ASSEMBLY INSTRUCTIONS
Uniform Medium
Open Bookcase
Size (mm): 800L x 440D x 1170H
S-OS90-117T
A
B
E
F
COMPONENTS
A
Minifix Housing x16
B
Collar Stud x10
C
Rubber Wood Dowel M8 x40mm x12
D
Minifix Connecting Bolt x16
E
Nylon Dowel x16
F
Adjustable Leveller N2880 x5
G
Leveller N2880 Cap x5
H
Deco Cap x5
I
Top Panel x1
J
Back Panel x1
K
Side Panel x2
L
Base Panel x1
M
Shelf Panel x2
www.jasonl.com.au
C
D
G
H
Need help!
Call us on
1300 527 665
D/E
Top panel
D/E
D/E
C
A
C
A
C
B
A
Back panel
C
B
A
A
C
C
D/E
D/E
Base panel
D/E
D/E
D/E
A
C
A
A
D/E
D/E
C
B
B
A
Side panel
C
B
B
A
D/E
D/E
A
C
A
D/E
Shelf panel
D/E
