Summary of Contents for Brinno TLC 2000
-
Page 3: Table Of Contents
CONTENTS Before You Start What's in the Box Camera Parts Display Icons Initial Operation Install microSD Card & Batteries Power On/ Off Power Saving Mode Set Date & Time Prepare For Shooting Change Capture Mode Change Capture Interval Time Lapse/ Step Video Recording Stop Motion Recording Still Photo Recording... - Page 4 CONTENTS Menu Settings Main Menu More Settings Specifications...
-
Page 5: Before You Start
Before You Start... -
Page 6: What's In The Box
WHAT'S IN THE BOX TLC2000 USB-C Cable Time Lapse Camera TLC 2000 Lens Cover 2 AA Batteries User Manual User Manual Screwdriver 8GB microSD Card... -
Page 7: Camera Parts
CAMERA PARTS 1. Power Button 6. Camera Reset Button 7. USB-C Socket Shutter/ Back to Preview Button 3. LED Status Indicator 8. Lens 4. Memory Card Door 9. Battery Door 5. microSD Card Slot... - Page 8 CAMERA PARTS 10. LCD Screen Next/ Capture Interval Button 14. Tripod Mount (size: ¼”) Previous/ Capture Mode Button 12. Menu/ Info/ OK Button...
-
Page 9: Display Icons
DISPLAY ICONS 1. Scene DAY: Daytime TWLT: Twilight NITE: Night 2. HDR 3. Schedule 4. Battery indicator 5. Capture mode TL: Time Lapse SV: Step Video SM: Stop Motion S I : Still Photo 6. Menu/ Info 7. Capture interval... -
Page 10: Initial Operation
Initial Operation... -
Page 11: Install Microsd Card & Batteries
INSTALL microSD CARD & BATTERIES 1. Insert microSD card. 2. Open battery door Then install 2 AA batteries. Support up to 128GB microSD card. For 64 or 128 GB microSD card, follow instruction on the LCD screen to format the card before using it the first time. -
Page 12: Power On/ Off
POWER ON / OFF Power On 5 secs 1. Power on: hold “Power Button” for 5 secs. 2. Power off: hold “Power Button” for 3 secs. -
Page 13: Power Saving Mode
POWER SAVING MODE When the camera is turned on, and there is no recording job: Sleep Mode The camera goes to sleep mode to save power after 20 seconds without activity. The LED indicator turns solid green Press “ ” button to wake up the camera. Power off The camera shuts down after 30 seconds without activity. -
Page 14: Set Date & Time
SET DATE & TIME The date & time menu appears when the camera is first turned on. DATE & TIME 2018 / 06 / 04 09 : 41 : 05 NEXT 1. Set the numeric value using “ ”. 2. Press “ ”... -
Page 15: Prepare For Shooting
Prepare For Shooting... -
Page 16: Change Capture Mode
CHANGE CAPTURE MODE ” button to go to CAPTURE MODE 1-1. At preview screen, press “ setting. 1-2. Select desired CAPTURE MODE and press “ ” button to confirm and return to preview screen. -
Page 17: Capture Modes
CAPTURE MODES Capture mode Description Camera captures series of photos at a time Time Lapse interval of your choice, and auto combines them into a ready-to-view time lapse video. Camera records a short video clip at a selected capture interval, and auto combines those clips Step Video to a ready-to-view step video. -
Page 18: Change Capture Interval
CHANGE CAPTURE INTERVAL ” button to go to CAPTURE 2-1. At preview screen, press “ INTERVAL setting. 2-2. Select your desired interval and press “ ” button to confirm and return to preview screen. -
Page 19: Capture Interval
CAPTURE INTERVAL Capture mode Interval options Time Lapse Select the desired capture rate Burst Length Step Video Burst Interval Stop Motion Still Photo... -
Page 20: Time Lapse/ Step Video Recording
TIME LAPSE / STEP VIDEO RECORDING Start 3-1. At TIME LAPSE or STEP VIDEO mode, press “ ” button to select capture interval. Press “ ” button to return to preview screen. 3-2. Press “SHUTTER” button to start recording. 3-3. The LCD screen displays “REC” icon along with beep sound. The LCD screen then turns off to save power. - Page 21 TIME LAPSE / STEP VIDEO RECORDING Stop 3-4. Press“SHUTTER” button to wake up LCD screen. The camera stops recording and starts post-editing video immediately. 3-5. LCD screen displays “PROCESSING” icon accompanied by beep sound to confirm the completion of video post-editing. 3-6.
-
Page 22: Stop Motion Recording
STOP MOTION RECORDING Start 4-1. At STOP MOTION mode, press “SHUTTER “ button. LCD screen shows “Initializing Stop Motion “ followed by a beep to start recording. 4-2. Press “SHUTTER “ button to capture each single frame. Stop 4-3. Hold “SHUTTER“button for 3 secs to stop recording. LCD screen displays “Closing Stop Motion“... -
Page 23: Still Photo Recording
STILL PHOTO RECORDING 5-1. At STILL PHOTO mode, press “SHUTTER“ along with beeps to capture one photo each time. -
Page 24: Menu Settings
MENU SETTINGS 1. At preview screen, press “ ” button to go to MENU SETTINGS screen. 2. At MENU SETTINGS, press “ ” or “ ” button to switch to menu options. 3. Press “ ” button to enter the setting. 4. -
Page 25: Main Menu
MAIN MENU Setting Level I Level II Displays current Info camera status Time Lapse Step Video Capture Mode Stop Motion Still Photo Time Lapse Burst Length Step Video Capture Interval Burst Interval Not available for Stop Motion Stop Motion and Still Photo Still Photo mode Daytime... - Page 26 MAIN MENU Setting Level I Level II HDR Enable On , Off Flicker Filter None / 60 Hz / 50 Hz Only available for Schedule On, Off Time Lapse mode Auto, tungsten, fluorescent (1), White Balance fluorescent (2), cloudy, shadow, daylight Image Setting Contrast Saturation...
-
Page 27: More Settings
MORE SETTINGS Setting Option LED Indicator On , off Date & Time Set camera date & time Time Stamp On , off 1080P Resolution 720P Camera ID Zoom in Focus Mode Zoom out Exit Playback Rate 1, 5, 10, 20, 30 FPS System Info Camera firmware version Format SD Card... -
Page 28: Specifications
SPECIFICATIONS Model TLC2000 Resolution 1080P Aperture F2.0 Field of View 118° Time Lapse, Step Video, Capture Mode Stop Motion, Still Photo LCD Screen 2.0” TFT LCD microSD/ microSDHC/ microSDXC Storage (up to 128 GB) 2 AA Batteries Power Source DC IN 5V 1A (USB-C connector) Operating Temperature 32 °F ~ 113 °F (0 °C ~ 45 °C) Size (WxHxD) - Page 29 T h e p r o d u c t f e a t u r e s , s p e c i f i c a t i o n s s h e e t s a n d instructions may differ from actual products. Please refer to Brinno official site for the latest version of user manual.
