DIGITAL CAMERA
Instruction Manual
Thank you for purchasing an Olympus digital camera. Before you start to use your new camera,
please read these instructions carefully to enjoy optimum performance and a longer service life. Keep
this manual in a safe place for future reference.
We recommend that you take test shots to get accustomed to your camera before taking important
photographs.
The screen and camera illustrations shown in this manual were produced during the development
stages and may differ from the actual product.
If there are additions and/or modifi cations of functions due to fi rmware update for the camera, the
contents will differ. For the latest information, please visit the Olympus website.
Model No. : IM010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-M1X and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus E-M1X

Summary of Contents for Olympus E-M1X

  • Page 1 Instruction Manual Model No. : IM010 Thank you for purchasing an Olympus digital camera. Before you start to use your new camera, please read these instructions carefully to enjoy optimum performance and a longer service life. Keep this manual in a safe place for future reference.

  • Page 2: Product Manuals

    Consult these manuals when using the product. Instruction Manual (this pdf) A how-to guide to the camera and its features. The Instruction Manual can be downloaded from the OLYMPUS website or directly using the “OLYMPUS Image Share” (OI.Share) smartphone app.

  • Page 3: Read This Chapter For Information On Using The Camera To Record Movies. This Chapter Also

    Product Manuals P. 2 Table of Contents P. 4 Feature Index P. 16 Parts of the Camera P. 20 Package Contents P. 24 Before You Begin P. 25 Getting Ready P. 27 Read this chapter, together with the other relevant sections of this manual, when using the camera to take photographs or fi...

  • Page 4: Table Of Contents

    Table of Contents Product Manuals ....................2 Feature Index ......................16 Parts of the Camera ..................... 20 Package Contents ....................24 Before You Begin ....................25 Getting Ready ....................27 Attaching the Strap .................. 28 Attaching Cable Protectors ..............29 Removing the Eyecup ................
  • Page 5 Taking and Viewing Photographs ..............51 Basic Photography and Playback ..............52 Taking Photos ..................52 Holding the Camera ................. 52 Taking Photos with the Shutter Button ..........53 Taking Photos with Touch Controls ..........54 Remote Photography ............... 55 Viewing Photographs ................
  • Page 6 Choosing an Aperture ( : Aperture-Priority AE) ........96 Adjusting Settings in Mode ............97 Choosing a Shutter Speed ( : Shutter-Priority AE)......... 98 Adjusting Settings in Mode ............100 Choosing Aperture and Shutter Speed ( : Manual Exposure) ....101 Adjusting Settings in Mode ............
  • Page 7 2-10 Drive Mode (j/Y/i) ................151 Sequential Shooting/Self-Timer ............. 151 Burst Shooting Options (jL Settings/jH Settings) ......155 Self-Timer Options (c Custom Self-timer) .......... 157 Reducing Shutter Slap (Anti-Shock r) ..........160 Adjusting Anti-Shock Settings ............160 The Electronic Shutter (Silent s) ............163 Long Exposure Noise Reduction (Noise Reduction s) ....
  • Page 8 Image Enhancement (Picture Mode) ............ 215 Choosing a Picture Mode .............. 217 Creating Custom Picture Modes (K Custom Picture Mode) ..219 Adjusting Sharpness (Sharpness) ..........220 Adjusting Contrast (Contrast) ............221 Adjusting Vividness (Saturation) ............ 222 Adjusting Shading (Gradation) ............223 Color Filters for Black-and-White Photography (Color Filter) ..
  • Page 9 Copying Pictures Between Cards (Copy) ..........272 Copying All Pictures (Copy All) ............274 Deleting Pictures (Erase) ..............275 Deleting All Pictures (All Erase) ............. 276 Selecting Pictures for Sharing (Share Order) ........277 Removing Share Marking from All Pictures (Reset Share Order) ..............
  • Page 10 Card-Related Settings .................. 316 Choosing a Card for Movies (n Save Slot) ......... 316 Storage Slot Selection ................318 Storage Folder Selection (Assign Save Folder) ........319 Movie File Settings ..................321 Frame Size, Rate, and Compression (nK) ........321 Time Codes (Time Code Settings) ............
  • Page 11 Filming at a Higher Zoom Ratio (Digital Tele-converter) ......411 3-11 Audio Recording ................... 412 Sound Recording Options (Movie K) ............ 413 Using the Olympus LS-100 IC Recorder ..........415 3-12 Customizing Camera Controls ..............417 Assigning Roles to Buttons (n Button Function) ......... 417 Choosing a Role for the Shutter Button (n Shutter Function) .....
  • Page 12 3-14 HDMI Devices ....................432 HDMI Output (n HDMI Output) ............432 External Monitor Display Options (HDMI) ..........434 3-15 Working with Saved Movies ................436 Choosing the Information Displayed ............. 436 The Movie Playback Info Display ............437 Finding Movies Quickly (Index and Calendar Playback) ....... 438 Protecting Movies (0) ................
  • Page 13 “My Menu” ..................... 477 Creating a Personalized Menu (My Menu) ..........477 Customizing Camera Functions ..............480 Focus-Related Items (Custom Menus J, K, L, and I) ....480 Control-Related Items (Custom Menus J and K) ......498 Release-Related Items (Custom Menus N and O) ......505 Display-, Sound-, and Connection-Related Items (Custom Menus P, Q, R, and S) ..........
  • Page 14 Copying Pictures to Smartphones ............592 Downloading Pictures Selected with OI.Share ......592 Auto Download ................594 Removing Share Marking (Reset Share Order) ......595 Remote Photography Using a Smartphone ........... 596 Accessing Field Sensor Logs ..............597 Ending the Connection ................598 Ending the Current Connection .............
  • Page 15 Technical Notes .................... 631 Storage and Maintenance ................632 Troubleshooting .................... 634 Warnings and Error Messages ..............637 Default Settings .................... 640 Live Controls/LV Super Control Panel ........... 640 The K Shooting Menus ............... 642 The n Video Menu ............... 643 The q Playback Menu ..............

  • Page 16: Feature Index

    Feature Index Feature Feature n Specifi cation Settings Shooting Mode 93 – 110 Custom Mode 111, 460 321, 339 b ISO-Auto Set Monitor Display 83, 326 n Noise Filter Viewfi nder Display 83, 326 Direct Button Functions 60, 305 n WB Live Controls 68, 312 n All x...
  • Page 17 Feature Feature q Playback Menu I AF/MF 129, 357, Preset MF distance Edit MF Assist Print Order 128, 356, Reset Protect 271, 440 MF Clutch Reset share Order 278, 447 Focus Ring Copy All 274, 443 Bulb/Time Focusing 107, 497 TWi-Fi Connect Reset Lens G Custom Menu...
  • Page 18 Feature Feature P Disp/8/PC U Exp/ISO/BULB/p K Control Settings Bulb/Time Timer G/Info Settings Bulb/Time Monitor Live Bulb Picture Mode Settings j/Y Settings Live Time Composite Settings 110, 535 Multi Function Settings K Flicker Scan Q Disp/8/PC V Exp/ISO/BULB/p Live View Boost 200, 521 Metering 186, 536...
  • Page 19 Feature Feature c K Utility Y Record/Erase Card Slot Settings Battery Settings File Name Backlit LCD Edit Filename Sleep dpi Settings Auto Power Off Copyright Settings Quick Sleep Mode Q K Utility Lens Info Settings Z Record/Erase Record GPS location Quick Erase GPS Priority 564, 579...

  • Page 20: Parts Of The Camera

    Parts of the Camera Mount (remove body cap before attaching Lens attachment mark (P. 39) lens) Self-timer lamp (P. 151) Lens lock pin AF illuminator (P. 490) External fl ash terminal One-touch white balance button e butto o n (P. 264) (XY) * (P.
  • Page 21 F (exposure compensation) button * Stereo microphone (P. 412) (P. 180, 227, 367, 403) #jY (fl ash/sequential shooting/ self-timer) button (P. 151, 252) Shutter button (P. 53) ISO button * (P. 181, 369) Strap eyelet (P. 28) R (movie) / H button * (P.
  • Page 22 AEL/AFL / 0 (protect) button * (P. 141, 188, 373 / P. 270, 439) Fn lever (P. 94–102, 334–338, 426, 475) Rear dial (P. 94–101, 334–338) Fn button * (P. 417, 463) Multi selector (S/T) * (P. 120, 123, 137, 349, Lock lever (P.
  • Page 23 Viewfi nder (P. 49, 83, 326) Eyecup (P. 30) Eye sensor Diopter adjustment dial (P. 49) u (LV) button * (P. 62, 86, 328) Card compartment cover lock (P. 36) Card compartment cover (P. 36) Monitor (touch screen) (P. 43, 54, 58, 83, 295, 303, 326) Remote cable terminal (b) (P.

  • Page 24: Package Contents

    Package Contents At purchase, the package contains the camera and the following accessories. Contact your retailer should you discover anything damaged or missing. Camera Body cap * EP-17 eyecup * Hot shoe cover * Battery cartridge * BLH-1 rechargeable BCH-1 charger for lithium-ion battery * lithium-ion batteries * CC-1 cable clip...

  • Page 25: Before You Begin

    • Use of these features outside the country or region of purchase may violate local wireless regulations; be sure to check with local authorities before use. Olympus will not be held liable for the user’s failure to comply with local regulations.
  • Page 26 MEMO 26 EN...

  • Page 27: Getting Ready

    Getting Ready Read this chapter whether you are taking photographs or fi lming movies.

  • Page 28: Attaching The Strap

    Attaching the Strap Before attaching the strap, remove the end from the keeper loop and loosen the strap as shown. Keeper loop Pass the end of the strap through the strap eyelet and back through the keeper loop. Pass the end of the strap through the buckle and tighten as shown. •...

  • Page 29: Attaching Cable Protectors

    Attaching Cable Protectors Attach the supplied cable protectors when connecting the supplied USB and HDMI cables. This prevents accidental disconnection and damage to the connectors. Mount the cable protector on the camera. Tighten the screw. Clip the cable clip to the cable and attach the clip to the strap. •...

  • Page 30: Removing The Eyecup

    Removing the Eyecup The eyecup can be removed from the viewfi nder eyepiece as shown. Push up where shown. To re-attach the eyecup, slide it straight down the rails. 30 EN...

  • Page 31: Inserting And Removing Batteries

    Inserting and Removing Batteries The camera can be used with up to two batteries at a time. It can also be used with a single battery. Charge the batteries. Insert battery in direction shown (▲) Battery charger Charge lamp Power cable Rechargeable Li-ion battery Outlet •...
  • Page 32 Unlatch the battery compartment cover and remove the battery cartridge. Insert the batteries into the battery cartridge. Bay 1 Bay 2 Insert the battery cartridge into the camera and latch the battery compartment cover. • We recommend that before using the camera for extended periods, you ready fully-charged spare batteries to swap in when the current batteries are exhausted.

  • Page 33: Batteries And Chargers

    To remove the batteries from the cartridge, slide them in toward the connectors and then lift them out. Batteries and Chargers • The camera uses two Olympus rechargeable Li-ion batteries. Use only genuine Olympus- brand batteries. • Camera power consumption varies widely with the conditions of use.

  • Page 34: Using External Power Sources

    Using External Power Sources Connecting via USB Batteries inserted in the camera will charge when the camera is connected to a USB-AC adapter, computer, or other USB device via a USB cable. The batteries charge only when the camera is off. Devices that conform to the USB Power Delivery (USB PD) standard can also be used to power the camera.

  • Page 35: Optional Ac Adapters

     Powering the Camera via USB  The camera can be powered using mobile batteries or similar devices connected via USB. The devices must: Standard: Conform to the USB Power Delivery (USB PD) standard Output: Be rated for an output of 9 V 3 A, 15 V 2 A, or 15 V 3 A For more information, see “6-6 Powering the Camera via USB (USB Power Delivery)”...

  • Page 36: Inserting Memory Cards

    Inserting Memory Cards The camera uses third-party SD, SDHC, or SDXC memory cards conforming to the SD (Secure Digital) standard. Read “Memory Cards” (P. 37) before use. Confi rm that the camera is off. Rotate the card compartment cover lock as shown (1, 2) and open the card compartment cover (3).

  • Page 37: Using Two Memory Cards

    This manual refers to storage devices as “memory cards”. The camera uses third-party SD, SDHC, or SDXC memory cards conforming to the SD (Secure Digital) standard. Visit the Olympus website for the latest information. • Use a memory card with a Speed Class of 10 or better when recording movies.

  • Page 38: Formatting Memory Cards (Card Setup)

    Formatting Memory Cards (Card Setup) Use the camera to format newly-purchased memory cards or cards that have been used in another camera, computer, or other device. Formatting deletes all data from the card, protected pictures included. Confi rm that the card does not contain important fi les before formatting. When fi...

  • Page 39: Attaching Lenses

    Attaching Lenses Confi rm that the camera is off. Remove the rear lens cap and the camera body cap. Rear lens cap Align the (red) attachment mark on the lens with the (red) attachment mark on the camera body and insert the lens into the camera lens mount.

  • Page 40: Removing Lenses

    Remove the front lens cap. • Be careful not to press the lens release button while attaching the lens. • Do not touch the camera’s internal parts. Removing Lenses Confi rm that the camera is off. Lens release button Hold the lens release button and rotate the lens as shown.

  • Page 41: Mf Clutch Lenses

    MF Clutch Lenses The “MF clutch” (manual focus clutch) mechanism on MF clutch lenses can be used to switch between auto and manual focus simply by repositioning the focus ring. • Check the position of the MF clutch before shooting. •...

  • Page 42: Interchangeable Lenses

    Interchangeable Lenses The camera can be used with interchangeable lenses designated exclusively for use with the “Micro Four Thirds” system, which can be identifi ed by the presence of the M.ZUIKO DIGITAL trademark or the logo shown at right. Four Thirds and OM system lenses can also be used. An adapter (available separately) is required.

  • Page 43: Using The Monitor

    Using the Monitor Rotate the monitor for ease of viewing. The angle of the monitor can be adjusted according to conditions at the time of shooting. Up to 90° Up to 90° Up to Up to 180° Up to Up to 270° •...

  • Page 44: Turning The Camera On

    Turning the Camera On Rotate the ON/OFF lever to ON. • The camera will turn on and the monitor will light. • To turn the camera off, rotate the lever to OFF. ON/OFF lever Monitor The Battery Level Display The level of the current battery and the number of the bay in which it is inserted are shown in the display.

  • Page 45: Initial Setup

    Initial Setup When fi rst turned on, the camera will prompt you to pick a language and set the clock. • The current time and date are saved with each picture taken. • File names include the current date. Be sure to set the clock before using the camera. Some features are only available if the clock is set.
  • Page 46 After highlighting the desired language, press the OK button. • If you press the shutter button before pressing the OK button, the camera will exit to shooting mode and no language will be selected. The language selection dialog can be displayed by turning the camera off and then on again, after which you can repeat the process from Step 1.

  • Page 47: What To Do If You Can't Read The Display

    What to Do If You Can’t Read the Display If you see unfamiliar characters or words in other languages, you may not have selected the language you intended. Follow the steps below to choose another language. Press the MENU button to view the menus.

  • Page 48: Correcting The Clock Using Gps

    Correcting the Clock Using GPS GPS can be used to correct the clock. Time and date information acquired via GPS are used to automatically correct the clock while the camera is on. The time zone must be selected in advance using the [Time Zone] option. g “Choosing a Language (W Language)”...

  • Page 49: Focusing The Viewfi Nder

    Focusing the Viewfi nder At default settings, putting your eye to the viewfi nder automatically turns the display on. Adjust viewfi nder diopter if the display is not in focus. • Rotate the diopter adjustment dial until the display in the viewfi...
  • Page 50 MEMO 50 EN...

  • Page 51: Taking And Viewing Photographs

    Taking and Viewing Photographs Read this chapter for information on using the camera to take photographs. This chapter also covers the features you’ll use when shooting and viewing photos.

  • Page 52: Basic Photography And Playback

    Basic Photography and Playback Read this section for information on basic photography and playback that will get you started using your camera right away. It also provides basic information on such topics as using the touch screen and switching memory cards. Taking Photos Holding the Camera Be careful that your fi...

  • Page 53: Taking Photos With The Shutter Button

    Taking Photos with the Shutter Button Frame your subject in the viewfi nder and take photos with the shutter button. Compose the shot to position the AF frame over your subject and focus before shooting. Focus. • Press the shutter button a short distance to the fi rst stop (referred to as “pressing the shutter button halfway”).

  • Page 54: Taking Photos With Touch Controls

    Taking Photos with Touch Controls Frame a shot in the monitor and touch your subject in the display to focus and shoot. You can also use touch controls to position or zoom in on the AF target.  Touch Shutter Options ...

  • Page 55: Remote Photography

    Remote Photography You can use remote photography when photographing night scenes, during macro photography, or in other situations in which you wish to avoid camera blur caused by operating the shutter button. You can either use an optional RM-CB2 remote cable or take pictures remotely via a wireless connection using the OI.Share smartphone app.

  • Page 56: Viewing Photographs

    Viewing Photographs View photographs stored on the memory cards. Press the q button. • The most recent picture will be displayed (single-frame playback). • Use the multi selector (T), front dial (k), or HI on the arrow pad to view other pictures. •...

  • Page 57: Choosing A Memory Card

    Press the shutter button halfway to end playback and exit to the shooting display. • Press the q (playback) button to view photos as they are saved to the memory card after shooting. You can check pictures even as the camera records large numbers of photos taken during burst photography or the like.

  • Page 58: Adjusting Volume

    Adjusting Volume Adjust playback volume for sound recorded with pictures. You can also add audio to photos after shooting. g [K] (P. 281) Press the q button to start playback. Press F or G on the arrow pad. • Press F to increase the volume, G to decrease. Playback Using Touch Controls Touch controls can be used to zoom in on and scroll pictures and to page through pictures during playback.

  • Page 59: Shooting Settings

    Shooting Settings The camera offers many photography-related functions. Depending on how often you use them, you can access settings via buttons, icons in the display, or menus that can be used for detailed adjustments. Method Description Adjust settings directly using buttons, including those listed below. Commonly-used functions are assigned to buttons for quick Direct buttons access during viewfi...

  • Page 60: Direct Buttons

    Direct Buttons Frequently-used photographic functions are assigned to buttons. These are referred to as “direct buttons”. Included are the buttons listed below, which can be used for basic shooting settings. The camera features buttons for shots framed in (“wide”) orientation and others that make the camera easier to use when rotated to take pictures in portrait (“tall”) orientation.
  • Page 61 Direct button Assigned function 9 #jY button Flash/sequential shooting/self-timer 0 AFp button AF/metering mode 115, 186 a BKT button Bracketing b u (LV) button Display (monitor/viewfi nder) selection 62, 83 c R button Movie recording * Also assigned to a button for use when the camera is rotated to take shots in portrait (“tall”) orientation.

  • Page 62: The Super Control/Lv Super Control Panel

    The Super Control/LV Super Control Panel The super control/LV super control panel lists shooting settings and their current values. Use the LV super control panel when framing shots in the monitor (“live view”), the super control panel when framing shots in the viewfi nder. The instructions in this manual are for the LV super control panel.
  • Page 63  Using the Super Control/LV Super Control Panel  Press the OK button. Cursor • If you press the button during live view, the LV super control panel will be displayed in the monitor. • The last setting used will be highlighted. Rotate the rear dial or tap to select a setting in display.
  • Page 64 Additional Options Pressing the OK button in Step 2 displays options for the INFO button highlighted setting. In some cases, additional options can be viewed by pressing the INFO button. OK button INFO [K Image Stabilizer] • Touch controls can be used in place of the OK button. Lightly tap the desired setting twice to display options.
  • Page 65  Settings Available in the Super Control/LV Super Control Panel  1 Option currently selected f Picture mode........P. 215 g N Sharpness........P. 220 2 ISO sensitivity ......... P. 181 3 K AF mode ........P. 115 u Contrast ........P. 221 t Saturation ........

  • Page 66: Using The Menus

    Using the Menus Items not listed in the control panels can be found in the menus, including items for adjusting shooting and playback settings and customizing the camera for ease of use. Tab name Item (setting) Tab name Description Photography-related items. Ready the camera for shooting or Shooting Menu 1 access basic photo settings.
  • Page 67 Press the MENU button to display the menus. Tool tip On-screen guides Press the MENU button to exit to Press the OK button to select the the previous display highlighted item • Tool tips are displayed for roughly 2 seconds after an item is highlighted. Press the INFO button to view or hide tool tips.

  • Page 68: Using Live Controls

    Using Live Controls Live controls are used to view and adjust settings S-IS AUTO S-IS AUTO during live view. The effects of the selected settings can be previewed in the live view display. AUTO AUTO Live controls are hidden by default. They can be accessed by enabling their display in the menus.
  • Page 69 Press the OK button during live view to display the LV super control panel. S-IS AUTO S-IS AUTO ISO-A 30 p 30 p 1:02:03 250 F5.6 0.0 1023 Press the INFO button to switch to the live control display. INFO •...
  • Page 70  Available Live Controls  S-IS AUTO S-IS AUTO AUTO AUTO Settings Natural 30 p 30 p Options K image stabilization ......P. 176 Flash mode ........... P. 254 Flash compensation ......P. 259 Picture mode ........P. 215 K white balance ......... P. 202 Metering mode........

  • Page 71: Card-Related Settings

    Card-Related Settings The camera can be used with up to two memory cards simultaneously. This section describes memory-card–related settings. The menus and control panels offer items choosing how fi les are saved when two memory cards are inserted. For example, you can opt to save pictures of different types to different cards or automatically switch to the other card when one card fi...

  • Page 72: Storage Options (K Save Settings)

    Storage Options (K Save Settings) Choose how the camera stores pictures when two memory cards are inserted. • This setting can be accessed via: - The LV super control panel (P. 73) - The menus (P. 73) • The option selected for image quality may change when you change settings or remove a memory card and replace it with a card that has space available.
  • Page 73  Access via the LV Super Control Panel  Highlight [K Save Settings] in the LV super control panel. Rotate the front dial to choose a setting. K save settings Press the shutter button halfway to exit the LV super control panel.

  • Page 74: Choosing A Card For Photos (K Save Slot)

    Choosing a Card for Photos (K Save Slot) Choose the memory card used to store photos when two memory cards are inserted. Card selection is available when y (standard) or z (auto switch) is selected for [K Save Settings]. • This setting can be accessed via: - The LV super control panel - The menus ...

  • Page 75: Storage Slot Selection

    Storage Slot Selection If two memory cards are inserted with y (standard) or z (auto switch) selected for [K Save Settings], the card used to store pictures can be selected using the CARD (card select) button. Press the CARD button. •...

  • Page 76: Storage Folder Selection (Assign Save Folder)

    Storage Folder Selection (Assign Save Folder) Choose the folder in which subsequent pictures will be stored. • This setting can be accessed via: - The LV super control panel - The menus (P. 77) New Folder Create a new folder as the destination for subsequent pictures. Existing Folder Choose an existing folder.
  • Page 77 Highlight an option using the FG buttons. [New Folder]: Choose the desired folder number and press the OK button. [Existing Folder]: Highlight an existing folder using the FG buttons and press the OK button. The camera will display the fi rst two photos and the last photo in the selected folder.

  • Page 78: Image Quality And Size

    Image Quality and Size Choose the compression ratio, fi le format, and size used when saving pictures. The options available via the LV super control panel or live controls can be selected in the menus. Photo File and Image Size Options (KK) Choose image quality settings used when photos are saved.
  • Page 79 Rotate the front dial to choose an option. • Choose from the following options. The image size/compression combinations available can be selected in the menus. g G Custom Menu X > [K Set] (P. 81) Option Image size Compression ratio File format 5184 ×...
  • Page 80 - Have the extension “.orf” - Cannot be viewed on other cameras - Can be viewed on computers using Olympus Workspace Digital Photo Managing software - Can be saved in JPEG format using the [RAW Data Edit] (P. 284) retouch option in the...

  • Page 81: Choosing Available Options (K Set)

    Choosing Available Options (K Set) Choose the combinations of image size (measured in pixels) and compression (“image quality”) available in the [KK] menu (P. 78). Press the MENU button to display the menus. Select G Custom Menu X (K/WB/Color). Highlight [K Set] using FG on the arrow pad and press the I button.

