FourStar 11222676C Assembly Instructions

MODEL: 11222676C
3 DRAWER
ORGANIZER
STEP 1.
INSERT DOWELS (2) TO SIDE PANELS (C) AND BACK
PANEL (E) WITH GLUE (7).
2 PLASTIC DOWEL - 6 PCS
STEP 5.
ATTACH BACK PANEL (E) TO
ASSEMBLED PART FROM
STEP 4 WITH GLUE (7).
CAUTION :
1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING AND
ASSEMBLING OF THIS PRODUCT.
2. ASSEMBLE ON SOFT SURFACE TO PREVENT DAMAGE TO
THE PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLING.
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY INSTRUCTIONS
CAREFULLY. FOLLOW STEP BY STEP.
ASSEMBLY TOOLS REQUIRED
RUBBER MALLET
PHILIPS SCREWDRIVER
Do you have any questions? Missing small parts or hardware? If you need
assistance with the assembly of your 3 DRAWER ORGANIZER please e-mail
support@fourstari.com or
our Customer Service Department at:
call us at (800) 639-3803 or (508) 435-4830
if calling locally
from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster
STEP 2.
INSTALL CASTERS (3) TO UNFINISHED
SURFACE OF BOTTOM SHELF (B) WITH
SCREWS (4).
3 CASTER
- 4 PCS UNFINISHED SURFACK
4 M3.5 X 12 CHIPBOARD SCREW - 16 PCS
STEP 6.
ATTACH BOTTOM SHELF (B)
TO BACK PANEL (E) AND SIDE
PANELS (C) WITH SCREWS (1).
1 CHIPBOARD
SCREW - 6 PCS
PARTS LIST AND HARDWARE
NO HARDWARE LIST
1 M4 X 32 CHIPBOARD SCREW
2 PLASTIC DOWEL
3 CASTER (FLAT)
4 M3.5 X 12 CHIPBOARD SCREW
5 LARGE BIN
6 SMALL BIN
7 WHITE GLUE
STEP 3.
ATTACH SIDE PANELS (C)
TO UNFINISHED SURFACE
OF TOP SHELF (A) WITH
GLUE (7).
UNFINISHED SURFACK
STEP 7.
UNFOLD BINS (5) (6) AND SLIDE ONTO SHELVES.
QTY
NO PARTS LIST
14 PCS
A TOP SHELF
6 PCS
B BOTTOM SHELF
4 PCS
16 PCS
C SIDE PANEL
1 PC
D MIDDLE SHELF
1 PC
E BACK PANEL
1 PC
STEP 4.
ATTACH MIDDLE SHELVES
(D) TO ASSEMBLED PART
FROM STEP 3 AND
TIGHTEN WITH
SCREWS(1)
1 CHIPBOARD
This unit is intended for use only with the products and
maximum weights indicated. Use with other products or
products heavier than the maximum weights indicated may
result in instability causing possible injury. Furniture can tip
over or break if improperly moved. Have a friend help to lift
and carry the unit to its new location.
QTY
1 PC
1 PC
2 PCS
2 PCS
1 PC
SCREW - 8 PCS
