mycom 3225**C Series Instruction Manual page 2

Thank you for purchasing the
(hereinafter referred to as "this product").
This Instruction Manual (hereinafter referred to as "this manual") provides safety information and
operation and maintenance procedures, so that users correctly understand how to handle this product
and, as a result, can use it safely and efficiently. This manual is applicable to the following models:
3225LLLC-*B*-51 3225LLLC-*B*-61
3225LLC-*B*-51 3225LLC-*B*-61
3225MLC-*B*-51 3225MLC-*B*-61
3225SLC-*B*-51 3225SLC-*B*-61
* -51 (-61) may not be written. For more information, see 2.2 "Model designation of the compressor"
in this manual Chapter 2.
Make sure you read this manual before installing or using this product.
Keep this manual in a safe place near this product for quick reference.
Title
3225**C Instruction Manual
Revision
Issue date
No.
00 Nov. 14, 2014
01 Apr. 30, 2015
Feb.28.2018 Corrected Table 2-1&2-2, Figure 2-1～12, Table
02
Compound 2-stage Screw Compressor 3225**C
Preface
C-series compound 2-stage screw compressor 3225**C
3225LLMC-*B*-51
3225LMC-*B*-51
3225MMC-*B*-51
3225SMC-*B*-51
Revision History
2202MYJE-MY-C8-N_2018.02.
Major Contents of revisions
Overall review associated
electronic document, document No. change
Modified the constitution of Chapter 4 and
Chapter 5. Correction of describing, etc.
7-1&7-2. Corrected other errors. Deleted
Contact Information
3225LLMC-*B*-61 3225LLSC-*B*-51
3225LMC-*B*-61 3225LSC-*B*-51
3225MMC-*B*-61 3225MSC-*B*-51
3225SMC-*B*-61 3225SSC-*B*-51
Document No.
with reissue
i
2202MYJE-MY-C8-N_2018.02.
Preface
3225LLSC-*B*-61
3225LSC-*B*-61
3225MSC-*B*-61
3225SSC-*B*-61
First edition issue date
Nov. 14, 2014
Created/approved by:
as Ikehara / Hirao
Ikehara / Muta
Takenouchi・Ito/Kato