  • Page 82: Choosing Values For [X] And [W] Sizes (Pixel Count)

    Choosing Values for [X] and [W] Sizes (Pixel Count) Choose the size, in pixels, of the [X] (Xiddle) and [W] (Wmall) [KK] options (P. 78). • The size, in pixels, of the [X] and [W] options can be selected from following: Xiddle (medium) 3200×2400, 1920×1440 Wmall (small)

  • Page 83: The Viewfi Nder And Monitor Displays

    The Viewfi nder and Monitor Displays Display Selection The camera uses an eye sensor to automatically switch between the monitor and viewfi nder displays. The monitor live view display and viewfi nder also show information on camera settings. Options are available for controlling display switching and choosing the information shown.

  • Page 84: Choosing The Information Displayed

    Choosing the Information Displayed Press the INFO button. • The information displayed changes each time the INFO button is pressed. INFO S-IS AUTO S-IS AUTO ISO-A 1:02:03 250 F5.6 0.0 1023 Basic info Info hidden INFO INFO INFO button INFO S-IS AUTO S-IS AUTO S-IS AUTO...

  • Page 85: Display Selection Options (Evf Auto Switch)

    Display Selection Options (EVF Auto Switch) Adjust settings for switching between the monitor and viewfi nder displays.  Using the u (LV) Button  Press and hold the u button. • The [EVF Auto Switch] menu will be displayed. u button Highlight an option using FG on the arrow pad and press the OK button.

  • Page 86: The Shooting Display

    The Shooting Display Camera menus can be used to choose the information shown in the monitor and viewfi nder. g [G/Info Settings] (P. 515), [V Info Settings] (P. 555) Monitor (Still Photography) 2 3 4 a b c d BKT HDR gh i FP RC BKT S-IS AUTO...
  • Page 87 2 3 4 a b c d BKT HDR gh i FP RC BKT S-IS AUTO S-IS AUTO S-AF AUTO ISO-A 30 p 30 p 1:02:03 1:02:03 250 F5.6 +2.0 1023 y w v u Available recording time ....P. 655 E Histogram .........
  • Page 88 Viewfi nder (Still Photography) FP RC S-IS AUTO S-IS AUTO S-AF Sh-3 Mid+2 Hi+6 1:02:03 ISO-A 250 F5.6 +2.0 1023 AUTO 2 3 45 Sh-3 Mid+2 Hi+6 1:02:03 ISO-A 250 F5.6 +2.0 1023 AUTO gh i d e f 1023 ISO-A +2.0 AUTO...

  • Page 89: Optical Viewfi Nder Simulation (S-Ovf)

    Optical Viewfi nder Simulation (S-OVF) Increase dynamic range of the viewfi nder display, increasing the amount of detail visible in highlights and shadows in a manner similar to optical viewfi nders. Backlit subjects and the like are easier to see. •...

  • Page 90: Photo Review (Rec View)

    Photo Review (Rec View) Pictures are displayed immediately after shooting. This gives you a chance to quickly review the shot. You can choose how long pictures are displayed or disable photo review altogether. To end photo review and resume shooting at any time, press the shutter button halfway.

  • Page 91: Restoring Default Settings (Reset)

    Restoring Default Settings (Reset) Reset the camera to factory default settings. You can opt to reset almost all settings or only those directly related to photography. Full Reset all settings with a few exceptions, such as the clock and language. Basic Reset photography-related settings only.
  • Page 92 • Settings can be saved to a computer using Olympus Workspace. For more information, visit the OLYMPUS website at the following URL: https://support.olympus-imaging.com/owdownload/ 92 EN K 2-7 Restoring Default Settings (Reset)

  • Page 93: Choosing A Shooting Mode

    Choosing a Shooting Mode Choose a shooting mode according to your artistic intent. The shooting mode is selected with the mode dial. Choose custom modes to save and recall shooting settings as required.  Shooting Modes  See the page numbers listed below for more information. Selected mode Program AE (P.

  • Page 94: Letting The Camera Choose Aperture And Shutter Speed ( P : Program Ae)

    Letting the Camera Choose Aperture and Shutter Speed : Program AE) The camera chooses the optimal aperture and shutter speed according to subject brightness. Rotate the mode dial to Focus and check the display. S-IS AUTO S-IS AUTO • The shutter speed and aperture chosen by the camera are displayed.

  • Page 95: Adjusting Settings In Mode P

    Adjusting Settings in Mode Use the front and rear dials to adjust the following settings. Front dial: Exposure compensation (P. 180) Rear dial: Program shift • Exposure compensation can also be adjusted using the F button. Press the F button and rotate the front or rear dial. •...

  • Page 96: Choosing An Aperture ( A : Aperture-Priority Ae)

    Choosing an Aperture : Aperture-Priority AE) In this mode, you choose the aperture (f/-number) and the camera automatically sets the shutter speed for optimal exposure according to subject brightness. Lower aperture values (larger apertures) reduce the depth of the area that appears to be in focus (depth of fi...

  • Page 97: Adjusting Settings In Mode A

    Subject Too Dark or Too Bright If the camera is unable to achieve optimal exposure, the shutter-speed display will fl ash as shown. Display Problem/solution Slow shutter speed Underexposure. 60" 60" F5.6 F5.6 • Choose a lower aperture value. Overexposure. •...

  • Page 98: Choosing A Shutter Speed ( S : Shutter-Priority Ae)

    Choosing a Shutter Speed ( : Shutter-Priority AE) In this mode, you choose the shutter speed and the camera automatically sets aperture for optimal exposure according to subject brightness. Faster shutter speeds appear to “freeze” fast-moving subjects. Slower shutter speeds add blur to moving objects, lending them a sense of motion for a dynamic effect.
  • Page 99 Subject Too Dark or Too Bright If the camera is unable to achieve optimal exposure, the aperture display will fl ash as shown. Display Problem/solution Low aperture value Underexposure. 2000 2000 F2.8 F2.8 • Choose a slower shutter speed. Overexposure. •...

  • Page 100: Adjusting Settings In Mode S

    Adjusting Settings in Mode Use the front and rear dials to adjust the following settings. Front dial: Exposure compensation (P. 180) Rear dial: Shutter speed • Exposure compensation can also be adjusted using the F button. Press the F button and rotate the front or rear dial. •...

  • Page 101: Choosing Aperture And Shutter Speed ( : Manual Exposure)

    Choosing Aperture and Shutter Speed : Manual Exposure) In this mode, you choose the aperture and shutter speed. You can adjust settings according to your goals, for example by combining fast shutter speeds with small apertures (high f/-numbers) for increased depth of fi eld. Rotate the mode dial to Adjust aperture and shutter speed.

  • Page 102: Adjusting Settings In Mode

    Subject Too Dark or Too Bright If the camera is unable to achieve optimal exposure with [AUTO] selected for [K ISO], the ISO sensitivity display will fl ash as shown. Display Problem/solution ISO-A ISO-A Overexposure. • Choose a higher aperture value or faster shutter speed. Underexposure.

  • Page 103: Using Exposure Compensation In Mode M

    Using Exposure Compensation in Mode In mode , exposure compensation is available when [AUTO] is selected for [K ISO]. Because exposure compensation is performed by adjusting ISO sensitivity, aperture and shutter speed are not affected. g [K ISO] (P. 181), [K ISO-Auto Set] (P.

  • Page 104: Long Exposures ( B : Bulb/Time)

    Long Exposures : Bulb/Time) Select this mode to leave the shutter open for a long exposure. You can preview the photo in live view and end the exposure when the desired results have been achieved. Use when long exposures are required, for example when photographing night scenes or fi...
  • Page 105 Highlight an interval using FG on the arrow pad. • Select [Off] to disable the preview. Press the OK button to select the highlighted option. • The menus will be displayed. Press the shutter button halfway to exit the menus. •...
  • Page 106 • During live time photography, you can refresh the preview by pressing the shutter button halfway. • Some limitations apply to the choice of ISO sensitivity settings available. • Bulb photography is used in place of live bulb photography when multiple exposure, keystone compensation, or fi...

  • Page 107: Adjusting Focus During Exposures (Bulb/Time Focusing)

    Adjusting Focus During Exposures (Bulb/Time Focusing) You can adjust focus manually while shooting in (bulb) mode. This allows you to defocus during the exposure or focus at the end of the exposure. Press the MENU button to display the menus. Select G Custom Menu I (AF/MF).

  • Page 108: Lighten Blending ( B : Live Composite Photography)

    Lighten Blending ( : Live Composite Photography) Leave the shutter open for a long exposure. You can view the light trails left by fi reworks or stars and photograph them without changing the exposure of the background. The camera combines multiple shots and records them as a single photograph.
  • Page 109 Press the shutter button again to end shooting. • Live composite photography can continue for up to three hours. The maximum recording time available varies with battery level and shooting conditions. • Some limitations apply to the choice of ISO sensitivity settings available. •...

  • Page 110: Choosing The Shutter Speed (Composite Settings)

    Choosing the Shutter Speed (Composite Settings) The exposure time for each exposure made during live composite photography can be chosen in advance using the menus. Press the MENU button to display the menus. Select G Custom Menu U (Exp/ISO/BULB/p). Highlight [Composite Settings] using FG on the arrow pad and press the I button.

  • Page 111: Saving Custom Settings To The Mode Dial

    Saving Custom Settings to the Mode Dial (C1/C2/C3/C4 Custom Modes) Frequently-used settings and shooting modes can be saved as custom modes and recalled as needed simply by rotating the mode dial. Saved menu settings can also be recalled directly. • Save settings to positions C1 through C4. •...

  • Page 112: Using Custom Modes (C1/C2/C3/C4)

    Highlight [Set] using the FG buttons and press the OK button. • The [Assign to Custom Mode] menu will be displayed again. • Any existing settings will be overwritten. • To restore default settings for the selected custom mode, highlight [Reset] and press the OK button. Press the MENU button repeatedly to exit the menus.
  • Page 113 Highlight [Recall from Custom Mode] using the FG buttons and press the I button. • The [Recall from Custom Mode] menu will be displayed. Highlight the desired custom mode using the FG buttons and press the I button. Highlight [Yes] using the FG buttons and press the OK button.

  • Page 114: Focus

    Focus Focus can be adjusted automatically (autofocus) or manually (manual focus). Autofocus features options for focusing on selected points or to track focus on a moving subject. In the case of moving subjects in particular, by adjusting settings according to the type of subject or shooting conditions, you can photograph a greater variety of subjects.

  • Page 115: Focus Mode (K Af Mode)

    Focus Mode (K AF Mode) Choose the focus mode for auto or manual focus. Autofocus (AF): The camera focuses automatically. Choose from single AF (P. 115), in which the camera focuses just once when the shutter button is pressed halfway, and continuous AF (P. 115), in which the camera adjusts focus continuously while the shutter button is pressed.

  • Page 116: Lens Mf Clutch (Manual Focus Clutch)

    Manual Focus (MF) Focus manually. • Rotate the lens focus ring to focus. Minimum focus distance • If the lens is equipped with an MF clutch, you can rotate the lens focus ring to engage manual focus regardless of the focus mode selected with the camera.
  • Page 117 [K AEL/AFL] (P. 141) • The lens focus ring can be used to interrupt autofocus only when M.ZUIKO PRO (Micro Four Thirds PRO) lenses are used. For information on other lenses, visit the OLYMPUS website. • In (bulb) mode, manual focus is controlled by the option selected for [Bulb/Time Focusing].
  • Page 118  Access via the AFp Button  Press the AFp button. AFp button • [K AF Mode] options will be displayed. [K AF Mode] options Rotate the rear dial. • You can also rotate the dial while pressing the button. •...
  • Page 119  Access via the LV Super Control Panel  The focus mode can also be selected using the LV super control panel. K AF mode Press the OK button [K AF Mode] Rotate the front dial to choose an option ...

  • Page 120: Choosing An Af-Target Mode (Af Target Mode)

    Choosing an AF-Target Mode (AF Target Mode) The point or area in the frame on which the camera focuses is called the “AF target”. [AF Target Mode] is used to choose the number of AF targets used and the size of the area covered.
  • Page 121 q All Targets (11 × 11) The camera chooses the target used for focus from all 121 targets. u/v/w/x Custom Target Use the AF target mode selected for [t Target Mode Settings] (P. 125) in G Custom Menu K. The default setting is single target. ...
  • Page 122 • The AF target display can be accessed using the multi selector. The multi selector can be confi gured using [S Center Button] in G Custom Menu J (P. 499). • Settings can be changed using the arrow pad. The role assigned to the arrow pad can be selected using [K Button Function] (P.

  • Page 123: Choosing A Focus Target (Af Target Point)

    Choosing a Focus Target (AF Target Point) The green frame showing the location of the focus point is referred to as the “AF target”. You can position the target over your subject. At default settings, the multi selector is used to position the AF target. •...
  • Page 124  Access via the LV Super Control Panel  Highlight [AF Area] in the LV super control panel and press the OK button. • AF-target selection will be displayed. • The number of targets available varies with the AF target mode.

  • Page 125: Custom Af Targets (T Target Mode Settings)

    Custom AF Targets (t Target Mode Settings) Choose the number of AF targets available and how far the AF target moves during AF target selection. Targets can be larger than group targets or sized for subjects whose motion can be predicted. You can also increase the distance between available targets for faster target selection.
  • Page 126 Choose the size of the AF target. • Highlight [Size] using the FG buttons and press the OK button. • Use the HI buttons or the front dial to choose the horizontal size and the FG buttons or the rear dial to choose the vertical size.

  • Page 127: Lens Mf Clutch (Manual Focus Clutch)

    Lens MF Clutch (Manual Focus Clutch) The “MF clutch” (manual focus clutch) mechanism on MF clutch lenses can be used to switch between auto and manual focus simply by repositioning the focus ring. • Check the position of the focus ring before shooting. •...

  • Page 128: Disabling The Mf Clutch (Mf Clutch)

    Disabling the MF Clutch (MF Clutch) Disable the manual focus clutch. This can prevent autofocus being disabled by the clutch engaging accidentally. Press the MENU button to display the menus. Select G Custom Menu I (AF/MF). Highlight [MF Clutch] using FG on the arrow pad and press the I button.

  • Page 129: Focusing At A Preset Distance (Preset Mf)

    Focusing at a Preset Distance (Preset MF) Quickly focus at a previously-stored distance. An example of a situation in which this option might be effective is astronomical photography featuring the moon or stars, when you want to focus quickly at infi nity. The focus distance can be set using AF/ MF or by entering the focus distance directly.
  • Page 130 Highlight [Preset MF] using the rear dial. Press the INFO button. • You will be prompted to choose the focus distance for [Preset MF]. Choose a focus distance. • To choose a focus distance using autofocus: Press the shutter button halfway to focus on a subject at the desired distance.
  • Page 131  Access via the LV Super Control Panel  Highlight [K AF Mode] > [PreMF] in the LV super control panel, press the OK button, and then press the INFO button to display options. You can then press the shutter button halfway to focus on a subject at the desired distance, or choose the focus distance manually by rotating the focus ring.
  • Page 132  Using [Preset MF]  Choose a focus distance using [Preset MF]. • For information on choosing a focus distance, see page 129. Highlight [K AF Mode] in the LV super control panel. K AF mode Select [PreMF] (preset MF) using the front dial. •...

  • Page 133: Face/Eye Priority Af

    Face/Eye Priority AF The camera automatically detects and focuses on the faces or eyes of portrait subjects. When digital ESP metering is used, exposure will be weighted according to the value metered for the face. • This setting can be accessed via: - The LV super control panel - Live controls (P.
  • Page 134  Menu Access  Choose an option using [I Face Priority] in G Custom Menu L. MENU button Press I on the arrow pad to G tab L tab [I Face Priority] Use the FG buttons to choose an option display options ...

  • Page 135: Using Face/Eye Priority Af

    Using Face/Eye Priority AF Point the camera at your subject. S-IS AUTO S-IS AUTO • Faces detected by the camera are indicated by white borders. ISO-A 30 p 30 p 1:02:03 250 F5.6 0.0 1023 Press the shutter button halfway to focus. S-IS AUTO S-IS AUTO S-IS AUTO...

  • Page 136: Zoom Frame/Focus Zoom Af (Super Spot Af)

    Zoom Frame/Focus Zoom AF (Super Spot AF) You can zoom in on the display during shooting. For greater precision during focusing, zoom in on the focus area. At higher zoom ratios, you can focus on areas smaller than the standard focus target. You can reposition the focus area as desired during zoom.

  • Page 137: Using [A] (Magnify)

     Menu Access  Use [K Button Function] in G Custom Menu J to choose the roles played by camera controls. MENU button J tab Press I G tab [K Button Function] Choose a control Use the FG buttons to choose [a] (magnify) on the arrow pad to display options Using [a] (Magnify) Press the button to which [a] (magnify) is assigned.
  • Page 138 Press the button to which [a] is assigned once more. • The camera will zoom the selected area in to fi ll the display. • Use the multi selector to scroll the display. • Use the front or rear dial to zoom in or out. •...

  • Page 139: Focus Zoom Options (Lv Close Up Settings)

    Focus Zoom Options (LV Close Up Settings) Choose display options for use with focus zoom. This item comes in handy when you want to view the entire composition before shooting or if you want an easy-to- see display for checking focus with focus zoom. Choose what happens if the shutter button is pressed halfway during focus zoom.
  • Page 140 Highlight an option using the FG buttons and press the OK button. • The [LV Close Up Settings] menu will be displayed. Press the OK button to accept the changes. • G Custom Menu Q will be displayed. Press the MENU button repeatedly to exit the menus.

  • Page 141: Setting Focus And Exposure With The Ael/Afl Button (K Ael/Afl)

    Setting Focus and Exposure with the AEL/AFL Button (K AEL/AFL) Choose how the camera sets focus and exposure when the shutter button or AEL/ AFL button is pressed. The camera normally focuses and locks exposure when the shutter button is pressed halfway, but this can be changed according to the subject or shooting conditions.
  • Page 142 Press the MENU button to display the menus. Highlight the G (Custom Menu) tab using FG on the arrow pad and press the I button. Select G Custom Menu J (AF/MF). Highlight [K AEL/AFL] using the FG buttons and press the I button. Highlight a focus mode using the FG buttons and press the I button.

  • Page 143: Lens Focus Range (Af Limiter)

    Lens Focus Range (AF Limiter) Choose the range in which the camera will focus using autofocus. This is effective in situations in which an obstacle presents itself between the subject and the camera during the focus operation, causing drastic changes in focus. You can also use it to prevent the camera focusing on foreground objects when shooting through a fence, window, or the like.
  • Page 144 Highlight the desired setting ([Setting 1]–[Setting 3]) using the FG buttons and press the I button. • Lens focus range options will be displayed. Choose a range using the arrow pad. • Press the FG buttons to choose a number and then press the I button to highlight the next digit.

  • Page 145: C-Af Tracking Sensitivity (K C-Af Sensitivity)

    C-AF Tracking Sensitivity (K C-AF Sensitivity) Choose how rapidly the camera responds to changes in the distance to the subject while focusing with [C-AF], [C-AFb], [C-AF+TR], or [C-AF+TRb] selected for [K AF Mode]. This can help autofocus track a quickly-moving subject or prevent the camera refocusing when an object passes between the subject and the camera.

  • Page 146: C-Af Lens Scanning (Af Scanner)

    C-AF Lens Scanning (AF Scanner) Choose whether the camera performs a focus scan. If the camera is unable to focus, it will scan for the focus position by cycling the lens from the minimum focus distance to infi nity. You can limit the scanning operation if desired. This option takes effect when [C-AF], [C-AF+TR], [C-AFb], or [C-AF+TRb] is selected for [K AF Mode] (P.

  • Page 147: C-Af Starting Focus Target (K C-Af Center Start)

    C-AF Starting Focus Target (K C-AF Center Start) When used in combination with an AF-target mode other than single target, [C-AF] and [C-AFb] focus on the center of the selected group only during the initial scan. During later scans, the camera will focus using the surrounding targets. Combining this option with an AF-target mode that covers a wide area makes it easier to focus on erratically-moving subjects.

  • Page 148: C-Af Center Target Priority (K C-Af Center Priority)

    C-AF Center Target Priority (K C-AF Center Priority) When focusing using group-target AF in [C-AF] and [C-AFb] modes, the camera always assigns priority to the center target in the selected group for a repeated series of focus operations. Only if the camera is unable to focus using the center focus target will it focus using the surrounding targets in the selected focus group.

  • Page 149: Tracking Focus On Selected Subjects (K Tracking Subject)

    Tracking Focus on Selected Subjects (K Tracking Subject) The camera can detect and track subjects of specifi c types when focusing using [C-AF+TR] or [C-AF+TRb]. You may fi nd it hard to focus on the driver or cockpit of a fast-moving subject such as a race car or airplane. This feature detects and focuses specifi...
  • Page 150 To use this feature, select [C-AF+TR] or [C-AF+TRb] for [K AF Mode]. • The focus mode can be selected using the menus or LV super control panel.  Taking Photographs Using [K Tracking Subject]  Select [C-AF+TR] or [C-AF+TRb] for [K AF Mode].

  • Page 151: Drive Mode (J/Y/I)

    2-10 Drive Mode (j/Y/i) Your choice of drive mode determines what happens when the shutter button is pressed, for example whether the camera takes a series of pictures while the button is pressed or starts a timer and takes a picture after a delay. Choose an option that suits your goals, whether they are to capture subject motion in a series of photos or take photos that record changes in your subject over a long period of time.
  • Page 152 Custom Self- Adjust self-timer settings, including the self-timer delay and the Timer number of shots taken when the timer expires (P. 157).  Reduce the slight blur caused by shutter motion. The electronic Anti-Shock r front-curtain shutter is used. Available in single-frame, sequential (sample low, and self-timer modes (P.
  • Page 153  Access via the #jY Button  Direct drive mode selection is available via the #jY button. Press the #jY button. #jY button • [j/Y] (sequential shooting/self-timer) options will be displayed. [j/Y] (sequential shooting/self-timer) options Rotate the rear dial to highlight an option. •...
  • Page 154  Access via the LV Super Control Panel  Highlight [j/Y] (sequential shooting/self-timer) in the LV super control panel. j/Y (sequential shooting/self-timer) Rotate the front dial to choose an option. Press the shutter button halfway to return to the shooting display. ...

  • Page 155: Burst Shooting Options (Jl Settings/Jh Settings)

    Burst Shooting Options (jL Settings/jH Settings) Choose the maximum frame advance rates and shots per burst for sequential shooting modes. Shooting ends if the maximum number of shots is reached while the shutter button is pressed all the way down. Choose the advance rate and number of shots per burst for (sequential low) and (sequential high) modes.
  • Page 156 Highlight [j/j], [♥j], or [J] using the FG buttons and press the I button. • The camera will display options for the selected item. Choose a setting for [Max fps]. • Highlight [Max fps] using the FG buttons and press the I button.

  • Page 157: Self-Timer Options (C Custom Self-Timer)

    Self-Timer Options (c Custom Self-timer) Adjust self-timer settings, including the shutter release delay and the number of shots taken when the timer expires. • This setting can be accessed via: - The #jY button - The menus (P. 159) - The LV super control panel (P. 158) - Live controls (P.
  • Page 158 Press the INFO button to display self-timer options. • Choose from [Y Timer], [Number of Frames], [Interval Length], and [Every Frame AF]. • Highlight items using the HI buttons and use the FG buttons to choose an option. Press the OK button to save the changes and return to the shooting display.
  • Page 159  Menu Access  Use [j/Y/i] (drive mode) > [j/Y] (sequential shooting/self-timer) in W Shooting Menu 1. MENU button W tab Press I on the arrow pad [j/Y/i] [j/Y] Use the FG buttons to highlight an item, press the I to view custom self-timer settings button, and use the FG buttons to choose an option ...

  • Page 160: Reducing Shutter Slap (Anti-Shock R)

    (Anti-Shock r) Reducing Shutter Slap Reduce the slight blur caused by the motion of the shutter. Pictures are taken using an electronic front-curtain shutter. This option can be used in combination with sequential shooting and self-timer modes. Disable anti-shock. Anti-shock options will not be listed when you press the #jY button or highlight the drive mode in the LV super control panel.
  • Page 161 Highlight the desired shutter-release delay using the FG buttons and press the OK button. Press the OK button when the desired option is highlighted. • [Anti-Shock r/Silent s] options will be displayed. • To disable anti-shock, highlight [Off] in the [Anti- Shock r/Silent s] display and press the OK button.
  • Page 162  Accessing Anti-Shock Options  When an option other than [Off] is selected for [Anti-Shock r/Silent s] > [Anti- Shock r] in X Shooting Menu 2, you can access anti-shock options using: The #jY Button #jY button Rotate the rear dial to select options marked with r The LV Super Control Panel Highlight [j/Y] (sequential shooting/self-timer) Rotate the front dial to select options...

