Installation, Operation and Maintenance Manual
LPV "Camel" Liquid Ring Medical Vacuum System
NASH Pump - Type 1 Configuration
Sizes: 3, 5, 7½ and 10 HP - Delta Series
3, 5, 7½ HP - MHF Series
This unit purchased from:
Date purchased:
Model number:
Serial number:
Option(s) included:
Any information, service or spare parts requests should include the machine serial number and be
directed to:
B
M
EACON
EDÆS
1800 Overview Drive
Rock Hill, SC 29730
Telephone: (803) 817-5600
Fax: (803) 817-5750
BeaconMedæs reserves the right to make changes and improvements to update
products sold previously and support materials without notice or obligation.
Issue Date: May 1, 2009
MAN 01 - 015
Advertisement
Chapters
Table of Contents
Troubleshooting
Summary of Contents for BeaconMedaes Lifeline Camel
- Page 1 Installation, Operation and Maintenance Manual LPV "Camel" Liquid Ring Medical Vacuum System NASH Pump - Type 1 Configuration Sizes: 3, 5, 7½ and 10 HP - Delta Series 3, 5, 7½ HP - MHF Series This unit purchased from: Date purchased: Model number: Serial number: Option(s) included:...
-
Page 2: Table Of Contents
"Camel" Liquid Ring Medical Vacuum Medical Systems Table of Contents Safety Precautions Installation 1.1 Uncrating 1.2 Location 1.3 Locations Above Sea Level 1.4 Vibration Control 1.5 Piping 1.6 Electrical requirements Preparation for Initial Start-up 2.1 Draining and Flushing 2.2 Preliminary Inspection General Operation 3.1 How the Vacuum System Works 3.2 Electrical Control Panel... -
Page 3: Safety Precautions
"Camel" Liquid Ring Medical Vacuum Medical Systems Safety Precautions The operator should carefully read the entire contents of this manual before installing, wiring, starting, operating, adjusting and maintaining the system. The operator is expected to use common-sense safety precautions, good workmanship practices’ and follow any related local safety precautions. -
Page 4: Installation
"Camel" Liquid Ring Medical Vacuum Medical Systems 1. Installation 1.1 Uncrating Upon delivery, the condition of the LifeLine "Camel" Medical Vacuum System should be carefully inspected. Any indication of damage by the carrier should be noted on the delivery receipt, especially if the system will not be immediately uncrated and installed. -
Page 5: Locations Above Sea Level
"Camel" Liquid Ring Medical Vacuum Medical Systems 1.3 Locations Above Sea Level The safety relief valves and vacuum control switches on the Lifeline “Camel” Vacuum systems are factory set for an altitude less than or equal to 2000 ft. However, if the altitude is greater than 2000 ft, certain adjustments may be necessary to compensate for a lower barometric pressure. -
Page 6: Piping
"Camel" Liquid Ring Medical Vacuum Medical Systems 1.5 Piping Connect piping to the system so that no strain is applied at the point of connection. Pipe strain on vacuum pump castings may cause hard-to-trace troubles after the system is in operation. Support inlet and discharge piping near the system. - Page 7 "Camel" Liquid Ring Medical Vacuum Medical Systems 1.5.4 Exhaust Piping Connect pipe to the air discharge connection on the Camel reservoir. This exhaust line must be piped outside of the building in accordance with NFPA 99. To ensure that no restriction of airflow will occur, size the piping according to the following chart.
- Page 8 "Camel" Liquid Ring Medical Vacuum Medical Systems 1.5.5 Air Discharge Piping Connect pipe to the air discharge connection on the Camel reservoir and pipe outdoors per NFPA99 or applicable code. 1.5.6 Flex Hoses...
