DPLLD Transducer Installation

This section discusses DPLLD transducer installation for the following DPLLD approved pumps:
• Red Jacket Standard and Quantum pumps - DPLLD transducer/SwiftCheck valve (page 8)
• Red Jacket Standard and Quantum pumps - DPLLD transducer/Pressurstat (page 12)
• Red Jacket Quantum with SpikeCheck Valve (page 13)
• The Red Jacket (page 14)
• Red Jacket Maxxum Big-Flo (page 15)
• FE-Petro (page 16)

Red Jacket Standard and Quantum Pumps (DPLLD w/SwiftCheck)

Use this installation procedure to install a DPLLD transducer with a SwiftCheck valve in a Red Jacket Standard or
Quantum pump.
WARNING
When servicing equipment, use non-sparking tools and use caution when removing or in-
stalling equipment to avoid generating a spark.
1. If a ball valve is installed down line from the pump, close it.
2. Do one of the following:
a. If the submersible turbine pump is equipped with a mechanical LLD, remove the mechanical unit and any
related tubing and fittings, or
b. If the submersible turbine pump is not equipped with a mechanical LLD, remove the 2-inch mechanical
LLD port plug.
3. Ensure that the sealing surface for the SwiftCheck valve's external o-ring is smooth and free from corrosion,
pitting, and any material build-up [Figure 3].
WARNING
Failure to ensure a smooth seal surface can result in false line leak alarms.
OFF
Disconnect, lock out, and tag all AC power to the TLS console, dispens-
ers and submersible pumps.