  • Page 163: The Electronic Shutter (Silent S)

    (Silent s) The Electronic Shutter Take pictures using the electronic shutter. Use for shutter speeds faster than 1/8000 s or in settings where the sound of the shutter would be unwelcome. The electronic shutter can be used in single-frame mode and self-timer modes and for frame rates as high as 60 fps in sequential shooting modes.
  • Page 164 Highlight the desired shutter-release delay using the FG buttons and press the OK button. Press the OK button when the desired option is highlighted. • [Anti-Shock r/Silent s] options will be displayed. • To disable anti-shock, highlight [Off] in the [Anti- Shock r/Silent s] display and press the OK button.
  • Page 165  Accessing Silent-Mode Options  When an option other than [Off] is selected for [Anti-Shock r/Silent s] > [Silent s] in X Shooting Menu 2, you can access silent-mode options using: The #jY Button #jY button Rotate the rear dial to select options marked with s The LV Super Control Panel Highlight [j/Y] (sequential shooting/self-timer) Rotate the front dial to select options...

  • Page 166: Long Exposure Noise Reduction (Noise Reduction S)

    (Noise Reduction s) Long Exposure Noise Reduction Reduce noise in long exposures when shooting in silent mode. Reduce noise in long exposures when shooting in silent mode. The sound of the Auto shutter may be audible when noise reduction is active. Noise reduction off.

  • Page 167: Silent-Mode Options (Silent S Mode Settings)

    (Silent s Mode Settings) Silent-Mode Options Choose whether to enable [8], [AF Illuminator], or [Flash Mode] in silent mode. Select [Allow] to use current settings for the selected item, [Not Allow] to ignore current settings and disable the selected item. Choose whether to use the settings currently selected for [8] in G Custom Menu S (P.

  • Page 168: Reducing Shutter Lag (Pro Capture Photography)

    Reducing Shutter Lag (Pro Capture Photography) Capture starts when the shutter button is pressed halfway; the moment the button is pressed the rest of the way down, the camera will start saving the last n captured pictures to the memory card, where n is a number selected before shooting begins. If the button is held all the way down, shooting will continue until the selected number of pictures is recorded.
  • Page 169 As is the case with other drive modes, Pro Capture modes can be selected using the #jY button. Press the #jY button. #jY button • [j/Y] (sequential shooting/self-timer) options will be displayed. [j/Y] (sequential shooting/self-timer) options Rotate the rear dial to highlight (Pro Capture (Pro Capture High) and press the OK Low) or...
  • Page 170  Pro Capture Options  Pro Capture options can be adjusted in G Custom Menu N. Use [jL Settings] (Pro Capture Low options) to adjust settings for Pro Capture Low and [jH Settings] (Pro Capture High options) to adjust settings for Pro Capture High. Choose the frame advance rate.
  • Page 171 Choose a setting for [Pre-shutter Frames]. • Highlight [Pre-shutter Frames] using the FG buttons and press the I button. • Highlight an option using the FG buttons and press the OK button. • To disable pre-capture, select [0]. Choose the maximum number of shots per burst ([Frame Count Limiter]).

  • Page 172: Interval-Timer Photography (Intrvl. Sh./Time Lapse)

    Interval-Timer Photography (Intrvl. Sh./Time Lapse) Take a series of photos automatically at a preset interval. You also have the option of saving the series as a time-lapse movie. • Interval-timer photography is available in modes , and • Bracketing, HDR bracketing, multiple exposure, and live ND fi lter features cannot be used. •...
  • Page 173 Highlight [On] using the FG buttons and press the I button. Highlight items using the FG buttons. • Press the I button to display options for the highlighted item. • Press the OK button when settings are complete. Press the OK button repeatedly to return to W Shooting Menu 1.

  • Page 174: Burst Mode Image Stabilization (J Image Stabilization)

    Burst Mode Image Stabilization (j Image Stabilization) Choose the type of image stabilization applied during burst shooting. To maximize the effects of image stabilization during burst shooting, the camera centers the image sensor for every shot. This slightly reduces the frame advance rate.

  • Page 175: Viewfi Nder Display Rate (Frame Rate)

    Viewfi nder Display Rate (Frame Rate) Increase the viewfi nder display rate to smooth subject motion. This eases the task of tracking fast-moving and otherwise hard-to-frame subjects. Normal The normal display rate. Select this option in most circumstances. Smooths motion even when the subject is moving quickly. Fast-moving subjects High are easier to track.

  • Page 176: 2-11 Image Stabilization

    2-11 Image Stabilization Image stabilization reduces blur caused by the camera moving while the shutter is open. The camera is equipped with 5-axis image stabilization that in addition to reducing blur caused by motion on the pitch and yaw axes, can be used with all lenses to reduce blur caused by motion on the horizontal, vertical, and roll axes.
  • Page 177  Access via the LV Super Control Panel  Highlight [K Image Stabilizer] in the LV super control panel. K image stabilization Highlight an option using the front dial. Press the shutter button halfway to select the highlighted option and exit the LV super control panel.

  • Page 178: Half-Press Image Stabilization (Half Way Rls With Is)

    Half-Press Image Stabilization (Half Way Rls With IS) Choose whether image stabilization applies while the shutter button is pressed halfway. An example of a situation in which you might want to suspend image stabilization would be when using the level gauge to keep the camera level while framing photographs.

  • Page 179: 2-12 Metering And Exposure

    2-12 Metering and Exposure The camera meters subject brightness and adjusts exposure accordingly. The camera can be confi gured to raise ISO sensitivity automatically when lighting is poor. You can also reduce fl icker when shooting under artifi cial light. K 2-12 Metering and Exposure...

  • Page 180: Adjusting Exposure (Exposure Compensation)

    Adjusting Exposure (Exposure Compensation) The exposure selected automatically by the camera can be altered to suit your artistic intent. Choose positive values to make pictures brighter, negative values to make them darker. Exposure compensation can be adjusted by up to ±5.0 EV. •...

  • Page 181: Adjusting Iso Sensitivity (K Iso)

    Adjusting ISO Sensitivity (K ISO) Select a value according to subject brightness. Higher values let you photograph darker scenes but also increase image “noise” (mottling). Select [AUTO] to let the camera adjust sensitivity according to lighting conditions. • This setting can be accessed via: - The ISO button - Live controls (P.
  • Page 182 Rotate the front or rear dial to highlight an option. • You can also rotate the front or rear dial while pressing the ISO button. Press the shutter button halfway to select the highlighted option and exit. • ISO sensitivity selection can be assigned to other controls. Use [K Button Function] (P.

  • Page 183: Options For [K Iso] > [Auto] (K Iso-Auto Set)

    Options for [K ISO] > [AUTO] (K ISO-Auto Set) Choose how the camera adjusts settings when [AUTO] is selected for [K ISO]. [High Limit]: Choose the maximum sensitivity selected automatically by the camera. [Default]: Choose the default sensitivity. Upper Limit / Default •...
  • Page 184 Highlight an item using the FG buttons and press the I button. [Upper Limit / Default]: Highlight an option using the HI buttons and use the FG buttons to change. Press the OK button to return to the [K ISO-Auto Set] menu.

  • Page 185: Shooting Mode And [K Iso] > [Auto] (K Iso-Auto)

    Shooting Mode and [K ISO] > [AUTO] (K ISO-Auto) Choose the shooting modes in which auto ISO sensitivity control ([K ISO] > [AUTO]) is available. Auto ISO sensitivity control is available when [AUTO] is selected for [K ISO] in P/A/S modes , and Auto ISO sensitivity control is available when [AUTO] is selected for [K ISO] in...

  • Page 186: Exposure Metering (Metering)

    Exposure Metering (Metering) Choose the method used to measure subject brightness. • This setting can be accessed via: - The AFp button - The menus (P. 187) - Live controls (P. 187) - The LV super control panel (P. 187) Suited to most scenes, including back-lit subjects.
  • Page 187 Rotate the front dial to highlight an option. • You can also rotate the front or rear dial while pressing the AFp button. Press the shutter button halfway to select the highlighted option and exit.  Access via the LV Super Control Panel ...

  • Page 188: Locking Exposure (Ae Lock)

    Locking Exposure (AE Lock) Lock exposure at the metered value. Use when you want to meter one subject while focusing on another or take several shots at the same exposure. Exposure lock is performed using a button. Exposure lock is available only when [mode1] or [mode2] is selected for [K AEL/AFL] (P.
  • Page 189  Using the AEL/AFL Button  Compose the shot to meter the subject for which you want to set exposure and press the AEL/AFL button once. AEL/AFL button • Exposure will lock and an u icon will appear in the S-IS AUTO S-IS AUTO display.

  • Page 190: Reducing Flicker (Flicker Reduction)

    Reducing Flicker (Flicker Reduction) When shooting under fl uorescent or other artifi cial workplace or outdoor lighting, you may notice fl icker in the live view display or uneven exposure in photos taken at fast shutter speeds. This item reduces these effects. Reducing Flicker in Live View (Anti-Flicker LV) Reduce fl...

  • Page 191: Reducing Flicker In Photographs (Anti-Flicker Shooting)

    Highlight an option using the FG buttons and press the OK button. • [Flicker reduction] options will be displayed. Press the MENU button repeatedly to exit the menus. Reducing Flicker in Photographs (Anti-Flicker Shooting) You may notice uneven exposure in photos taken under fl ickering light. When this option is enabled, the camera will detect the fl...
  • Page 192 Highlight [On] or [Off] using the FG buttons and press the OK button. • [Flicker reduction] options will be displayed. Press the MENU button repeatedly to exit the menus. • A u icon appears in the display when [On] is selected. u icon S-IS AUTO S-IS AUTO...

  • Page 193: Reducing Flicker Under Led Lighting (K Flicker Scan)

    Reducing Flicker Under LED Lighting (K Flicker Scan) Banding may occur in photographs taken under LED lighting. Use [K Flicker Scan] to optimize shutter speed while viewing banding in the display. This item can be used in , and silent mode and with High Res Shot and Pro Capture shooting.
  • Page 194 Press the MENU button repeatedly to exit the menus. • The camera will exit to the shooting display. A P icon will be displayed. 250.0 Flicker Scan P icon Choose a shutter speed while viewing the display. • Choose a shutter speed using the front or rear dial or the FG buttons.

  • Page 195: High Dynamic Range (Hdr)

    High Dynamic Range (HDR) The camera varies exposure over a series of shots, selects from each tone range with the highest level of detail, and combines them to create a single picture with a wide dynamic range. If the photo features a high-contrast subject, details that would otherwise be lost in shadows or highlights will be preserved.
  • Page 196 Press the MENU button repeatedly to exit the menus. • The camera will return to the shooting display. An c c icon icon will be displayed. • The drive mode will be fi xed at T (sequential high). S-IS AUTO S-IS AUTO 30 p 30 p...

  • Page 197: Slowing The Shutter In Bright Light (Live Nd Shooting)

    Slowing the Shutter in Bright Light (Live ND Shooting) The camera makes a series of exposures and combines to create a single photo that appears to have been taken at a slow shutter speed. • This option is available in modes Choose an ND fi...
  • Page 198 Choose an option for [ND Number]. • Highlight [ND Number] using the FG buttons and press the I button to view [ND Number] options. • Highlight the desired option using the FG buttons and press the OK button to select the highlighted option. Choose an option for [LV Simulation].
  • Page 199 Adjust shutter speed while previewing the results in S-IS AUTO S-IS AUTO S-IS AUTO S-IS AUTO the display. • Adjust shutter speed using the front or rear dial. ISO-A • The slowest shutter speed available varies with the ND fi lter selected. 30 p 30 p [ND2 (–1EV)]: 1/30 s...

  • Page 200: Live View Exposure Preview (Live View Boost)

    Live View Exposure Preview (Live View Boost) Exposure settings such as exposure compensation can be previewed during live view. Alternatively, you can adjust brightness for ease of viewing under night skies and in other dark environments. Settings can be adjusted separately for mode long exposures, live composite photography, and the like.
  • Page 201 Highlight an option using the FG buttons and press the OK button. • [Off] is not available when [Bulb/Time] is selected. • If you press the I button when [On2] is highlighted, you will be prompted to choose whether to give priority to display frame rate or display quality.

  • Page 202: 2-13 Color And Quality

    2-13 Color and Quality This section is primarily devoted to features that affect the color and fi nal look of photographs. Covered are white balance, picture mode, and other items that affect color balance and features (such as High Res Shot) for shooting high-resolution pictures.
  • Page 203  Access via the WB Button  Press the WB button. WB button • [K WB] options will be displayed. [K WB] options Rotate the front or rear dial to highlight an option. • Pressing the INFO button when [AUTO] is highlighted displays [KW Keep Warm Color] options (P.
  • Page 204  Access via the LV Super Control Panel  White balance can be selected using the LV super control panel. OK button [K WB] Use the front dial to choose an option • [KW Keep Warm Color] options can be adjusted after you highlight [AUTO] in the [K WB] menu and press the OK button (P.

  • Page 205: Preserving Warm Colors (Kw Keep Warm Color)

    Preserving Warm Colors (KW Keep Warm Color) If desired, auto white balance can be adjusted to preserve the warm colors seen under incandescent lighting. White balance would normally be adjusted to make white colors appear white, but this feature can be used to preserve the ambiance created by incandescent lighting.

  • Page 206: Fine-Tuning White Balance (K White Balance Compensation)

    Fine-Tuning White Balance (K White Balance Compensation) Fine-tune white balance. Separate values can be selected for each white balance option. Adjust settings as described below. • This setting can be accessed via: - The LV super control panel - The menus A A (amber–blue) axis Positive values add a red cast, negative values a blue cast.

  • Page 207: Metering White Balance (One-Touch White Balance P/Q/W/X)

    Metering White Balance (One-Touch White Balance P/Q/W/X) Set white balance to a value measured under the lighting that will be used in the fi nal photograph. Use this option to fi ne-tune white balance when you fi nd it hard to obtain the desired results with white balance compensation or preset white balance options such as 5 (sunlight) or O (overcast).
  • Page 208 Press the INFO button. • One-touch white balance measurement options will be displayed. Frame a sheet of uncolored (white or gray) paper in the center of the display and release the shutter. • Be sure the subject is free of shadows. •...
  • Page 209  Access via the LV Super Control Panel  One-touch white balance can be selected using the LV super control panel. OK button INFO button Highlight P to X using the front dial [K WB] Meter white balance • Press the shutter button to meter white balance as described in “Access via the WB Button” (P.

  • Page 210: High-Resolution Photos (High Res Shot)

    (extension “*.ORI”). Select High Res Shot before adjusting [KK]. g “High Res Shot Image Quality (KK)” (P. 213) • Unprocessed RAW (ORI) images can be viewed using the latest version of Olympus Workspace. Choose how long the camera waits to begin shooting after the shutter High Res Shot button is pressed all the way down.
  • Page 211 Highlight the desired item and press the I button. • Press the OK button after adjusting each of: Highlight [0 sec] using the G button [High Res Shot]: and press the I button. Choose a wait time. Choose a time. [#Charge Time]: [Shooting Method]: Select [Tripod] or [Handheld].
  • Page 212 High Res Shot can also be selected using the #jY button, the LV super control panel, and live controls. If High Res Shot does not appear in the drive mode list, it can be added using the menus (P. 210). ...

  • Page 213: High Res Shot Image Quality (Kk)

    High Res Shot Image Quality (KK) Enabling High Res Shot automatically sets image quality to an option compatible with the higher resolution. Before shooting, be sure to check the option selected for image quality. • This setting can be accessed via: - The LV super control panel - Live controls (P.
  • Page 214 Press the shutter button halfway to exit the LV super control panel. • The option selected for image quality may change if you choose a different option for [K Save Settings] (P. 72) or insert a memory card with space remaining; before shooting, be sure to check the option selected for image quality.

  • Page 215: Image Enhancement (Picture Mode)

    Image Enhancement (Picture Mode) Choose how pictures are processed during shooting to enhance color, tone, and other properties. Choose from preset picture modes according to your subject or artistic intent. Contrast, sharpness, and other settings can be adjusted separately for each mode. You can also add artistic effects using art fi lters. Art fi lters give you the option of added frame effects and the like.
  • Page 216 Increase saturation and contrast and blur out-of-focus areas to make Diorama the picture look like a photo of a miniature. Choose for an edgy, surrealistic effect. Choose Cross Process 2 for a Cross Process color balance that exaggerates magenta. Choose for a peaceful, refi ned effect that softens the image overall, Gentle Sepia creating serene pictures with clearly-defi...

  • Page 217: Choosing A Picture Mode

    Choosing a Picture Mode This setting can be accessed via: • The LV super control panel • The menus (P. 218) • Live controls  Access via the LV Super Control Panel  Highlight [Picture Mode] in the LV super control Picture mode panel.
  • Page 218  Menu Access  Use [Picture Mode] in W Shooting Menu 1. MENU button W tab Use FG on the arrow pad to select [Picture Mode] Press the I button to view picture mode parameters or fi lter effects • You can adjust the individual parameters for each picture mode. You can also adjust parameters in the LV super control panel.

  • Page 219: Creating Custom Picture Modes (K Custom Picture Mode)

    Creating Custom Picture Modes (K Custom Picture Mode) Create custom picture modes by editing the parameters for exiting modes. Custom picture modes can be created using [i-Enhance], [Vivid], [Natural], [Muted], [Portrait], and [Monochrome]. Press the MENU button to display the menus. Highlight [Picture Mode] in W Shooting Menu 1 and press I on the arrow pad.

  • Page 220: Adjusting Sharpness (Sharpness)

    Adjusting Sharpness (Sharpness) Adjust image sharpness. Outlines can be emphasized for a sharp, clear picture. Settings are stored separately for each picture mode. • This setting can be accessed via: - The LV super control panel - The menus Hi (+) Increase sharpness.

  • Page 221: Adjusting Contrast (Contrast)

    Adjusting Contrast (Contrast) Adjust image contrast. Increasing contrast heightens the difference between bright and dark areas for a harder, more well-defi ned picture. Settings are stored separately for each picture mode. • This setting can be accessed via: - The LV super control panel - The menus Hi (+) Increase contrast.

  • Page 222: Adjusting Vividness (Saturation)

    Adjusting Vividness (Saturation) Adjust color saturation. Increasing saturation makes pictures more vivid. Settings are stored separately for each picture mode. • This setting can be accessed via: - The LV super control panel - The menus Hi (+) Increase saturation. Colors are more vivid. Lo (−) Lower saturation.

  • Page 223: Adjusting Shading (Gradation)

    Adjusting Shading (Gradation) Adjust color brightness and shading. Bring pictures closer to what you envisage by, for example, brightening the entire picture. Settings are stored separately for each picture mode. • This setting can be accessed via: - The LV super control panel - The menus Brightness is adjusted separately for every detail.

  • Page 224: Color Filters For Black-And-White Photography (Color Filter)

    Color Filters for Black-and-White Photography (Color Filter) Color fi lter effects can be added when [Monochrome] is selected for picture mode (P. 215). Depending on the color of the subject, color fi lter effects can make subjects brighter or enhance contrast. Orange adds more contrast than yellow, red more contrast than orange.

  • Page 225: Monochrome Tints (Monochrome Color)

    Monochrome Tints (Monochrome Color) Add a tint to black-and-white pictures in the [Monochrome] picture mode (P. 215). • This setting can be accessed via: - The LV super control panel - The menus N:Normal Shoot in black and white. S:Sepia Shoot in sepia-tinted monochrome.

  • Page 226: Adjusting I-Enhance Effects (Effect)

    Adjusting i-Enhance Effects (Effect) Choose the strength of the effect for [i-Enhance]. • This setting can be accessed via: - The LV super control panel - The menus 3 Low (Effect: Low) Effect reduced. 3 Standard Standard effect. (Effect: Standard) 3 High (Effect: High) Effect heightened.

  • Page 227: Choosing A Tone Curve (Highlight&Shadow Control)

    Choosing a Tone Curve (Highlight&Shadow Control) Adjust brightness separately for highlights, mid-tones, and shadows. You gain greater control over exposure than you would with exposure compensation alone. You can selectively make highlights darker or shadows brighter. Adjusting shadows Adjusting mid-tones Adjusting highlights (The illustrations above show the display when the highlight and shadow control is accessed via a button and the LV super control panel.)
  • Page 228 • Exposure compensation, and with it highlight and shadow control, can be assigned to controls other than the F button. Use [K Button Function] (P. 463) in G Custom Menu • Assigning [Multi Function] to the control gives you direct access to [Highlight&Shadow Control].

  • Page 229: Hue And Saturation (Color Creator)

    Hue and Saturation (Color Creator) The camera permits intuitive adjustments to color saturation and hue. Choose from 30 hues and 8 levels of saturation. The results can be previewed in the display. [Color Creator] is a picture mode option. Settings can be accessed directly using [Multi Function].
  • Page 230 Adjust saturation and hue. Color Color • Rotate the front dial to adjust hue. • Rotate the rear dial to adjust saturation. • Press and hold the OK button to restore default settings. ViVid±0 ViVid±0 Reset Reset Press the OK button to save changes. •...

  • Page 231: Leave Color" Effects (Partial Color)

    “Leave Color” Effects (Partial Color) Shoot in black-and-white while capturing objects of a selected hue in color. For example, you can shoot in black-and-white while leaving only reds in color. The results can be previewed in the display. [Partial Color] is an art fi lter option. Settings can be adjusted when it is selected for picture mode.

  • Page 232: Choosing A Color Space (Color Space)

    Choosing a Color Space (Color Space) Choose a color space to ensure accurate color reproduction when photos are output to a printer or external display. The established color space standard for Windows systems. It is widely sRGB supported across displays, printers, digital cameras, and computer applications. This setting is recommended in most circumstances.

  • Page 233: 2-14 Effects

    2-14 Effects This section deals with multiple exposure, zoom, and other features used to manipulate the image during shooting. It also covers features such as exposure bracketing, which varies exposure over a series of pictures, and focus stacking. Aspect Ratio (Image Aspect) Choose the ratio of width to height for pictures according to your intent or your goals for printing or the like.
  • Page 234  Access via the LV Super Control Panel  Highlight [Image Aspect] in the LV super control panel. Image aspect Highlight an option using the front dial. Press the shutter button halfway to select the highlighted option and exit the LV super control panel.

  • Page 235: Zoom (Digital Tele-Converter)

    Zoom (Digital Tele-converter) This option takes a crop at the center of the frame the same dimensions as the size option currently selected for image quality and zooms it in to fi ll the display. The zoom ratio increases by about 2×. This allows you to zoom in past the lens’ maximum focal length, making it a good choice when you are unable to switch lenses or fi...

  • Page 236: Varying Settings Little-By-Little Over A Series Of Shots (Bracketing)

    Varying Settings Little-by-Little over a Series of Shots (Bracketing) Bracketing is used to vary shooting settings such as exposure and white balance over a series of shots. Depending on the setting, you may be able to combine several different forms of bracketing. Use bracketing if you are unsure what settings to use or lack the time needed to change settings during shooting.
  • Page 237 WB BKT (White Balance Bracketing) The camera varies white balance to record a series of pictures. You choose the color axis, the amount, and the number of shots. Shooting ends after a single shot. The camera takes one picture when the shutter button is pressed all the way down and automatically processes it to record the selected number of shots.
  • Page 238 ISO BKT (ISO Sensitivity Bracketing) The camera varies ISO sensitivity to record a series of pictures. You choose the amount and the number of shots. Shooting ends after a single shot. The camera takes one picture when the shutter button is pressed all the way down and automatically processes it to record the selected number of shots.
  • Page 239 Focus stacking ([Focus Stacking], P. 243) can be used to create a single picture from a series of shots taken using focus bracketing. This option is available only with lenses that support focus stacking. See the Olympus website for information on compatible lenses.
  • Page 240  Access via the BKT Button  Use the BKT to choose the bracketing type and adjust settings. Settings for [ART BKT] or [Focus BKT] must be adjusted in the menus beforehand. Hold the BKT and rotate the front or rear dial a small amount.
  • Page 241 Press the BKT once to enable bracketing. BKT button • A t icon will be displayed. t icon • Bracketing turns on or off each time the BKT button is pressed. S-IS AUTO S-IS AUTO ISO-A 30 p 30 p 1:02:03 250 F5.6 1023...
  • Page 242 Highlight a bracketing type using the FG buttons and press the I button. • The camera will display bracketing options for the selected bracketing type. Using the FGHI buttons, select [On] or a bracketing program. • AE BKT Highlight the number of shots (for example, 2f) and press the I button to view bracketing amounts.