-
Page 9: Electrical Requirements
"Camel" Liquid Ring Medical Vacuum Medical Systems 1.6 Electrical Requirements WARNING! BE SURE THAT ALL POWER IS TURNED OFF PRIOR TO PERFORMING ANY WORK ON THE ELECTRICAL PANEL! Refer to the electrical diagram provided with the unit before starting any installation or maintenance work. -
Page 10: Preparation For Initial Start-Up
"Camel" Liquid Ring Medical Vacuum Medical Systems 2. Preparation for Initial Start-up 2.1 Draining and Flushing WARNING! ISOLATE POWER SOURCE TO THE MOTOR OF EACH VACUUM PUMP TO ENSURE THAT ACCIDENTAL STARTING CANNOT OCCUR. Contact your BeaconMedæs representative for start-up assistance. Before starting the system, proceed as follows: a. -
Page 11: Preliminary Inspection
"Camel" Liquid Ring Medical Vacuum Medical Systems 2.2 Preliminary Inspection Perform the following preliminary inspections on each of the vacuum pumps separately before starting the system: a. Inspect all piping to make certain that the proper connections have been made in accordance with the installation drawing(s) supplied with your system. -
Page 12: General Operation
"Camel" Liquid Ring Medical Vacuum Medical Systems 3. General Operation 3.1 How the Vacuum System Works (See Figures 3-1-1 & 3-1-2) The BeaconMedæs "Camel" Liquid Ring Medical Vacuum System works basically like other vacuum systems with the air from the system piping (vacuum system inlet) being drawn through the vacuum control tank, then through the inlet check valve, and finally into the inlet of the vacuum pump. - Page 13 "Camel" Liquid Ring Medical Vacuum Medical Systems 3.1.4 Camel Reservoir Tank The Camel reservoir has three specific functions. It separates the air and water discharge from the vacuum pumps by means of a specially designed muffler/baffle system. It reclaims discharge water and holds it for use as re- circulated seal water.
-
Page 14: Relief Valve
"Camel" Liquid Ring Medical Vacuum Medical Systems Minimum Run Timer(s) All LifeLine "Camel" vacuum systems incorporate minimum run timers to minimize the starts and stops on the vacuum pumps. For multiplex systems, there is a minimum run timer built into the PLC for each pump, but they all have the same time value. -
Page 15: Vacuum Check Valve
"Camel" Liquid Ring Medical Vacuum Medical Systems 3.6 Vacuum Check Valve Vacuum check valves are designed and engineered for the unique problems of the vacuum field. Featuring extremely low pressure drop, they open on less than 1/10” W.C. Special design permits a lightweight, stamped stainless steel disc to open fully, providing full flow with minimum resistance. -
Page 16: Start-Up And Operating Checks
"Camel" Liquid Ring Medical Vacuum Medical Systems 4. Start-up and Operating Checks 4.1 Manual Operation Check manual operation as follows: a. Close shut-off valve in inlet line to isolate system. Air will enter through relief valve. b. Make certain that the seal water shut-off valve is open. c. -
Page 17: Automatic Operation
"Camel" Liquid Ring Medical Vacuum Medical Systems 4.2 Automatic Operation Check automatic operation as follows: a. Set the HAND-OFF-AUTO selector switch to the AUTO position on all the vacuum pumps. b. Monitor the vacuum gauge and check that each vacuum pump starts when the vacuum reaches the low vacuum setting of the vacuum switch. -
Page 18: Trouble Shooting
"Camel" Liquid Ring Medical Vacuum Medical Systems 5. Trouble Shooting General Operation Problem Solution No power to the system 1.) Check main circuit breaker 2.) Check system disconnect(s) 3.) Check fuses in control panel 4.) Check for 115V at output of control transformer(s) Manual Operation - HAND-OFF-AUTO switch in HAND position Vacuum pump will not start. - Page 19 "Camel" Liquid Ring Medical Vacuum Medical Systems Manual Operation - HAND-OFF-AUTO switch in HAND position Problem Solution Change in vacuum pump operating CAUTION temperature, noise or vibration SHUT DOWN VACUUM PUMP IMMEDIATELY. 1.) If the vacuum pump bearing brackets bearing housing temperature exceeds 140 °...
