FourStar 11224029 Assembly Instructions

MODEL: 11224029
9 BIN WOODEN
STORAGE ORGANIZER
STEP 1
PLACE THE TOP SHELF (A) SURFACE FACE
DOWN ON A SOFT CLOTH/BLANKET IN
ORDER TO PROTECT SURFACE, PUT
DOWELS (Q) INTO THE SHORT CROSS BAR
(L) AND INSERT SHORT CROSS BARS IN
THE MIDDLES HOLES, SCREW SHORT
SPINDLES ( J) AT THE 4 CORNERS. AFTER
THAT, PUT 2ND SHELF ON IT AND INSERT
LONG CROSS BARS (M) AND SCREW LONG
SPINDLES (K) AT THE 4 CORNERS. THEN
REPEAT THE SAME STEP FOR THE 3RD
SHELF (C). PUT
4TH SHELF (D) ON
N
N
IT, SCREW LONG
N
SPINDLES ( K).
FINALLY PLACE
BOTTOM SHELF
(E) ON THE
FRAME AND
SCREW THE 4
M
M
FEET (N) AS
SHOWN.(NOTICE:
Q
PLACING SOME
Q
M
M
GLUE (R) ON THE
WOODEN
DOWELS (Q) CAN
TIGHTEN THE
FRAME.)
Q
Q
CAUTION :
1. ADULT SUPERVISION IS REQUIRED DUE TO SMALL PARTS.
CARE SHOULD BE TAKEN IN THE UNPACKING AND
ASSEMBLING OF THIS PRODUCT.
2. ASSEMBLE ON SOFT SURFACE TO PREVENT DAMAGE TO THE
PRODUCT FINISH.
3. MAKE SURE ALL PARTS ARE INCLUDED BEFORE ASSEMBLING.
BEFORE YOU BEGIN, PLEASE READ ASSEMBLY INSTRUCTIONS
CAREFULLY. FOLLOW STEP BY STEP.
ASSEMBLY TOOLS REQUIRED
PHILIPS SCREWDRIVER
Do you have any questions? Missing small parts or hardware? If you need assistance with the
assembly of your 9 BIN WOODEN STORAGE ORGANIZER please e-mail our Customer
support@fourstari.com or call us at
Service Department at:
(800) 639-3803 or (508) 473-7688
if calling locally from Massachusetts area
Please include the following information in your email:
• Where item was purchased • Item, model, style or SKU number listed on
instructions or box • Part number, description of the part and quantity needed
This information will help us get the proper part to you faster
STEP 2
TURN OVER THE
FRAME, USE LONG
O
SCREWS (O) TO
SCREW THE CROSS
BARS AS SHOWN.
O
O
O
O
O
O
STEP 3
ATTACH THE SHORT
BACK PANELS (F) AND
LONG BACK PANELS
P P
(G) TO THE BACK P
FRAME, USE SHORT
SCREWS (P) AS
P
P
P
SHOWN.
P
P
P
P
P
P
HARDWARE
NO
& PART LIST
A TOP SHELF
B 2ND SHELF
C 3RD SHELF
D 4TH SHELF
E BOTTOM SHELF
F
SHORT BACK PANEL
G
LONG BACK PANEL
H
SMALL BIN
I
BIG BIN
STEP 4
INSERT THE SMALL BINS (H) ON THE
FIRST FLOOR AND BIG BINS ON THE
OTHER FLOORS AS SHOWN.
IF NECESSARY, PLEASE FOLLOW BELOW INSTRUCTION
TO PREVENT PRODUCT TIP OVER.
HARDWARE LIST QTY
2 SETS
WALL PLUG EYELET SCREW CABLE TIE
1/4''
DRILL BIT
WALL
1
WALL
CABLE
TIE
PARTS LIST AND HARDWARE
HARDWARE
QTY NO
& PART LIST
1 PC J SHORT SPINDLE
1 PC K LONG SPINDLE
1 PC L SHORT CROSS BAR
1 PC M LONG CROSS BAR
1 PC
N FOOT
3 PCS O
LONG SCREW
2 PCS P
SHORT SCREW
3 PCS Q
WOODEN DOWEL
R
GLUE
6 PCS
CAUTION:
MAXIMUM LOADING
CAPACITY IS 40 LBS.
DO NOT SIT, STAND, LEAN, WALK OR
JUMP! FAILURE TO COMPLY WITH
THIS CAUTION COULD RESULT IN
PERSONAL INJURY AND/OR
PROPERTY DAMAGE!
40 lbs (18.1 kg)
3 lbs
5 lbs
Weight Maximum 40 lbs (18.1 kg)
QTY
4 PCS
12 PCS
4 PCS
4 PCS
4 PCS
8 PCS
14 PCS
12 PCS
1 PC
