All cable connections should be made using special wires with double insulation
oriented for use of the electric devices powered by 230V alternating current. Cables
should be rounded with diameter suitable into holes in the controller back casing
accordingly. Tips of the cables should be cleaned and special quill should be used or
tips should be covered by thin tin layer. Please follow this instructions very carefully
especially electric connections should be made according to provided instructions. It is
required for correct and failure-free controller operating.
Machine where the controller is mounted should be equipped in well working head saw
ending switchers and contactors of the up and down feeding should be protected to be
on at the same time !!!
Point - 2
Power transformer TSS-8/001 assembly
In power cubicle added power transformer TSS-8/001 needs to be mounted. Mounting is
designed for well known and used holding bus TSS-35. Please place the transformer as far as
possible from other electrical elements ( e.g. frequency changer, contactors, other
transformers). It is important because of the electromagnetic interference which may
disturbing controller's electronics. Please connect to the connections marked as PRI power
supply of 230V. For power supply please choose this phase of electric supply of the machine
which is not connected to the any inductions coils, contactors or inverters. 230V supply
cables should be placed as far as it is possible form other cables in the power cubicle. To the
transformer's clips marked as SEC 12V please connect wires which feed electronic plate of
the controller. Analogically please place this wires as far as it is possible from other power
cables, especially from 230V which powered the transformer. Length of the cables (12V)
should be chosen accordingly to the place where the controller is mounted.
Point - 3
Choke DPZ-320 mounting
Anti-disturbance choke DPZ-320 added in the controller kit is designed to protect from any
other electromagnetic disturbance made by other electrical devices mounted on the frame
machine saw. Its correct mounting is decisive for correct controller operating. Choke DPZ-
320, as transformer, is equipped in casing which is easy to install on the TSS-35 holding bus.
It should be mounted just next to up and down head feeding contactors.
DPZ-320 contains three independence choking sections (fig. 3) marked as DŁ-1 ... DŁ-3 and
each of them has two connections named A and B. Those A and B outputs should connected
in parallel to the contactors' coil (A connected with one coil output and B with another one).
Those sections should be connected with contactor's coil of the down feeding, up feeding and
barker contactor separately (if the sawing frame machine is equipped with barker).