-
Page 20: Maintenance
"Camel" Liquid Ring Medical Vacuum Medical Systems 6. Maintenance 6.1 Routine Checks WARNING! BE SURE THAT ALL POWER IS TURNED OFF PRIOR TO PERFORMING ANY MAINTENANCE. 6.1.1 Weekly a. Check the temperature of the bearing housing area or bearing brackets on the vacuum pump. b. -
Page 21: Replacement Parts
"Camel" Liquid Ring Medical Vacuum Medical Systems 7. Replacement Parts Service and parts for BeaconMedæs systems and NASH pumps are assured through a network of sales and service offices. For information, service or parts contact your nearest BeaconMedæs representative. If the location of the nearest office is unknown, or you are requesting parts and service, contact BeaconMedæs at 1- 800-756-2590, Fax 803-817-5750. -
Page 22: Maintenance Record
"Camel" Liquid Ring Medical Vacuum Medical Systems 8.0 Maintenance Record Model Number Serial Number Installation Date Date of Service Hours Vacuum Level Water Level Ambient Temp. Pump Operating Temp. Rebuild/ Replace Solenoids Replace Flow Control Valves Misc. Serviced... - Page 23 "Camel" Liquid Ring Medical Vacuum Medical Systems 8.0 Maintenance Record Model Number Serial Number Installation Date Date of Service Hours Vacuum Level Water Level Ambient Temp. Pump Operating Temp. Rebuild/ Replace Solenoids Replace Flow Control Valves Misc. Serviced...
- Page 24 "Camel" Liquid Ring Medical Vacuum Medical Systems Appendix A - NASH "Delta" EC Pump Information Introduction These directions should be read carefully before the installation and start up of your Nash vacuum pump. In order to ensure operator safety and to avoid damage to the equipment it is important that the operators and the personnel in charge of the equipment are fully acquainted with the safety instructions in Section A.1.
-
Page 25: Section A.1 Safety
"Camel" Liquid Ring Medical Vacuum Medical Systems Contents Page Section A.8 Storage A-12 A.8.1 2-6 Months A-12 A.8.2 6+ Months A-12 Section A.9 Repair and Warranty Orders A-13 Section A.10 Spare Parts A-13 Section A.11 Parts List A-13 Cross Sectional Drawings A-14 Delta EC 50M A-14... -
Page 26: Section A.2 Description
"Camel" Liquid Ring Medical Vacuum Medical Systems Description This bulletin contains information for owners and operators of Nash "Delta" EC series vacuum pumps. This information includes a description of how to operate and maintain these vacuum pumps. A.2.1 How the Nash vacuum pump works The "Delta"... -
Page 27: Inlet Gas Or Vapor
"Camel" Liquid Ring Medical Vacuum Medical Systems Table A-1 Vacuum Operating Limits 3500 RPM (EC 50) Maximum Rotation 1800 RPM (EC 90/125/150/250) and Speed Maximum Vacuum 29" HgVac/1.0 HgAbs (980 mbar/33 mbar Abs) 0.5 PSIG (0.03 Barg) Maximum Discharge Pressure 212 °... -
Page 28: Section A.4 Installation
"Camel" Liquid Ring Medical Vacuum Medical Systems Installation A.4.1 On Site Positioning The "Delta" EC pumps do not require any specialized foundations in order to be mounted. The pump should be set horizontally on an even surface and fixed through the motor feet on close-coupled pumps, or through the bracket feet on pedestal mounted pumps. -
Page 29: Section A.5 Operation
"Camel" Liquid Ring Medical Vacuum Medical Systems Operation A.5.1 Preparation for initial start-up Contact your BeaconMedæs representative for start up assistance. A.5.2 Service Liquid Piping connections must be made to a service liquid supply. The usual service liquid is fresh water at 60°F (15°C). WARNING The service liquid flow must be started before starting the pump drive motor, even if the pump is only being operated to check the direction of... -
Page 30: Starting And Stopping The Pump
"Camel" Liquid Ring Medical Vacuum Medical Systems 8. Inspect all pump control components (valves, gauges, etc.) to ensure that they have been installed in accordance with the BeaconMedæs installation drawing(s). Make certain that these components are correctly oriented in the piping scheme in order to achieve the proper direction of flow and functional operation. -
Page 31: Stopping
"Camel" Liquid Ring Medical Vacuum Medical Systems A.5.5.2 Stopping The following steps should be followed when shutting down the pump: 1. Turn off the electric power to the drive motor. 2. Close the service liquid shut off valve. In the case of a solenoid valve this will automatically close when power is removed. -