  • Page 243: Increasing Depth Of Field (Focus Stacking)

    • If focus stacking fails, the camera will record the selected number of photos without creating a composite image. • This option is available only with lenses that support focus stacking. See the Olympus website for information on compatible lenses.
  • Page 244 Highlight [On] using the FG buttons and press the I button. • [Focus BKT] settings will be displayed. Highlight a setting using the FG buttons and press the I button. Highlight [On] and press the OK [Focus Stacking]: button. [Set number of shots]: Choose the number of shots. Choose from values of from 3 to 15.
  • Page 245 Press the BKT button to end bracketing. • To take more pictures at the same bracketing settings, press the BKT button. • The fl ash can only be used if [Allow] is selected for [Silent s Mode Settings] (P. 167) > [Flash Mode] in X Shooting Menu 2.

  • Page 246: Overlaying Pictures (Multiple Exposure)

    Overlaying Pictures (Multiple Exposure) Take two shots and combine them into a single picture. Alternatively, you can take a shot and combine it with an existing picture stored on the memory card. The combined image is recorded at current image quality settings. Only RAW pictures can be selected for multiple exposures that include an existing image.
  • Page 247 Press the MENU button to exit the menus. • A a icon will be displayed. a icon • If [Overlay] is selected, the chosen photograph will be visible superimposed on the view through the lens. ISO-A 1:02:03 250 F5.6 1023 Take pictures.

  • Page 248: Keystone Effects/Enhancing Perspective (Keystone Comp.)

    Keystone Effects/Enhancing Perspective (Keystone Comp.) Keystone distortion due to the infl uence of lens focal length and proximity to the subject can be corrected, or enhanced to exaggerate the effects of perspective. Keystone compensation can be previewed in the monitor during shooting. The corrected image is created from a smaller crop, slightly increasing the effective zoom ratio.
  • Page 249 To adjust aperture, shutter speed, and other shooting settings, press the INFO button. • Standard shooting indicators will be displayed. • A z icon is displayed while keystone compensation is S-IS AUTO S-IS AUTO S-IS AUTO S-IS AUTO enabled. The icon is displayed in green if adjustments have been made to keystone compensation settings.

  • Page 250: Correcting Fisheye Distortion (Fisheye Compensation)

    Correcting Fisheye Distortion (Fisheye Compensation) Correct distortion caused by fi sheye lenses to give photos the appearance of pictures taken with a wide-angle lens. The amount of correction can be selected from three different levels. You can also opt simultaneously to correct distortion in photos taken under water.
  • Page 251 Press the OK button repeatedly to exit to the custom menu. • After confi rming that [On] is selected for [Fisheye Compensation], press the MENU button to exit the menus. • When fi sheye compensation is enabled, a A icon will Fisheye compensation be displayed together with the selected crop.

  • Page 252: 2-15 Flash Photography

    2-15 Flash Photography When using an optional fl ash unit designed for use with the camera, you can choose the fl ash mode using camera controls and take pictures with the fl ash. See the documentation provided with the fl ash unit for information on fl ash features and their use.
  • Page 253  Features Available with Compatible Flash Units  Supported fl ash control GN (Guide Number, Supported wireless Flash unit modes ISO 100) systems TTL-AUTO, MANUAL, CMD, #CMD, RCV, GN 42 (150 mm * FL-700WR FP TTL AUTO, FP MANUAL, X-RCV, RC GN 21 (24 mm * MULTI, RC, SL MANUAL GN 58 (200 mm *...

  • Page 254: Choosing A Flash Mode (#Flash Mode)

    Choosing a Flash Mode (#Flash Mode) When taking pictures with a fl ash unit designed for use with the camera, you can select a fl ash mode using camera controls. Turning an attached fl ash unit on automatically limits the fastest available shutter speed. ...
  • Page 255  Flash Mode and Shutter Speed  The range of shutter speeds available varies with the fl ash mode. The range of available speeds can be further restricted using the options in the G custom menu. g [#X-Sync.] (P. 260), [#Slow Limit] (P. 261) Exposure LV super mode...
  • Page 256  Attaching Compatible Flash Units  The methods used to attach and operate external fl ash units vary with the unit. See the documentation provided with the unit for details. The instructions here apply to the FL-LM3. • Confi rm that both the camera and fl ash unit are off. Attaching or removing a fl ash unit while either the camera or fl...
  • Page 257  Removing Flash Units  Keeping the UNLOCK button pressed, slide the UNLOCK button fl ash unit from the hot shoe.  Accessing Flash Settings via the #jY (Flash/Sequential  Shooting/Self-timer) Button Press the #jY button. Flash mode options • Flash mode options will be displayed. Rotate the front dial to highlight an option.
  • Page 258  Access via Live Controls  Flash settings can be accessed via live controls. • For information on displaying live controls, see “Using Live Controls” (P. 68). #Flash Mode OK button Press HI on the arrow pad to choose an option [#Flash Mode] •...

  • Page 259: Adjusting Flash Output (X)

    Adjusting Flash Output Adjust fl ash output. Use this option to adjust fl ash level if the fl ash is too bright even in auto mode or if the value selected by the camera leaves your subject underexposed. Flash compensation is available in modes other than [# Manual] (manual). Highlight [x] in the LV super control panel.

  • Page 260: Choosing A Flash Sync Speed (#X-Sync.)

    Choosing a Flash Sync Speed (#X-Sync.) Choose the fastest shutter speed available for fl ash photography. Shutter speeds faster than the chosen value cannot be selected even when the subject is brightly lit. 1/60  –   1 /250 s Available options Press the MENU button to display the menus.

  • Page 261: Setting A Slow Shutter Speed Limit (#Slow Limit)

    Setting a Slow Shutter Speed Limit (#Slow Limit) Choose the slowest shutter speed available for fl ash photography. The shutter speed chosen automatically by the camera will not exceed this value even when the subject is poorly lit. This limit does not apply in slow sync fl ash modes (2, M, or 1).

  • Page 262: Wireless Remote Flash Control

    Wireless Remote Flash Control Wireless fl ash photography is available with compatible fl ash units that support wireless remote control (RC). The remote fl ash units are controlled via a unit mounted on the camera hot shoe. Settings can be adjusted separately for the camera-mounted unit and units in up to three other groups.
  • Page 263 Adjust fl ash settings. • Highlight items using the FGHI buttons and rotate the rear dial to choose settings. Flash control mode Flash mode A Mode +5.0 Optical signal strength Manual Group – +3.0 Channel Flash compensation 1:02:03 F5.6 1023 Choose a group.

  • Page 264: Third-Party Flash Units

    fl ash units requiring voltages over about 250 V must not be used, as they could damage the connectors. • Attaching fl ash units with connectors that do not conform to Olympus specifi cations could cause product malfunction.

  • Page 265: 2-16 Working With Saved Images

    2-16 Working with Saved Images Pictures are saved to the memory card and can be viewed in the camera monitor. You can rotate or delete pictures or retouch them using many of the same functions used when they were recorded. You can also quickly select pictures for later upload to a smartphone.

  • Page 266: The Playback Info Display

    The Playback Info Display Basic Info Full Info 2 3 4 8 90a ×10 ×10 48kHz 48kHz F5.6 +2.0 45mm +1.0 AUTO ISO 400 sRGB Natural 5184×3888 100-0015 100-0015 HDR1 HDR1 2019.04.01 12:30:00 2019.04.01 12:30:00 f e d HDR1 1 Battery level ........P. 44 i Live ND fi...

  • Page 267: Zooming In (Playback Zoom)

    Zooming In (Playback Zoom) You can zoom in on pictures during playback. Use zoom to examine photos in the monitor. You can scroll the picture to view areas not currently visible in the display. Press the q button. • The most recent picture will be displayed. 100-0015 2019.04.01 12:30:00 Rotate the rear dial to a.

  • Page 268: Finding Pictures Quickly (Index And Calendar Playback)

    Finding Pictures Quickly (Index and Calendar Playback) “Index playback” lists the pictures on the memory card as small “thumbnail” images so that you can view multiple pictures at once. This makes it easier to fi nd the picture you want. You can also switch to a calendar display and search for pictures by date of recording.

  • Page 269: Rotating Pictures (Rotate)

    Rotating Pictures (Rotate) Rotate pictures for display. Use this option to view pictures taken in portrait (“tall”) orientation without rotating the camera. Press the q button. • The most recent picture will be displayed. 100-0015 2019.04.01 12:30:00 Press the OK button. •...

  • Page 270: Protecting Pictures (0)

    Protecting Pictures Protect pictures from accidental deletion. Protected pictures cannot be deleted using options that delete multiple pictures, but they will be deleted if the memory card is formatted. • This setting can be accessed via: - The 0 button - The menus (P.

  • Page 271: Removing Protection From All Pictures (Reset Protect)

     Menu Access  Display a picture and press the OK button to view options. OK button OK button Press F or G on the arrow pad once to protect, again Press the OK button to save changes and exit to remove protection Removing Protection from All Pictures (Reset Protect)

  • Page 272: Copying Pictures Between Cards (Copy)

    Copying Pictures Between Cards (Copy) To copy a picture from one memory card to the other when two memory cards are inserted: Press the q button. • The most recent picture will be displayed. 100-0015 2019.04.01 12:30:00 Rotate the front dial to display a picture you want to copy.
  • Page 273 If you selected [Assign] in Step 5, choose the destination folder. • Highlight [New Folder] or [Existing Folder] using the FG buttons and press the OK button. [New Folder]: Choose the desired folder number using the FG buttons and press the OK button.

  • Page 274: Copying All Pictures (Copy All)

    Copying All Pictures (Copy All) When two memory cards are inserted, you can copy all pictures from one card to the other in a single operation. Copy all pictures from the memory card in Slot 1 to the card in Slot 2. Copy all pictures from the memory card in Slot 2 to the card in Slot 1.

  • Page 275: Deleting Pictures (Erase)

    Deleting Pictures (Erase) Delete pictures from the memory card one at a time. • Pictures can be deleted via: - The  button - The menus  Deleting Pictures via the  Button  Press the q button. • The most recent picture will be displayed. 100-0015 2019.04.01 12:30:00 Rotate the front dial to display a picture you want to...

  • Page 276: Deleting All Pictures (All Erase)

    Deleting All Pictures (All Erase) Delete all pictures from the memory card. Protected pictures will not be deleted. Press the MENU button to display the menus. Highlight [Card Setup] in the e setup menu and press I on the arrow pad. •...

  • Page 277: Selecting Pictures For Sharing (Share Order)

    Selecting Pictures for Sharing (Share Order) Smartphones running the OI.Share smartphone app can download pictures from the camera. Pictures marked for download on the camera can be downloaded automatically when the camera is off. For information on establishing a connection between the camera and smartphone, see “6-2 Connecting to Smartphones via Wi-Fi”...

  • Page 278: Removing Share Marking From All Pictures

     Menu Access  Display a picture and press the OK button to view options. OK button OK button Press F or G on the arrow pad once to select, [Share Order] Press the OK button to save changes and exit again to deselect •...

  • Page 279: Selecting Multiple Pictures

    Selecting Multiple Pictures (0/Copy Select/Erase Selected/ Share Order Selected) You can select multiple pictures for protection, copying, deletion, or sharing. Press the q button. • The most recent picture will be displayed. 100-0015 2019.04.01 12:30:00 Rotate the front dial to display a picture you want to share.
  • Page 280 After selecting pictures, press the OK button. • To exit without proceeding to Step 5, press the MENU button. Highlight the operation you want to perform on the selected pictures ([0], [Copy Select], [Erase Selected], or [Share Order Selected]) and press the OK button.

  • Page 281: Adding Audio To Pictures (K)

    Adding Audio to Pictures You can record audio and add it to pictures. The recorded audio provides a simple replacement for written notes about the pictures. • Audio recordings can be up to 30 s long. Press the q button. •...
  • Page 282  Audio Playback  Playback begins automatically when a picture with audio is displayed. To adjust the volume: Press the q button to display a picture. Press F or G on the arrow pad. • F button: Raise volume. • G button: Lower volume. 282 EN K 2-16 Working with Saved Images...

  • Page 283: Automatically Rotating Portrait-Orientation Pictures For Playback (R)

    Automatically Rotating Portrait-Orientation Pictures for Playback Choose whether pictures shot in portrait orientation are automatically rotated for display on the camera. Pictures are automatically rotated for display during playback. Pictures are not automatically rotated for display during playback. Press the MENU button to display the menus. Highlight [R] in the q playback menu and press I on the arrow pad.

  • Page 284: Retouching Pictures (Edit)

    Retouching Pictures (Edit) Create retouched copies of pictures. In the case of RAW pictures, you can adjust the settings in effect at the time the picture was taken, such as white balance and picture mode (art fi lters included). With JPEG pictures, you can make simple edits such as cropping and resizing.
  • Page 285 Highlight [Sel. Image] using the FG buttons and press the OK button. • The pictures on the memory card will be displayed. Using the HI buttons, select a picture you want to retouch and press the OK button. • Retouch options will be displayed. •...
  • Page 286 To create additional copies from the same original, highlight [Reset] and press the OK button. To exit without creating more copies, highlight [No] and press the OK button. • Selecting [Reset] displays the retouch menu. Repeat the process from Step 5. •...

  • Page 287: Retouching Jpeg Pictures (Jpeg Edit)

    Retouching JPEG Pictures (JPEG Edit) The [JPEG Edit] menu contains the following options. Shadow Adj. Brighten back-lit subjects. Red-eye Fix Reduce “red-eye” in pictures taken with a fl ash. Crop pictures. Size the crop with the front or rear dial and position it with the arrow pad.
  • Page 288 Using the HI buttons, select a picture you want to retouch and press the OK button. • Retouch options will be displayed. • If the current picture is not a JPEG image, [JPEG Edit] will not be displayed. Select a different image. 100-0015 +RAW +RAW...

  • Page 289: Combining Pictures (Image Overlay)

    Combining Pictures (Image Overlay) Overlay existing RAW photos and to create a new picture. Up to 3 pictures can be included in the overlay. The results can be modifi ed by adjusting brightness (gain) separately for each picture. • The overlay is saved in the format currently selected for image quality. Overlays created with [RAW] selected for image quality are saved in RAW format and in JPEG format using the image quality option selected for [K2] (P.
  • Page 290 Adjust gain for the pictures in the overlay. • Use the HI buttons to select pictures and the FG buttons to choose a value. • Choose from values of from 0.1 to 2.0. Check the results in the display. Press the OK button to display a confi rmation dialog.

  • Page 291: Selecting Pictures For Printing (< - Dpof)

    Selecting Pictures for Printing (< — DPOF) You can select pictures for printing and choose the number of copies and the information printed on each picture. The pictures can be printed at print shops that support the Digital Print Order Format (DPOF). A digital print order is stored on the memory card.
  • Page 292  Removing All or Selected Pictures from the Print Order  You can remove all or selected pictures from the print order. Press the OK button during playback and select [<]. Highlight [<] and press the OK button. • To remove all pictures from the print order, highlight [Reset] and press the OK button. To proceed without removing all pictures from the print order, highlight [Keep] and press the OK button.

  • Page 293: Shooting And Viewing Movies

    Shooting and Viewing Movies Read this chapter for information on using the camera to record movies. This chapter also covers the features needed to record movies and view them on the camera.

  • Page 294: Basic Recording And Playback

    Basic Recording and Playback The R (movie) button can be used for basic movie recording even in still photography modes. The camera also offers a dedicated n (movie) mode for advanced movie recording. Basic recording and playback operations are the same in either case.

  • Page 295: Recording Movies

    Recording Movies Holding the Camera • Keep your fi ngers or objects such as the camera strap away from the lens. Recording Movies with the Touch Screen When the mode dial is rotated to n (movie), the movie recording display will appear in the monitor.
  • Page 296 Press the R (movie) button to start recording. • The camera will start the recording count and display the recording time. • You can tap the display at any time during recording to shift focus to a new location. R (movie) button TC 00:00:00:12 DF M-IS M-IS...

  • Page 297: Remote Photography

    • You can select different options for [n AF Mode] (P. 345). • You can zoom in on the AF target (P. 364). Use this feature for greater precision when focusing using manual focus (MF). • You can confi gure the display so that it does not automatically switch from the monitor to the viewfi...

  • Page 298: Touch Screen Options

    Touch Screen Options When touch controls are enabled, you can touch your subject in the display to focus or to position or zoom in on the AF target. Tap V in the monitor to choose an option. • The option selected changes each time you tap V. TC 00:00:00:00 DF M-IS M-IS...

  • Page 299: Using The Viewfi Nder

    Using the Viewfi nder Putting your eye to the viewfi nder turns it on and turns the monitor off. Rotate the mode dial to n. • Movie recording info will be displayed. • Movies can also be fi lmed in modes , and .

  • Page 300: Viewing Movies

    Viewing Movies View movies stored on the memory cards. Press the q button. • The most recent picture will be displayed (single-frame 48kHz playback). • Use the multi selector (T) or front dial (k) or HI on the arrow pad to view other pictures. •...

  • Page 301: Playback Volume

    Display a movie and press the OK button. • Movie playback options will be displayed. • If the movie exceeds 4 GB in size, a list options will be displayed. g “Viewing Movies over 4 GB in Size” (P. 301) Highlight [Play Movie] and press the OK button.

  • Page 302: Choosing A Memory Card

    Choosing a Memory Card When two memory cards are inserted, you can switch slots without leaving playback. Press the q button. 48kHz • The most recent picture will be displayed. AUTO TC 00:00:00:00 DF 100-0004 30 p 30 p 2019.04.01 12:30:00 Hold the CARD (card select) button, rotate the front or rear dial to choose a card slot, and then release the CARD button.

  • Page 303: Playback Using Touch Controls

    Playback Using Touch Controls Movies can be viewed using touch controls. Press the q button to view pictures. Touch the monitor and slide your fi nger left or right. • Flick left to view the next picture, right to view the previous picture.

  • Page 304: Shooting Settings

    Shooting Settings The camera offers many recording-related functions. Settings can be adjusted using any of the following methods; choose a method according to shooting conditions and how often the setting is accessed. Exposure compensation, white balance, and other frequently-used settings Direct buttons are assigned to buttons.

  • Page 305: Direct Buttons

    Direct Buttons Frequently-used shooting functions are assigned to the camera’s buttons, dials, and other controls. These are referred to as “direct buttons”. Included are the controls listed below, which can be used for basic shooting settings. Direct button Assigned function Y (one-touch white Focus peaking balance button) button...

  • Page 306: Touch Controls (Silent Controls)

    Touch Controls (Silent Controls) Frequently-used options can be accessed via touch TC 00:00:00:00 DF M-IS M-IS controls. This prevents the sound of the buttons being C-AF recorded with movies. By default, a silent control tab is ISO-A displayed when you select n (movie) mode; if it is not, it can be displayed using the menus.
  • Page 307  Using Silent Controls  Using silent controls prevents the sound of the buttons being recorded with movies and helps reduce blur caused by camera shake. Tap the silent control tab in the display. TC 00:00:00:00 DF M-IS M-IS • Silent controls will be displayed. C-AF •...
  • Page 308  Displaying the Silent Control Tab  Use the menus to hide or display the silent control tab. When the tab is not displayed, it can be displayed using the menus. Press the MENU button to display the menus. Highlight the n (video menu) tab using FG on the arrow pad and press the I button.

  • Page 309: The Lv Super Control Panel

    The LV Super Control Panel Access shooting settings via the list displayed in the LV super control panel. You can also check current settings. The panel lists settings for both still photography and movie recording. • The settings listed in still photography modes differ from those displayed in n (movie) mode.
  • Page 310  Additional Options  Pressing the OK button in Step 2 displays options for the INFO button highlighted setting. In some cases, additional options can be viewed by pressing the INFO button. OK button INFO [n Image Stabilizer] • Touch controls can be used in place of the OK button. Lightly tap the desired setting twice to display options.
  • Page 311  Settings Available in the LV Super Control Panel  1 Option currently selected f Picture mode........P. 388 2 n ISO sensitivity ......P. 369 g N Sharpness........P. 396 3 n AF mode ........P. 345 u Contrast ........P. 397 t Saturation ........

  • Page 312: Using Live Controls

    Using Live Controls Live controls are used to view and adjust settings during live view. The effects of the selected settings can be previewed in the live view display. At default settings, live controls can be accessed from the LV super control panel. If you are unable to access live controls, their display can be enabled in the menus.
  • Page 313 Highlight [n Display Settings] using the FG buttons and press the I button. Highlight [n Control Settings] using the FG buttons and press the I button, then highlight [Live Control] and press the OK button again. • A check (v) will appear next to [Live Control]. •...

  • Page 314: Using The Menus

    Using the Menus Items not listed in the control panels can be found in the menus, including items for adjusting shooting and playback settings and customizing the camera for ease of use. Tab name Item (setting) Tab name Description Photography-related items. Ready the camera for shooting or Shooting Menu 1 * access basic photo settings.
  • Page 315 Press the MENU button to display the menus. Tool tip On-screen guides Press the MENU button to exit to Press the OK button to select the the previous display highlighted item • Tool tips are displayed for roughly 2 seconds after an item is highlighted. Press the INFO button to view or hide tool tips.

  • Page 316: Card-Related Settings

    Card-Related Settings This section describes memory-card–related settings. In movie mode, you can choose the card used to store movies. You can also choose the folder used to store movies. For information on the memory cards that can be used for movie recording, see “Memory Cards”...
  • Page 317 Highlight [n Save Slot] using FG on the arrow pad and press the I button. Highlight an option using the rear dial or the FG buttons. [5]: Movies are recorded to the card in Slot 1. [4]: Movies are recorded to the card in Slot 2. Press the OK button to select the highlighted option.

  • Page 318: Storage Slot Selection

    Storage Slot Selection When two memory cards are inserted, the card used to store new pictures can be selected using the CARD (card select) button. Press the CARD button. • In n (movie) mode, the camera will display [n Save Slot] options.
  • Page 319 Storage Folder Selection (Assign Save Folder) Choose the folder in which subsequent pictures will be stored. This option is available even when only one memory card is inserted. • This setting can be accessed via: - The LV super control panel - The menus (P.
  • Page 320 Highlight an option using the FG buttons. [New Folder]: Choose the desired folder number and press the OK button. [Existing Folder]: Highlight an existing folder using the FG buttons and press the OK button. The camera will display the fi rst two photos and the last photo in the selected folder.
  • Page 321 Movie File Settings Choose the frame size and frame rate at which movies are recorded. The camera can store multiple user-selected combinations of frame size and rate for quick recall via the LV super control panel or live controls. The camera also records time codes that can be used, for example, when editing movies.
  • Page 322 The Movie Quality Icon Changes to settings are refl ected in the [nK] icon as shown below. Frame size FHD Full HD * 1920 × 1080 HD * 1280 × 720 4K * 3840 × 2160 C4K 4K Digital Cinema * 4096 ×...
  • Page 323  Access via the LV Super Control Panel  Highlight [nK] in the LV super control panel and press the OK button. • Movie quality options will be displayed. n image quality Choose a movie quality option using the front dial. •...

  • Page 324: Time Code Settings

    Time Codes (Time Code Settings) Adjust time code settings. Time codes are used to synchronize picture and sound during editing and the like. Choose from the following options. Choose a time code recording option. Use time codes where precise timing is required.
  • Page 325 Highlight an option using the FG buttons and press the OK button. • If you selected [Starting Time], choose from [Reset], [Manual Input], and [Current Time] and press the OK button. If you selected [Manual Input], choose a value using the arrow pad. Press the MENU button repeatedly to exit the menus.

  • Page 326: The Viewfi Nder And Monitor Displays

    The Viewfi nder and Monitor Displays The camera uses an eye sensor to automatically switch between the monitor and viewfi nder displays. The monitor live view display and viewfi nder also show information on camera settings. Options are available for controlling display switching and choosing the information shown.

  • Page 327: Choosing The Information Displayed

    Choosing the Information Displayed Choose the indicators shown in the shooting display. Press the INFO button repeatedly. • The information displayed changes each time the INFO button is pressed. INFO TC 00:00:00:00 DF M-IS M-IS TC 00:00:00:00 DF M-IS M-IS C-AF C-AF ISO-A...
  • Page 328 Display Selection Options (EVF Auto Switch) Choose how the camera selects the display used for live view. • This setting can be accessed via: - The u button - The menus  Using the u (LV) Button  Press and hold the u button. •...

