Phonak ZoomLink+ Quick Reference Manual page 2

Quick Reference Guide
A pupils radio aid system consists of
two parts:
• Transmitter (worn by teacher) and
• Receivers (worn by pupil)
For audio shoe advice visit
ZoomLink+ transmitter
www.phonak.com/eschooldesk
3
4
5
1
2
6
7
8
A
B
C
Audio Shoes MLxi receiver
On/Off Button
Key
Phonak recommends
that you push the
Twin Microphone Ports
1
Middle "Zoom" button
On/Off & Mic Positions
2
down for 2 seconds to
Toggle Button turn off and on for
3
normal teaching.
Lavaliere Cord / Antenna
4
Clip
5
LCD Display
LCD Display
6
7 Channel Select
ZoomLink+ Interface Port
8
Synchronising
To synchronise a receiver, turn the
ZoomLink+ on within a 50cm range
of the receiver. The receiver should
beep through the hearing aid to
confirm this action.
Change Channel
Push button down
ZoomLink+ Interface
with pen to scroll
channels.
Audio in
A
Release to stop
Mic in
B
and synchronise
Charging Port
C any receivers
within range.
Wearing & Adjustment
Integrated
receiver
Channel Number
Battery Status
Mic Position
- Superzoom
- Zoom
- Omni (360°)
Standard 3.5mm audio cable
ZoomLink+ Compatability
Zoomlink+ is fully compatible with
ALL of Phonak's FM receivers, past
and present (examples shown).
Simply turn on the transmitter...
and start teaching!
For more information about your ZoomLink+ and how to use other functions
please consult the user manual, or visit www.phonak.com/eschooldesk
Microphone Directionality
Zoomlink+ has three microphone settings...
Superzoom
6 inches
Narrow beam directionality for, in exceptional
circumstances, pointing at sound source, or
extremely harsh teaching environments.
Zoom (Recommended)
The recommended directional setting for
everyday teaching scenarios.
Omni-directional
For using in quiet, group discussion situations
by placing at the opposite end of the table.
Charging
ZoomLink+ interface
should be attached to
charge the ZoomLink+
or attach external
devices.
IF
OR
✓ ✓