Page 32: Section A.6 Maintenance
"Camel" Liquid Ring Medical Vacuum Medical Systems Maintenance A.6.1 Introduction One of the main features of the "Delta" EC pump is its simple design, great sturdiness and requirement of minimum maintenance. In order to avoid inconvenience and trouble, the operators should be reminded that: The pump should not be operated without service liquid. -
Page 33: Section A.7 Disassembly And Re-Assembly
"Camel" Liquid Ring Medical Vacuum Medical Systems A.7 Disassembly and Re-Assembly A.7.1 Before Disassembling Disassembly of the "Delta" EC pump for repairs and maintenance is an easy operation, but should be carried out only by skilled personnel provided with suit-able equipment. If these directions are not adhered to, faulty operation or damage not covered by warranty could result. -
Page 34: Disassembly Of Rotor And Mechanical Seal
"Camel" Liquid Ring Medical Vacuum Medical Systems A.7.2.2 Disassembly of Rotor and Mechanical Seal 1. Remove small flange (232), O-Ring (401), and hex nut (233). 2. Pull rotor (230) from shaft. Use two screwdrivers to assist in prying the rotor from the shaft. 3. -
Page 35: Section A.8 Storage
"Camel" Liquid Ring Medical Vacuum Medical Systems Storage A.8.1 2-6 Months When the pump is expected to be inoperative for a period of 2-6 months, it is recommended that the pump be completely drained as described in Section A.4.3. After draining, pour rust preventative into the suction and operate the pump for a very short time. -
Page 36: Section A.9 Repair And Warranty Orders
"Camel" Liquid Ring Medical Vacuum Medical Systems Repair and Warranty Orders If a warranty is claimed, the pump is to be shipped to our company in a closed package. It is to be emptied and cleaned before packaging. For safety reasons, if the pump has been working with harmful or dangerous liquids it is to be washed with appropriate materials. -
Page 37: Delta Ec 50M
"Camel" Liquid Ring Medical Vacuum Medical Systems Cross Sectional Diagrams Delta EC 50M Delta EC 90M, EC 125M, EC 150M A-14... -
Page 38: Delta Ec 250M
"Camel" Liquid Ring Medical Vacuum Medical Systems Delta EC 250 M A-15... - Page 39 "Camel" Liquid Ring Medical Vacuum Medical Systems Appendix B - NASH MHF Pump Information Introduction These directions should be read carefully before the installation and start up of your Nash vacuum pump. In order to ensure operator safety and to avoid damage to the equipment it is important that the operators and the personnel in charge of the equipment are fully acquainted with the safety instructions in Section B.1.
-
Page 40: Safety
"Camel" Liquid Ring Medical Vacuum Medical Systems Safety B.1.1 Operational While the pump is running the following safety pre-cautions should be adhered to: - Avoid the suction and discharge connections. - Do not touch the casing and the cover while the pump is working and conveying hot fluids. - Do not go close to the pump while it is working with a special or toxic fluid and the mechanical seal is leaking. -
Page 41: Description
"Camel" Liquid Ring Medical Vacuum Medical Systems Description This bulletin contains information for owners and operators of Nash MHF 50, MHF 80, and MHF 120 vacuum pumps. This information includes a description of how to operate and maintain these vacuum pumps. B.2.1 How the Nash vacuum pump works The main functional assemblies of a Nash vacuum... -
Page 42: Operation
"Camel" Liquid Ring Medical Vacuum Medical Systems Operation B.3.1 Preparation for initial start-up Contact your BeaconMedæs representative for start up assistance. B.3.2 Liquid Compressant (Seal Liquid) Proper operation of the vacuum pump requires that liquid compressant (seal liquid) be supplied at the proper rate of flow. - Page 43 "Camel" Liquid Ring Medical Vacuum Medical Systems d. Inspect all vacuum pump control devices (such as flow control valves, solenoid valves, orifices, etc.) to make certain that they have been located in accordance with the BeaconMedæs installation drawing(s). Make certain that these components are correctly oriented in the piping scheme in order to achieve the proper direction of flow and functional operation.