  • Page 329: The Shooting Display

    The Shooting Display The following indicators are displayed when the camera is in n (movie) mode. The indicators displayed can be chosen in the menus. 2 3 4 ±0 M-IS M-IS TC 00:00:00:12 DF C-AF AUTO ISO-A 30 p 30 p ●...
  • Page 330 Viewfi nder (Movie Recording) M-IS M-IS TC 00:00:00:00 DF C-AF Sh-3 Mid+2 Hi+6 REC 00:12 ISO-A 250 F5.6 +2.0 0:29:47 123min AUTO Sh-3 Mid+2 Hi+6 REC 00:12 ISO-A 250 F5.6 +2.0 0:29:47 123min AUTO a b c +2.0 AUTO • This is the default display style ([Style 2]). The display style can be selected using G Custom Menu a >...

  • Page 331: Restoring Default Settings (Reset)

    Restoring Default Settings (Reset) Reset the camera to factory default settings. You can opt to reset almost all settings or only those directly related to photography. • This option applies in both still photography and movie modes. Press the MENU button to display the menus. Highlight [Reset / Custom Modes] in W Shooting Menu 1 and press I on the arrow pad.
  • Page 332 Movie Recording Options Adjust shutter speed and aperture to suit your subject. You can exploit depth of fi eld and motion blur just as you would when taking photos. You’ll also fi nd it easy to record slow- and fast-motion movies and to fi lm at extremely high frame rates for ultra-clear slow-motion playback.
  • Page 333  Menu Access  Press the MENU button to display the menus. Highlight [n Mode Settings] in the n video menu and press I on the arrow pad. Highlight [n Mode] (movie exposure mode) using the FG buttons and press the I button. •...
  • Page 334 Letting the Camera Choose Aperture and Shutter Speed : Program AE) The camera chooses the optimal aperture and shutter speed according to subject brightness. This option can be combined with exposure compensation. Focus and check the display. M-IS M-IS TC 00:00:00:00 DF •...
  • Page 335 Choosing an Aperture : Aperture-Priority AE) In this mode, you choose the aperture (f/-number) and the camera automatically sets the shutter speed for optimal exposure according to subject brightness. Lower aperture values (larger apertures) reduce the depth of the area that appears to be in focus (depth of fi...
  • Page 336 Choosing a Shutter Speed : Shutter-Priority AE) In this mode, you choose the shutter speed and the camera automatically sets aperture for optimal exposure according to subject brightness. Choose a shutter speed according to subject motion and movie frame rate. If subject motion seems jerky, choosing a slow shutter speed will smooth the subject’s apparent motion.
  • Page 337 Choosing Aperture and Shutter Speed : Manual Exposure) In this mode, you choose the aperture and shutter speed. Shooting at a fi xed aperture and shutter speed makes any changes in the brightness of the subject or the scene readily apparent. Adjust aperture and shutter speed.
  • Page 338  Using Exposure Compensation in Mode  In mode , exposure compensation is available when [AUTO] is selected for [n ISO]. Because exposure compensation is performed by adjusting ISO sensitivity, exposure can be adjusted without changing shutter speed or aperture. g “Adjusting ISO Sensitivity (n ISO)”...
  • Page 339 Filming High-Speed Movies (nK) Film at high frame rates. Movies are fi lmed at 120 fps and play back at 60 fps. Stretching playback to double the recording time (as is the case when 60p is selected as the playback frame rate) lets you view in slow motion movements that in real life took only the blink of an eye.
  • Page 340 Highlight (high-speed movie recording) using the front dial. • To use the options currently selected for high-speed movie recording, press the OK button. The camera will exit the menu with the current options selected. To edit current settings, press the INFO button in Step 2.
  • Page 341  Menu Access  High-speed movie recording can also be accessed via the menus. Choose settings using [nK] in the n video menu. MENU button n (movie) tab Press I on [n Specifi cation Settings] [nK] the arrow pad to view options ...
  • Page 342 Filming Slow- or Fast-Motion Movies (Slow- and Fast-Motion Movies) Film slow- or fast-motion movies. Choose a recording rate faster than the playback rate for slow-motion movies or slower than the playback rate for fast-motion movies. Slow- and fast-motion recording are available as custom movie image quality options.
  • Page 343  Access via the LV Super Control Panel  Highlight [nK] in the LV super control panel and press the OK button. • Movie quality options will be displayed. n image quality Highlight G (custom) using the front dial and press the INFO button.
  • Page 344  Access via Live Controls  OK button [nK] Select (custom) Press the INFO button, select [Slow or Fast Motion] and choose the desired settings n image quality  Menu Access  Slow- and fast-motion movie recording can also be accessed via the menus. Choose settings using [nK] in the n video menu.

  • Page 345: Focus

    Focus Focus can be adjusted automatically (autofocus) or manually (manual focus). Autofocus features options for focusing on selected points or for tracking focus on a moving subject. Settings can be customized according to the subject or shooting conditions, allowing you to fi lm a greater variety of subjects. This section describes the settings available and how they can be combined to get the most from autofocus.

  • Page 346: Lens Mf Clutch (Manual Focus Clutch)

    Continuous AF (C-AF) Track focus on subjects whose distance to the camera is continuously changing. The camera focuses continuously before and during recording. Manual Focus (MF) Focus manually. • Rotate the lens focus ring to focus. Minimum focus distance • If the lens is equipped with an MF clutch, you can rotate the lens focus ring to engage manual focus regardless of the focus mode selected with the camera.
  • Page 347  Access via the AFp Button  Press the AFp button. AFp button • [n AF Mode] options will be displayed. [n AF Mode] options Rotate the rear dial. • You can also rotate the dial while pressing the button. Press the shutter button halfway to exit to the shooting display.
  • Page 348  Access via Live Controls  When the mode dial is rotated to n (movie), focus settings can also be adjusted using live controls. Highlight [n AF Mode] in the live controls and use HI on the arrow pad to choose an option. n AF mode ...
  • Page 349 Choosing an AF Target Mode (AF Target Mode) The point or area in the frame on which the camera focuses is call the “AF target”. [AF Target Mode] is used to choose the number of AF targets used and the size of the area covered.
  • Page 350  Access via the Multi Selector  Keep the multi selector pressed while rotating the front or rear dial. Multi selector • The camera cycles through AF target modes as shown. Release the multi selector when the desired mode is displayed. •...
  • Page 351  Access via the LV Super Control Panel  When the mode dial is rotated to n (movie), the AF target mode can also be selected in the LV super control panel. Highlight [AF Area] in the LV super control panel and press the OK button.
  • Page 352 Choosing a Focus Target (AF Target Point) When an option other than [All Targets] is selected for AF target mode, you can position the target or targets over the subject on which you wish to focus. At default settings, the multi selector is used to position the AF target. The target can be moved while fi...
  • Page 353 • When [On] is selected for [AF Targeting Pad], you can reposition the AF target using monitor touch controls while framing your subject in the viewfi nder. g [AF Targeting Pad] (P. 486) • You can disable the use of the multi selector in the shooting display. g [T Direction Key] (P.
  • Page 354 • You can disable the use of the multi selector in the shooting display. g [T Direction Key] (P. 499) • The following focus settings can be recalled simultaneously using the Fn lever. Separate settings can be assigned to Positions 1 and 2. Use this option to quickly adjust settings according to shooting conditions.
  • Page 355 Lens MF Clutch (Manual Focus Clutch) The “MF clutch” (manual focus clutch) mechanism on MF clutch lenses can be used to switch between auto and manual focus simply by repositioning the focus ring. • Check the position of the focus ring before shooting. •...
  • Page 356 Disabling the MF Clutch (MF Clutch) Disable the manual focus clutch, which is found on some lenses. This can prevent autofocus being disabled by the clutch engaging accidentally. Press the MENU button to display the menus. Select G Custom Menu I (AF/MF). Highlight [MF Clutch] using FG on the arrow pad and press the I button.
  • Page 357 Focusing at a Preset Distance (Preset MF) Quickly focus at a previously-stored distance. This can be used, for example, to focus quickly at infi nity. The focus distance can be set using auto or manual focus or by entering the focus distance directly. If the lens is equipped with a focus limiter, disable it before proceeding.
  • Page 358 Highlight [Preset MF] using the rear dial. Press the INFO button. • You will be prompted to choose the focus distance for [Preset MF]. Choose a focus distance. • To choose a focus distance using autofocus: Press the shutter button halfway to focus on a subject at the desired distance.
  • Page 359  Access via the LV Super Control Panel  When the mode dial is rotated to n (movie), preset manual focus can also be selected in the LV super control panel. Highlight [n AF Mode] > [PreMF] in the LV super control panel, press the OK button, and then press the INFO button to display options.
  • Page 360 Face Priority AF The camera automatically detects and focuses on the faces of portrait subjects. Exposure is weighted according to the value metered for the face. • This setting can be accessed via: - The LV super control panel - The menus (P. 361) - Live controls (face priority on) The camera detects and focuses on faces.

  • Page 361: Using Face Priority Af

     Access via Live Controls  Face priority AF options can also be accessed by highlighting [I Face Priority] in the live controls and selecting an option using HI on the arrow pad. • You can also select face priority by rotating the rear dial in the AF-target selection display.

  • Page 362: N C-Af Sensitivity

    C-AF Tracking Sensitivity (n C-AF Sensitivity) Choose how rapidly the camera responds to changes in the distance to the subject while focusing with [C-AF] or [C-AF+TR] selected for [n AF Mode]. This can help autofocus track a quickly-moving subject or prevent the camera refocusing when an object passes between the subject and the camera.

  • Page 363: N C-Af Speed

    C-AF Focus Speed (n C-AF Speed) Choose how quickly the camera responds to changes to the distance to subject when [C-AF] or [C-AF+TR] is selected for focus mode. This can be used to adjust the time the camera takes to refocus when, for example, you switch subjects. •...

  • Page 364: Zoom Frame/Focus Zoom Af

    Zoom Frame/Focus Zoom AF The camera can focus on the area indicated by a zoom frame. For more accurate focus, you can zoom in on the zoom frame. The zoom frame can be moved while recording is in progress. Focus zoom can be accessed via buttons or touch controls. The former requires that you assign [a] (Magnify) to a button using [n Button Function].
  • Page 365 Slide a fi nger over the display to zoom in or out. • Use the multi selector or arrow pad (FGHI) to scroll the display. • When [M] (manual) is selected for [n Mode], you can press the INFO button during zoom to choose aperture or shutter speed.
  • Page 366 Press the OK button again. • The menu will clear from the display. Press the button to which [a] is assigned. M-IS M-IS TC 00:00:00:00 DF • The zoom frame will be displayed. C-AF • The frame is displayed in the same position as the target ISO-A most recently used for autofocus.

  • Page 367: Metering And Exposure

    Metering and Exposure The camera meters subject brightness and adjusts exposure accordingly. The camera can be confi gured to raise ISO sensitivity automatically when lighting is poor. You can also reduce fl icker when shooting under artifi cial light. Exposure for movie mode is metered using p (digital ESP) metering. Digital ESP metering is suited to most scenes, including back-lit subjects.
  • Page 368  Access via the F Button  Hold the F button and rotate the front or rear dial. TC 00:00:00:00 DF M-IS M-IS Alternatively, you can press the F button and then use the HI buttons on the arrow pad. ISO-A 30 p 30 p...
  • Page 369 Adjusting ISO Sensitivity (n ISO) Adjust ISO sensitivity when [M] is selected for [n Mode] (movie exposure mode). Higher values let you photograph darker scenes but also increase image “noise” (mottling). Select [AUTO] to let the camera adjust sensitivity according to lighting conditions.
  • Page 370  Access via the ISO Button  ISO sensitivity for movie recording can only be adjusted when [M] is selected for [n Mode]. [AUTO] is available only when [On] is selected for [b ISO-Auto] in the n video menu (P. 372). Press the ISO button.
  • Page 371  Access via Touch Controls (Silent Controls)  When [M] is selected for [n Mode], ISO sensitivity can be adjusted using touch controls. g “Touch Controls (Silent Controls)” (P. 306) Tap the silent control panel to view silent controls Tap [ISO] TC 00:00:00:00 DF M-IS M-IS...

  • Page 372: B Iso-Auto Set

    Auto ISO Sensitivity Control (b ISO-Auto Set) [AUTO] can be selected for [n ISO] in [n Mode] (movie exposure mode) [M] (manual). This allows the camera to respond to changes in brightness without you having to adjust aperture or shutter speed. Exposure compensation can also be used.
  • Page 373 Locking Exposure (AE Lock) Lock exposure at the metered value. Use this option when you want to set focus and exposure separately. Exposure lock is performed using a button. Exposure lock ([AEL/AFL]) must therefore be assigned to a button using [n Button Function] (P. 417). At default settings, it is assigned to the AEL/AFL button.

  • Page 374: N Flicker Scan

    Reducing Flicker Under LED Lighting (n Flicker Scan) Banding may occur in movies fi lmed under LED lighting. Use [n Flicker Scan] to optimize shutter speed while viewing banding in the display. This option is in [n Mode] (movie exposure modes) [S] and [M]. •...
  • Page 375 Choose a shutter speed while viewing the display. • Choose a shutter speed using the front or rear dial or the FG buttons. • Continue adjusting shutter speed until banding is no longer visible in the display. • Press the INFO button; the display will change and the 250.0 Flicker Scan P icon will no longer be displayed.

  • Page 376: Image Stabilization, Color, And Quality

    Image Stabilization, Color, and Quality The features described in this section reduce blur and noise compensate for the color of the light source. This section also covers picture mode options that can be used to control exactly how your pictures turn out. Reducing Camera Blur (n Image Stabilizer) Reduce blur caused by the camera shake that commonly occurs, for example,...
  • Page 377  Access via the LV Super Control Panel  Highlight [n Image Stabilizer] in the LV super control panel. n image stabilizer Highlight an option using the front dial. Press the shutter button halfway to select the highlighted option and exit the LV super control panel.
  • Page 378 Image Stabilization Options (n IS Level) Choose the amount of image stabilization applied. Choose for static hand-held shots. ±0 Recommended in most situations. −1 Choose for hand-held panning, tilting, or tracking shots. Press the MENU button to display the menus. Highlight [n AF/IS Settings] in the n video menu and press I on the arrow pad.

  • Page 379: N Noise Filter

    High ISO Noise Reduction Options (n Noise Filter) Reduce image artifacts (“noise”) in footage fi lmed at high ISO sensitivities. This can help reduce “graininess” in footage fi lmed under low light. You can choose the amount of noise reduction performed. Noise reduction disabled.
  • Page 380 Adjusting Hue (n WB) White balance makes white objects look white. Although [AUTO] works well in most situations, you can choose an option suited to the light source if [AUTO] fails to make white objects appear white or if instead you wish to deliberately lend white objects a color cast.
  • Page 381  Access via the WB Button  Press the WB button. WB button • [n WB] options will be displayed. [n WB] options Rotate the front or rear dial to highlight an option. • Pressing the INFO button when [AUTO] is highlighted displays [nW Keep Warm Color] options (P.
  • Page 382  Access via the LV Super Control Panel  White balance can be selected using the LV super control panel. OK button [n WB] Use the front dial to choose an option • To access [nW Keep Warm Color] options, press the INFO button after highlighting [AUTO] in the [n WB] menu and pressing the OK button (P.

  • Page 383: Nw Keep Warm Color

    Preserving Warm Colors (nW Keep Warm Color) If desired, auto white balance can be adjusted to preserve the warm colors seen under incandescent lighting. White balance would normally be adjusted to make white colors appear white, but this feature can be used to preserve the ambiance created by incandescent lighting.
  • Page 384 White Balance Compensation (n White Balance Compensation) Fine-tune white balance. Separate values can be selected for each white balance option. Adjust settings as described below. • This setting can be accessed via: - The LV super control panel - The menus A (amber–blue) axis Positive values add a red cast, negative values a blue cast.
  • Page 385 (n All x) Fine-Tuning White Balance Fine-tune white balance across the board. This item fi ne-tunes all modes by the same amount. Fine-tune white balance for all modes. White balance can be fi ne-tuned on the A All Set (amber–blue) and G (green–magenta) axes. All Reset Reset fi...
  • Page 386 Metering White Balance (One-Touch White Balance P/Q/W/X) Set white balance to a value measured under the lighting that will be used in the fi nal photograph. Use this option to fi ne-tune white balance when you fi nd it hard to obtain the desired results with white balance compensation or preset white balance options such as 5 (sunlight) or O (overcast).
  • Page 387 Highlight [Yes] using FG on the arrow pad and press the OK button. • The camera will store the setting as the value for the selected one-touch white balance option and exit to the shooting display. • To exit without measuring white balance, highlight [No] and press the OK button.
  • Page 388 Image Enhancement (Picture Mode) Choose how pictures are processed during shooting to enhance color, tone, and other properties. Choose from preset picture modes according to your subject or artistic intent. You can also opt to make individual adjustments to parameters such as contrast and sharpness.
  • Page 389 Choose for a peaceful, refi ned effect that softens the image overall, Gentle Sepia creating serene pictures with clearly-defi ned shadows. Dramatic Tone Selectively enhance contrast to further differentiate light from dark. Key Line Enhance edges for a photo-illustration effect. Dramatically brighten shadows to give the effect of a scene painted in Watercolor bright pastel colors on white canvas, and add soft outlines for warm,...

  • Page 390: Choosing A Picture Mode

    Choosing a Picture Mode This setting can be accessed via: • The LV super control panel • The menus (P. 391) • Live controls  Access via the LV Super Control Panel  Highlight [Picture Mode] in the LV super control Picture mode panel.
  • Page 391  Menu Access  Use [Picture Mode] in W Shooting Menu 1. MENU button W tab Use FG on the arrow pad to select [Picture Mode] Press the I button to view picture mode parameters or fi lter effects • You can adjust the individual parameters for each picture mode. You can also adjust parameters in the LV super control panel.
  • Page 392 Creating Custom Picture Modes (K Custom Picture Mode) You can select one of the following picture modes, edit its parameters as desired, and save it as a custom picture mode. Choose from [i-Enhance], [Vivid], [Natural], [Muted], [Portrait], and [Monochrome]. Press the MENU button to display the menus. Highlight [Picture Mode] in W Shooting Menu 1 and press I on the arrow pad.

  • Page 393: N Picture Mode

    Highlight&Shadow Control (n Picture Mode) Choose a picture mode exclusively for movie recording. Priority is given to dynamic range for a tone curve suitable for color grading and other post-processing operations. These options are available for [Picture Mode] when [On] is selected for [n Picture Mode].
  • Page 394 Press HI on the arrow pad to choose an option [Picture Mode] • LUT fi les are available for editing movies recorded using movie-only picture modes. Visit the OLYMPUS website for details. 394 EN n 3-9 Image Stabilization, Color, and Quality...

  • Page 395: A View Assist

    Preview Options for Movie Picture Modes (a View Assist) The display can be adjusted for ease of viewing when a movie-only picture mode option ([k Flat] or [l OM-Log400]) is selected. Adjust the picture for ease of viewing. The indicators in the display may change color. Do not adjust the picture for ease of viewing.
  • Page 396 Adjusting Sharpness (Sharpness) Adjust image sharpness. Outlines can be emphasized for a sharp, clear picture. Settings are stored separately for each picture mode. • This setting can be accessed via: - The LV super control panel - The menus Hi (+) Increase sharpness.
  • Page 397 Adjusting Contrast (Contrast) Adjust image contrast. Increasing contrast heightens the difference between bright and dark areas for a harder, more well-defi ned picture. Settings are stored separately for each picture mode. • This setting can be accessed via: - The LV super control panel - The menus Hi (+) Increase contrast.
  • Page 398 Adjusting Vividness (Saturation) Adjust color saturation. Increasing saturation makes pictures more vivid. Settings are stored separately for each picture mode. • This setting can be accessed via: - The LV super control panel - The menus Hi (+) Increase saturation. Colors are more vivid. Lo (−) Lower saturation.
  • Page 399 Adjusting Shading (Gradation) Adjust color brightness and shading. Bring pictures closer to what you envisage by, for example, brightening the entire picture. You can also heighten dark tones or light tones as appropriate to the distribution of tones in the original image. Settings are stored separately for each picture mode.
  • Page 400 Color Filters for Black-and-White Photography (Color Filter) Filter effects can be added when [Monochrome] is selected for picture mode (P. 388). You can brighten subjects or enhance contrast according to the original color of the subject. Orange adds more contrast than yellow, red more contrast than orange.
  • Page 401 Monochrome Tints (Monochrome Color) Add a tint to black-and-white pictures in the [Monochrome] picture mode (P. 388). • This setting can be accessed via: - The LV super control panel - The menus N:Normal Shoot in black and white. S:Sepia Shoot in sepia-tinted monochrome.
  • Page 402 Adjusting i-Enhance Effects (Effect) Choose the strength of the effect for [i-Enhance]. • This setting can be accessed via: - The LV super control panel - The menus 3 Low (Effect: Low) Effect reduced. 3 Standard Standard effect. (Effect: Standard) 3 High (Effect: High) Effect heightened.
  • Page 403 Choosing a Tone Curve (Highlight&Shadow Control) Adjust brightness separately for highlights, mid-tones, and shadows. You gain greater control over exposure than you would with exposure compensation alone. You can selectively make highlights darker or shadows brighter. Adjusting shadows Adjusting mid-tones Adjusting highlights (The illustrations above show the display when the highlight and shadow control is accessed via a button and the LV super control panel.)
  • Page 404 Press the OK button to save changes. • You can also save changes by pressing the shutter button halfway. • Exposure compensation, and with it highlight and shadow control, can be assigned to controls other than the F button. Use [n Button/Dial/Lever] > [n Button Function] (P.
  • Page 405 Hue and Saturation (Color Creator) The camera permits intuitive adjustments to color saturation and hue. Choose from 30 hues and 8 levels of saturation. The results can be previewed in the display. [Color Creator] is a picture mode option. Settings can be accessed directly using [Multi Function].
  • Page 406 Press the OK button to save changes. • You can also save changes by pressing the shutter button halfway.  Menu Access  The color creator can also be accessed via the menus. Saturation and hue, however, cannot be adjusted via the menus. The menus can be used to recall saved values only.
  • Page 407 “Leave Color” Effects (Partial Color) Shoot in black-and-white while capturing objects of a selected hue in color. For example, you can shoot in black-and-white while leaving only reds in color. The results can be previewed in the display. [Partial Color] is an art fi lter option. Settings can be adjusted when it is selected for picture mode.

  • Page 408: Effects

    3-10 Effects The camera offers simple effects that can be added during fi lming. Instead of waiting to edit the movie on a computer or other device, you can view the effects in real time while recording is in progress. Some effects can be saved to display settings or direct buttons.
  • Page 409 (Movie H) Adjusting Zoom During Filming You can zoom in on a selected area of the frame for movie recording without using lens controls. Use for instant close-ups or cuts to wider angle. Buttons or touch controls can be used to choose the zoom location and cut to close ups or wide angles during fi...
  • Page 410  Using [Movie H]  Press the button to which [H] is assigned. M-IS M-IS TC 00:00:00:00 DF • A frame will appear in the center of the display. C-AF ISO-A 30 p 30 p 250 F5.6 1:02:03 Position the frame as desired. •...

  • Page 411: Digital Tele-Converter

    Filming at a Higher Zoom Ratio (Digital Tele-converter) This option takes a crop at the center of the frame the same dimensions as the size option currently selected for image quality and zooms it in to fi ll the display. The zoom ratio increases by about 2×.

  • Page 412: Audio Recording

    There are also microphone and headphone options for use that can be employed for high-level cinematography using an external recorder. If desired, the optional Olympus IC recorder (LS-100) can be used in tandem with the camera to record sound. 412 EN...
  • Page 413 Adjust settings for use with external IC recorders. Record a slate tone or choose whether camera controls can be used to start and stop recording when using an Olympus LS-100 IC recorder. [Camera Rec. Volume]: Choose [Operative] to record sound at the...
  • Page 414 Press the MENU button to display the menus. Highlight [Movie K] in the n video menu and press I on the arrow pad. Highlight [On] using the FG buttons and press the I button. • Movie audio recording options will be displayed. Highlight the desired option using the FG buttons and press the I button.

