -
Page 17: Ethernet Cable
High-bright Display Modules Connect DC Power WARNING: Explosion Hazard Do not disconnect equipment unless power has been switched off and the area is known to be nonhazardous. Disconnect all power before installing or replacing components. Failure to disconnect power may result in electrical shock or damage to the terminal. -
Page 18: Troubleshooting
High-bright Display Modules The maximum cable length between the terminal's Ethernet port and a 10/100 Base-T port on an Ethernet hub (without repeaters or fiber) is 100 m (328 ft). For additional information, refer to the EtherNet/IP Media Planning and Installation Manual, publication ENET-IN001. WARNING: Do not connect or disconnect any communication cable with power applied to this device or any device on the network. - Page 19 High-bright Display Modules The table shows indicator states if the terminal powers up and stops during startup. Indicator States if the Terminal Stops During Startup Fault (Red) Comm (Green) Description Recommended Action Indicator Indicator Blinking red indicator identifies a recoverable error. Reload firmware by using Firmware Blinking Last firmware download failed.
-
Page 20: Specifications
High-bright Display Modules Specifications PanelView Plus, PanelView Plus CE, and PanelView Plus 6 Terminals with High-bright Display Module Attribute 2711P-RDT12H Display Color active matrix, thin film transistor (TFT) liquid crystal display Display type (LCD) Display size 12.1 in. Display area (W x H) 246 x 184 mm (9.7 x 7.2 in.) - Page 21 High-bright Display Modules Environmental Specifications Specification 2711P-RDT12H Temperature, operating 0…55 °C (32…131 °F) Temperature, nonoperating -20…70 °C (-13…158 °F) 10… 57 Hz, 0.012 pk-pk displacement Vibration 57…500 Hz 2.0 g pk acceleration Shock, operating 15 g at 11 ms Shock, nonoperating...
-
Page 22: Additional Resources
High-bright Display Modules Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Resource Description Provides an overview of the PanelView Plus and PanelView Plus CE PanelView Plus Terminal User Manual, publication terminals and gives information on how to install, operate, configure, and 2711P-UM001 troubleshoot these devices. - Page 23 High-bright Display Modules Notes: Rockwell Automation Publication 2711P-IN026H-EN-P - May 2018...
- Page 24 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, PanelView, Rockwell Automation, and Rockwell Software are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400...