-
Page 44: Troubleshooting
"Camel" Liquid Ring Medical Vacuum Medical Systems Troubleshooting Nash Type MHF vacuum pumps require little attention other than periodic checking of the ability of the vacuum pump to obtain full volume or maintain constant vacuum. If operating difficulties arise, make the following checks: a. -
Page 45: Maintenance
"Camel" Liquid Ring Medical Vacuum Medical Systems Maintenance B.5.1 Periodic Maintenance B.5.1.1 General a. Check that the seal liquid flow rate is as specified in Table B-1. B.5.1.2 Monthly a. Clean the seal liquid line strainer. B.5.1.3 Semi-Annually Check and lubricate the motor bearings as specified in the motor manufacturer's standard recommendations. -
Page 46: Disassembly And Re-Assembly
"Camel" Liquid Ring Medical Vacuum Medical Systems B.6 Disassembly and Re-Assembly B.6.1 Before Disassembling The vacuum pump operates most efficiently when the rotor-to-head clearance is the same as that set by the factory. Continued use over a long period of time may cause this internal clearance to change. If pump operation indicates that trouble has developed, it may be necessary to dismantle the pump to inspect for readjustment of this clearance. - Page 47 "Camel" Liquid Ring Medical Vacuum Medical Systems Before disassembling the pump the following must be done: 1. Isolate, lock, and tag-out all sources of electrical input. 2. Isolate, drain and bleed the pump and piping. 3. Disconnect the suction, discharge, and service liquid lines. B.6.2.1 Disassembly Procedure To disassemble the vacuum pump: Disconnect piping from air inlet and discharge and the liquid compressant inlet ports.
- Page 48 "Camel" Liquid Ring Medical Vacuum Medical Systems Note: If mechanical puller screw has removable tip, remove tip to expose hollow end and do not center punch rotor nut (110-1) in step j. j. Center punch top of rotor nut and install rotor nut on shaft (302 or 401) finger-tight to protect end of shaft.
-
Page 49: Inspection Of Disassembled Parts
"Camel" Liquid Ring Medical Vacuum Medical Systems s. If the shaft sleeve (114) is damaged or worn and requires replacement, use propane torch and 350°F (177°C) temp stick, and heat shaft sleeve to 300° to 350°F (149° to 177°C) to loosen Loctite 262 that bonds shaft sleeve to motor shaft. - Page 50 "Camel" Liquid Ring Medical Vacuum Medical Systems Note If the motor is not mounted on a base, clamp or bolt the motor feet to a sturdy flat work surface so that lobe (106) flange will overhang edge of work surface when installed. CAUTION Make certain that lobe (106) is centered on shaft and not cocked when performing the following step.
-
Page 51: Adjusting Rotor-To-Head Clearance
"Camel" Liquid Ring Medical Vacuum Medical Systems k. On stainless steel pumps: 1. Insert rotor key (110-4) into keyway in shaft. 2. Install rotor (110) on shaft. 3. Install rotor washer (110-2) on shaft. If 4. Wedge balled-up rag between rotor and lobe. Turn rotor clockwise until rag is jammed and prevents rotor from turning. - Page 52 "Camel" Liquid Ring Medical Vacuum Medical Systems 3. Using feeler gauge, measure gap A between lobe and motor mounting flanges at four points 90 degrees apart. Make certain that feeler gauge leaves are tight fit in gap. Record four measurements. 4.
-
Page 53: Repair And Warranty Orders
"Camel" Liquid Ring Medical Vacuum Medical Systems 15. Install rotor washer (110-3) on shaft. 16. Perform step j.12, Section B.6.4. 17. Perform step j.l3, Section B.6.4, and fill lathe center in end of shaft with Loctite 262. 18. Perform steps f.l4, f.15 and f.l6, Section B.6.4. 19. -
Page 54: Parts List
"Camel" Liquid Ring Medical Vacuum Medical Systems Parts List Refer to the cross sectional diagrams for item identification. PARTS LIST Item Number Qty. Description Item Number Qty. Description Shaft Seal Assembly 106-2 Lobe Stud Rotating Seal Rotor Stationary Seal *110-1 Rotor Nut †2-3 Seal Spring...