  • Page 415: Using The Olympus Ls-100 Ic Recorder

    Using the Olympus LS-100 IC Recorder When recording audio with an Olympus LS-100 IC recorder, you can use camera controls to record slate tones or to start and stop recording. Connect the LS-100 using the USB cable and a third-party stereo mini-jack cable.
  • Page 416 Start fi lming. • The LS-100 will begin recording audio. • To record a slate tone, press and hold the OK button. End fi lming. • The LS-100 will stop recording audio. • You can choose how long you have to keep the button pressed to record a slate tone. g [Press-and-hold Time] (P.

  • Page 417: Customizing Camera Controls

    3-12 Customizing Camera Controls The camera is equipped with “direct” buttons that can be used for direct adjustments to settings such as ISO sensitivity and white balance, and controls such as the dials and Fn lever that can be assigned different roles. These controls can be customized for ease of use.
  • Page 418 Icon Button (orientation) Default role AEL/AFL button Exposure lock WB button White balance Arrow pad AF-target selection Arrow pad I (right) * Off (X) Arrow pad G (down) * Off (WB) One-touch white balance button Focus peaking Preview button Zoom Vertical-use F (exposure compensation) button Vertical-use ISO button...
  • Page 419 Role Function Adjust AF-target settings. You can choose the AF-target mode (P. 349) and position (P. 352) AF Area Select and adjust settings for face-detection AF (P. 360). Press the control to view the AF-target selection display. Use the front or rear dial to choose AF-target mode and face-detection settings and the multi selector or arrow pad to position the AF target.
  • Page 420 Role Function Focus on the subject in the zoom frame (P. 364). Press the control once to display the zoom frame and again to zoom in. Press the control a third time to exit zoom; to hide the zoom frame, press and hold Magnify (a) the control.
  • Page 421 Role Function Toggle [n AF Mode] > [Preset MF] on or off (P. 357). Press the control once to enable preset MF and again to restore the previous focus mode. Alternatively, you can choose the [n AF Mode] by holding the control Preset MF (PreMF) and rotating a dial.
  • Page 422  Menu Access  Press the MENU button to display the menus. Highlight [n Button/Dial/Lever] in the n video menu and press I on the arrow pad. Highlight [n Button Function] using the FG buttons and press the I button. Highlight the desired control using the FG buttons and press the I button.

  • Page 423: N Shutter Function

    Choosing a Role for the Shutter Button (n Shutter Function) Confi gure the shutter button as a R (movie record) button. A release cable can then be used to start or stop recording when the mode dial is rotated to n (movie). The button functions as a shutter button.

  • Page 424: N Dial Function

    Assigning Roles to the Front and Rear Dials (n Dial Function) Choose the roles played by the front and rear dials in n (movie) mode. The roles played by the front and rear dials vary with the position of the Fn lever, and you can choose the functions assigned to them in each position.
  • Page 425 Highlight [n Dial Function] using the FG buttons and press the I button. Highlight the desired mode and press the I button. • Choose a dial using the HI buttons and use the FG buttons to choose a role. • Press the INFO button to move between lever positions. •...

  • Page 426: Customizing The Fn Lever (N Fn Lever Function)

    Customizing the Fn Lever (n Fn Lever Function) Choose the role played by the Fn lever in n (movie) mode. The Fn lever can be used to choose the roles of the front and rear dials or to recall focus settings. The role assigned to the Fn lever using this item takes effect in n (movie) mode.
  • Page 427  [n Fn Lever Function] > [mode2]  When [mode2] is selected for [n Fn Lever Function], the camera will store separate focus settings for Positions 1 and 2. • The [MF] and [Preset MF] options assigned to controls using [n Button Function] cannot be used.

  • Page 428: Display Settings

    3-13 Display Settings Adjust display settings for movie recording. You can choose whether to display on-screen controls in the form of the LV super control panel or live controls. You can also choose the indicators displayed in the monitor during fi lming. Choose options that suit your shooting style. Viewing On-Screen Controls (n Control Settings) View or hide on-screen controls during shooting.

  • Page 429: N Info Settings

    Shooting Indicators (n Info Settings) Choose the indicators listed in the shooting display. You can display or hide shooting setting indicators or view GPS or other sensor data (fi eld sensor info). Use this option to choose the icons that appear in the display. You can choose from two custom displays containing the indicators you select and a third display showing fi...
  • Page 430 Press the MENU button to display the menus. Highlight [n Display Settings] in the n video menu and press I on the arrow pad. Highlight [n Info Settings] using the FG buttons and press the I button. Highlight options using the FG buttons and press the OK button.

  • Page 431: Display Pattern

    Battery Level Display Options (8 Display Pattern) Choose a format for the battery level display. Battery level can be displayed as a percentage or as the amount of shooting time remaining. • The shooting time display is intended as a guide only. Battery level is shown as a percentage.

  • Page 432: Hdmi Devices

    3-14 HDMI Devices The camera can output video signals to HDMI devices. You can view the contents of the camera display in a monitor during shooting or use an HDMI recorder to record footage captured with the camera. This section describes settings for use when the camera is connected to an HDMI device.
  • Page 433 Press the MENU button to display the menus. Highlight [n HDMI Output] in the n video menu and press I on the arrow pad. Highlight the desired item using the FG buttons and press the I button. Highlight the desired option using the FG buttons and press the OK button.
  • Page 434 External Monitor Display Options (HDMI) Choose the signal output to external monitors connected via HDMI. Adjust the frame rate, movie frame size, and other settings according to monitor specifi cations. Choose the type of signal output to the HDMI connector. [C4K]: The signal is output in 4K digital cinema (4096 ×...
  • Page 435 Highlight the desired option using the FG buttons and press the OK button. • Repeat Steps 4 and 5 as necessary. Press the MENU button repeatedly to exit the menus. n 3-14 HDMI Devices...

  • Page 436: Working With Saved Movies

    3-15 Working with Saved Movies Movies are saved to the memory card and can be viewed in the camera monitor. Movies can be deleted or lightly edited using camera controls. You can also select movies for quick upload to a smartphone. Choosing the Information Displayed Choose the information displayed during playback.

  • Page 437: The Movie Playback Info Display

    The Movie Playback Info Display 2 3 4 7 8 90 48kHz AUTO 100-0004 TC 00:00:00:00 DF 30 p 30 p 2019.04.01 12:30:00 1 Battery level ........P. 44 0 “Selected” icon ........ P. 448 a n mode (movie exposure mode) .. P. 332 2 Wireless LAN connection b n white balance ......
  • Page 438 Finding Movies Quickly (Index and Calendar Playback) “Index playback” lists the pictures on the memory card as small “thumbnail” images so that you can view multiple pictures at once. This makes it easier to fi nd the movie you want. You can also switch to a calendar display and search for movies by date of recording.
  • Page 439 Protecting Movies Protect pictures from accidental deletion. Protected pictures cannot be deleted using “delete all” but will be deleted if the memory card is formatted. • This setting can be accessed via: - The 0 button - The menus (P. 440) ...
  • Page 440  Menu Access  Display a movie and press the OK button to view options. OK button OK button Press F or G on the arrow pad once to protect, again Press the OK button to save changes and exit to remove protection Removing Protection from All Pictures (Reset Protect)
  • Page 441 Copying Pictures Between Cards (Copy) To copy a picture from one memory card to the other when two memory cards are inserted: Press the q button. 48kHz • The most recent picture will be displayed. AUTO 100-0004 TC 00:00:00:00 DF 30 p 30 p 2019.04.01 12:30:00...
  • Page 442 If you selected [Do not assign] in Step 5, choose the destination folder. • Highlight [New Folder] or [Existing Folder] using the FG buttons and press the OK button. [New Folder]: Choose the desired folder number and press the OK button. [Existing Folder]: Highlight an existing folder using the FG buttons and press the OK button.

  • Page 443: Copying All Pictures (Copy All)

    Copying All Pictures (Copy All) Copy all pictures from one memory card to the other when two memory cards are inserted. Copy all pictures from the memory card in Slot 1 to the card in Slot 2. Copy all pictures from the memory card in Slot 2 to the card in Slot 1. Press the MENU button to display the menus.
  • Page 444 Deleting Pictures (Erase) Delete pictures from the memory card one at a time. • Pictures can be deleted via: - The  button - The menus  Deleting Pictures via the  Button  Press the q button. 48kHz • The most recent picture will be displayed. AUTO TC 00:00:00:00 DF 100-0004...
  • Page 445 Deleting All Pictures (All Erase) Delete all pictures from the memory card. Protected pictures will not be deleted. Press the MENU button to display the menus. Highlight [Card Setup] in the e setup menu and press I on the arrow pad. •...
  • Page 446 Selecting Movies for Sharing (Share Order) Smartphones running the OI.Share smartphone app can download movies from the camera. Pictures marked for download on the camera can be downloaded automatically when the camera is off. For information on establishing a connection between the camera and smartphone, see “6-2 Connecting to Smartphones via Wi-Fi”...
  • Page 447  Menu Access  Display a picture and press the OK button to view options. OK button OK button Press F or G on the arrow pad once to select, [Share Order] Press the OK button to save changes and exit again to deselect •...
  • Page 448 Selecting Multiple Pictures (0/Copy Select/Erase Selected/ Share Order Selected) You can select multiple pictures for protection, copying, deletion, or sharing. Press the q button. 48kHz • The most recent picture will be displayed. AUTO 100-0004 TC 00:00:00:00 DF 30 p 30 p 2019.04.01 12:30:00 Rotate the front dial to display a picture you want to...
  • Page 449 After selecting pictures, press the OK button. • To exit without proceeding to Step 5, press the MENU button. Highlight the operation you want to perform on the selected pictures ([0], [Copy Select], [Erase Selected], or [Share Order Selected]) and press the OK button.
  • Page 450 Editing Movies (Movie Edit) Simple edit options are available for existing movies. Trim unwanted footage or create a movie still from a selected frame. Trimming Movies (Movie Trimming) Cut selected footage from movies. Movies can be trimmed repeatedly to create fi les containing only footage you want to preserve.
  • Page 451 Highlight [Yes] and press the OK button. • The edited movie will be saved. • To select different footage, highlight [No] and press the OK button. • If you selected [Overwrite], you will be prompted to choose whether to trim additional footage from the movie.
  • Page 452 MEMO 452 EN...
  • Page 453 Customizing the Camera Customize camera buttons and dials to suit your shooting style. You can also customize camera menus.

  • Page 454: Basic Camera Settings (The E Setup Menu)

    Basic Camera Settings (the e Setup Menu) Adjust basic camera settings. Examples include language selection and monitor brightness. The setup menu also contains options used during the initial setup process. Formatting Memory Cards and Deleting All Photos and Movies (Card Setup) Ready memory cards for use in the camera.

  • Page 455: X Settings

    Setting the Camera Clock (X Settings) Set the camera clock. You can also update the clock automatically via GPS. This option applies in both still photography and movie modes. Set the clock (P. 45). Choose a time zone. Although the time zone is selected after the clock is Time Zone set, you can change it later using this option.

  • Page 456: Monitor Brightness And Hue (S)

    Monitor Brightness and Hue Adjust monitor brightness, color temperature, and hue. This option applies in both still photography and movie modes. Color temperature (j) Adjust color temperature. Choose from settings between +7 and −7. Adjust brightness. Choose from settings between +7 and −7. Brightness (k) Adjust hue.

  • Page 457: Firmware

    Wireless LAN Options (Wi-Fi/Bluetooth Settings) Adjust settings for connection to wireless networks. Take pictures and view pictures using a computer, or leave the camera off and view pictures on your smartphone while on the road. For information on establishing a connection and using these features, see “6-2 Connecting to Smartphones via Wi-Fi”...

  • Page 458: Custom Shooting Modes

    Custom Shooting Modes Functions and custom settings can be saved to a selected position on the mode dial as a custom shooting mode. Multiple settings can be recalled simultaneously just by rotating the mode dial. The camera can store settings for four custom modes, one for each of positions C1 through C4 on the mode dial.
  • Page 459 Highlight [Reset / Custom Modes] in W Shooting Menu 1 and press I on the arrow pad. • [Reset / Custom Modes] options will be displayed. Highlight [Assign to Custom Mode] using the FG buttons and press the I button. •...

  • Page 460: Custom Mode

    Using Custom Modes (C1/C2/C3/C4) Custom settings can be recalled using the mode dial, which restores all saved settings, or via the menus, which restores all settings except the shooting mode. You can choose the settings restored when a custom is selected. The saved settings will be restored when you next select the custom mode.
  • Page 461 Highlight [Yes] using the FG buttons and press the OK button. • W Shooting Menu 1 will be displayed. Press the MENU button repeatedly to exit the menus.  Recalling Settings via the Fn Button  Custom settings can be recalled using a control to which [Recall from Custom Mode] has been assigned.

  • Page 462: Customizing Buttons And Dials

    Customizing Buttons and Dials The camera is equipped with dials and variety of buttons used to adjust settings. Each of these controls has a default function. Each of these functions sees frequent use. Depending on your shooting style, you may nevertheless fi nd yourself using other functions more frequently still.

  • Page 463: Assigning Roles To Buttons (K Button Function)

    Assigning Roles to Buttons (K Button Function) Other roles can be assigned to buttons in place of their existing functions. Menu items can be assigned to buttons for quick access during shooting. [K Button Function] is for still photography. The functions assigned to controls using this item are available only in modes , and (still photography...
  • Page 464  Available Roles  Role Function Suspend autofocus. Focus locks and autofocus is suspended while the AF Stop control is pressed. Applies only to lens L-Fn buttons. Lock focus and/or exposure (P. 141). When used for exposure lock, the control locks exposure when pressed and releases the lock when AEL/AFL (t) pressed a second time.
  • Page 465 Role Function Switch between AF and MF. Press once to select MF and again to return to the previous mode. The focus mode can also be selected by holding MF (AF/MF toggle) the button and rotating a dial. This option has no effect when [mode2] is selected for [K Fn Lever Function].
  • Page 466 Role Function Press the control once to display the zoom frame and again to zoom in (P. 136). Press the control a third time to exit zoom; to hide the zoom Magnify (a) frame, press and hold the control. Use the multi selector, touch controls, or the arrow pad (FGHI) to position the zoom frame.
  • Page 467 Role Function Enable the AF limiter (P. 143). Press once to enable [AF Limiter]. Press AF Limiter again to disable. Hold the button and rotate the front or rear dial to (AF Limit) choose from three stored settings. Toggle [K AF Mode] > [Preset MF] on or off (P. 129). Press the control once to enable preset MF and again to restore the previous focus mode.
  • Page 468 Role Function Enable the live ND fi lter (P. 197). Press once to enable [Live ND Live ND Shooting Shooting]. Press again to disable. Hold the button and rotate the front or rear dial to adjust [Live ND Shooting] settings. The control is not used.
  • Page 469  Menu Access  Press the MENU button to display the menus. Display G Custom Menu J (Button/Dial/Lever). Highlight [K Button Function] using FG on the arrow pad and press the I button. Highlight the desired control using the FG buttons and press the I button.
  • Page 470 Multi-Function Button Options (Multi Function) Assign multiple roles to a single button. Assigning [Multi Function] (multi-function) to a control turns it into a multi-function button. The multi-function button can be used to: Highlight&Shadow Individually adjust the brightness of highlights, shadows, and mid-tones Control (P.
  • Page 471 Highlight the desired control using FG on the arrow pad and press the I button. Highlight [Multi Function] using the FG buttons and press the OK button. • Depending on the control selected, [Multi Function] may not be available. Select a different control. Press the OK button to exit when settings are complete.
  • Page 472  Choosing the Settings Available via Multi-Fn  Choose the settings that can be accessed via multi-function buttons. The selection is made from a menu. Press the MENU button to display the menus. Display G Custom Menu P (Disp/8/PC), highlight [Multi Function Settings], and press I on the arrow pad.
  • Page 473 Assigning Roles to the Front and Rear Dials (K Dial Function) Choose the roles performed by the front and rear dials. You can also choose the function selected using the Fn lever (P. 475). You can also choose the operations performed during playback or when menus are displayed.
  • Page 474 Press the MENU button to display the menus. Display G Custom Menu J (Button/Dial/Lever). Highlight [K Dial Function] using FG on the arrow pad and press the I button. Highlight the desired mode and press the I button. If you selected [P], [A], [S], or [M/B]: •...
  • Page 475 Customizing the Fn Lever (K Fn Lever Function) Choose the role played by the Fn lever. The Fn lever can be used to choose the roles of the front and rear dials or to recall focus settings. It can also be used to select movie mode. This setting takes effect in modes , and (still photography modes).
  • Page 476 Press the MENU button repeatedly to exit the menus.  [K Fn Lever Function] > [mode2]  When [mode2] is selected for [K Fn Lever Function], the camera will store separate focus settings for Positions 1 and 2. • The [MF] and [Preset MF] options assigned to controls using [K Button Function] cannot be used.

  • Page 477: My Menu

    “My Menu” The camera menus contain a profusion of items for different subjects and shooting styles. Quickly fi nd the items you need when, for example, choosing menu options during shooting. Creating a Personalized Menu (My Menu) You can use “My Menu” to create a personalized menu tab containing only items you select.
  • Page 478 Press the R (movie) button. R (movie) button • You will prompted to choose a page. Use FG on the arrow pad to choose the “My Menu” page to which the item will be added. Press the OK button to add the item to the selected page.
  • Page 479  Managing “My Menu”  You can reorder items in “My Menu”, move them between pages, or remove them from “My Menu” altogether. Press the MENU button to display the menus. Display the “My Menu” page you want to edit and press the R (movie) button.

  • Page 480: Customizing Camera Functions

    Customizing Camera Functions The camera features many menus for customizing camera functions according to your subject or shooting style. Fine-tuning such functions as autofocus, drive mode, or exposure helps you get the most from your camera. These menus may be found under the G (custom) menu.

  • Page 481: K Af+Mf]

    [K AEL/AFL] (P. 141) • The lens focus ring can be used to interrupt autofocus only when M.ZUIKO PRO (Micro Four Thirds PRO) lenses are used. For information on other lenses, visit the OLYMPUS website. • In (bulb) mode, manual focus is controlled by the option selected for [Bulb/Time Focusing].
  • Page 482 Setting Focus and Exposure with the AEL/AFL Button (K AEL/AFL) Choose how the camera sets focus and exposure when the shutter button or AEL/ AFL button is pressed. The camera normally focuses and locks exposure when the shutter button is pressed halfway, but this can be changed according to the subject or shooting conditions.
  • Page 483 C-AF Tracking Sensitivity (K C-AF Sensitivity) Choose how rapidly the camera responds to changes in the distance to the subject during focusing. This can help prevent the camera refocusing when you are unable to track a quickly-moving subject or when an object passes between the subject and the camera.
  • Page 484 C-AF Center Target Priority (K C-AF Center Priority) When focusing using group- or custom-target AF in [C-AF] and [C-AFb] modes, the camera always assigns priority to the center target in the selected group for a repeated series of focus operations. Only if the camera is unable to focus using the center focus target will it focus using the surrounding targets in the selected focus group.
  • Page 485 Hiding AF Target Modes (KNMode Settings) Choose the target modes displayed during AF-target mode selection (P. 120). Hiding unused modes speeds target-mode selection. • This item is for still photography. Highlight [KNMode Settings] in the K (AF/MF) menu and press I on the arrow pad. Highlight an AF target mode you wish to have displayed.

  • Page 486: Af Area Pointer

    AF Target Display Mode (AF Area Pointer) In autofocus mode, the position of the subject on which the camera has focused is shown by a green focus target. This item controls the display of the focus target. The focus target is not displayed. The focus target is displayed only briefl...

  • Page 487: N Set Home]

    Choosing the AF Home Position (N Set Home) Choose the home position for the [N Home] feature. The [N Home] feature lets you recall a previously-saved “home position” for autofocus at the touch of a button. This item is used to choose the home position. To access [N Set Home], assign it to a control using [K Button Function] (P.

  • Page 488: Settings

    AF-Target Selection (N Select Screen Settings) Choose the roles played by the front and rear dials or arrow pad during AF target selection. The controls used can be selected according to how the camera is used or personal taste. You can choose up to two combinations. •...

  • Page 489: K Orientation Linked N

    Matching AF-Target Selection to Camera Orientation (K Orientation Linked N) The camera can be confi gured to change the AF-target position and AF-target mode automatically when it detects that it has been rotated between landscape (wide) or portrait (tall) orientations. Rotating the camera changes the composition and consequently also the position of the subject in the frame.
  • Page 490 Lens Focus Range (AF Limiter) Choose the range in which the camera will focus using autofocus. This is effective in situations in which an obstacle presents itself between the subject and the camera during the focus operation, causing drastic changes in focus. You can also use it to prevent the camera focusing on foreground objects when shooting through a fence, window, or the like.
  • Page 491 Face/Eye Priority AF (I Face Priority) The camera detects faces automatically. Depending on the option selected, it can detect and focus on faces or eyes. In either instance, exposure is weighted according to the value metered for the face. • This item applies during both still photography and movie recording. See pages 133 and 360 for more information.

  • Page 492: Af Focus Adj

    Fine-Tuning Autofocus (AF Focus Adj.) Fine-tune phase-detection autofocus. Focus can be fi ne-tuned by up to ±20 steps. • This item is for still photography. • Normally there is no need to fi ne-tune autofocus using this item. Fine-tuning focus may prevent the camera focusing normally.
  • Page 493 Choose a fi ne-tuning value using the FG buttons and press the OK button. • The selected value will be saved. If you chose [Default Data], the options shown in Step 2 will be displayed. • If you chose [Lens Data], the dialog shown in Step 3 will be displayed.
  • Page 494 Highlight [Delete] using the FG buttons and press the I button. • A confi rmation dialog will be displayed. Highlight [Yes] using the FG buttons and press the OK button. • The dialog shown in Step 3 will be displayed. Confi rm that the lens name has been deleted.

  • Page 495: Mf Assist

    Manual Focus Assist (MF Assist) This feature is used to assist manual focus. You can set the camera to automatically zoom in on the view through the lens or highlight in-focus areas in color when the lens focus ring is rotated. •...

  • Page 496: Focus Ring

    Disabling the MF Clutch (MF Clutch) Disable the manual focus clutch. This can prevent autofocus being disabled by the clutch engaging accidentally. • This item applies during both still photography and movie recording. See pages 128 and 356 for more information. Operative The camera responds to the position of the lens focus ring.

  • Page 497: Reset Lens

    Adjusting Focus During Long Exposures (Bulb/Time Focusing) You can change focus position manually when using bulb photography for a long exposure. This allows you to defocus during the exposure or focus at the end of the exposure. This option takes effect in mode •...
  • Page 498 Control-Related Items (Custom Menus J and K) These menus contain items used to customize camera buttons, dials, the multi selector, and switches. Assigning Roles to Buttons (K Button Function) Other roles can be assigned to buttons in place of their existing roles. Menu items can be assigned to buttons for quick access during shooting.

  • Page 499: S Center Button

    Multi Selector Press (S Center Button) Choose the operation performed by pressing the multi selector. The multi selector can then function as a button. • This item applies during both still photography and movie recording. No role assigned. Pressing the multi selector has no effect. Press the multi selector to adjust settings for AF target selection, AF target mode, or face priority AF.

  • Page 500: Dial Direction

    Assigning Roles to the Front and Rear Dials (K Dial Function) Choose the roles performed by the front and rear dials. You can also choose the function selected using the Fn lever. You can also choose the operations performed during playback or when menus are displayed. •...

  • Page 501: Fn Lever/Power Lever

    Assigning a Role to the Fn Lever (K Fn Lever Function) Choose the role performed by the Fn lever. • This item is for still photography. The functions assigned to controls using this item are available only in modes , and (still photography modes).
  • Page 502 Power Zoom Lenses (K Elec. Zoom Speed) Choose the speed at which power zoom lenses zoom in or out when the zoom ring is rotated. Adjust zoom speed if it is so quick that you fi nd it hard to frame your subject.

  • Page 503: C-Lock Settings

    Confi guring the Lock Lever (C-LOCK Settings) Choose the controls locked when the lock lever on the back of the camera is set to C-LOCK. The lock lever can be used to lock controls and prevent them being used. In the C-LOCK position, you can choose the controls locked.
  • Page 504 Highlight [C-LOCK Settings] in the K (Button/Dial/ Lever) menu and press I on the arrow pad. Highlight controls you want locked when the lock lever is the C-LOCK position and press the OK button. • Selected items are marked with a v. Selected items will be locked.

