Point - 5
Connect two pairs of wires to the head motion control contractors; short circuit (in the first or
the second pair) will cause switching of the reduction contractor (the first pair) and of the
increase contactor (the second pair). Adjust the cable length to the mounting space of the
adjuster. Cable ends should be fitted with connection sleeves or tin-plated.
Point - 6
Prepared cables connections and casing assembly of the controller.
After creation of the all required connections next step is to connect them with the
controller's main plate.
In the back casing please screw in two PG chokes facing nuts from the inside. Please lead
through mounted chokes follows cables:
- through the biggest one, wires of the head saw contactors steering (two pairs of the cables
from steering buttons)
- though middle one, cable of the rotating encoder
- though choke which is the nearest of the casing middle, power cable 12 V (connection
SEC 12 V from the transformer TSS8/001).
Please connect power cable 12 V (with prepared cables' tips) to the junction marked as 12V
on the controller's main plate.
Contactors steering wires connect with junctions on the controller's main plate as follow:
- no. 1 pair of cables of the reduce dimension with junction marked as DWN
- no. 2 pair of the increasing dimension with junction marked as UP.
Magnetic encoder cables please connect with junctions marked ENCODER as follow:
- brown cable of MSK-320 with controller's junction marked as (+) plus
- black cable of MSK-320 with controller's junction marked as (-) minus
- red cable of MSK-320 with controller's junction marked as IN-1
- orange cable of MSK-320 with controller's junction marked as IN-2
Incorrect connection of the rotating or magnetic encoder may cause
its serious damage!!
Connecting increase-reduce motion control cables
Magnetic encoder's connection MSK-320
:
CAUTION!!!
