ASSEMBLY INSTRUCTIONS

Uniform Large
Open Bookcase
Size (mm): 440L x 800W x 1870H
S-OS90-196T
01
Back Panel Top Panel
4
3
5
1
Side Panel L Base Panel
Assemble all panels in the following order.
Side Panel R
2
6
Fix Shelf
7
Shelf Panel
www.jasonl.com.au
Need help!
Call us on
1300 527 665

Function of Klix Cam

Turn for locking
75° Min - 195° Max
Make sure the arrow is
pointing upwards before
inserting into the panel's hole.
Insert Nylon Dowel
into Boring Hole.
Tighten Minifix
Connecting into
Nylon Dowel.
Insert collar stud into boring
holes, at the height you want
shelves.
Insert Minifix Housing
into Boring Hole.