  • Page 505: S-Af Release Priority

    (Custom Menus N and O) Release-Related Items These menus contain items used to customize features related to the shutter release, including burst shooting options. Choosing the Operation Performed If Focus Fails with [S-AF] Selected for [K AF Mode] (S-AF Release Priority) Choose whether the camera will take a photograph if unable to focus with [S-AF] or [S-AFb] selected for [K AF Mode].
  • Page 506 [Sequential Low] Frame Rates and Burst Limits (jL Settings) Customize settings for [Sequential Low], [jL Anti-Shock r], [jL Silent s], and [Pro Capture Low] modes. • This item is for still photography. For more information, see the pages listed below. Choose the frame rate and maximum number of shots (P.
  • Page 507 Highlight a setting using the FG buttons and press the OK button. • When choosing the [Frame Count Limiter] for [J], highlight a value and press the I button. When prompted to choose the maximum number of shots, highlight a value using the FGHI buttons and press the OK button.
  • Page 508 Highlight [jH Settings] in the N (Release/j/ Image Stabilizer) menu and press I on the arrow pad. Highlight an option using the FG buttons and press the I button. Highlight a sub-option using the FG buttons and press the I button. Highlight a setting using the FG buttons and press the OK button.
  • Page 509 Release Timing (Flicker Reduction) When shooting under fl uorescent or other artifi cial workplace or outdoor lighting, you may notice fl icker in the live view display or uneven exposure in photos taken at fast shutter speeds. This item reduces these effects. •...
  • Page 510 Reducing Camera Blur (K Image Stabilizer) Reduce blur caused by the camera shake that commonly occurs, for example, when the subject is poorly lit or in photos taken at high zoom ratios. • This item is for still photography. See page 176 for more information. The option selected for [n AF/IS Settings] >...
  • Page 511 Burst Mode Image Stabilization (j Image Stabilization) Choose the type of image stabilization applied during burst shooting. To maximize the effects of image stabilization during burst shooting, the camera centers the image sensor for every shot. This slightly reduces the frame advance rate.
  • Page 512 Image Stabilization for IS Lenses (Lens I.S. Priority) When using a third-party lens with an on-board image stabilizer, choose whether image stabilization gives priority to the camera or the lens. This option has no effect if the lens is equipped with an IS switch that can be used to enable or disable image stabilization.

  • Page 513: K Control Settings

    Display-, Sound-, and Connection-Related Items (Custom Menus P, Q, R, and S) These menus contain items pertaining to the information displayed in the monitor and viewfi nder to aid shooting, the choice of on-screen controls, the settings used for connection to external devices, and the like. Viewing On-Screen Controls (K Control Settings) View or hide on-screen controls during shooting.
  • Page 514  Displaying On-Screen Controls  Press the OK button during live view in , or mode. • The LV super control panel will be displayed. S-IS AUTO S-IS AUTO ISO-A 30 p 30 p 1:02:03 250 F5.6 0.0 1023 Press the INFO button to display live controls. •...

  • Page 515: G/Info Settings

    Choosing the Information Displayed with the INFO Button (G/Info Settings) The INFO button is used to select the content and type of the information displayed during shooting or playback. This option is used to choose the items displayed. • This item applies during still photography and playback. The option selected for [n Info Settings] in the n video menu applies in n (movie) mode (P.
  • Page 516 Highlight [G/Info Settings] in the P (Disp/8/PC) menu and press I on the arrow pad. Highlight an item and press the I button. Highlight the items you wish displayed press the OK button. • Selected items are marked with a v. Selected items will be displayed.
  • Page 517  q Info: Available Displays  The displays corresponding to the different options are shown below. Press the INFO button to cycle the display during playback. Basic Info ×10 48kHz Display a limited amount of shooting info. • Basic info is displayed at all times, regardless of the option selected (P.
  • Page 518  q Info: The Light Box Display  Compare two images by displaying them side-by-side and zooming in and out. Press the q button. ×10 48kHz • A picture will be displayed. HDR1 100-0015 2019.04.01 12:30:00 Press the INFO button repeatedly until the light box is displayed.
  • Page 519  qa Info: Playback Zoom  A playback info settings option. It is used to choose the operations available during playback zoom. It also determines the behavior of the button to which [a] (magnify) has been assigned using the [K Button Function] (P. 463) option. Pressing the multi selector or the control to which [a] (magnify) is assigned Magnify Frame displays the zoom frame.

  • Page 520: Picture Mode Settings

    Picture Mode Selection (Picture Mode Settings) Limit the choice of picture modes to include only those you require. This applies to displays such as the live controls and LV super control panel. • This item applies during both still photography and movie recording. •...

  • Page 521: Multi Function Settings

    Multi Fn Display Options (Multi Function Settings) Choose the functions available when accessing the multi-function feature. • This item applies during both still photography and movie recording. • For information on the multi-function feature, see the explanation on page 470. Highlight options and press the OK button P tab [Multi Function Settings]...
  • Page 522 Art Filter Preview (Art LV Mode) You can preview the effects of art fi lters in the monitor or viewfi nder during shooting. Some fi lters may cause subject movement to appear jerky, but this can be minimized so as to not infl uence photography. •...

  • Page 523: Qa Default Setting

    Zoom AF Display Options (LV Close Up Settings) Choose display options for use with focus zoom. • This item applies during both still photography and movie recording. • For information on live view zoom options, see the explanation on page 139. Choose what happens if the shutter button is pressed halfway during focus zoom.

  • Page 524: Z Settings

    Depth-of-Field Preview (z Settings) Choose the behavior of the control used for depth-of-fi eld preview and adjust settings for the depth-of-fi eld preview display. • This item is for still photography. Choose the behavior of the control used for depth-of-fi eld preview. [Off]: Aperture stops down while the control is pressed.

  • Page 525: Peaking Settings

    Focus Peaking Options (Peaking Settings) Highlight objects using color outlines. This makes objects that are in focus easier to see during manual focus and the like. • This item applies during both still photography and movie recording. Peaking Color Choose the focus peaking color. Highlight Intensity Choose the focus peaking level.

  • Page 526: Histogram Settings

    Histogram Exposure Warning (Histogram Settings) Choose the brightness levels that the histogram shows as overexposed (highlights) or underexposed (shadows). These levels are used for exposure warnings in the histogram displays during shooting and photo playback. • This item applies during both still photography and movie recording. •...

  • Page 527: Selfi E Assist

    Selfi e Assist (Selfi e Assist) Choose the display used when the monitor is reversed for self-portraits. • This item applies during both still photography and movie recording. When reversed for self-portraits, the monitor shows a mirror image of the view through the lens.
  • Page 528 External Monitor Display Options (HDMI) Choose the signal output to external monitors connected via HDMI. Adjust the frame rate, movie frame size, and other settings according to monitor specifi cations. • This item applies during both still photography and movie recording. See the relevant sections for details.

  • Page 529: Usb Mode

    Windows Vista or later. The camera can be controlled from the computer, while pictures shot using OLYMPUS Capture can be downloaded as they are taken. For more information, see “6-5 Connecting to Computers via USB” (P. 620).

  • Page 530: Iso Step

    Exposure-Related Items (Custom Menus T, U, and V) These menus contain exposure-related items. Included are items for customizing ISO sensitivity, bulb photography, and other functions. EV Steps for Exposure Control (EV Step) Choose the size of the increments used when adjusting shutter speed, aperture, exposure compensation, and other exposure-related settings.
  • Page 531 [K ISO] > [AUTO] Control Range (K ISO-Auto Set) Choose the range of ISO sensitivity values selected by the camera and the shutter speed at which auto ISO sensitivity control takes effect when [AUTO] is selected for [K ISO]. • This item is for still photography. See page 183 for more information. •...

  • Page 532: K Noise Filter

    High [K ISO] Noise Reduction Options (K Noise Filter) Reduce image artifacts (“noise”) in pictures taken at high ISO sensitivities. This can help reduce “graininess” in photos shot under low light. You can choose the amount of noise reduction performed. •...

  • Page 533: Noise Reduct

    Long Exposure Noise Reduction Options (Noise Reduct.) Choose whether to process photos taken at slow shutter speeds to reduce image artifacts (“noise”). At slow shutter speeds, noise is caused by the heat generated from the camera itself. After each photo is taken, the camera captures a second image for noise reduction, causing a delay equal to the selected shutter speed before the next photo can be taken.

  • Page 534: Bulb/Time Monitor

    Long Exposure Display Brightness (Bulb/Time Monitor) Choose the brightness of the monitor when shooting in (bulb) mode. The monitor can be brightened for ease of viewing in the dark conditions typical of bulb photography. • This item applies during still photography in (bulb) mode.

  • Page 535: Live Time

    Live Time Update Frequency (Live Time) Choose the frequency with which the display is updated during live time photography in mode (bulb). The display will be refreshed at the selected interval while live time photography is in progress, allowing you to view the results in the display.

  • Page 536: K Flicker Scan

    Reducing Flicker Under LED Lighting (K Flicker Scan) Adjust shutter speed while viewing the display to eliminate banding under LED lighting. Banding may occur in photographs taken under LED lighting. Use [K Flicker Scan] to optimize shutter speed while viewing banding in the display. This item can be used in , and silent mode and with High Res Shot and Pro Capture photography.

  • Page 537: N Spot Metering

    AE Lock Exposure Metering (AEL Metering) Choose the metering method used to meter exposure when exposure is locked using the AEL/AFL button. This allows you to use metering method when exposure is locked by pressing the shutter button halfway and another when exposure is locked by pressing the AEL/AFL button.

  • Page 538: Exposure Shift

    Fine-Tuning Exposure (Exposure Shift) Fine-tune exposure. Use this option if you want the results of auto exposure to be consistently brighter or darker. • This item applies during both still photography and movie recording. • Fine-tuning is not normally required. Use only as necessary. In normal circumstances, exposure can be adjusted using exposure compensation (P.
  • Page 539 (Custom Menu W) Flash-Related Items This menu contains fl ash-related items. It includes fl ash sync settings and options for remote fl ash photography in RC mode. Choosing a Flash Sync Speed (#X-Sync.) Choose the fastest shutter speed available for fl ash photography. Choose the fastest shutter speed available for fl...
  • Page 540 Flash and Exposure Compensation (x+F) Choose whether exposure compensation is added to the value for fl ash compensation. For information on fl ash compensation, see page 259. • This item is for still photography. Flash and exposure compensation are set independently. The value for exposure compensation is added to the value for fl...

  • Page 541: Rc Mode]

    Wireless Remote Flash Control (#RC Mode) Adjust settings for wireless remote fl ash control. Remote control is available with optional fl ash units that support wireless remote control (“wireless RC fl ash”). For information on using wireless remote fl ash control, see page 262. •...
  • Page 542 Image Quality, White Balance, and Color-Related (Custom Menu X) Items This menu contains image-enhancement items, including options for fi ne-tuning white balance and for selecting image quality and size. Image Quality and Size (K Set) Choose the image size and compression (quality) options available in the [KK] menu (P.
  • Page 543 Choosing Values for [X] and [W] Sizes (Pixel Count) Choose the size, in pixels, of the [X] (Xiddle) and [W] (Wmall) [KK] options (P. 78). • This item is for still photography. See page 82 for more information. The sizes available for the [X] and [W] options are: Xiddle (medium) 3200×2400, 1920×1440 Wmall (small)
  • Page 544 Adjusting Hue (K WB) Compensate for changes in color due to the color of the light source. White balance makes white objects look white. Although [Auto] works well in most situations, you can choose an option suited to the light source if [Auto] fails to make white objects appear white or if instead you wish to deliberately lend white objects a color cast.
  • Page 545 (K All x) Fine-Tuning [K WB] Fine-tune white balance across the board. White balance is set by choosing a mode that matches the light source; this item fi ne-tunes all modes by the same amount. • This item is for still photography. The option selected for [n All x] takes effect in n mode (P.
  • Page 546 Choosing a Color Space (Color Space) Choose a color space to ensure accurate color reproduction when photos are output to a printer or external display. • This item is for still photography. See page 232 for more information. A color space established as the standard for Windows computers. It is used sRGB in standard displays, printers, digital cameras, and applications.

  • Page 547: Card Slot Settings

    Storage- and Deletion-Related Items (Custom Menus Y and Z) These menus contain items pertaining chiefl y to the storage and deletion of the image data recorded with the camera. Card Slot Selection (Card Slot Settings) The camera has slots for two memory cards. Choose a role for the card in each slot. For more information, see “2-3 Card-Related Settings”...

  • Page 548: File Name

    File Naming Options (File Name) Choose how the camera names fi les when saving photos or movies to memory cards. Filenames consist of a four-character prefi x and a four-digit number. Use this option to choose how fi le numbers are assigned. •...

  • Page 549: Dpi Settings

    Copyright information is stored as Exif tags. • This item is for still photography. Olympus will not be held liable for any disputes or damages arising from use of the [Copyright Settings] feature. Use at your own risk. Copyright Info.

  • Page 550: Lens Info Settings

    Saving Lens Data (Lens Info Settings) Add user-specifi ed lens data to image Exif data. You can add information as necessary when using lenses that do not supply lens data to the camera. The camera can store information for up to 10 lenses. These data also supply the focal length used for the image stabilization and keystone compensation features.

  • Page 551: Quick Erase

    Disabling Deletion Confi rmation (Quick Erase) If this option is enabled when the  button is pressed to delete photos or movies, the camera will not display a confi rmation dialog but will instead delete the images immediately. A confi rmation dialog is displayed when the  button is pressed. No confi...

  • Page 552: Priority Set

    [Yes]/[No] Default (Priority Set) Choose the option highlighted by default when a [Yes]/[No] confi rmation is displayed. [No] is highlighted by default. [Yes] is highlighted by default. Z tab [Priority Set] Choose an option 552 EN 4-5 Customizing Camera Functions...

  • Page 553: Evf Adjust

    (Custom Menu a) Viewfi nder-Related Items This menu contains items pertaining to the electronic viewfi nder (EVF) display. • “EVF” stands for “electronic viewfinder”. Automatic Display Selection (EVF Auto Switch) Choose whether the camera switches automatically between the viewfi nder and monitor live view.

  • Page 554: Evf Style

    Viewfi nder Display Style (EVF Style) Choose the viewfi nder display style. • This item applies during both still photography and movie recording. • For information on the display, see pages 83 (photo mode) and 326 (movie mode). • For more information on the content of the viewfi nder display, see “Viewfi nder (Still Photography)”...

  • Page 555: V Info Settings

    Viewfi nder Info Display Options (V Info Settings) Choose the information that can be viewed by pressing the INFO button in the viewfi nder display. Just as you can with the monitor, you can display a histogram or level gauge in the viewfi...

  • Page 556: Evf Grid Settings

    Viewfi nder Framing Grid Options (EVF Grid Settings) Choose whether to display a framing grid in the viewfi nder. You can also choose guide color and transparency. This item takes effect when [Style 1] or [Style 2] is selected for [EVF Style]. •...
  • Page 557 Optical Viewfi nder Simulation (S-OVF) Increase the dynamic range of the viewfi nder display, increasing the amount of detail visible in highlights and shadows in a manner similar to optical viewfi nders. Backlit subjects and the like are easier to see. •...

  • Page 558: Pixel Mapping

    Other Custom Settings (Custom Menus b, c, and Q) These menus contain items related to touch-screen controls, batteries, and the like. GPS-related items can also be found here, as well as an item for reducing distortion in pictures taken with fi sheye lenses. Image Processing Check (Pixel Mapping) Check the image sensor and image processing functions simultaneously.

  • Page 559: Level Adjust

    Calibrating the Level Gauge (Level Adjust) Correct deviation in the level gauge. Calibrate the gauge if you fi nd it is no longer truly plumb or level. • This item applies during both still photography and movie recording. Reset Reset the gauge to factory default settings. Choose the reference (zero) point.

  • Page 560: Menu Recall

    Storing the Cursor Position (Menu Recall) The camera stores the current cursor position at the time you exit the menus and returns to that position when next the menus are displayed. • This item applies during both still photography and movie recording. The camera stores the cursor position.

  • Page 561: Battery Settings

    Battery Order and Status (Battery Settings) View battery status and choose the order in which the batteries are used. • This item applies during both still photography and movie recording. Choose the battery the camera uses fi rst. Choose from [5 Battery] and Battery Priority [4 Battery].

  • Page 562: Sleep

    Sleep (Power Saving) Options (Sleep) Choose the delay before the camera enters sleep mode when no operations are performed. In sleep mode, camera operations are suspended and the monitor turns off. • This item applies during both still photography and movie recording. •...

  • Page 563: Quick Sleep Mode

    Reducing Power Consumption (Quick Sleep Mode) Further reduce power consumption during viewfi nder photography. The delay before the backlight turns off or the camera enters sleep mode can shortened. • This item is for still photography. • Power saving is not available: during live view photography, while the viewfi...
  • Page 564 Enabling or Disabling GPS (Record GPS location) Enable GPS. GPS co-ordinates are included in the information recorded with photos, together with data from other sensors. For more information, see “5 Using Field Sensor Data” (P. 567). • This item is for still photography. Enable GPS.
  • Page 565 Sensor Info Options (Elevation/Temperature) Choose the units in which information is displayed. You can also calibrate the altitude display. For more information, see “5 Using Field Sensor Data” (P. 567). Calibrate the altitude display. Use this option if you notice error in the Calibrate Elevation altitude display.

  • Page 566: Certifi Cation

    Viewing Certifi cates (Certifi cation) Display the compliance certifi cates for some of the standards with which the camera complies. The remaining certifi cates can be found on the camera itself or in the camera manual. Press the OK button Q tab [Certifi...
  • Page 567 Using Field Sensor Data Read this chapter for information on using the GPS feature and the camera’s built-in sensors, including sensors for temperature and barometric pressure.

  • Page 568: Notes On Field Sensors

    The camera can log data on position, altitude, and heading acquired via GPS, as well as data from temperature and pressure sensors. These data can also be recorded with photographs. Logs can be viewed using the “OLYMPUS Image Track” (OI.Track) smartphone app.

  • Page 569: Updating The A-Gps Data Using A Smartphone

    • If a connection error is displayed, you will need to re-establish the connection between the camera and smartphone Updating the A-GPS Data Using a PC Download the OLYMPUS A-GPS Utility software from the URL below, and install it on your PC. http://sdl.olympus-imaging.com/agps/ Refer to “OLYMPUS A-GPS Utility Instruction Manual”...

  • Page 570: Using Field Sensors

    Using Field Sensors Recording Location Data (Record GPS location) With the exception of location data, data provided by camera sensors are recorded with every picture. GPS must be enabled before location data will be recorded. • Pictures with location data are indicated by a g icon during g icon playback.

  • Page 571: Field Sensor Logs

    The camera records sensor and GPS data at regular intervals to create a log. Logs can be viewed using the “OLYMPUS Image Track” (OI.Track) smartphone app. You can see the route you traveled with your camera and the locations where pictures were taken.
  • Page 572 Press the MENU button to display the menus. Highlight [Field Sensor Logger] in G Custom Menu Q (K Utility) and press I on the arrow pad. Press the OK button when [Start Log] is displayed. • The item displayed varies with log status. See “Menu Items”, below.
  • Page 573 Warnings The following table describes the steps to be taken when a warning is displayed. Warning Problem Solution The number of log fi les stored on Delete unwanted fi les after copying the current card is approaching the the logs to a computer. maximum.
  • Page 574 Viewing Sensor Data (G/Info Settings) GPS and other sensor data can be viewed in an electronic compass display. Sensor data can be added to the displays available during live view photography. An electronic compass display is available during viewfi nder photography and on other occasions when live view is not available.

  • Page 575: Enabling Sensor Data Display

    • Location data are only shown in the sensor data display when GPS is enabled. GPS can be enabled using any of the following items: - [Record GPS location] in G Custom Menu Q (P. 570) - [Field Sensor Logger] in G Custom Menu Q (P. 571) - [Auto Time Adjust] in the e setup menu (P.
  • Page 576 Display sensor data or the electronic compass. • Sensor data appear in the live view display. Press the INFO button repeatedly until sensor data are displayed. INFO S-IS AUTO S-IS AUTO ISO-A 1:02:03 250 F5.6 0.0 1023 Basic info Info hidden INFO INFO INFO...
  • Page 577  Movie Mode (n Info Settings)  Press the MENU button to display the menus. Highlight [n Display Settings] in the n video menu and press I on the arrow pad. Highlight [n Info Settings] using the FG buttons and press the I button. Highlight [Field Sensor Info] using the FG buttons and press the OK button.
  • Page 578 Sensor Data Display Options (Elevation/Temperature) Choose the units used for temperature and altitude in the sensor data display. You can also calibrate altitude. Calibrate Calibrate altitude when the current altitude and the value shown by the camera Elevation do not match. m/ft Choose whether altitude is shown in meters (m) or feet (ft).
  • Page 579 GPS Options (GPS Priority) Choose the GPS mode. GPS accuracy Prioritize accuracy over power saving. Power consumption increases. Prioritize power saving over accuracy. The size of the error in the location Battery power data increases slightly. Press the MENU button to display the menus. Highlight [GPS Priority] in G Custom Menu Q (K Utility) and press I on the arrow pad.

  • Page 580: Disabling Gps

    Disabling GPS The use of GPS or Wi-Fi may be prohibited in some countries, regions, or locations. To disable GPS, disable all the following settings as described below. G Custom Menu Q > [Record GPS location] (P. 570) Select [Off] G Custom Menu Q >...
  • Page 581 Connecting the Camera to External Devices Connect the camera to external devices such as computers or displays using cables or via wireless LAN.

  • Page 582: Connection Types And Software

    Connect using the “OLYMPUS Image Share” (OI.Share) app. Connecting to Computers via Wi-Fi Pictures can be automatically uploaded to a computer connected via a router or access point.

  • Page 583: Precautions For Using Wi-Fi And Bluetooth

    Each country and region has its own laws and regulations. Check them before traveling and observe them while abroad. Olympus assumes no liability for any failure on the part of the user to observe local laws and regulations.

  • Page 584: Connecting To Smartphones Via Wi-Fi

    Wi-Fi Connect the camera and smartphone using a direct Wi-Fi link. Use the “OLYMPUS Image Share” (OI.Share) smartphone app to connect to the camera from a smartphone. Once installed on your smartphone, OI.Share can be used to view the scene visible through the camera lens and take pictures remotely.

  • Page 585: Installing Apps

    In addition to OI.Share, Olympus offers the following apps for viewing sensor logs and retouching pictures: • OLYMPUS Image Track Use “OLYMPUS Image Track” (OI.Track) to view and manage fi eld sensor logs recorded with the camera. For more information, visit: http://app.olympus-imaging.com/oitrack/ •...
  • Page 586 Connecting to Smartphones (Wi-Fi/Bluetooth Settings) Adjust camera settings for connection to a smartphone. OI.Share is required. ® Changes made using OI.Share apply to both Wi-Fi and Bluetooth . Install the app on the smartphone before proceeding. Readying the Camera (Availability) ®...

  • Page 587: Pairing The Camera And Smartphone

    Pairing the Camera and Smartphone Follow the steps below when connecting the devices for the fi rst time. • Adjust pairing settings using OI.Share, not the settings app that is part of the smartphone operating system. Launch the copy of the dedicated OI.Share app previously installed on your smartphone.
  • Page 588 Tap the camera icon at the bottom of the OI.Share display. • An [Easy Setup] tab will be displayed. Following the instructions displayed by OI.Share, scan the QR code to proceed with pairing. QR コードを枠内に配置してください。 • OI.Share will display a message when settings are complete.
  • Page 589 • You can change the connection password generated by the camera (P. 618). • If the smartphone is unable to read the QR code, you will need to confi gure the device manually following the instructions displayed by OI.Share. ® ®...
  • Page 590 Connecting When the Camera Is Off (Power-off Standby) The camera can be confi gured not to end the connection to the smartphone when turned off. The smartphone can then access the camera and automatically download pictures while the camera is off. •...
  • Page 591 [Select] If you select [Select] for [Power-off Standby], a confi rmation dialog will be displayed the next time the camera is turned off. Highlight an option using FG on the arrow pad and press the OK button. The camera will turn off, leaving the wireless connection to the smartphone active. The camera will end the connection to the smartphone before turning off.

  • Page 592: Copying Pictures To Smartphones

    Copying Pictures to Smartphones Pictures on the camera memory card can be downloaded to a smartphone using either of the following methods: • Use the smartphone to select pictures for download. • Automatically download previously-selected pictures while the camera is off. These methods are described below.
  • Page 593 Tap [Import Photos] in OI.Share. • OI.Share will list the images on the camera. • The memory card can be selected using OI.Share. Select pictures and tap the save button. • Once download is complete, you can turn the camera off from OI.Share.

