Dell Latitude 5424 Rugged Owner's Manual page 43

Integrated Graphics Controller
Maximum Vertical Refresh Rate
Operating Systems Graphics/ Video API Support
Supported Resolutions and Max Refresh Rates (Hz) (Note: Analog
and/or digital)
Numbers of Displays Supported
Intel HD Graphics 520
Table 35. Intel HD Graphics 520 Graphics specification
Integrated Graphics Controller
Bus Type
Memory Interface
Graphics Level
Estimated Maximum Power Consumption (TDP)
Display Support
Maximum Vertical Refresh Rate
Operating Systems Graphics/ Video API Support
Supported Resolutions and Max Refresh Rates (Hz) (Note: Analog
and/or digital)
Intel UHD Graphics 620 (8th Generation Intel Core)
Up to 85 Hz depending on resolution
DirectX 11 (Windows 7/8.1), DirectX 12 (Windows 10), OpenGL 4.3
System ports:
• Max Digital: (HDMI) 4096x2304@24 Hz
• Analog: (VGA) system (14 inches/15 inches) or docking
2048x1152 @60 Hz
Docked:
• Max Digital: (DisplayPort 1.2) 3860 x2160 @60 Hz
• Max Digital: (SL-DVI) 1920x1080 @60 Hz
• Analog: (VGA) system (14 inches/15 inches) 2048x1152 @60 Hz
For 3 displays:
• (native or docked) up to 1920x1200 max resolution each
• System Ports - 3 displays max with LCD plus 1 display max on
each output (HDMI, VGA (14 inches/15 inches)
• Docked - 3 displays max (combo of LCD, VGA, DP, HDMI)
Intel UHD Graphics 620 (8th Generation Intel Core)
Internal PCIe
N/A (unified memory architecture)
GT2
15 W (included in the CPU power)
On System:
HDMI 2.0
USB Type-C
Up to 85 Hz depending on resolution
DirectX 11 (Windows 7/8.1), DirectX 12 (Windows 10), OpenGL 4.3
System ports:
• Max Digital: (HDMI) 4096x2304@24 Hz
• Analog: (VGA) system (14 inches/15 inches) or docking
2048x1152 @60 Hz
Docked:
• Max Digital: (DisplayPort 1.2) 3860 x2160 @60 Hz
• Max Digital: (SL-DVI) 1920x1080 @60 Hz
• Analog: (VGA) system (14 inches/15 inches) 2048x1152 @60 Hz
For 3 displays:
• (native or docked) up to 1920x1200 max resolution each
Technology and components 43
