Resistance Value - BAPI -Stat Quantum Series Installation & Operating Instructions Manual

41012_ins_quantum_slider_temp_display
Optional Communication Jack Wiring
Fig. 4: Back Plate
Comm. Jack
Locations
Optional Test and Balance Switch (SW7)
On the Test and Balance Switch (SW7), the NORM position allows the
real sensor to be monitored. The HIGH position forces the output to a
very hot reading and the LOW position forces a very cold reading (see
Table below).
3000Ω Thermistor
10K-2 Thermistor
10K-3 Thermistor
10K-3(11K) Thermistor
Building Automation Products, Inc., 750 North Royal Avenue, Gays Mills, WI 54631 USA
Tel:+1-608-735-4800 • Fax+1-608-735-4804 • E-mail:sales@bapihvac.com • Web:www.bapihvac.com
BAPI-Stat "Quantum" Temperature Sensor with Display
Sensor Type
1000Ω RTD
Specifications subject to change without notice.
Fig. 5: C35L Comm. Jack
(3.5mm plug shown for
clarity)
Fig. 6:
C11/C22
Comm. Jack
Low Temp (40° F)

Resistance Value

1.02KΩ (41.20°F)
7.87KΩ (39.8°F)
30.1KΩ (34.9°F)
26.7KΩ (35.9°F)
7.32KΩ (43.7°F)
and Slider Setpoint
Installation & Operating Instructions
C35L Comm. Jack Wiring
Location
Ground
Tip
Ring
C11L/C22L Comm. Jack Wiring
PIN #
1
2
3
4
5
6
Test and Balance Switch (SW7)
LOW: Sets the sensor value low
NORM: Sensor operates normally
HIGH: Sets the sensor value high
High Temp (105°F)
Resistance Value
1.15KΩ (101.5°F)
1.5KΩ (106.8°F)
4.75Ω (109.1°F)
5.11KΩ (108.4°F)
3.65Ω (105.2°F)
rev. 04/23/18
WIRE COLOR
Black
White
Red
WIRE COLOR
Not Connected
Black
Red
Yellow
Green
Not Connected
3 of 6