  • Page 594: Auto Download

    Auto Download Pictures previously marked for sharing on the camera can be downloaded automatically when the camera is off. Mark pictures for sharing. • Display pictures and mark them for sharing. See “Selecting Pictures for Sharing (Share Order)” (P. 277) and “Selecting Movies for Sharing (Share Order)” (P. 446) for more information.

  • Page 595: Removing Share Marking (Reset Share Order)

    Removing Share Marking (Reset Share Order) Remove share marking from all the pictures on the card in a selected slot. Share marking can be removed from multiple pictures in one operation. See “Selecting Pictures for Sharing (Share Order)” (P. 277) and “Selecting Movies for Sharing (Share Order)”...

  • Page 596: Remote Photography Using A Smartphone

    Remote Photography Using a Smartphone Use OI.Share to control the camera remotely and take pictures from a smartphone. Launch the dedicated OI.Share app on the smartphone. Tap V in the camera monitor and tap [Device Connection] when prompted. • If connection options are displayed, highlight [Device Connection] and press the OK button.

  • Page 597: Accessing Field Sensor Logs

    Accessing Field Sensor Logs Use OI.Share to view sensor logs created with the camera. g [Field Sensor Logger] (P. 565) Launch the dedicated OI.Share app on the smartphone. Tap V in the camera monitor and tap [Device Connection] when prompted. •...

  • Page 598: Ending The Connection

    Use the [Power Off] slider in the OI.Share or OI.Track settings dialog. • Alternatively, you can press the camera MENU button and tap [Disconnect] in the monitor. E-M1X MENU button Disconnect Select [Off] for [Power-off Standby] to disable the “auto upload while off”...
  • Page 599 Highlight [Off] using the FG buttons and press the OK button. 6-2 Connecting to Smartphones via Wi-Fi...

  • Page 600: Connecting To Computers Via Wi-Fi

    Connect the camera and computer via Wi-Fi. Using Wi-Fi, the camera can connect via a router to a computer on a household network or the like. Use “OLYMPUS Capture” computer software to connect to the camera from a computer. Pictures taken with the camera are uploaded automatically to the computer, where you can view the results while shooting is in progress.

  • Page 601: Installing Software

    Use “OLYMPUS Capture” to connect the camera and computer via Wi-Fi. OLYMPUS Capture Use “OLYMPUS Capture” to automatically download and view pictures taken with a camera connected via Wi-Fi to the same network as the computer. To learn more or to download the software, visit the website below.

  • Page 602: Readying The Computer (Windows)

     Windows 7  Connect the camera and computer using a USB cable. • [E-M1X] will be displayed in Windows Explorer. Right-click [E-M1X] and select [Install]. • A message will be displayed when device registration is complete. • Check that the device is registered in the Device Manager.

  • Page 603: Pairing The Computer With The Camera (New Link)

    Pairing the Computer with the Camera (New Link) The camera and computer must be paired in order to connect. Up to four computers can be paired with the camera at a time. To pair a computer with the camera, connect it via USB. Pairing need only be performed once per computer. After confi...
  • Page 604 Settings Cancel [Settings] • Repeat the above steps to pair the camera with each additional computer. • The pairing information stored on the camera can be viewed and deleted using “OLYMPUS Capture”. 604 EN 6-3 Connecting to Computers via Wi-Fi...
  • Page 605 Adjusting Wi-Fi Settings (T Wi-Fi Connect) Adjust settings for connection to the network to which the paired computer belongs. Before the camera can connect to the computer via Wi-Fi, it must be confi gured for connection to the network via the Wi-Fi router or access point. Multiple network profi...
  • Page 606 Enabling Camera Wi-Fi (Wi-Fi/Bluetooth Settings) Before connecting to a network via Wi-Fi, you will need to enable Wi-Fi on the camera. Note that this is not necessary at default settings, as Wi-Fi is enabled by default. Proceed to page 607. Press the MENU button to display the menus.
  • Page 607 Connecting via WPS (Connect by WPS) Connect using the WPS feature on the router or access point. Press the MENU button on the camera to display the camera menus. Highlight [T Wi-Fi Connect] in the q playback menu and press I on the arrow pad. •...
  • Page 608 If the camera is able to connect, the network will be displayed with a check (v) next to the network name. • If the camera has been paired with more than one computer, you will be prompted to choose a computer before the network is displayed.
  • Page 609 Connecting Manually (Manual Connections) Adjust network settings manually. You will need to provide: SSID The network name (SSID). Authentication The type of security used on the network. Password The password for connection to a secured network. Choose whether the camera IP address is assigned automatically IP Address Assign by the network DHCP server.
  • Page 610 Highlight items using the FG buttons and press the OK button. • Options for the selected item will be displayed. SSID Enter the network SSID. Select the type of security used on the network. Choose from Authentication [None] and [WPA2]. If you selected [WPA2] for [Authentication], enter the network Password password.
  • Page 611 Press the OK button to exit to the shooting display. • Standard shooting indicators will be displayed. A w icon w icon will appear in the monitor. S-IS AUTO S-IS AUTO ISO-A 30 p 30 p 1:02:03 250 F5.6 0.0 1023 6-3 Connecting to Computers via Wi-Fi...
  • Page 612 Choosing a Network from a List (Connect from Access Point List) The camera will search for available networks and display them in a list from which you can choose the network to which you wish to connect. Press the MENU button on the camera to display the camera menus.
  • Page 613 If the camera is able to connect, the network will be displayed with a check (v) next to the network name. • Password-protected networks are indicated by a t icon. • If the camera has been paired with more than one computer, you will be prompted to choose a computer before the network is displayed.

  • Page 614: Uploading Pictures As They Are Taken

    Exit [Wi-Fi Connection] • The camera will display the message shown at right when a connection is established. Confi gure “OLYMPUS Capture” to automatically Select file types to export download pictures as they are taken. Slot 1 • Select the source card slot (1 or 2) and the type of...
  • Page 615 - The source memory card is removed • The upload queue for each card can contain no more than 3000 pictures. • If “OLYMPUS Capture” displays the message [This application is unable to fi nd a camera in the camera control mode.], check:...

  • Page 616: Ending The Connection

    Ending the Connection End the Wi-Fi connection. The use of Wi-Fi may be prohibited in some countries or regions, in which case Wi-Fi should be disabled. Ending the Current Connection Tap V in the camera monitor. S-IS AUTO S-IS AUTO S-IS AUTO S-IS AUTO ISO-A...

  • Page 617: Disabling Wi-Fi/Bluetooth

    ® Disabling Wi-Fi/Bluetooth Press the MENU button to display the menus. Highlight [Wi-Fi/Bluetooth Settings] in the e setup menu and press I on the arrow pad. • [Wi-Fi/Bluetooth Settings] options will be displayed. Highlight [Availability] using the FG buttons and press the I button.

  • Page 618: Network Settings

    Network Settings Change the password used for Wi-Fi connections from a smartphone or restore default Wi-Fi settings used for connection to a computer. The latter are not restored when a camera reset is performed and can only be restored as described below. Changing Passwords (Connection Password) Generate new passwords for use when connecting to the camera from a...
  • Page 619 ® Restoring Default Wi-Fi/Bluetooth Settings (Reset Settings) ® Restore default Wi-Fi and Bluetooth settings. All settings, including those for connection via a router and pairing information for the computers on the network, are reset. Press the MENU button to display the menus. Highlight [Wi-Fi/Bluetooth Settings] in the e setup menu and press I on the arrow pad.

  • Page 620: Connecting To Computers Via Usb

    USB. Pictures on the camera memory cards can be downloaded directly to the computer via USB and organized using a computer application. Use Olympus Workspace to manage your pictures. You can also use the computer to download and perform fi rmware updates. Product fi...

  • Page 621: Compatible Computers

    USB. OLYMPUS Capture Use “OLYMPUS Capture” to automatically download and view pictures as they are taken or control the camera remotely. To learn more or to download the software, visit the website below. When downloading the software, be prepared to provide the camera serial number.
  • Page 622 Uploading Pictures as They Are Taken Connect the camera to a computer via USB to upload pictures as they area taken. You can take pictures using the controls on the camera body or while controlling the camera remotely from the computer. After confi...
  • Page 623 Launch the copy of “OLYMPUS Capture” installed on the computer. • When prompted to choose the connection type, click [USB Connection]. USB Connection Wi-Fi Connection Create new link Exit [USB Connection] Confi gure “OLYMPUS Capture” for download. File Save Settings •...
  • Page 624 Copying Pictures to the Computer (Storage) When connected to a computer, the camera can function as external storage in much same way as a hard drive or other external storage device. Data can be copied from the camera to the computer. After confi...

  • Page 625: Powering The Camera Via Usb (Usb Power Delivery)

    Powering the Camera via USB (USB Power Delivery) Mobile batteries or USB AC adapters conforming to the USB Power Delivery (USB PD) standard can be used to power the camera. The devices must: Standard: Conform to the USB Power Delivery (USB PD) standard Output: Be rated for an output of 9 V 3 A, 15 V 2 A, or 15 V 3 A •...

  • Page 626: Connecting To Tvs Or External Displays Via Hdmi

    Connecting to TVs or External Displays via HDMI Pictures can be displayed on televisions connected to the camera via HDMI. Use the television to display pictures to an audience. The TV remote can be used to control the display while the television is connected to the camera. No app or other software is required.

  • Page 627: Hdmi Output

    Viewing Pictures on a TV (HDMI) Photos and movies can be viewed on a high-defi nition TV connected directly to the camera by means of an HDMI cable. A remote control can be used to operate the display while it is connected to the camera. HDMI Output Choose the signal output to the HDMI device.
  • Page 628 Highlight an item using the FG buttons and press the I button. Highlight the desired option using the FG buttons and press the OK button. • Repeat Steps 4 and 5 as required. Press the MENU button repeatedly to exit the menus.

  • Page 629: Connecting The Camera To A Tv

    Connecting the Camera to a TV Connect the camera using an HDMI cable. After confi rming that the camera is off, connect it to the TV using an HDMI cable. • Use the supplied cable protector and cable clip to prevent damage to the connectors when an HDMI cable is connected.
  • Page 630 Using a TV Remote (HDMI Control) When connected to a TV via an HDMI cable, the camera can be operated using the television remote control. • The television must support HDMI control. See the television manual for more information. The television remote control can be used to operate the camera in playback mode. The camera can be used for playback only.

  • Page 631: Technical Notes

    Technical Notes This chapter covers such topics as camera maintenance and provides a list of default settings that you can refer to while using the camera.

  • Page 632: Storage And Maintenance

    Storage and Maintenance Cleaning Before cleaning the camera, turn it off and remove the batteries. • Never use chemically-treated dust cloths or strong solvents such as benzine or alcohol. Camera Exterior • Gently clean the exterior with a soft cloth. To remove stubborn stains, use a cloth that has been moistened in a solution of water and neutral detergent and then thoroughly wrung out.

  • Page 633: Pixel Mapping

    Cleaning and Checking the Image Sensor In addition to a design that prevents dust accumulating on the image sensor, the camera is equipped with a dust-reduction feature that vibrates the sensor at high frequencies to remove dust from its front surface. Dust reduction is performed automatically when the camera is turned on.

  • Page 634: Troubleshooting

    Troubleshooting The camera does not turn on. The batteries are not charged. • Charge the batteries in the battery charger. Cold temperatures have caused a temporary drop in battery performance. • Battery performance drops at low temperatures. Resume use after warming the batteries slightly by removing them from the camera and placing them in your pocket or other warm location.
  • Page 635 The camera is unable to focus. • The camera may be unable to focus (and the monitor in-focus indicator may fl ash) if the subject is too close or unsuited to autofocus. Move away from your subject or focus on a high-contrast object at the same distance from the camera and recompose the shot using focus lock.
  • Page 636 Settings have been reset. Settings adjusted in custom modes (modes C1–C4) will be reset to saved values when another shooting mode is selected or the camera is turned off. Pictures look “washed out”. This may occur in pictures of subjects that are back-lit or partially back-lit. It is the result of phenomena known as “fl...

  • Page 637: Warnings And Error Messages

    Warnings and Error Messages Message/warning Cause Solution No memory card inserted. Also Insert a memory card. If a card is displayed if no memory card is inserted, check that it is inserted detected. correctly. No Card There is a problem with the Remove and reinsert the memory memory card in Slot 1.
  • Page 638 Turn the camera off and then on again; if the warning does not GPS error. The camera’s GPS clear from the display, take the has malfunctioned. (steady) camera to an Olympus-authorized service representative. 638 EN 7-3 Warnings and Error Messages...
  • Page 639 Message/warning Cause Solution Turn the camera off and wait for it to cool. The camera’s internal The camera is about to turn temperature is elevated following off automatically. Wait until the burst shooting or the like. Internal camera temperature camera has cooled and is ready is too high.

  • Page 640: Default Settings

    Default Settings *1: Can be saved using [Assign to Custom *3: Default setting can be restored using Mode]. [Reset] (basic). *2: Default setting can be restored using [Reset] (full). Live Controls/LV Super Control Panel Shooting mode Item Default K ISO ...
  • Page 641 Shooting mode Item Default ― n (movie) n ISO   [P], [A], or [S] selected for [n Mode]: Auto (fi xed) [M] selected for [n Mode]: 200 ― ― ― ― Flash Mode Flash Off (fi xed) ― ― ―...

  • Page 642: The K Shooting Menus

    The K Shooting Menus Item Default ― ― ―  Reset / Custom Reset 91, 111, Modes 331, 458, Assign to Custom Mode Shooting mode: Image quality: RAW+YF ― Recall from Custom Mode CNatural    Picture Mode 215, 388 ...

  • Page 643: The N Video Menu

    Item Default ―   Multiple Number of Frames ― Exposure   Auto Gain ―   Overlay    Keystone Comp. ― Anti-Shock r/ Anti-Shock r r0 sec   160, 163 Silent s Silent s s0 sec Noise Reduction s ―...
  • Page 644 Item Default n Button/Dial/Lever ― ― n Button  Function RREC Off (X) Off (WB) Peaking AF Stop ― ― n Dial Position 1 k: F  j: F Function Position 2 k: KVOL j: KVOL ― ― Position 1 k: F ...

  • Page 645: The Q Playback Menu

    Item Default n Display Settings Live Control, Live SCP ― ― n Control Settings  ― ― n Info Settings  Custom1 ― ―  Time Code Time Code Mode Drop Frame ― ― Settings  Count Up Rec Run ―...

  • Page 646: The E Setup Menu

    The e Setup Menu Item Default 38, 276, ― ― ― ― Card Setup 445, 454 ― ― ― ― ― ― ― ― X Settings Time Zone ― ― ― Auto Time Adjust ― ― ― English ― j±0, k±0, Natural ...

  • Page 647: The G Custom Menus

    The G Custom Menus Item Default AF/MF J K AF Mode    S-AF K AF+MF    K AEL/AFL    S-AF mode3 C-AF mode4 mode3    Half Way AF Operative    AF Scanner mode2 146, 482...
  • Page 648 Item Default Button/Dial/Lever ― J K Button   Function RREC Off (#) Off (j/Y) AF Stop ― S Center Button   ― T Direction Key   ― k: F K Dial   Position 1 473, 500 Function j: Ps k: ISO...
  • Page 649 Item Default ― K K Elec. Zoom Speed   Normal ― ―   C-LOCK Settings Release/j/Image Stabilizer N S-AF Release Priority       C-AF Release Priority jL Settings 155, 506 j/j    Max fps 10 fps ...
  • Page 650 Item Default Q Live View    Manual Shooting 200, 521 Boost Bulb/Time On2, Frame Rate Priority Live Composite Others ―   Art LV Mode mode1    Frame Rate Normal 175, 522 ―   LV Close Up LV Close Up Mode mode2 139, 523 ―...
  • Page 651 Item Default U Bulb/Time Timer    8 min −7 ―   Bulb/Time Monitor ―   Live Bulb ―   Live Time 0.5 sec ―   Composite Settings 1 sec 110, 535 K Flicker Scan ...
  • Page 652 Item Default Record/Erase ― Y Card Slot K Save Settings   Standard ― K Save Slot Settings   ― n Save Slot   ― q Slot   ―   Assign Save Folder Do not assign ―...
  • Page 653 Item Default K Utility ― ― ― ― b Pixel Mapping 558, 633 ― End LV a   Press-and-hold 0.7 sec ― Time Reset LV a Frame 0.7 sec   ―   End 6 0.7 sec ― ...

  • Page 654: Memory Card Capacity

    Memory Card Capacity Memory Card Capacity: Photos Figures are for an 16 GB SD card used to record photos with an aspect ratio of 4:3. Image Image size Approx. fi le Capacity quality (pixels) Compression File format size (MB) (photos) (Tripod) (Tripod) (Tripod)
  • Page 655 Memory Card Capacity: Movies Figures are for a 32 GB SDHC memory card. Frame size Compression Frame rate Capacity (approx.) — 17 minutes — 30p, 25p, 24p 39 minutes 30p, 25p, 24p 20 minutes 1 hour 15 minutes 60p, 50p, 30p, 25p, 2 hours 4 minutes 3 hours 15 minutes 39 minutes...

  • Page 656: Specifi Cations

    Specifi cations  Camera  Type Digital camera supporting interchangeable lenses conforming to the Micro Type Four Thirds system standard Supported lenses M.ZUIKO DIGITAL/Micro Four Thirds system lenses Lens mount Micro Four Thirds 35 mm format lens focal Approx. 2× length conversion factor Image sensor Type...
  • Page 657 Exposure control TTL (Imager) metering Metering Digital ESP; center-weighted; spot −2  –   + 20 EV (f/2.8 lens, ISO100 equivalent) Range program AE (with program shift); aperture-priority AE; shutter- (bulb, time, composite); C1–C4 custom modes; Exposure modes priority AE; manual; n movie ISO sensitivity L64;...
  • Page 658 −20 °C  –   6 0 °C/−4 °F  –   1 40 °F (storage) 30%  –   9 0% (operating); 10%  –   9 0% (storage) Humidity Type: IEC Standard publication 60529 Water resistance IPX1 (applies if camera is used with Olympus waterresistant lens) 658 EN 7-6 Specifi cations...
  • Page 659 • The appearance and specifi cations of this product are subject to change without notice or obligation on the part of the manufacturer. • Visit the OLYMPUS website for the latest specifi cations. The terms HDMI and HDMI High-Defi nition...

  • Page 660: System Chart

    Visit the OLYMPUS website for the latest information. *1 HDMI cables are available from third-party suppliers. *2 There are restrictions on the lenses that can be used with the adapter. Visit the OLYMPUS website for details. *3 Visit the OLYMPUS website for information on compatible lenses.
  • Page 661 Lenses Converter Lenses * FCON-P01 Fisheye Micro Four Thirds system lenses WCON-P01 Wide MCON-P01 Macro MCON-P02 Macro MMF-2/MMF-3 * Four Thirds system lenses Four Thirds Adapter Flash Units FL-LM3 FL-900R FL-700WR Electronic fl ash Electronic fl ash Electronic fl ash STF-8 FC-WR FR-WR...
  • Page 662 MEMO 662 EN...
  • Page 663 SAFETY PRECAUTIONS The precautions in this chapter must be observed to prevent personal injury or the like. Be sure to read this chapter in its entirety.

  • Page 664: Safety Precautions

    CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED OLYMPUS SERVICE PERSONNEL. An exclamation mark enclosed in a triangle alerts you to important operating and maintenance instructions in the documentation provided with the product.
  • Page 665 • Should you notice that the charger is • The camera can be powered by one or two emitting smoke, heat, or an unusual noise Olympus lithium-ion batteries. Use only or smell, immediately cease use and batteries of the designated type. Batteries of unplug the charger from the power outlet, other types could explode (or rupture).
  • Page 666 Use Only Dedicated Rechargeable accidental loss. Battery and Battery Charger • OLYMPUS accepts no liability for any loss of We strongly recommend that you use only data associated with this device. the genuine Olympus dedicated rechargeable •...
  • Page 667 • Do not leave the camera pointed directly • Using an exhausted battery may cause the at the sun. This may cause lens or shutter camera to turn off without displaying the curtain damage, color failure, ghosting on battery level warning. the image pickup device, or may possibly •...
  • Page 668 This is not a malfunction; it will • Olympus reserves all rights to this manual. be less noticeable in playback mode. Warning • In places subject to low temperatures, the...
  • Page 669 RF that does not produce heating effects causes TV technician for help. no known adverse health effects. Many studies • Only the OLYMPUS-supplied USB cable of low-level RF exposures have not found any should be used to connect the camera to biological effects.
  • Page 670 Products shall be Olympus’s sole obligation and repaired, tampered with, altered, changed, the customer’s sole remedy hereunder. Repair or modifi ed by persons other than Olympus’s or replacement of a Product shall not extend the own authorized service personnel unless...
  • Page 671 PRODUCT DESIGN, SELECTION, OR placed and recorded Olympus serial number, PRODUCTION, IMAGE OR DATA LOSS OR unless they are a model on which Olympus IMPAIRMENT OR FROM ANY OTHER CAUSE, does not place and record serial numbers. WHETHER LIABILITY IS ASSERTED IN...
  • Page 672 Olympus’s option replaced, When service is completed, the Product will be free of charge. In order to enable Olympus to returned to you postage prepaid. provide you with the requested warranty services...
  • Page 673 3. Since this Warranty Certifi cate will not be re-issued, keep it in a safe place. 4. Please note that Olympus will not assume For customers in Singapore any risks or bear any costs incurred in transporting the product to the dealer or Complies with Olympus authorized service station.
  • Page 674 Bluetooth SIG, Inc. and any use of such marks by OLYMPUS CORPORATION is under license. • The standards for camera fi le systems referred to in this manual are the “Design Rule for Camera File System/DCF”...

  • Page 675: Index

    Index...
  • Page 676 z Settings ..........524 Symbols 0 (Camera control) ....603, 622 < (DPOF) ..........291 (Aperture-Priority AE) ....96, 335 # RC Mode ........262, 541 AC adapter ..........35 #+WB ..........540 Accessories ..........660 # Slow Limit.........261, 539 AdobeRGB ........232, 546 # X-Sync........260, 539 AEL/AFL ........141, 482 8 Display Pattern ......431 AEL Metering ........537 a (Close-up playback) ......267...
  • Page 677 Battery charge ........31 Compression rate .........322 Battery level ..........431 Continuous AF ......115, 346 Battery Settings ........561 Contrast ........221, 397 Beep sound ..........527 Control Settings BKT (Bracketing) ........236 Movie ..........428 ® Bluetooth ........582, 584 Still image ..........513 Bracketing..........236 Copy BULB ............104 All images ........274, 443 Bulb/Time Focusing ......107, 497 Single-frame ......272, 441...
  • Page 678 Exposure compensation ....180, 367 High Res Shot ......151, 210 Exposure Shift ........538 High-speed movie.........339 Eye priority AF ......133, 491 Histogram display ......84, 327 Histogram Settings .......526 Face priority AF ....133, 360, 491 Fast-motion movie ........342 IC recorder..........415 Field sensor ..........567 Image Aspect ........233 Field Sensor Logger .....565, 571 Image Overlay ........289...
  • Page 679 571, 597 Log tone curve movie recording ...393 OLYMPUS A-GPS Utility ......569 Long exposure ( Bulb/Time) ....104 OLYMPUS Capture ..582, 601, 614, 620 Low ISO Processing ......532 Olympus Workspace ......620 LV Close Up Mode ........139 Optional fl ash unit .........252 LV Close Up Settings ....139, 523...
  • Page 680 Preset MF distance.......494 SD card...........36 Press-and-hold Time ......558 Formatting the card ......38 Preview ..........464 Select Screen Settings (N Select Screen Settings) ...........488 Printing ..........291 Selfi e Assist ..........527 Priority Set ..........552 Self-timer ..........151 Pro capture ........151, 168 Sequential shooting ....151, 506, 507 Program AE ( ) ......94, 334 Set Home (N Set Home) ....487...
  • Page 681 Trimming ..........450 TV ............626 USB connection ......34, 620 USB Mode ..........529 USB PD ..........625 User registration ........25 Video Bit Rate ........322 Video Frame Rate ....175, 322, 522 Video Menu ..........643 View Assist ...........395 Volume adjustment .........58 Movie ..........380 Still image ........202, 544 WB (White balance)......202, 544 White balance Movie ..........380...
  • Page 683 date of issue 2019.01. WD517400...

This manual is also suitable for:

Im010

Table of Contents

Save PDF
