Summary of Contents for Echogear EGLT2
- Page 1 #YourGearUpgraded Extendable Tilt TV Wall Mount Model EGLT2 INSTRUCTION MANUAL...
- Page 2 Also check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly contact The Echogear Pros at www.echogear.com. or use of this product,...
- Page 3 Stud Kit: model EGHWSS. install into Sold online at ECHOGEAR.com UUHHH ?!? drywall alone or Amazon. Unsure? Steel Stud Kit required (not included) For questions, contact the Echogear pros: Perfect! Perfect! www.echogear.com Grab Your Tools 1/2 in. (13 mm) Socket Tape Pencil...
- Page 4 What’s in the Box WARNING: DON'T FEED TO CHILDREN — This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included in this kit will be used.
- Page 5 Order the Steel Stud Anchor Kit: Order the Steel Stud Anchor Kit: Drill Bit Model EGHWSS. Sold online at Model EGHWSS. Sold online at 1/4 in. 1/4 in. Included with ECHOGEAR.com or Amazon. ECHOGEAR.com or Amazon. (qty. 4) (qty. 4) (qty. 4) the EGHWSS kit...
- Page 6 STEP 1 Attach the TV BRACKETS TO YOUR TV TV Screw Diameter TV Screw Diameter TV Screw Length STEP 1.1 STEP 1.1 STEP 1.2 Only one screw size fits your TV. NO SPACER SPACER NEEDED Flat Back TV Flat Back TV Rounded or Irregular Back TV with Extra Space...
- Page 7 If your TV included inset spacers or wall Secure the TV Brackets STEP 1.3 mount adapters, see Troubleshooting (PAGE 20). NO SPACER SPACER NEEDED Alternate Spacer CAUTION: setups Ensure TV brackets are equally centered on your TV AND securely fastened in place.
- Page 8 STEP 2 I nstall the Wall Plate WOOD STUD STEEL STUD CONCRETE INSTALLATIONS, INSTALLATIONS, INSTALLATIONS, follow STEP 2B on PAGE 12 follow STEP 2A on PAGE 10 follow STEP 2C on PAGE 14 CAUTION: Avoid potential personal Min. Wood Stud Depth: injuries and property damage! nominal 102 mm (4 in.) ½...
- Page 9 STEP 2A Wood Stud) Install the Wall Plate Find a Stud Align the Template STEP 2A.1 STEP 2A.2...
- Page 10 Drill Holes Secure Wall Plate STEP 2A.3 STEP 2A.4 6.9 cm ( 2¾ in.) 5.5 mm (7/32 in.) CAUTION: Avoid potential personal injury or property damage! All four lag screws MUST BE firmly tightened to prevent unwanted Go to STEP 3 movement of the wall plate assembly.
- Page 11 STEP 2B CONCRETE) Install the Wall Plate Align the Template Drill Holes STEP 2B.1 STEP 2B.2 7.6 cm (3 in.) M i n . h o l e S p a c 6 1 0 10 mm i n g : (3/8 in.) ( 2 4 i n .
- Page 12 Insert Concrete Anchors Secure Wall Plate STEP 2B.3 STEP 2B.4 CAUTION: Avoid potential personal injury or property damage! All four lag screws MUST BE firmly tightened to prevent unwanted Go to STEP 3 movement of the wall plate assembly. on PAGE 16...
- Page 13 STEP 2C STEEL Stud) Install the Wall Plate Find a Stud Drill Holes STEP 2C.1 STEP 2C.2 25 mm (1 in.) 13 mm (1/2 in.)
- Page 14 Install Anchors Secure Wall Plate STEP 2C.3 STEP 2C.4 CAUTION: Avoid potential personal injury or property damage! All four lag screws MUST BE firmly tightened to prevent unwanted movement of the wall plate assembly.
- Page 15 STEP 3 Hang Your TV Attach Your TV STEP 3.1 HEAVY! You may need assistance with this step. TIP: Tilt TV brackets as shown for ease of installation.
- Page 16 Secure Your TV STEP 3.2 IMPORTANT: BEFORE MOVING YOUR TV, securely tighten down screws to properly install the assembly. CAUTION: Avoid potential personal injuries or property damage! Screws must be installed to secure arms to wall plate . Periodic tightening may be required.
- Page 17 Adjustments LEVEL TILT EXTEND / RETRACT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust side If your TV doesn't extend or retract tension knobs properly, remove your TV (See PAGE 19), then reinstall following STEP 3 on PAGE 16.
- Page 18 REMOVING THE TV TV LATERAL SHIFT Remove your TV BEFORE shifting side-to-side: HEAVY! You may need Loosen screws to remove your TV from the wallplate. assistance with this step. Rehang your TV on the wallplate where desired (STEP 3). Reinstall your TV and screws (STEP 3).
- Page 19 Troubleshooting If you are uncertain about your hardware selection, TV Supplied contact Customer Service TV supplied spacers Spacers : Use your TV supplied spacer and spacer for: : Use your TV supplied spacer for flat back TVs (AND you want your TV closer to the wall).
- Page 20 Milestone assumes no responsibility for accuracy, completeness or su ciency of the information contained in this document. ©2018 Milestone AV Technologies. All rights reserved. ECHOGEAR is a Milestone brand. ECHOGEAR and the ECHOGEAR logo are trademarks of Milestone. Made in China.
