ATTENTION: All covers and doors must be in place before you apply power to the MCC. If units are removed, they must be replaced with the appropriate items

such as units, doors, and unit support pans. If the unit is not replaced, the arc resistant rating does not apply.

Page

Table of Contents

Need help?

Do you have a question about the CENTERLINE 2100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Allen-Bradley CENTERLINE 2100

Page 1: Table Of Contents
Installation Instructions Original Instructions CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles Bulletin Number 2100 Topic Page About This Publication Important User Information Before You Begin Recommended Tools Ground the Unit Install the Unit Support Pan...
Page 2: Important User Information
CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles Important User Information Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
Page 3: Before You Begin
100 ms arc duration. If the incorrect unit is installed, the arc resistant rating does not apply. ATTENTION: SecureConnect units must be installed in Series P or later CENTERLINE 2100 motor control centers. If you install a SecureConnect unit in a Series N or earlier MCC, you must have compatible bus covers installed.
Page 4: Recommended Tools
CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles Recommended Tools You need the following tools: • Screwdriver • 5/16 in. and a 3/8 in. socket wrench, for installing ArcShield units • 1/4 in. hex tool, for installing SecureConnect units •...
Page 5 CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles 1. For ArcShield sections with 100 ms arc duration rating, remove the vertical wireway baffle and set aside for installation later. 2. If present, remove the isolation barrier from the vertical-wireway wall cutout.
Page 6 CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles 9. Secure the support pan. See the table for more instructions. Follow This Step Insert the white plastic retaining-clip through the holes in the vertical wireway wall and pan, work from inside the vertical wireway as shown. See...
Page 7: Install Swing-Out Latch Brackets
CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles Install Swing-out Latch Brackets Swing-out latch brackets are used on ArcShield units with 100 ms arc duration rating that have more than two latches (for example, in the middle latch position).
Page 8 For the CENTERLINE 2100 MCC units with arc-resistant door latches, you can tilt the top of the unit slightly to the rear to avoid interference with the top arc latch bracket. If you do not have enough clearance, loosen the latch bracket screw (approximately two turns) to install the unit.
Page 9 CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles 6. For all units, secure the unit by tightening the front top and bottom captive latches to 22 lb•in (2.5 N•m). Units that are 2.0 space factors or larger have two captive latches on the top of the unit and one on the bottom of the unit.
Page 10: Install The Door
CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles Install the Door Follow this procedure to install the door. ATTENTION: Doors that are not rated for 100 ms arc duration or Device Limited ArcShield must not be installed in a section that is rated for 100 ms arc duration or Device Limited ArcShield.
Page 11 CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles 3. If a control station is present, place it through the door cutout and tighten the captive screws. 4. If swing-out latch brackets are present, rotate the movable portion of the swing-out latch bracket in the counter-clockwise direction unit it stops.
Page 12: Extend Secureconnect Unit Power Stabs
CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles Extend SecureConnect Unit Power Stabs Follow this procedure to extend the SecureConnect unit power stabs. 1. Verify that the disconnect handle is in the OFF/O position. 2. Insert 1/4 in. hex tool into shaft port and rotate tool clockwise.
Page 13: Additional Resources
CENTERLINE 2100 Motor Control Center (MCC) Doors and Units with Vertical Operating Handles Additional Resources These documents contain more information about related products from Rockwell Automation. Resource Description CENTERLINE 2100 Low Voltage Motor Control Centers Instruction Manual, publication 2100-IN012 Provides general instructions for MCC Units.
Page 14 Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, ArcShield, CENTERLINE, Rockwell Automation, Rockwell Software, and SecureConnect are trademarks of Rockwell Automation, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies. Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400...
