CE875 Instant Issuance System
Multi-Hopper Printer
1. Unlock the multi-hopper lock.
a
2. Slide the lock bar release button (B1) to the left.
3. Rotate a lock bar to the left.
3
1
30
1
2
3
2
527762-001EN_E
4. Press the cartridge release button at the top of the
b
cartridge and open the cartridge door.
5. Lift the card weight to the top of the cartridge and pull
it forward until it locks in position.
6. Load the cards into the cartridge.
7. Close the cartridge door to release the card weight so
that it rests on top of the cards.
4
8. Repeat for each input hopper cartridge.
9. Return all locks to the locked position when finished.
527762-001EN_E
Quick Install Guide
5
6
Card Weight
Cards
